BY-ALARM PLUS
01742
By-alarm Plus passive infrared and microwave dual technology detector, with anti-blinding, 120° coverage up to 12m, high (2.2-2.7 metres) or
low (0.8-1.2 metres) mounting, can be set for PET immunity, IP54, 1 NO and NC 28 VDC 0.1 A relay output, 9.5-16 VDC power supply with 30 mA
12V, surface mounting, for outdoor use.
The device is designed to cover a detection area of up to 12 metres and over 120 degrees, which can be adjusted with the masking labels supplied. It can be installed at a height of
between 2.2 and 2.7 metres creating a Multibeam volumetric detection model which allows small animals to be ignored; vice versa, in the case of environments with larger animals, the
detector can be mounted at a height of between 0.8 and 1.2 metres to provide a "corridor" for pets. The device is not affected by the environment or by small animals; the alarm will not
be triggered by climate changes, swaying vegetation or animals near the detection area, contributing to a reliable outdoor detection. There is also a dual conductive shielding that filters
out visible light and radio frequency interference (RFI).
CHARACTERISTICS
• Power supply: 9.5-16 VDC
• Absorption: 30 mA a 12 VDC
• Detection mode: passive infrared and microwave
• PIR cover: 12 m, 120° wide
• PIR zones:
- 40-zone multibeam
- 18-zone PET mode
• Alarm output: 28 VDC 0.1 A (max), [NO or NC] selectable
• Fault output: NC 28 VDC 0.1 A (max)
• Tamper output: NC 28 VDC 0.1 A (max), open when the front cover is opened
• Detectable speed: from 0.3 to 2 m/s
• Sensitivity: 2°C (at 0.6 m/s)
• Alarm duration: 2 ± 0.5 s
• Initialisation time: approximately 60 s
• Operating temperature: - 30..+ 60 °C
• Ambient humidity: 95%
• Protection degree: IP54
LED SIGNALLING
Red side LED:
• permanently lit -> Alarm
• flashing -> Blockage detection and initialisation phase
INSTALLATION RULES
• Installation must be carried out by qualified persons in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are
installed.
• Install the detector in a place where no cause for false alarms is present, such as:
- sunlight and reflections;
- heat sources;
- moving objects or objects which the wind may move.
• The ideal installation height is between 2.2 to 2.7 m in Multibeam mode and between 0.8 and 1.2 m in PET mode with the base of the detector always parallel with the wall.
• In PET mode, remove the detection of the lower area so that small animals are not detected.
REACH (EU) Regulation no. 1907/2006 – Art.33. The product may contain traces of lead.
WEEE - User information
The crossed out bin symbol indicates that the product must be sent to separate collection facilities for recovery and recycling, in compliance with the national laws of EU Countries that implement the WEEE Directive. The objective is to prevent
any harmful effects on the environment and on human health by ensuring that products are disposed of correctly, avoiding illegal disposal sanctioned by law.
To dispose of the product correctly, please check local dispositions in your country.
