Assa Abloy NORTON RIXSON 93 Installation Instructions Manual

Model 93 Overhead Concealed Closer
Non-Hold Open and Hold Open
Metal Frame Installation Instructions
WARNING
This product can expose you to lead which is known to the
state of California to cause cancer and birth defects or other
reproductive harm. For more information go to:
www.P65warnings.ca.gov.
Model 93, (Left Hand Shown)
Center Pivot Hung
Components
(Supplied fasteners shown on page 3)
LH: 90236-(finish)
RH: 90237-(finish)
Pivot Kit
70224KIT- (finish)
Tools Needed
Phillips Flathead
Screwdriver Screwdriver
Copyright © 2021, 2023, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
IS93 Rev 2 08/23
Arm
Closer Body
93 LAP or
PH93 LAP (ADA)
AND
1/4-20
#7
5/16" 3/8"
Hex
Drill
for Metal
Wrenches
Approved 2024-02-02
READ AND FOLLOW ALL INSTRUCTIONS.
SAVE THESE INSTRUCTIONS.
Cover Plate
LH: 90272-(finish)
RH: 90275-(finish)
Retrofit Track Spacer and
Screws, Optional (90260)
Not for new installation.
Replacement only. Consult factory.
Framing
Level
3/16"
Hammer Drill Plumb Bob
for Wood
Track
(90239)
Optional Hold Open
Assembly (90254)
Slider Non-Hold Open Stop
(90253)
Tape
Measure
Square
Grout
Spreader
Tool
Block (90255)
Pencil
Hammer
