HDMI EXTENDER
Point to Point Extender
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI
Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
User Manual
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Lenkeng LKV223P
Summary of Contents for Lenkeng LKV223P
- Page 1 User Manual HDMI EXTENDER Point to Point Extender Disclaimer The product name and brand name may be registered trademark of related manufactures. ™ and ® may be omitted on the user manual. The pictures in this user manual are just for reference. We reserve the rights to make changes without further notice to a product or system described herein to The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI improve reliability, function or design.
-
Page 2: Important Safety Notice
· Important Safety Notice 1. Please distinguish the transmitter and receiver before installation. 2. Do not disassemble the machine to repair the product during the working process to avoid electric shock. 3. Please cut off the power before installation. Live installation may damage the equipment. - Page 3 · Package Contents · Interfaces Transmitter unit x1pc Receiver unit x1pc DC5V/2A x1pc ① ② ③ ④ ⑤ User manual x1pc ⑥ ⑦ ⑧ ① Reset button Press to restart the device · Installation Requirements ② RJ45 signal output Output modulated HDMI signal. Connect the IR receiver extension cable to ③...
-
Page 4: Installation Procedures
· Installation Procedures 1. Connection 3.5mm L/R HDMI Display Speaker Network cable HDMI OUT ① ② ③ ④ ⑤ Video Source HDMI Display IR IN Power IR OUT Note: When using the 3.5mm stereo audio jack, please switch the audio ⑥... - Page 5 2 ) Connect the CAT out port of the transmitter and the CAT in port of the receiver via a network cable (CAT6/CAT6A/CAT7). Q: There is no output on screen when all connections are correct? 3 ) If using HDMI loop out, connect the display device to the HDMI OUT A: 1) Please make sure the HDMI cables support the resolution of the port of the transmitter.
- Page 6 · Specification Items Specification Voltage/Current DC5V/2A Power consumption TX<4W RX<4W HDMI compliance HDCP compliance 800x600, 1024x768, 1280x720, 1280x960, 1366x768, 1440x900, 1680x1050, 1920x1080, 480i@60Hz, HDMI resolution 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz, 1080i@50/60Hz, 1080p@24/25/30/50/60Hz, 3840x2160@24/25/30Hz Supports audio formats PCM, LPCM, DTS HD, DTS Audio Input and output TMDS signal 0.7~1.2Vp-p(TMDS) Input and output DDC signal...
