- Page 1 EN User Manual | Cooker LKR540066X LKR540066W...
- Page 2 Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, troubleshooting, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. INSTALLATION....................7 4. PRODUCT DESCRIPTION................10 5. BEFORE FIRST USE..................10 6.
- Page 3 be kept away from the appliance unless continuously supervised. • Children should be supervised to ensure that they do not play with the appliance. • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use.
- Page 4 • Never use water to extinguish the cooking fire. Switch off the appliance and cover flames with e.g. a fire blanket or lid. • CAUTION: The cooking process has to be supervised. A short term cooking process has to be supervised continuously.
- Page 5 • To remove the shelf supports first pull the front of the shelf support and then the rear end away from the side walls. Install the shelf supports in the opposite sequence. • The means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules.
- Page 6 • The electrical installation must have an • Do not put flammable products or items isolation device which lets you disconnect that are wet with flammable products in, the appliance from the mains at all poles. near or on the appliance. The isolation device must have a contact •...
- Page 7 • Before maintenance, deactivate the extreme physical conditions in household appliance. appliances, such as temperature, Disconnect the mains plug from the mains vibration, humidity, or are intended to socket. signal information about the operational • Make sure the appliance is cold. There is status of the appliance.
- Page 8 Minimum distances You must install the anti-tilt protection. If you do not install it, the appliance can tilt. Dimension Your appliance has the symbol shown on the picture (if applicable) to remind you about the installation of the anti-tilt protection. 3.2 Technical data Voltage 230 V...
- Page 9 2. You can find the hole on the left side at Applicable types of cables for different the back of the appliance. Lift the front of phases: the appliance and put it in the middle of Phase Min. size cable the space between the cupboards.
- Page 10 4. PRODUCT DESCRIPTION 4.1 General overview Knobs for the hob 2 3 4 5 Temperature indicator / symbol Knob for the temperature Knob for the Minute Minder Knob for the oven functions Heating element Lamp Shelf support, removable Shelf positions 4.2 Cooking surface layout Cooking zone 1800 W Cooking zone 1200 W...
- Page 11 2. Let the oven operate for 1 hour. 3. Set the function . Set the maximum Refer to "Care and cleaning" chapter. temperature. The maximum temperature for this function is 210 °C. Clean the oven and the accessories before 4. Let the oven operate for 15 minutes. the first use.
- Page 12 7. HOB - HINTS AND TIPS To save energy and ensure that the hob WARNING! operates properly the cookware bottom must have a suitable minimum diameter (at least Refer to Safety chapters. the same as the zone diameter). 7.1 Cookware The cooking results depend on the cookware material The bottom of the cookware must be as...
- Page 13 Heat setting Use to: Time Hints (min) 4 - 5 Cook larger quantities of food, stews 60 - 150 Up to 3 l of liquid plus ingredients. and soups. 6 - 7 Gentle fry: escalope, veal cordon bleu, as neces‐ Turn over when needed.
- Page 14 overheating. To prevent this, the oven has a supply. The oven turns on again safety thermostat which interrupts the power automatically when the temperature drops. 9.3 Oven functions Symbol Oven functions Application Off position The oven is off. Oven lamp To turn on the lamp without a cooking func‐...
- Page 15 10. OVEN - CLOCK FUNCTIONS 10.1 Minute Minder 2. Turn the knob for the timer as far as it goes, then turn it to necessary time Use it to set a countdown time. period. After the time period is completed, an acoustic signal sounds.
- Page 16 Cakes and pastries at different heights do not always brown equally. There is no need to change the temperature setting if an unequal The temperature and baking times in the browning occurs. The differences equalize tables are guidelines only. They depend during baking.
- Page 17 Food Quantity (g) Temperature Time (min) Shelf po‐ Accessories (°C) sition Drip pan cake 1500 160 - 170 baking tray 45 - 55 Chicken, whole 1350 200 - 220 60 - 70 wire shelf baking tray Chicken, half 1300 190 - 210 35 + 30 wire shelf baking tray...
- Page 18 12.7 Fan Cooking Food Quantity (g) Temperature Time (min) Shelf po‐ Accessories (°C) sition 1000 baking tray Flat cake Yeast cake with ap‐ 2000 170 - 180 40 - 50 baking tray ples Drip pan cake 1200 150 - 160 baking tray 30 - 35 Chicken, whole...
- Page 19 12.8 True Fan Cooking Food Quantity (g) Temperature Time (min) Shelf po‐ Accessories (°C) sition 1000 baking tray Flat cake 1000 + 1000 1 + 3 baking tray Flat cake Yeast cake with ap‐ 2000 170 - 180 40 - 50 baking tray ples Drip pan cake...
- Page 20 Food Quantity (g) Temperature Time (min) Shelf po‐ Accessories (°C) sition 600 + 600 150 - 170 20 - 30 1 + 3 baking tray Buttered cake Preheat the oven for 10 minutes. After you switch off the appliance, leave the cake in the oven for 7 minutes. After you switch off the appliance, leave the cake in the oven for 10 minutes.
- Page 21 Food Temper‐ Time (min) Shelf Accessories ature position (°C) Shortcrust pastry biscuits 25 - 35 baking tray or grill- / roasting pan Tartelettes 20 - 30 baking tray or grill- / roasting pan Vegetarian Mixed vegetables in pouch 20 - 30 baking tray or grill- / roasting pan 400 g Omelette...
- Page 22 Food Function Tempera‐ Accessories Shelf po‐ Time ture (°C) sition (min) Fatless sponge cake Conventional wire shelf 20 - 30 Cooking Fatless sponge cake True Fan Cooking wire shelf 1 + 3 30 - 40 Short bread / Pastry Conventional baking tray 15 - 30 stripes...
- Page 23 3. Pull the door trim to the front to remove it. Install the removed accessories in the WARNING! opposite sequence. When you take out the glass panels 13.4 Removing and installing the the oven door tries to close. oven glass panels 4.
- Page 24 1. Turn off the oven. Wait until the oven is cold. 2. Disconnect the oven from the mains. 3. Put a cloth on the bottom of the cavity. The back lamp 1. Turn the lamp glass cover to remove it. 2.
- Page 25 Do not remove the rating plate from the appliance cavity. 15. ENERGY EFFICIENCY 15.1 Product Information according to EU Ecodesign Regulation for Hob Model identification LKR540066X LKR540066W Type of hob Hob inside Freestanding Cooker Number of cooking...
- Page 26 • Put the smaller cookware on the smaller cooking zones. 15.3 Product Information Sheet and Product Information according to EU Energy Labelling and Ecodesign Regulations for Oven Supplier's name Electrolux LKR540066X 943005704 Model identification LKR540066W 943005705 Energy Efficiency Index 94.9 Energy efficiency class Energy consumption with a standard load, conventional mode 0.84 kWh/cycle...
- Page 27 "appliance - Daily use" chapter, appliance functions. 15.5 Product Information for power consumption and maximum time to reach applicable low power mode Power consumption in off mode 0.3 W Maximum time needed for the equipment to automatically reach the applicable low power mode 20 min 16.
- Page 28 867375530-A-162024...
