LED Rear Bike Light
Art. no 31-1799
Model GS-1R(I)
Please read the entire instruction manual before using
the product and then save it for future reference. We reserve
the right for any errors in text or images and any necessary
changes made to technical data. In the event of technical
problems or other queries, please contact our Customer
Services.
Safety
Warning:
Do not point the light beam into anyone's eyes.
Do not let children play with the product.
Never expose the batteries to fire or high temperatures.
Avoid contact with leaking batteries.
Fitting and replacing the battery
A
1. Slot the edge of a coin into the lower part of the housing (A)
and twist it to open.
2. Insert 2 × AAA/LR03 1.5 V batteries (sold separately).
Refer to the markings in the battery compartment to
ensure correct polarity. Never mix old and new batteries.
Never mix rechargeable and non-rechargeable batteries.
3. Click the housing back into place to reassemble.
UNITED KINGDOM • CUSTOMER SERVICE tel: 020 8247 9300 e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.co.uk postal: 10 – 13 Market Place, Kingston Upon Thames, Surrey, KT1 1JZ
ENGLISH
Instructions for use
1. Press [
] repeatedly to turn on,
to start the flash function and to
turn off the light.
Mode Function
1
3 bulbs will shine steadily
2
1 bulb shines steadily,
2 bulbs flash
3
3 bulbs flash
4
OFF
2. Battery status indicator. Steady
green light when battery is
capacity is below 50%.
Installation
D
C
F
E
G
B
1. Remove the screw (B) from the bracket and open
the bracket strap (D).
2. Wrap the strap (D) around the seat post and feed it back
through the bracket slot as far as it will go. Reinsert
the screw (B) into the bracket (C) and tighten securely to
lock the bracket strap.
3. Attach the light (F) by sliding the clip into the bracket (E).
Make sure that the light is securely attached before riding
your bicycle.
Care and maintenance
Clean the product using a damp cloth. Use only mild
cleaning agents, never solvents or corrosive chemicals.
1
2
Remove the battery and store the light in a dry, dust-free
environment, out children's reach whenever it is not to be
used for an extended period.
Responsible disposal
This symbol indicates that this product
should not be disposed of with general
household waste. This applies throughout
the entire EU. In order to prevent any harm to
the environment or health hazards caused by
incorrect waste disposal, the product must
be handed in for recycling so that the material
can be disposed of in a responsible manner.
When recycling your product, take it to your
local collection facility or contact the place of
purchase. They will ensure that the product
is disposed of in an environmentally sound
manner.
Specifications
Batteries
2 × AAA/LR03, 1.5 V (sold separately)
Operating time Mode 1: 30 hours
Mode 2: 40 hours
Mode 3: 60 hours
Size
35 × 60 × 34 mm
Weight
30 g (without batteries)
