Operating Instructions & Parts Manual
20,000KG
INCORRECT USE MAY RESULT IN INJURY OR DEATH!
CAREFULLY READ INSTRUCTIONS AND PROCEDURES
Read this manual and follow all the Safety Rules and Operating Instructions before using this product.
Imported by:
SHINN FU AUSTRALIA PTY. LTD.
15 Viewtech Place, Rowville 3178 VIC Australia
CAUTION:
FOR SAFE OPERATING INSTRUCTIONS
SINGLE STAGE
AXLE JACK
Safety Instructions
Operation
Maintenance
Specifications
PRINTED IN TAIWAN
23203A
23203A-M0_052021
Advertisement
Table of Contents
Related Manuals for Omega Lift Equipment 23203A
Summary of Contents for Omega Lift Equipment 23203A
- Page 1 23203A Operating Instructions & Parts Manual 20,000KG SINGLE STAGE AXLE JACK Safety Instructions Operation Maintenance Specifications CAUTION: INCORRECT USE MAY RESULT IN INJURY OR DEATH! CAREFULLY READ INSTRUCTIONS AND PROCEDURES FOR SAFE OPERATING INSTRUCTIONS Read this manual and follow all the Safety Rules and Operating Instructions before using this product.
-
Page 2: Safety Instructions
SAFETY INSTRUCTIONS 23203A OWNER’S RESPONSIBILITY 1. The owner and/or the operator shall have an understanding of these operating instructions and the following warnings before operating the jack. Failure to follow these warnings may result in loss of load, damage to the jack, property damage, personal, or fatal injury. -
Page 3: Instructions Before Use
OPERATIONS 23203A INSTRUCTIONS BEFORE USE 1. Check Oil Level Take off the cover plate. With the jack in an upright position and the ram completely retracted, open the release knob by turning it counterclockwise (but no more than 3 turns). Remove the filler plug. -
Page 4: Exploded Diagram
EXPLODED DIAGRAM 23203A *Picture is for reference only SPARE PARTS ITEM DESCRIPTION QTY. PART NUMBER Top Nut 23203A-01 Cover 23203A-02 Hydraulic Unit 23203A-03 Filler Plug 23203A-04 Spring 23203A-05 Flexible Joint Assy. 23203A-06 Air Pump Assy. 23203A-07 Rubber Wheel Assy. 23203A-08... -
Page 5: Maintenance
MAINTENANCE 23203A 1. When the jack is not in use, keep the ram and the extension screw completely retracted and the release knob closed. 2. Keep the jack clean, and apply lubricant to all pivot points every 3 months or more often when used in the dusty environment. -
Page 6: Specification
SPECIFICATION 23203A Working Min. Model Hyd. Saddle Extension Load Working Working Jack Size Adapters Range Dia. Screw Weight Limit Height Height (L x W xH) 23203A 20,000 433.5 118.5 1235 20/65/127 TROUBLESHOOTING Symptom Possible Causes Remedies 1. Release knob not tightly closed 1. -
Page 7: Warranty
WARRANTY 23203A 1. This product is covered by an express warranty for 12 months from the date of purchase by the original purchaser. Subject to the conditions of this warranty Shinn Fu Australia Pty Ltd or its authorised repair agents will replace the product or perform necessary service on the product without charge for parts or labour if the product is found to be faulty within the warranty period. - Page 8 NOTES 23203A Imported by: SHINN FU AUSTRALIA PTY. LTD. 15 Viewtech Place, Rowville 3178 VIC Australia...
