Assa Abloy NORTON RIXSON 1600 Series Installation Instructions

1600 Series Cushion Stop Non-Handed Door Closer
Arm Models CA1601, CA1603BC, and CA1604BC
Installation Instructions
Non-hold Open models, adjustable size 1-6 (CA1601 model
size 3 & 4 (CA1603BC and CA1604BC models).
WARNING
This product can expose you to lead which is known to the
state of California to cause cancer and birth defects or other
reproductive harm.
For more information go to: www.P65warnings.ca.gov.
Regular Mount
Right Hand Door - RH
Left Hand Reverse - LHR
Included Components
Closer
Screw Pack
(Refer to page 2 for a
Pinion Cap
list of contents)
To Determine Your Hand of Door:
Right Hand
Reverse
LEFT
HAND
DOOR
Copyright © 2019, 2020, 2022, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9316-2538-020 Rev 7 02/23
Left Hand Door - LH
Right Hand Reverse - RHR
Main Arm
Pinion Screw
Main Arm
To Identify Your Model:
Left Hand
Reverse
RIGHT
HAND
DOOR
Size
Code
Approved 2023-02-23
) and
READ AND FOLLOW ALL INSTRUCTIONS.
SAVE THESE INSTRUCTIONS.
Left Hand Door - LH
Right Hand Reverse - RHR
3/16"
Adjusting Tube
Hex
and Shoe
Forearm Screw
3/16"
Hex
Cushion
Stop Kit
Tools Needed:
Spring Power
Adjustment
(1601 ONLY)
1-6 = 1601 Date
3 = 1603BC Code
4 = 1604BC
Top Jamb Mount
0" to 3" (76mm) Reveal
Right Hand Door - RH
Left Hand Reverse - LHR
Optional Components
Stud
Cushion
Screw 1600P
Cover
6-32 x 5/16" Pan Head
Self Tapping Screw
