Operating Instructions & Parts Manual
MagicLift™ Service Jack Combo
!
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
ADVERTENCIA
!
• Leer, comprender, y seguir las instrucciónes antes
de utilizar el aparato.
• El manual de instrucciónes y la información de
seguridad deben estar comunicado en lengua del
operador antes del uso.
• No seguir estas indicaciónes puede causar daños
personales o materiales.
Read this manual and follow all the Safety Rules and Operating Instructions before using this product.
Model
25032
Capacity
3 Ton
WARNING
!
To avoid crushing and related injuries:
NEVER work on, under or around a
load supported only by a hydraulic
jack. ALWAYS use adequately rated
jack stands.
http://www.omegalift.com
SFA Companies
Printed in China
25032-M0 rev 11/07
Advertisement
Table of Contents
Related Manuals for Omega Lift Equipment MagicLift 25032
Summary of Contents for Omega Lift Equipment MagicLift 25032
- Page 1 Operating Instructions & Parts Manual MagicLift™ Service Jack Combo Capacity Model 3 Ton 25032 This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. WARNING ADVERTENCIA To avoid crushing and related injuries:...
-
Page 2: Safety And General Information
SAFETY and GENERAL INFORMATION Save these instructions. For your safety, read, understand, and follow the information provided with and on this product before using. The owner and operator of this product shall have an understanding of this product and safe operating procedures before attempting to use. -
Page 3: Specifications
SPECIFICATIONS Service Jack: Min. Max. Saddle Jack Size Volume of Hyd. Capacity Height Height Diameter (L x W x H) Weight 3 Ton 5 1/4" 20 7/8" 5" 27 1/8" x 13 3/8" x 6 3/4" 245mL 78 lb. Jack Stands: Min. -
Page 4: Operation
OPERATION WARNING Lifting Only attachments and/or adapters supplied • Study, understand, and follow all printed by the manufacturer shall be used. materials provided with/on this product before use. Use jack stands only on areas of the vehicle as specified by the vehicle manufacturer. Use •... -
Page 5: Maintenance
MAINTENANCE A. Service Jack: Important: Use ONLY good grade hydraulic jack oil. Avoid mixing different types of fluid and Never use brake fluid, turbine oil, transmission fluid, motor oil or glycerin. Improper fluid can cause failure of the jack and the potential for sudden and immediate loss of load. -
Page 6: Replacement Parts
REPLACEMENT PARTS Not all components of the jack are replacement items, but are illustrated as a convenient reference of location and position in the assembly sequence. When ordering parts, please give the Model number, part number and parts description. Call or write for current pricing: SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153, U.S.A. E-Mail: sales@omegalift.com Tel: (888) 332-6419 Fax: (816) 891-6599... - Page 7 Replacement Parts List for model 25032 Service Jack Item Part No. Description A20060-0002 Filler Screw G48900-0023 Pump Piston G48900-0004 Release Valve G43000-0002 Grease Fitting Nipple, M6 G59508-0004 Saddle G62000-1003 Return Spring G58900-0002 Handle Sleeve G48900-0015 Pin, f13 G59305-0003 Nut M10 G48900-0016 Release Valve Gear G59305-0005...
-
Page 8: One-Year Limited Warranty
ONE YEAR LIMITED WARRANTY For a period of one (1) year from date of purchase, SFA Companies will repair or replace, at its option, without charge, any of its products which fails due to a defect in material or workmanship under normal usage. This limited warranty is a consumer's exclusive remedy.
