Operating Instructions & Parts Manual
GARAGE SERVICE JACK
THIS JACK CONFORMS TO MANDATORY STANDARD AS 2615:2016
READ RULES FOR SAFE OPERATION AND INSTRUCTIONS CAREFULLY
WARNING: THE JACK MUST BE USED ONLY ON HARD LEVEL
SURFACES AND BE FREE TO ROLL DURING LIFTING AND LOWERING.
DO NOT GET UNDER A VEHICLE THAT IS SUPPORTED BY A TROLLEY
JACK - USE THIS HYDRAULIC TROLLEY JACK WITH SUITABLY RATED
VEHICLE SUPPORT STANDS.
Imported by:
SHINN FU AUSTRALIA PTY. LTD.
15 Viewtech Place, Rowville 3178 VIC Australia
WORKING LOAD LIMIT 2200KG
HEAVY DUTY
Model No: 21220AA
PRINTED IN CHINA
21220AA-M0_012020
Advertisement
Table of Contents
Related Manuals for Omega Lift Equipment 21220AA
Summary of Contents for Omega Lift Equipment 21220AA
- Page 1 HEAVY DUTY GARAGE SERVICE JACK THIS JACK CONFORMS TO MANDATORY STANDARD AS 2615:2016 Model No: 21220AA READ RULES FOR SAFE OPERATION AND INSTRUCTIONS CAREFULLY WARNING: THE JACK MUST BE USED ONLY ON HARD LEVEL SURFACES AND BE FREE TO ROLL DURING LIFTING AND LOWERING.
-
Page 2: Safety Instructions
SAFETY INSTRUCTIONS INSPECTIONS 1. BEFORE EACH USE Visual inspection should be made before each use of the trolley jack for abnormal conditions such as cracked welds, leaks and damaged, loose, or missing parts. 2. AFTER EACH USE Trolley jack should be inspected immediately if the lift is believed to have been subjected to an abnormal load or shock. - Page 3 SAFETY INSTRUCTIONS CAUTION BEFORE USE Due to shipment and/or handling air can be trapped in the hydraulic system, which can interfere with the jacks lifting. To release air from the hydraulic system: • Open release valve by turning the jack handle counterclockwise. •...
-
Page 4: Maintenance
OPERATIONS TO RAISE: Know Your Jack Place vehicle in park, apply brake and chock wheels with suitable devices. 1. Position the jack under the load and close release valve by turning clockwise firmly. 2. Operate manually by pumping with handle until saddle ALMOST contacts with vehicle. -
Page 5: Specification
Length Width Height Load Limit Lowered Raised Lift Length Dia. Weight 21220AA 2,200 1,330 TROUBLE SHOOTING Symptom Possible Causes & Solutions 1. Release valve not tightly closed. To close or tighten, turn release valve clockwise. Jack will not lift load 2. -
Page 6: Spare Parts
SPARE PARTS Item # Description Item # Description Snap Ring Gear Washer Washer Front Wheel Side Plate Assembly Gear Shaft Bolt Handle Assembly Bolt Handle II Lock Washer Bolt Lock Washer Lock Washer Snap Ring Washer Rear Caster Assembly Bevel Gear Lock Washer Power Unit Assembly Retainer... - Page 7 SPARE PARTS Item # Description Item # Description Valve Base O Ring O Ring Bolt Cylinder Washer Steel Ball Cylinder Copper Washer Y Type Sealing Ring Guide Washer Washer Oil Return Valve Bolt Ring Oil Return Shaft Steel Ring O Ring Shaft Base Top Cap Steel Ball...
- Page 8 WARRANTY 1. This product is covered by an express warranty for 12 months from the date of purchase by the original purchaser. Subject to the conditions of this warranty Shinn Fu Australia Pty Ltd or its authorised repair agents will replace the product or perform necessary service on the product without charge for parts or labour if the product is found to be faulty within the warranty period.
