Toto GLORIA TX108LG Quick Start Manual
Toto GLORIA TX108LG Quick Start Manual

Toto GLORIA TX108LG Quick Start Manual

Single lever lavatory faucet w/ 1¼" pop-up waste

Advertisement

Available languages

Available languages

Quick Links

SPECIFICATIONS
120
Ø60
Ø60
G1¼
max.230
TX108LG
"GLORIA" Single Lever Lavatory Faucet w/ 1¼" Pop-Up Waste
120
Ø60
Ø60
G1¼
max.230
TX108LGC
"GLORIA" Ceramic Single Lever Lavatory Faucet w/ 1¼" Pop-Up Waste
OPERATING CONDITIONS
1. Water supply pressure : 0.05 ~ 0.75MPa.
2. Ensure that water supply is clean ( No Sand, Dirt, Etc.).
S06574N
"GLORIA" SINGLE LEVER LAVATORY FAUCET
INSTALLATION
1.
Ø35 Hole
To Hot Water
Supply
2.
Plug
Siphon
Packing
PLUG CONNECTION
Pivot
Rod
Plug
3.
Open
Position
Bolt
W/ 1¼" POP-UP WASTE
TROUBLESHOOTING
PROBLEM
Lift Rod
Flow rate unsatisfactory
Faucet
Water leaks around the handle
Handle is loose
Plug cannot open and close
Packing
Setting Bolt
Washer
Setting Nut
To Cold Water
Supply
2. CONNECTING NUT
Triangle
1. AERATOR
Packing
Pivot Rod
Nut
Washer
Packing
Kick Box
Bottom
Position
5
ATTENTION
1. Don t use abrasive cleaners or solvents on faucets and fittings.
2.
As the product model is constantly updated, the actual product
may not look the same as it shown in the diagram, but the basic
Bolt
installation principles are the same.
MAINTENANCE
Pop-Up Clip
All Finishes : Clean the finish with mild soap and warm water. Wipe
entire surface completely dry with clean soft cloth. Many cleaners may
contain chemicals, such as ammonia, chlorine, toilet cleaner etc. which
could adversely affect the finish and are not recommended for cleaning
TX108LG
CHECK
SOLUTION
POINT
1
Remove and clean
2
Tighten
3
Tighten
4
Tighten
3. BOLT
4.SCREW
H
C
R6
