- Page 1 EN User Manual | Cooker LKR500005W...
-
Page 2: Table Of Contents
Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. INSTALLATION....................7 4. PRODUCT DESCRIPTION................10 5. -
Page 3: General Safety
be kept away from the appliance unless continuously supervised. • Children should be supervised to ensure that they do not play with the appliance. • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use. - Page 4 • Never use water to extinguish the cooking fire. Switch off the appliance and cover flames with e.g. a fire blanket or lid. • CAUTION: The cooking process has to be supervised. A short term cooking process has to be supervised continuously.
-
Page 5: Safety Instructions
• To remove the shelf supports first pull the front of the shelf support and then the rear end away from the side walls. Install the shelf supports in the opposite sequence. • The means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules. -
Page 6: Care And Cleaning
• The electrical installation must have an • Do not put flammable products or items isolation device which lets you disconnect that are wet with flammable products in, the appliance from the mains at all poles. near or on the appliance. The isolation device must have a contact •... -
Page 7: Internal Lighting
• Before maintenance, deactivate the extreme physical conditions in household appliance. appliances, such as temperature, Disconnect the mains plug from the mains vibration, humidity, or are intended to socket. signal information about the operational • Make sure the appliance is cold. There is status of the appliance. -
Page 8: Technical Data
Minimum distances Dimension 3.2 Technical data 6. Push the plinth in to the required height Voltage 230 V setting: 923, 898 or 858 mm. Frequency 50 - 60 Hz 7. Screw in screws C and D. Appliance class 3.4 Levelling of the appliance Dimension Height 858 - 923... -
Page 9: Electrical Installation
must adjust the side measurement to centre the appliance. If you changed the dimensions of the cooker, you must align the non-tip device correctly. CAUTION! If the space between the bench cupboards is larger than the width of the appliance, you must adjust the side measurement to the centre of the appliance. -
Page 10: Product Description
4. PRODUCT DESCRIPTION 4.1 General overview Knobs for the hob Temperature indicator / symbol Knob for the temperature Knob for the oven functions Heating element Lamp Shelf support, removable Shelf positions ENGLISH... -
Page 11: Cooking Surface Layout
4.2 Cooking surface layout Cooking zone 1200 W Steam outlet - number and position depend on the model Cooking zone 1800 W 140 mm 180 mm Cooking zone 1200 W Residual heat indicator Cooking zone 1800 W 180 mm 140 mm 4.3 Accessories •... -
Page 12: Hob - Daily Use
5.3 Mechanical Door lock 5.4 Condensation collector fitting The door cannot be opened by children. 1. Place the condensation collector on the front side of the storage drawer. Opening the oven door: 1. Pull and hold the door lock. 2. Empty the condensation collector after 2. -
Page 13: Residual Heat Indicator
The indicator appears when a cooking zone is hot, but it does not function if mains power is disconnected. For heat settings 1-3, the zone remains red for about 2-3 seconds and then The indicator may also appear: deactivates. • for the neighbouring cooking zones even if you are not using them, •... -
Page 14: Hob - Care And Cleaning
Heat setting Use to: Time Hints (min) Keep cooked food warm. as neces‐ Put a lid on the cookware. sary 1 - 2 Hollandaise sauce; melt: butter, choco‐ 5 - 25 Mix from time to time. late, gelatine. Solidify: fluffy omelettes, baked eggs. 10 - 40 Cook with a lid on. -
Page 15: Oven - Daily Use
• Remove shiny metallic discoloration: use a mixture of baking powder and lemon juice or vinegar. 9. OVEN - DAILY USE 3. To turn off the oven, turn the knobs for WARNING! the oven functions and temperature to the off position. Refer to Safety chapters. -
Page 16: Oven - Using The Accessories
Symbol Oven function Application Fast Grilling To grill flat food in large quantities and to toast bread. Quick Heat To roast larger joints of meat or poultry on one level. To make gratins and to brown. The maximum temperature for this function is 210 °C. Slow Cook To prepare tender, succulent roasts. -
Page 17: Conventional Cooking
11.1 General information 11.4 Cooking meat and fish The appliance has four shelf positions. Count Use a deep pan for very fatty food to prevent the shelf positions from the bottom of the the oven from stains that can be permanent. appliance floor. - Page 18 Food Tempera‐ Time Shelf po‐ Accessories ture (°C) (min) sition Quiche Lorraine 210 - 230 35 - 45 1 round enameled tin (diameter: 27 cm) Potato gratin 190 - 210 55 - 65 2 rectangular Pyrex dish, 24 cm x 15 cm x 5 cm Baking in baking tray or grill- / roasting pan Drip pan cake...
- Page 19 Food Tempera‐ Time (min) Shelf po‐ Accessories ture (°C) sition Frozen pizza 350 g 30 - 40 wire shelf Cakes in baking tray Swiss roll 20 - 30 baking tray or grill- / roasting pan Brownie 25 - 35 baking tray or grill- / roasting pan Cakes in tin Soufflé...
-
Page 20: Information For Test Institutes
Food Tempera‐ Time Shelf po‐ Accessories ture (°C) (min) sition Chicken, half 220 - 240 30 - 35 first wire shelf on level 3 and grill- / roasting side; 15 -25 pan on level 2 second side Pork chops 220 - 240 10 - 20 first wire shelf on level 3 and grill- / roasting side;... -
Page 21: Removing The Shelf Supports
Do not use steel wool, acids or abrasive WARNING! materials as they can damage the oven surface. Clean the oven control panel with the Keep the oven door slightly open during same precautions. the cleaning process. When you open it fully it may accidentally close causing 12.3 Removing the shelf supports potential damage. -
Page 22: Replacing The Lamp
above steps in the opposite sequence. Install 2. Slowly lift the drawer. the smaller panel first, then the larger. 3. Pull the drawer out fully. To install the drawer, do the above steps in CAUTION! the opposite sequence. Make sure that you install the internal 12.6 Replacing the lamp glass panel in the appropriate seats. -
Page 23: Service Data
Do not remove the rating plate from the appliance cavity. 14. ENERGY EFFICIENCY 14.1 Product Information according to EU Ecodesign Regulation for Hob Model identification LKR500005W Type of hob Hob inside Freestanding Cooker Number of cooking zones... -
Page 24: Hob - Energy Saving
14.3 Product Information Sheet and Product Information according to EU Energy Labelling and Ecodesign Regulations for Oven Supplier's name Electrolux Model identification LKR500005W 943005660 Energy Efficiency Index 95.0 Energy efficiency class Energy consumption with a standard load, conventional mode 0.76 kWh/cycle... -
Page 25: Environmental Concerns
Residual heat Conventional Baking When the cooking duration is longer than 30 Function designed to save energy during min, reduce the appliance temperature to cooking. For additional details refer to minimum 3 - 10 min before the end of "appliance - Daily use" chapter, appliance cooking. - Page 28 867375516-A-462023...
