INTRODUCTION The Baicells mmW is an advanced outdoor millimeter wave integrated base station (gNB), which is designed and developed based on Qualcomm 5G SoC solution. This 49dBm EIRP gNB is low power consumption, subminiature and easy to maintenance. This product helps operators to enhance the coverage performance of 5G networks effectively, improve the capacity of 5G networks and eliminate the blind district, meanwhile it also can help to reduce the system power consumption.
Page 3
TECHNOLOGY Standard 5G NR TDD (3GPP R16 compliant) 5ms periodicity (μ=1): DDDSU TDD UL/DL Configuration Frequency Band n261 (27.5GHz ~ 28.35GHz) Channel Bandwidth 100MHz x 4CC Multiplexing DL:2, UL:1 Security Radio: SNOW 3G/AES-128 Backhaul: IPsec (X.509 AES-128, AES-256, SHA-128, SHA-256) INTERFACE Ethernet Interface 1 optical (10G SFP+) and 1 RJ-45 Ethernet interface (1 GE)
Page 4
FCC COMPLIANCE This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Interface Description Interface Description Power interface, connect to -48VDC power supply RJ-45 interface, used for debug or data backhaul. Optical interface (SFP+), connect to external transmission network, used for data backhaul. External GPS antenna, N-female connector. Interface Indicators Identity Color Status Description Green...
Installation Tool Leveling instrument Marker pen Knife Vise Wrench Percussion drill hammer Cross screw Cable vice Tape measure driver NOTE: Other accessories have been packed in the packing box. Install GPS Antenna Read the following GPS antenna installation requirements before installing it on the base station.
Tighten the connector. Push the cold shrink tube to the top joint, and pull out the strip. Ensure the cold shrink tube is tightly fitted with the connection. Pole Mounting Check to ensure the diameter of the pole is in the range of 1.6 inches to 2.8 inches (40mm to 70 mm).
After mounting, adjust the gNB to a proper angle by adjusting the adjustable bracket. Wall Mounting NOTE: The wall must bear at least 4 times the weight of the gNB. Take apart assembly bracket first, only remains the wall bracket, as shown in Figure 2-2. Figure 2-2 Wall Bracket Following steps introduce how to fix the pre-assembled gNB on a wall.
Connect Cables Power ON Power on the gNB, and wait a few minutes while the gNB boots up. Per the previous indicator description in “1 Appearance”, check that the LED indicators are lighting as expected.
