User Manual
4K60Hz HDMI KVM EXTENDER
Disclaimer
The product name and brand name may be registered trademark of related
manufactures. ™ and ® may be omitted on the user manual. The pictures in this
user manual are just for reference. We reserve the rights to make changes
without further notice to a product or system described herein to improve
reliability, function or design.
Advertisement
Table of Contents
Related Manuals for Lenkeng LKV565KVM-P
Summary of Contents for Lenkeng LKV565KVM-P
- Page 1 User Manual 4K60Hz HDMI KVM EXTENDER Disclaimer The product name and brand name may be registered trademark of related manufactures. ™ and ® may be omitted on the user manual. The pictures in this user manual are just for reference. We reserve the rights to make changes without further notice to a product or system described herein to improve reliability, function or design.
-
Page 2: Important Safety Instructions
· Important Safety Instructions: 1. To prevent electric shock, please ensure that all devices are properly grounded. 2. Do not place this device near or over a radiator or heat register, or where it is exposed to direct sunlight. 3. Place the device in a well-ventilated area, do not block any ventilation openings. -
Page 3: Package Contents
· Features · Installation Requirements 1. Zero-latency transmission Item Description Requirement 2. Extend 4K@60Hz HDMI signal up to 60m over Cat6/6A/7 cable Signal PC, DVD, NVR, etc. with HDMI port HDMI cable ≤ 5m 3. Compatible with a wider range of screen resolutions such as 3440x1440, source 2560x1440, 2560x1080, 2048x1080, 1920x1440 CAT6/6A/7，following standard... - Page 4 · Panel Description 1. Transmitter 2. Receiver ① ② ③ ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ④ ⑤ ⑥ ⑦ ⑧ ① Power Input PoC, only TX power supply is needed ① Power Input Connect with DC 5V/2A power adapter ②...
-
Page 5: Installation Procedures
· Installation Procedures 1. Connection Diagrams Q: The devices are connected correctly, but why is there no image displayed? 1) Please make sure the HDMI cable meets the transmission requirements. (e.g. 4K HDMI cable) 2) Please check and make sure the network cable is connected firmly. 3) Restart the transmitter or receiver by pressing the reset button. -
Page 6: Technical Parameters
Technical Parameters Item Transmitter Receiver Working -10℃~60℃ Video Storage -30℃~70℃ temperature Input interface 1x HDMI 1x RJ45 Humidity 0~90% RH (no condensation) 1x HDMI Output interface 1x HDMI 1x RJ45 Physical Properties HDMI length ≤ 5m ≤ 5m Housing lron Maximum 18Gbps Weight...
