LED Bike Light Set
Art.no 31-7321
Model JY-286, JY-3209BT
Please read the entire instruction manual before using the product
and then save it for future reference. We reserve the right for any
errors in text or images and any necessary changes made to
technical data. In the event of technical problems or other queries,
please contact our Customer Services.
Safety
Warning
Do not point the light beam into anyone's eyes.
Do not let children play with the product.
Never expose the batteries to high temperatures or
naked flames.
Avoid contact with leaking batteries.
Never mix old and new batteries. Never mix rechargeable and
non-rechargeable batteries.
Front light
Inserting batteries
1. Press the catches to fold open
the cover.
2. Insert 3 x AAA/LR03 batteries
(sold separately). Refer to the
markings in the bottom of the
battery compartment to ensure
correct polarity.
3. Fold back the battery cover until it clicks into place.
Installation
1. Fit the bracket by pulling the strap
around the handlebar and hooking
the appropriate hole over the hook.
Note! Mounting the bracket is
easier if the lamp bracket is turned
sideways.
2. Slide the lamp onto the bracket.
ENGLISH
Instructions for use
Push the button on top of the lamp repeatedly to select between
three light settings: Flashing, Steady and Off.
Rear light
Inserting batteries
1. Insert a coin or a
slotted screwdriver
into the groove on
the side of the light
and carefully pry the
lens off to access the
battery compartment.
2. Insert 2 x AAA/
LR03 batteries (sold
separately). Refer to the markings in the bottom of the battery
compartment to ensure correct polarity.
3. Click the lens back into place.
Installation
Decide where the rear light is to
A
be placed. Either attach it with a
clip to a saddle bag (A) or use the
included light bracket (B).
Attaching the bracket
1. Wrap the rubber shim around the
seat post.
2. Cover the shim with the clamp
and screw on the bracket.
3. Click the light into place by
pushing it straight down.
4. Remove the light by pressing in
the catch on the bracket at the
same time as you pull the light
straight up.
Instructions for use
Push the button on the back of the light repeatedly to select
between four different light settings: Chasing, Flashing, Steady,
and Off.
Care and maintenance
Clean the product by wiping it with a damp cloth. Use only
mild cleaning agents, never solvents or corrosive chemicals.
Remove the batteries and store the light in a dry, dust-free
environment, out children's reach whenever it is not to be
used for an extended period.
Responsible disposal
This symbol indicates that the product should not
be disposed of with general household waste. This
applies throughout the entire EU. In order to prevent
any harm to the environment or health hazards caused
by incorrect waste disposal, the product must be
handed in for recycling so that the material can be
disposed of in a responsible manner. When recycling your product,
take it to your local collection facility or contact the place of
purchase. They will ensure that the product is disposed of in an
environmentally sound manner.
Specifications
Front light (JY-286)
B
20 lumens
Light intensity
Batteries
3 × AAA/LR03, 1.5 V (sold separately)
Dimensions
83,8 x 44,5 x 43 mm
Weight
53.6 g
Rear light (JY-3209BT)
Light intensity
3 lumens
Batteries
2 × AAA/LR03, 1.5 V (sold separately)
Dimensions
78 x 60,6 x 46,2 mm
Weight
36.8 g
C
