Teana
Installation Guide
For Model:
TEA52
net weight of fan: 33.05 lb (15 kg)
READ THESE INSTRUCTIONS AND
AND SAVE THEM FOR FUTURE USE
Table of Contents:
Safety Tips. pg. 2
Unpacking Your Fan. pg. 3
Parts Inventory. pg. 3
Installation Preparation. pg. 4
Hanging Bracket Installation. pg. 4
Fan Assembly. pgs. 5 - 6
Wiring. pg. 7
Wiring-Wall Control. pg. 7
Canopy Assembly. pg. 8
Blade Assembly. pg. 8
Light Kit Assembly. pgs. 8 - 9
Wall Control Operation. pg. 9
Testing Your Fan. pg. 9
Troubleshooting. pg. 10
Parts Replacement. pg. 10
Warranty. pg. 10
page 1
PRINTED IN CHINA
Advertisement
Table of Contents
Related Manuals for Craftmade TEA52
Summary of Contents for Craftmade TEA52
-
Page 1: Table Of Contents
READ THESE INSTRUCTIONS AND AND SAVE THEM FOR FUTURE USE Teana Installation Guide For Model: TEA52 Table of Contents: Safety Tips. pg. 2 Unpacking Your Fan. pg. 3 Parts Inventory. pg. 3 Installation Preparation. pg. 4 Hanging Bracket Installation. pg. 4 Fan Assembly. -
Page 2: Safety Tips
SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS. -
Page 3: Unpacking Your Fan
1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs. -
Page 4: Installation Preparation
3. Installation Preparation. blade edge To prevent personal injury and damage, ensure inches 7 feet that the hanging location allows the blades a (2.13 m) (76 cm) clearance of 7 feet (2.13m) from the floor and 30in. (76cm) from any wall or obstruction. This fan is suitable for room sizes up to 400 square 12ft. -
Page 5: Fan Assembly. Pgs
set screw stop pin 5. Fan Assembly. hanging ball Remove hanging ball from downrod provided by loosening set screw on hanging ball. Remove pin and clip. Lower hanging ball and remove stop pin. Slide hanging ball off of the downrod. [Refer to clip diagram 1.] diagram 1... - Page 6 safety cable loop wood 5. Fan Assembly. (cont.) ceiling joist With the hanging bracket secured to the outlet box and wood screw able to support the fan, you are now ready to hang your and washer fan. Grab the fan firmly with two hands. Slide downrod through opening in hanging bracket and let hanging safety cable ball rest on the hanging bracket.
-
Page 7: Wiring
7. Wiring. WARNING: Turn off circuit breakers to current fixture ground white supply wire from breaker panel and be sure switch is turned to the (green or bare) OFF position. black supply wire CAUTION: Be sure outlet box is properly grounded and that a ground wire (GREEN or Bare) is present. -
Page 8: Canopy Assembly
9. Canopy Assembly. Locate 2 screws on underside of hanging bracket hanging bracket and remove screw closest to the open end of the hanging bracket. Partially loosen the other screw. Lift canopy to hanging bracket. Place rounded screw part of slotted hole in canopy over loosened screw in hanging bracket and push up. -
Page 9: Wall Control Operation
motor housing 11. Light Kit Assembly. (cont.) Remove 3 screws from under fitter plate. molex fitter plate Connect WHITE wire from motor housing to connections WHITE wire from the LED light kit and BLUE (or BLACK) wire from motor housing to BLACK wire from LED light kit. -
Page 10: Troubleshooting
1. Check wall switch to fan/wall control. Service at 1-800-486-4892 to arrange for return of fan. Return fan, shipping prepaid, to Craftmade. We will repair 2. Verify that reverse switch is set completely in or ship you a replacement fan, and we will pay the return either direction.
