- Page 1 AGE 14+ FOLDING DRONE WITH OBSTACLE AVOIDANCE FUNCTION OPERATING MANUAL 避障功能折叠无人机 使用说明书 *请在飞行前仔细阅读说明书并妥善保管以便日后参考。...
- Page 2 KNOW YOUR DRONE 认识你的无人机 Drone 无人机采用2.4G频段，可多人同时操作而互不干扰。 通过遥控器可操控无人机实现飞行、翻滚、微调、一键 起飞、一键降落、速度、无头模式、校正、定高等功能。 Battery Upper Casing 电池 机壳上盖 Motor Lower Casing 电机 机壳下盖 Camera Propeller 摄像头 风叶 Obstacle avoidance 机臂 equipment 避障设备...
- Page 3 配件表 ACCESSORIES DRONE x1 Remote Control x1 (Battery Included) 遥控器 x1 无人机 x1 (内含电池） Backup Propellers Ax1 Bx1 Protective Guard x4 备用风叶 Ax1 Bx1 防护架 x4 USB Charger x1 Screwdriver x1 User Manual x1 USB充电器 x1 十字螺丝刀 x1 说明书 x1 Notes 注意：...
-
Page 4: Optional Accessories List
OPTIONAL ACCESSORIES LIST 可另购配件表 Propellers Launch board Motor 风叶 发射板 电机 Receiving board Upper Casing Lower Casing 接收板 机身上盖 机身下盖 Battery Protective Guard 电池 护架 Notes 注意： If any of the above accessories are damaged during operation, you can contact the seller to purchase. 操作过程中，如有以上配件损坏，可自行联系卖家购买。... -
Page 5: Pre-Flight Preparation
PRE-FLIGHT PREPARATION 飞行前准备 选择飞行环境 1.FLIGHT ENVIRONMENT Indoor: Spacious spaces away from barriers, crowds or pets are preferred. 在室内飞行：请选择附近无障碍物、人群和宠物的开阔 空间飞行。 Outdoor: Sunny, windless and breezy weathers are preferred. 在室外飞行：请选择晴朗无风的天气或微风的天气飞行。 Please keep the drone in sight during the flight and keep it away from barriers, high-tension cables, trees and people. - Page 6 2.OPEN THE WINGS 打开机翼 OPENING STEPS 打开机翼顺序： ① Open the front arm(close to camera) 先打开前机臂。（靠摄像头一侧） ② Open the back arm Fold the back armf firstly and then the ront arm when folding. 再打开后机臂，折叠时顺序相反。 Opening arm 机翼展开 防护架安装 3.ASSEMBLING PROTECTIVE GUARD Align the protective frame with the hole of the arm to install, and press it into place.
- Page 7 5.BATTERY CHARGING FOR DRONE 机身充电方法 A. Remove the lithium battery from the bottom of the drone. 按下箭头指示的位置，把电池箱往外拉出，取出电池。 B. Connect USB charging cable with the charging interface of the lithium battery. USB充电器连接电池与USB充电接口 Notes 注意： The LED light is red on when charging, and the LED light is green when charging is finished.
- Page 8 BATTERY LNSTRUCTIONS There is a certain risk when using lithium battery. It may cause fire, body injury or property loss. Users must be aware of the risks and take full responsibility of using battery improperly. If battery leakage occurs, please avoid contacting your eyes or skin with electrolyte.
- Page 9 KNOW YOUR REMOTE CONTROL 认识你的遥控器 1.Parts of remote control 遥控器各部位名称 Standard version/Obstacle avoidance version 普通 版本/避障版本 The regular version is a light control key The obstacle avoidance version is the obstacle avoidance mode button One-key Flips&Rolls Phone clip 常规版本为灯控键 360°翻滚 手机夹...
- Page 10 LITHIUM BATTERY INSTRUCTION Open the remote control battery cover 遥控器电池盖的开启 Remote control battery installation 遥控器电池的安装 Open the battery cover and insert the 3 AA batteries correctly according to the electrode instructions.(Batteries not included) 打开电池盖，依照电极指示正确放入3粒AA电池。（电池需另购） Notes 注意： SIGNAL CONNECTION OF TRANSMITTER AND RECEIVER 遥控器与无人机对频...
- Page 11 TRANSMITTER CALIBRATION 遥控器校准 Apply transmitter calibration when the drone fails to take off vertically. Standard version/Obstacle avoidance version Press the "One button calibration" button，When the lights of drone are on and then start flashing and keep on again, the calibration is complete. the drone must be placed on ahorizontal surface in a steady state when the calibrationis conducted.
- Page 12 电调版本 将左右操控杆同时拨向左下方，听到“滴”一声，然 后将左右操控杆拨向右下方，听到“滴”一声，此时 无人机指示灯快速闪烁，待指示灯常亮，校正完成。 在执行校正命令时，必须在与水平线平行的平稳状态 下执行，否则会影响校正效果。 START YOUR FLIGHT 开始飞行 1. One-key Ascend 一键起飞 Press the "One-key Ascend" button, the drone blades rotate and automatically fly to a height of 1.5 meters. 按下“一键起飞”按键，无人机风叶转动，自动飞 到1.5米的高度。 2. Basic Flight 基本飞行 Use the left joystick to control the flight altitude and turn left/ right, and the right joystick to control the forward, backward, left and right sidde flight directions.
- Page 13 Obstacle Avoidance Mode (The obstacle avoidance function is only available when you purchase the obstacle avoidance version) 避障模式 (购买避障版本才避障功能） Press the button to turn on the obstacle avoidance mode, and press again to turn off the obstacle avoidance mode. Avoid obstacles on four sides and retreat in the opposite direction of the obstacle.
- Page 14 Headless Mode 无头模式 The flight direction of drone is subjected to the direction of remote control. 1.When drone adjust the frequency, the drone is default as common mode. Then the indication light of drone is normally on. When you press the headless function key of remote control, the remote control beeps once and enters headless state.
- Page 15 FINE-TUNING FUNCTION 微调功能 When the aircraft spins in the air or tilts in different directions, you can use fine-tuning to correct the action. Press the fine-tuning button and hear a beep, then move the joystick in the opposite direction to adjust and calibrate until the aircraft does not deviate.
- Page 16 遇到问题不用慌...
