The PROINDMV-EU is a battery powered, wireless indoor motion detector with a built-in video camera and is designed for use
with Control Panels that support SiX™ series devices. The detector is powered by three 3-volt, Lithium batteries that provide up
to 4 years of battery life.
Note: Installation shall be performed in accordance with local regulations.
FEATURES
• No wiring or remote power required. Fully portable battery powered camera allows for
flexibility in selecting locations.
• Provides video on-demand viewing functionality.
• Spread Spectrum, Interactive, AES encrypted wireless technology provides optimum signal
integrity and security.
• CMOS camera sensor with a wide angle 90° lens (horizontal field of view).
• Embedded illuminator for night vision (white light).
• PIR sensor and Fresnel lens for motion detection (12m and 90° detection pattern).
Camera sends color video.
ENROLLING
You must enroll the detector in the Control panel. Set the
Control panel in the Programming Mode, and when
prompted:
Note: For detailed programming instructions, refer to the
Installation Instructions for the Control Panel with which
this device is used.
1.
From AlarmNet 360:
• Select "SENSORS"
• Select "ADD SENSOR"
• Select "LEARN" and wait for the Control Panel to be
in learning mode.
2.
When prompted, perform one of the following:
• Carefully remove (and discard responsibly) the
battery tab [A].
• If powered, open and close the cover again [B].
The LED flashes rapidly at power up.
3.
Note: After enrolling, verify adequate signal strength by conducting a sensor test with the device installed in its intended mounting
location (see the Control Panel instructions). Adjust the device mounting location and orientation as necessary to achieve
maximum signal strength.
INSTALLATION GUIDELINES
Programming and RF testing should be done while the device is in its intended mounting location to ensure good communication
between the Control Panel and the device.
Mounting Considerations:
Mount indoors in a temperature-controlled
environment.
Mounting height should be 2.1 – 2.7 m, with an
optimal range height of 2.3 m.
Allow a clear line-of-sight to all areas to protect.
Do not aim detector at windows, especially those in
direct sunlight, or at heat sources (fireplaces,
radiators, and heating vents, etc.).
Avoid mounting in areas with high humidity (such
as garages) to minimize the risk of false alarms.
Do not aim detector at moving objects such as
fans.
Do not paint or cover the detection or camera lens.
For use in applications with pets up to 36 kg (with
PIR "Low Sensitivity" setting selected from the
Control Panel).
Installation and Setup Instructions
PROINDMV-EU
Indoor Motion Viewer

Advertisement

loading
Need help?

Need help?

Do you have a question about the Pro Indoor Motion Viewer and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for resideo Pro Indoor Motion Viewer

  • Page 1 PROINDMV-EU Indoor Motion Viewer Installation and Setup Instructions The PROINDMV-EU is a battery powered, wireless indoor motion detector with a built-in video camera and is designed for use with Control Panels that support SiX™ series devices. The detector is powered by three 3-volt, Lithium batteries that provide up to 4 years of battery life.
  • Page 2 MOUNTING Press the latch on the bottom of the detector. Separate the front housing from the rear mounting plate. Secure the rear mounting plate at the desired location with two screws. (See the Mounting Options section. Note: Rear mounting plate must be mounted on a stud, solid wall, or with a robust wall anchor. Slide the front housing onto the rear mounting plate.
  • Page 3 BATTERY REPLACEMENT The detector is powered by three Lithium batteries. To maximize battery efficiency, it is important to remove all of the old batteries, wait approximately 10 seconds, and then install new batteries. Note: See the Specifications section for recommended replacement batteries.
  • Page 4 WARRANTY Sécurité Communications SAS (SECOM) Ademco 1 Ltd., 200 Berkshire Place 1198, Avenue du Docteur Maurice Donat Winnersh Triangle, Berkshire, RG41 5RD – UNITED KINGDOM 06250 Mougins - FRANCE PROINDMV-EU © 2023 Resideo Technologies, Inc. www.resideo.com R800-26481C 10/21 Rev C...
