- Page 1 Assembly Instructions Manual Refilling Pump MFP Date: 31.01.2025 Document no.: 951-175-023-EN Version: Read this manual before installing or commissioning the product and keep it at hand for later reference!
-
Page 2: Table Of Contents
We conduct detailed training in order to enable maximum safety English and efficiency. We recommend taking advantage of this training. Tel: +358 20 7400 800 For further information, contact your authorized SKF dealer or E-mail: skf-lube@skf.com the manufacturer. www.skf.com/lubrication Table of contents Masthead .................. -
Page 3: Safety Alerts
Safety alerts While reading these instructions, you will encounter various symbols, illustrations, and text layouts intended to help you navigate and understand the instructions. Their meaning is explained below. Safety alerts: Activities that present specific hazards (to life and limb or possible damage to property) are indicated by safety alerts. -
Page 4: Safety Instructions
Only 2.3 Avoidance of faults and hazards original SKF spare parts and SKF accessories may be used. • Any unclear points regarding proper condition or correct To avoid faults and hazards, please observe the following: assembly/operation must be clarified. -
Page 5: Description & Design
25 cm³ per stroke and operates at are available for most SKF grease pumps. The filling filter pressures of up to 60 bar. Two versions of the MFP are availa- features a compatible 2500 series male connector with an ble, each tailored for different NLGI grades of lubricants. -
Page 6: Operating Instructions
4. Operating instructions 4.2 Lube-Shuttle® cartridge filling 4.1 Reservoir filling Fig. 3 < NOTICE Contaminant will cause severe wear and ultimately failure of the pump. Prevent that the piston rod is (temporarily) placed on a dirty surface at any time. Fig. -
Page 7: Technical Data, Dimensions & Order Codes
Pos: 3 19 /Ge neral content/_H eadline s/"Column wide" hea dlines (50% + 50% )/1 /1 Techni cal data @ 1 \ mod_15 50128 7317 35_42 70.docx @ 45 140 @ 2 @ 1 4 Technical data, dimensions & order codes 4.1 Technical data Table 1 Technical data... -
Page 8: Dimensions
Manual filling pump for NLGI 000-0 fluid grease 11600340 SKF REFILL PUMP 18 NLG-2 Manual filling pump for NLGI-2 grease incl. follower plate 11770464 FILLING ADAPTER LS Lube-Shuttle cartridge filling adapter for MFP pump 4.4 Accessories Table 3 Order number Description 11650850... -
Page 9: Delivery, Returns, Storage, Disposal
5 Delivery, returns, storage, disposal 5.1 Delivery After receipt of the shipment, it must be inspected for any shipping damage and for completeness according to the shipping documents. Immediately inform the transport carrier of any shipping damage. The packaging material must be preserved until any discrepancies are resolved. -
Page 10: Assembly & Spareparts
Pos. Description Order number PUMP UNIT 11600325 HANDLE OF REFILL PUMP 18 11600334 MFP LID ASSEMBLY 11600335 MFP LID NUT ASSEMBLY 11600336 HOSE ASSEMBLY 11600360 ACCESSORY KIT FILLING DEVICE 11600333 FOLLOWER PLATE (INCLUDED IN 11600340 PUMP) 11600327 QUICK COUPLING 11650650... - Page 11 ® SKF and Lincoln are registered trademarks of the SKF Group. ™ eLube is a trademark of the SKF Group. © SKF Group 2025 Reprint or reproduction of the contents of this information - even in part - is permitted only with SKF's prior written consent.
