KKG 9401-90 T
INSTRUCTION MANUAL
GAS HOB
IO-HOB-1553/ 8513917
(12.2022 / v3)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KKG 9401-90 T and is the answer not in the manual?

Questions and answers

Summary of Contents for Gram KKG 9401-90 T

  • Page 1 KKG 9401-90 T INSTRUCTION MANUAL GAS HOB IO-HOB-1553/ 8513917 (12.2022 / v3)
  • Page 2: Basic Information

    Congratulations on the new GRAM hob Your hob is exceptionally easy to use and extremely efficient. After reading these Operating Instructions, operating the appliance will be easy. Before being packaged and leaving the manufacturer, the appliance was thoroughly checked with regard to safety and functionality.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Basic Information....................2 Safety instructions....................4 Description of the appliance................9 Specification......................10 Installing (instructions for the installer)...............11 Operation.........................18 Cleaning and maintenance..................24 Troubleshooting.....................25...
  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS FOR USE Note.The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concern-...
  • Page 5 SAFETY INSTRUCTIONS FOR USE Caution: The cooking process has to be supervised. A short term cooking process has to be supervised continuously. Warning: Use only hob guards designed by manufacturer of the cooking appliance or indicated by the manufacturer of the appliance in the instructions for use as suitable or hob guards incorporated in the appliance.
  • Page 6 SAFETY INSTRUCTIONS FOR USE ● IF YOU SUSPECT A GAS LEAK, DO NOT: light matches, smoke, turn on or off any electrical devices (door bell, light switch, etc.) and use other electrical or mechanical equipment that can produce an electrical or impact spark. In such a case, immediately close the valve on the gas cylinder or the gas system shut-off valve, ventilate the room and call a qualified person to remove the cause of the leak.
  • Page 7: How To Save Energy

    HOW TO SAVE ENERGY Using energy responsibly not only saves money but also helps the environment. So let’s save energy! And this is how you can do it: ● Use proper pans for cooking. Pans with thick, flat bases can save up to 1/3 on electric energy.
  • Page 8: Disposal Of The Appliance

    UNPACKING DISPOSAL OF THE APPLIANCE The appliance was packed In accordance with European to protected it from damage Directive 2012/19/UE and Pol- during of transport. After ish legislation regarding used unpacking, please dispose electrical and electronic goods, of all elements of packaging this appliance is marked with in a way that will not cause the symbol of the crossed-out...
  • Page 9: Description Of The Appliance

    DESCRIPTION OF THE APPLIANCE Gas hob 1,2,3,4,5 - top burners 6 - burner knobs with igniter switch 7 - grids 6- Indicator of on/off sensor 1- Sensor on/off 7- Indicator of timer 2- Sensor plus 8- Indicator of “child lock” 3- Sensor minus 9- Timer display 4- Sensor change time...
  • Page 10: Specification

    SPECIFICATION height 113,4 mm depth 520 mm width 890 mm weight of the appliance 18 kg The appliance is equipped with burners: 1 - ultra large burner, heat load - 4.0 kW 2 - large burner, heat load - 3.0 kW 2 - medium large burners, heat load - 2.0 kW 3 - small burner, heat load...
  • Page 11: Installing (Instructions For The Installer)

    INSTALLING The following instructions are intended for a qualified professional installer. These instructions are intended to provide the most professional installation and maintenance of the appliance. l Before you install the appliance, make sure that the local distribution conditions (gas type and pressure) and the appliance configuration is appropriate. l Configuration details are given on the appliance nameplate.
  • Page 12 INSTALLING Install gas hob B/B* 500x20 mm 500x10 mm 500x10 mm min 30 mm *optional...
  • Page 13 INSTALLING Installing hob - bracket* ● prepare an opening in the worktop of a kitchen cabinet, as per the installation drawing ● connect the hob to a gas and electrical system in accordance with the instructions supplied, ● loosely attach fixing brackets to the bottom of the hob, ●...
  • Page 14 INSTALLING Tips for the installer The appliance has an G 1/2" threaded pipe connector to connect it to the gas system. The installer must: The LPG (propane-butane) hob version has Have appropriate qualification ● the connector terminated with a hose tip ∅...
  • Page 15 INSTALLING Adapt the hob to a particular type of gas This may be performed by an installer with the appropriate qualifications only. If the gas, which the hob will be supplied with is different from the gas type specified by the manufacturer, i.e.
  • Page 16 INSTALLING SOMIPRESS burner. (indicated "SOMIPRESS." on the burner body) Burner auxiliary medium large ultra large Type of gas G20 2E 20 mbar 0,77 0,97 1,29 1,30 G30 3B/P 30mbar 0,50 0,65 0,87 0,84 G110 1a 8 mbar 1,50 1,85 3,20 3,00 Once converted, place a sticker indicating the gas type for which the appliance is intended.
  • Page 17 INSTALLING In order to check the flame, heat up the burner Adjust the valves on a full flame for about 10 min., and then turn the burner knob to an economic flame To adjust the valves turn the burner knob to position.
  • Page 18: Operation

    OPERATION Turn on the appliance Timer function When you connect the appliance to power The timer function can be activated at any the power indicator will come on. Your hob time during cooking. Just activate the control is then ready for use. panel, and then use the Timer sensor to select the desired burner.
  • Page 19 OPERATION Timer The minute minder does not affect any of the burners. It only alerts you when the count- down has come to an end. To use function, use the Timer sensor to select the central display. When Minute Minder is active its indicator is on. Use the + / –...
  • Page 20: Burner Operation

    OPERATION Cookware lid: Burner operation Lid prevents heat from escaping and thus reduces heating time. To achieve significant energy savings, use the appliance as instructed in these operating instructions, make the appropriate adjustments and use suitable pots. Do not use cookware that protrude Potential energy savings: over the edges of the hob.
  • Page 21 OPERATION Using the hob equipped with igniter knobs Repeat the above step if flame does ("Zp" model) not ignite. If flame is extinguished, the flame- ● push down the knob of a selected burner failure device will cut off gas supply until you feel resistance and turn left to within about 60 seconds.
  • Page 22 OPERATION Adjust flame “Zt” Adjust flame “Zs” Flame from a properly adjusted burner is Flame from a properly adjusted burner is pale blue with a clearly outlined inner cone. pale blue with a clearly outlined inner cone. You can adjust flame by setting the knob to You can adjust flame by setting the knob to different positions.
  • Page 23 OPERATION In the event a gas leak risk 1 gas system 2 gas system shut-off valve A valve "open" B valve "closed" In the event of a fault ● turn off the burners ● close the gas system shut-off valve ●...
  • Page 24: Cleaning And Maintenance

    CLEANING AND MAINTENANCE Make sure that burner is correctly re- Proper routine maintenance and cleaning assembled after cleaning. of the appliance can significantly extend its trouble-free operation. CORRECT B e f o r e c l e a n i n g o r o t h e r maintenance work, always unplug the appliance or use the main electrical system circuit breaker...
  • Page 25: Troubleshooting

    ● have the appliance repaired ● based on the instructions given in the table below, some minor issues can be corrected by the user. Please check the consecutive points in the table before you refer the repair to customer GRAM service. PROBLEM POSSIBLE CAUSE REMEDY 1.The appliance does not...
  • Page 28 Gram A/S Gram A/S Gram A/S Tel.: 22 07 26 30 Tel.: 040 38 08 40 Tel.: 020 7756 350 www.gram.no www.gram.se www.gram.fi Gram A/S Gejlhavegård 2B DK-6000 Kolding +45 73 20 10 00 www.gram.dk...
