MP52 (E2) Hardware Introduction MP52 (E2) Hardware Introduction
The following figure displays the hardware features of the MP52 (E2) phones.
No. No.
1 Power LED Indicator
2 Line Keys
3 Soft Keys
4 Navigation Keys
5 Mute Key
6 Headset Key
Message Key(MP52)
7 Transfer key (MP52
E2)
8 Redial Key
9 Speakerphone Key
10 Volume Key
Item Item
Indicate phone statuses.
/
Access the function displayed on the screen above the soft keys.
The soft keys change depending on what you are doing at the time.
Scroll through information or options displayed on the screen.
Toggle the microphone on or off.
Toggle the headset on or off.
Message key: Access your voice messages.
Transfer key: Transfer a call.
Redial a dialed number.
Enable you to place and receive calls using the speakerphone.
Adjust the handset volume, headset, speaker, and orringer.
Description Description
1
