- Page 1 V5C Plus Quick Start Guide The information in this manual is subject to change without notice. Rexing All Rights Reserved www.rexingusa.com 012024REV1...
- Page 2 Activate Your 18-Month Warranty & Choose Your FREE Gift! Activate within 30 days of purchase to claim your free gift and extend your limited 12-month warranty to 18 months. Scan The QR To Activate & Select Your Free Gift https://www.rexingusa.com/productreg/...
- Page 3 We hope you love your new products as much as we do. If you need assistance, or have any suggestions to improve it, please contact us. care@rexingusa.com (877) 740-8004 Our support team will respond you as soon as possible. Always a surprise in Rexing. Check us out here • https://www.facebook.com/rexingusa/ • https://www.instagram.com/rexingdashcam/ • https://www.rexingusa.com/support/registration/ •...
-
Page 4: What's In The Box
Paste the bracket into this circular area The information in this manual is subject to change without notice. Rexing All Rights Reserved www.rexingusa.com Rexing V5C Plus Dash Cam Quick Start Guide 64GB Micro SD Card Safety Guide Car Power Connector (12ft) -
Page 5: Camera Overview
2. Camera Overview Reset Power Button / Screen Toggle Button Menu Button / Mode Button Up Navigation Button / Screen View Button/ WiFi On-Off Button Down Navigation Button / Mute Button/ GPS Info Button OK (Confirm) Button / Record Button/ Emergency Lock Button USB Charging Port Micro SD Card Slot Rear Camera Port (rear camera sold seperately) -
Page 6: Screen Icons
Screen Icons Recording G-Sensor (ON） (Low) Wide Dynamic Range (ON) WiFi (OFF) Video Recording Recording Timer Mode Flashing Red While Recording Loop Recording Video Resolution UHD24fps+FHD24fps (1 Minutes) Exposure (0.0) MIC (ON) GPS Status (Disconnected) Power Connected Micro SD Card Inserted Current Date and Time (24h) GPS Speed... -
Page 7: Installation
3. Installation Step 1 Installing the Electrostatic Stickers 1.1 Prepare Your Windshield Thoroughly cleanse your windshield with either water or alcohol. Follow this by wiping it dry using a clean, dry cloth to ensure a spotless surface. 1.2 Position the Sticker Next, carefully peel off the protective film from the electrostatic sticker. -
Page 8: Insert The Memory Card
Step 3 Insert the Memory Card The Rexing V5C Plus accepts Class 10/UHS-3 or higher Micro SD memory cards up to 256GB. You will need to insert a memory card before you can begin recording. Before inserting or removing a memory card, first ensure you’ve powered down the device. - Page 9 Step 4 Power on the Camera and Format the Memory Card Power on the camera by connecting the charger to the car cigarette lighter and camera. To ensure the V5C records to your memory card properly and without error. Before you start using a new memory card, you must format the card within the camera using the format function.
- Page 10 Step 5 Mount the Rear Camera (optional) Rear cam needs to purchase separately. Mount the rear camera as shown below. Use rear camera cable to connect the rear camera to the V5C Plus camera. front cabin rear...
- Page 11 Step 6 Installing the Camera onto the Windshield Place the camera on the mount and carefully route the power cable around the windscreen and tuck in under the trim. Plug the Car Charger Cable into a 12V DC power outlet or the car cigarette lighter.
-
Page 12: Basic Operation
4. Basic Operation Device Power The device is automatically powered on when plugged into a 12V accessory socket or cigarette lighter and received a charge (i.e. the vehicle is started). To turn the device on manually, press and hold the Power button until the welcome screen appears. -
Page 13: Video Recording
Video Recording The camera will automatically start recording when the device receives charge. The LED lights and red dot will blink device when recording. Press the OK button to stop recording. UHD24fps+FHD24fps Reset The camera automatically starts recording when powered on EMR Mode (Locked Video) To use the Emergency Record Mode, hold the button to manually... -
Page 14: Video Playback
Video Playback Playback of videos can be done on the device or a computer. To playback a video on the device, toggle to the Playback mode. Use the buttons to toggle to the desired video. Press the OK button to play. During playback use the OK (pause), (rewind) and (fast forward) - Page 15 Wi-Fi Connect Step 1 With your dash cam powered on, hold the UP Navigation button to enable the Wi-Fi function. The Wi-Fi name (aka the SSID) and password for the dash cam should be displayed on-screen. Step 2 On your mobile device, navigate to your Wi-Fi settings. Connect to your dash cam's Wi-Fi by tapping its name when it appears.
- Page 16 Step 3 Once you're connected to the dash cam, open the Rexing Connect app on your mobile device. Please select "Keep Trying Wi-Fi" if you see the notification on the right. Step 4 In the app, hit the "Connect" button to connect to your dash cam, allowing you to access live view and view/download your recordings.
- Page 17 Easily download the app by scanning the QR code below or search via the App Store or Google Play. Wi-Fi Connect Troubleshooting If you bring up the Rexing connect app and cannot connect your phone to the dash cam please go to https://www.rexingusa.com/wifi-connect/...
-
Page 18: Gps Logger
GPS Logger You can then access this information while playing back your recordings using the GPS Video player (For Windows and Mac, available at rexingusa.com). The dash cam will automatically search for the GPS signal once it’s connected to the power source. Press the MENU button twice and go to System Settings. -
Page 19: Voice Command
Voice Command Below is a list of voice commands that you can use to carry out system functions hands-free. The device will not recognize a command that is not included in the following list: Take Photo Video Start Video Stop Turn on Audio Turn off Audio Turn on Screen... - Page 20 Parking Monitor (Parking Surveillance Mode) Parking monitor provides surveillance on your parked vehicle. When the engine is off, the hardwire kit is used to provide continuous power and protect your car battery from being discharged. Option 1: Vibration Detection To enable the Parking Monitor, you'll need to connect it with a Smart Hardwire Kit (sold separately).
- Page 21 WITHOUT connecting a smart hardwire kit. They may cause a malfunction. Option 2: Motion Detection To use this feature, you need to connect it with a Rexing Intelligent Hardwire Kit (sold separately). Make sure that the Parking Mode is turned off...
-
Page 22: Taking Photos
Taking Photos To take a photo, Please use “take phote”voice command. To view a photo, stop video recording and hold on MENU button to the Playback Mode. Press and Buttons to toggle through your photos. To delete a photo, stop video recording and toggle to the Playback Mode and toggle through the videos and photos to the one you want to delete. -
Page 23: Warranty And Support
Warranty & Support Warranty The Rexing V5C Plus Dash Cam comes with a full 12-month warranty. If you register your product on our official site (https://www.rexingusa.com/support/registration), you can extend the warranty to 18 months. Support If you have any questions regarding your product, please do not hesitate to contact us at care@rexingusa.com, or call us at... - Page 24 FCCID: 2AW5W-V5C This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.
