- Page 1 1473-1-8570 │ 10.11.2014 Technical Manual Sensor / Dimming actuator 1/1gang; 2/1gang 1/1gang (SDA-F-1.1.PB.1) 2/1gang (SDA-F-2.1.PB.1)
- Page 2 ® ABB-free@home Content Notes on the instruction manual ________________________________________________________ 3 Safety ____________________________________________________________________________ 4 Used symbols ________________________________________________________________________ 4 Intended use _________________________________________________________________________ 5 Improper use _________________________________________________________________________ 5 Target group / qualification of personnel ____________________________________________________ 5 Safety instructions _____________________________________________________________________ 6 Information on protection of the environment ______________________________________________ 7...
- Page 3 ® ABB-free@home Notes on the instruction manual Notes on the instruction manual Please read this manual through carefully and adhere to the information contained therein. This will assist you in preventing damage to persons and property and ensure reliable operation and long service life of the device.
- Page 4 ® ABB-free@home Safety Safety The device has been constructed according to the latest valid regulations governing technology and is operationally reliable. It has been tested and left the factory in a technically safe and reliable state. However, residual hazards remain. Read and adhere to the safety instructions to pre- vent such hazards.
- Page 5 ® ABB-free@home Safety Intended use This device is a sensor/dimming actuator unit for decentralized flush-mounted instal- lation. The device is intended for the following: » operation according to the listed technical data, » installation in dry interior rooms and suitable flush-mounted boxes, »...
- Page 6 ® ABB-free@home Safety Safety instructions Warning Electric voltage! Risk of death and fire due to electrical voltage of 230 V. Dangerous currents flow through the body when coming into direct or indirect contact with live components. This can result in electric shock, burns or even death.
- Page 7 ® ABB-free@home Information on protection of the environment Information on protection of the environment All packaging materials and devices bear the markings and test seals for proper disposal. The products meet the legal requirements, in particular the laws governing elec-...
- Page 8 ® ABB-free@home Product description Product description Fig. 1: Product overview [1] Flush-mounted insert, 1/1gang, [2] Flush-mounted insert, 1/1gang, [3] Support ring (not included in scope of delivery) [4] Cover frame (not included in scope of delivery) [5] Push-button (not included in scope of delivery) This device is a sensor/dimming actuator unit for decentralized flush-mounted in- stallation.
- Page 9 Sensor Actuator Switching Article no. Product name channels channels load Sensor/dimming SDA-F-1.1.PB.1 1 x 180 W actuator, 1/1gang Sensor/dimming SDA-F-2.1.PB.1 1 x 180 W actuator, 2/1gang Table 1: Overview of types Function overview The following table provides an overview of the possible functions and applica-...
- Page 10 ® ABB-free@home Product description Device overview of sensor/dimming actuator 1/1gang Fig. 2 Device overview of sensor/dimming actuator 1/1gang [1] Mark TOP [2] Type plate [3] Bottom terminal block [4] Bus connection terminal Device overview of sensor/dimming actuator 2/1gang Fig. 3: Device overview of sensor/dimming actuator 2/1gang...
- Page 11 ® ABB-free@home Technical data Technical data Main overview Parameters Value Power Supply 24 V DC (via bus line) Bus subscribers 1 (12mA) Connection Bus connection terminal: 0.4-0.8 mm Line type J-Y(St)Y, 2 x 2x 0.8 mm Wire stripping 6-7 mm...
- Page 12 ® ABB-free@home Technical data Dimensions Note... All dimensions are specified in mm. All device types listed in this manual have the same dimensions. 31,5 Fig. 4: Dimensions of all described device types Circuit diagrams 10 A Fig. 5: Electrical connection Derating curve »...
- Page 13 ® ABB-free@home Mounting Mounting Planning instructions Note... Planning and application instructions for the system are available in the free@home system manual. They can be downloaded at www.abb.com/freeathome. Safety instructions for mounting >10 mm Fig. 6: SELV power circuits [1] Bus line...
- Page 14 ® ABB-free@home Mounting Warning - Risk of death due to electrical voltage Dangerous currents flow through the body when coming into di- rect or indirect contact with live components. This results in elec- tric shock, burns or even death. Work improperly carried out on electrical systems is a hazard to one's own life and that of the user.
- Page 15 ® ABB-free@home Mounting » Connect the free@home bus line with the bus connection terminal [1]. Observe the correct polarity! » Connect the 230 V power cord to the bottom terminal block [2]. Observe the circuit diagrams in chapter 5.4. »...
- Page 16 ® ABB-free@home Commissioning Commissioning Commissioning is always carried out via the Web-based surface of the System Access Point. The System Access Point establishes the connection between the free@home participants and the smartphone, tablet or PC. It is used to identify and program the participants during commissioning.
- Page 17 ® ABB-free@home Commissioning 7.1.1 Adding device Fig. 7: Adding device » In the "Add device" bar select the desired application and pull it via drag-and- drop onto the floor plan in the working area. Fig. 8: Allocation A pop-up window opens automatically which lists all the devices suitable for the application selected.
- Page 18 ® ABB-free@home Commissioning Identification via serial number Sensor / Dim actuator 2/1gang Sens/Dim act. flushm. ABB700000003 Fig. 9 Identification via serial number » Compare the short 3-digit number of the identity label, which should be glued to the device plan, with the numbers in the list and in this way identify the de- vice you are searching for and, if necessary, also the channel.
- Page 19 ® ABB-free@home Commissioning Assigning a name Dim actuator Ceiling light Ceiling light Fig. 11: Assigning a name » Enter a name that is easy to understand and under which the application is to be displayed later (e.g. "Ceiling light"). »...
- Page 20 ® ABB-free@home Commissioning Setting options per channel General settings and special parameter settings can be made for each channel. The settings are made via the allocation function of the Web- based user interface of the System Access Point. Device selection Fig.
- Page 21 ® ABB-free@home Commissioning 7.2.1 Settings for sensor/dimming actuator 1/1gang Actuator settings [1] Changing the name [2] Deleting the channel via 'X' [3] Switching of the actuator via the button; dimming the actuator via buttons -/+ [4] Setting of the load connected to the actua- tor.
- Page 22 ® ABB-free@home Commissioning 7.2.2 Settings for sensor/dimming actuator 2/1gang Actuator settings: As for sensor/dimming actuator 1/1gang Sensor settings: [1] Changing the name [2] Deleting the channel via 'X' Sensor / Dim actuator 2/1gang [3] Selecting the push-button in the list view...
- Page 23 ® ABB-free@home Commissioning Linking The sensor/dimming actuator units created via the allocation function can now be linked with each other. This allows simple ON/OFF circuits or two-way circuits to be implemented. The linking in the list view is then made via the linking function of the Web-based user interface of the System Access Point.
- Page 24 ® ABB-free@home Commissioning Connecting an actuator with an additional sensor Fig. 14: Connecting actuator and sensor » To connect the actuator with an additional sensor, first click on the second desired sensor [1] which is to operate the actuator and then on the actuator [2].
- Page 25 ® ABB-free@home Updating options Updating options A Firmware update is carried out via the Web-based user interface of the System Access Point. Technical Manual 0073-1-1473-1-8570 │25...
- Page 26 ® ABB-free@home Operation Operation Operation is carried out by pressing the individual push-buttons. Their function is fixed via the assigned application or its pre-programming and its parameter set- tings. Extensive applications are available for the push-buttons (control buttons). Note... The scope of delivery contains only the electronic insert. It must still be completed with a suitable push-button and a cover frame.
- Page 27 ® ABB-free@home Maintenance Maintenance The unit is maintenance-free. In case of damage (e.g., during transport or stor- age), do not perform repairs. Once the device is opened, the warranty is void! Access to the device must be guaranteed for operation, testing, inspection, maintenance and repairs (according to DIN VDE 0100-520).
- Page 28 ® ABB-free@home A member of the ABB Group Note We reserve the right to at all times Busch-Jaeger Elektro GmbH make technical changes as well as PO Box changes to the contents of this 58505 Lüdenscheid document without prior notice.
