Summary of Contents for Gram HI 6234 T
- Page 1 HI 6234 T IN 6244 TI N INSTRUCTION MANUAL INDUCTION HOB IO-HOB-2214 / 9519844 (05.2025 / v4)
- Page 2 Congratulations on the new GRAM hob Your hob combines exceptional ease of use with excellent effectiveness. Once you have read the instructions, operating your hob will not be a problem. Before being packed and leaving the factory, the safety and functions of this hob were ca- refully tested.
-
Page 3: Table Of Contents
TABLE OF CONTENTS SAFETY INSTRUCTIONS DESCRIPTION OF THE APPLIANCE INSTALLATION OPERATION CLEANING AND ROUTINE MAINTENANCE PRACTICAL EVERYDAY TIPS EMERGENCY PROCEDURE TECHNICAL DATA... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Warning: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless con- tinuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given... - Page 5 SAFETY INSTRUCTIONS Warning: If the surface is cracked, switch off the ap- pliance to avoid the possibillity of electric shock. The appliance is not intended to be operated by me- ans of an external timer or separate remote-control system. You should not use steam cleaning devices to cle- an the appliance.
- Page 6 Should cracks or splits appear on the surface of your ceramic plate immediately discon- nect it from the mains. In order to do so, switch off the fuse or pull out the mains plug from the socket. Call the Customer GRAM Service ●...
- Page 7 ENERGISPARETIPS UDPAKNING Apparatet er blevet sikret Hvis du sparer på ener gien, mod transportskader under er det godt for miljøet, og det befordringen ved hjælp af vil reducere din elregning. en emballage. Efter fore- taget udpakning bedes du sørge for, at emballagens elementer bortskaffes på...
-
Page 8: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE Description of hob 1. Power Booster induction cooking Power Booster induction cooking zone Ø Ø 210 (front left) zone Ø Ø 210 (rear right) 2. Power Booster induction cooking 4. Power Booster induction cooking zone Ø Ø 160 (rear left) zone Ø... -
Page 9: Installation
INSTALLATION Making the worktop recess • Worktop thickness should be 28 - 40 mm, while its width at least 600 mm. The worktop must be flat and level. Edge of the worktop near the wall must be sealed to prevent in- gress of water or other liquids. - Page 10 max 44 INSTALLATION Variant 1 Variant 2 5 6 0 6 0 0 Variant 3...
- Page 11 INSTALLATION Tips for the installer The hob is equipped with a terminal block allowing different connections appropriate for a specific type of power supply. Terminal block allows the following connections: - single-phase 220-240 V ~ - two-phase 380-415 V 2N~ The hob can be adapted to a specific type of power supply by bridging the appropriate terminals according to wiring diagram.
- Page 12 INSTALLATION Inside the packaging you will find accessories necessary to connect the appliance to home electrical system. Use the enclosed accessories to ensure the proper operation of the appliance. The accessories include: Strain relief, bridge connection, 2 screws and connection terminal cover. Install the strain relief using the provided Install the terminal cover by inserting it until screws.
-
Page 13: Operation
OPERATION Operate your induction hob Under the surface glass, there are induction coils that produce pulsing magnetic field. This electromagnetic field penetrates a pot placed on the hob surface causing the pot to heat up. It is important to use pots with a suitable base. Depending on the pots used and heat setting during cooking, the appliance pro- duces a distinctive whiz. -
Page 14: Pan Detector
OPERATION Pan detector Induction hobs feature a pan detector. The hob will detect the presence of a suit- able pan placed on a cooking zone and automatically activate it. This helps save electricity. • If a suitable cookware is placed on the cooking zone, the set power level is shown on the corresponding display. - Page 15 OPERATION Check for marking indicating that Kitchen cookware marking the cookware is suitable for induc- tion cooking. Cookware is not detected Stainless Steel With the exception of the ferromagnetic steel cook- ware Aluminum Cookware is not detected High efficiency Cast iron Note: cookware can scratch the hob surface High efficiency Enamelled steel...
-
Page 16: Before Using The Appliance For The First Time
OPERATION Before using the appliance for the first time • Thoroughly clean the induction hob. The hob has a glass surface, therefore handle it with care. • Odours may be released when you first start your appliance. If this happens, turn on exhaust hood or open the window in the room. - Page 17 OPERATION Control Panel • Immediately after the appliance is connected to electrical mains, all displays will light up briefly. Your appliance is then ready for use. • The induction hob is equipped with electronic touch control sensors, which are operated by touching with a finger for at least 1 second. •...
-
Page 18: Turn Off The Appliance
OPERATION Deactivate cooking zones Deactivate cooking zone by doing one of the following: • Turn off the hob with the sensor. • Touch and hold the sensor for 3 seconds • Activate the cooking zone - simultaneously touch and hold the heat setting touch sensors •... -
Page 19: Child Lock
OPERATION The Booster function can be activated for two cooking zones at the same time, i.e. one of the left cooking zones and one of the right cooking zones. You will not be able to activate the Booster function if another cooking zone on the same side already has the Booster function activated. - Page 20 OPERATION Limit the operating time In order to ensure the safety of users, the induction hob is fitted with an operating time limiter for each of the cooking zones. Cooking heat Maximum operat- setting ing time The maximum operating time is determined in- dividually depending on the heat setting when cooking.
-
Page 21: Minute Minder
OPERATION When the set cooking time has elapsed, you will hear an alarm beep. Touch any sen- sor to mute it or the alarm will turn off automatically after 30 seconds. If you want to cancel the timer ahead of time, activate the desired cooking zone by touching its sensor (the power indicator will flash), then cancel the timer as follows: •... - Page 22 OPERATION Maintain temperature Your hob is equipped with special programmes that allow you to cook at the set temperature while consuming the least possible amount of energy. 3 programmes are available: • Melt 40 This is intended for melting butter or a bar of chocolate. Place the butter or chocolate in a pan at room temperature and then activate the Melt 40 programme.
-
Page 23: Cleaning And Routine Maintenance
CLEANING AND ROUTINE MAINTENANCE Daily cleaning and proper maintenance have crucial impact on the durability of your ceramic plate. Clean the ceramic plate observing the same rules as for glass. Never use abrasive or aggressive clean- ing agents, scrubbing powders or scratching sponges. -
Page 24: Practical Everyday Tips
PRACTICAL EVERYDAY TIPS Table of example hob settings FUNCTION DISH TIME [MIN] PORTION SIZE Brownie / Chocolate Melt 40* Melt chocolate 300 g Fondant 1 piece approx. Melt 40* Defrost Pork neck / Bigos 800 g Yeast dough Melt 40* Proof yeast dough 1 kg Parboil meats and... -
Page 25: Emergency Procedure
● have the appliance repaired ● Based on the instructions given in the table below, some minor issues can be corrected by the user. Please check the consecutive points in the table before you refer the repair to customer GRAM service. PROBLEM POSSIBLE CAUSE... - Page 26 EMERGENCY PROCEDURE Activate the cooking The cooking zone has The maximum operating zone again and set the turned itself off. time has been reached. heat setting. Noises are heard during Normal operation of the appliance. The noises emit- cooking. ted depend on the pots used and the heat setting. The “h”...
-
Page 27: Technical Data
TECHNICAL DATA 220-240V/380-415 V Rated voltage ~50/60 Hz 2N Rated power: HI 6234 T HI 6234 T Type: IN 6244 TI N IN 6244 TI N Induction cooking zone power: 3,7 kW - induction cooking zone: - induction cooking zone: Ø 210-220 mm Ø... - Page 28 Gram A/S Gram A/S Gram A/S Tel.: 22 07 26 30 Tel.: 040 38 08 40 Tel.: 020 7756 350 www.gram.no www.gram.se www.gram.fi Gram A/S Gejlhavegård 2B DK-6000 Kolding +45 73 20 10 00 www.gram.dk...
