Graco GC1147 Quick Start Manual

Displacement pump

Download this manual

Parts

Displacement

Pump

For use with polyurethane foam, polyurea, and similar non-flammable material. Not for use

in explosive atmospheres. For professional use only.

Part No. GC1147

3500 psi (24 MPa, 241 bar) Maximum Fluid Working Pressure

Important Safety Instructions

Read all warnings and instructions in Reactor H-VR

manual 313539. Save these instructions.

313485D

r_gc1147_313485

Need help?

Do you have a question about the GC1147 and is the answer not in the manual?

Page 1 313485D For use with polyurethane foam, polyurea, and similar non-flammable material. Not for use in explosive atmospheres. For professional use only. Part No. GC1147 3500 psi (24 MPa, 241 bar) Maximum Fluid Working Pressure Important Safety Instructions Read all warnings and instructions in Reactor H-VR manual 313539.
Page 2 Repair Repair Tools Needed Disassemble Pump Base • Vise with flat jaws See parts illustration on page 3. • Small screwdriver 1. Relieve pressure. Remove pump as detailed in your separate system repair manual. • 7/16 deep-well socket 2. Clamp pump head (8) in a vise. •...
Page 3 Parts Parts GC1147, Fluid Pump Apply blue loctite and torque to 100 ft-lbs (136 N•m). Ref. Parts Description Ref. Parts Description 26‡ GC0874 WIPER, FELT GC0016 RETAINER, ring GC2104 NUT, hex, std, 7/16-14, UNC 2‡ GC0048 O-RING GC2111 WASHER, lock, spring, 7/16 3‡...
Page 4 With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
