3 W LED Front
Cycle Light
Art.no. 18-4342
Model MLF-3K-UK
31-2000
MLF-3K
Please read the entire instruction manual before use
and save it for future reference. We reserve the right for
any errors in text or images and for making any neces-
sary technical changes to this document. If you should
have any questions concerning technical problems
please contact our Customer Services.
1. Warning
• Only use the charger supplied.
• The charger is for indoor use only.
• Both the charger and the battery pack will become
warm during charging. Stop the charging process
immediately if any of the components becomes
unusually hot.
• The battery pack is a sealed unit. Do not attempt to
dismantle the battery, it may become damaged and
void the guarantee.
• Do not throw the battery pack/charger onto the fire,
they can explode/leak.
• Do not leave the charger connected to the battery
pack for prolonged periods.
• Suitable for handlebar diameters of 25–32 mm.
• Make sure that the light is securely attached before
riding your bicycle.
2. Product description
1. Control switch
5. Lateral adjustment
2. Charging socket
screw
3. Rubber seal for
6. Locking knob
charging socket
7. Clamp
4. DC connector
8. Release catch
GREAT BRITAIN For consumer contact, please visit www.clasohlson.co.uk and click on customer service.
ENGLISH
10 5
10 8
10 7
10 6
3. Use
Charging
Fully charge the battery pack before using the light if
it has not been used for a long time.
1. Connect the provided charger to an electrical outlet
and unwind the entire cable.
2. Remove the rubber seal on the bottom of the cycle
light. Plug the charger's DC connector into the socket.
3. The charger has an indicator lamp that shines red
when charging is in progress.
4. When the indicator lamp shines green, the battery
pack is fully charged. A completely discharged
battery will take approximately 2½ hours to charge.
5. Unplug the charger from the electrical outlet, discon-
nect the DC connector and replace the rubber seal.
Mounting
1. Unscrew the knob on the
bracket and move it out so
that you can open the clamp.
2. Carefully open the clamp
and position it on the
handlebars or your cycle.
Move the locking knob back
and tighten the clamp.
3. The upper part of the bracket
10 1
has a lateral adjustment for
changing the direction of the
10 2
light beam. Undo the screw
on the top of the bracket a
10 3
half-turn, rotate the bracket
to the desired position and
10 4
tighten the screw again.
4. Push the cycle light into the bracket until
it clicks into place.
5. The control switch has the following settings:
High – low – flashing – off.
6. To remove the cycle light: Push the release
catch down and slide the light forwards.
10 4
4. Disposal
Follow local ordinances when disposing of this
product. If you are unsure of how to dispose of this
product, please contact your local authority.
5. Specifications
Power
3 W (LED)
High, low, flashing and off
Light modes
Operating time Approx. 5 hours
Battery
Li-Ion
Charging time Approx. 2½ hours
10 2
Charger
In: 100–240 V AC
Out: 4.2 V DC, 1000 mA (+ centre pin)
10 1
10 3
10 6
