- Page 1 OPERATION MANUAL MAGNETIC FIELD METER MP-4000 Firmware Version 740 and up 2025-03 NDT Supply.com, Inc. 7952 Nieman Road Lenexa, KS 66214-1560 USA Phone: (913)-685-0675 Email: sales@ndtsupply.com...
-
Page 2: Table Of Contents
Lima Connect for Windows .....................26 Lima Connect for Android and iOS ..................26 SCPI Communication Interface ........28 Checking with Calibration Standard ......29 Important Instructions ..........30 Preserve stored Measurements when changing the battery ............30 Changing the probe .......................30 List-Magnetik GmbH EN MP-4000 2025-03.doc... -
Page 3: Introduction
Alternating field waveforms up to 20 kHz frequency can also be displayed and stored. The pulse curves generated in this way can be displayed and stored in the MP-4000 as a graph, providing an accurate picture of the pulse curve of a magnetic field. -
Page 4: Warnings And Hazards
ARNINGS AND AZARDS List-Magnetik expressly states that the magnetic field meter MP-4000 may only be used for its intended purpose: the measurement of magnetic fields. Any use not in accordance with the intended purpose is not permitted and involves incalculable risks for the instrument and the operator. -
Page 5: Quick Start Guide
UIDE • First connect the probe cable to the probe and the instrument. • Turn on the MP-4000 with the red power button. • The probe will be recognized by the instrument and the model will be automatically displayed in the upper left corner of the status bar. -
Page 6: Display Structure
In the center is the measurement display with the current measurement and addi- tional information about it. Depending on the current display, there are symbols in the action area that trigger appropriate processing and special functions. List-Magnetik GmbH EN MP-4000 2025-03.doc... -
Page 7: Navigation
This section allows you to set the language, unit of measure, and other measurement and display parameters, as well as power management settings. Info and System Turn off the unit, view hardware and software status, or perform a factory reset. List-Magnetik GmbH EN MP-4000 2025-03.doc... -
Page 8: Measurement
The color of the reading is black. If limit values are set, the measured value is displayed in blue if it is below the lower limit value and in red if it is above the upper limit value. List-Magnetik GmbH EN MP-4000 2025-03.doc... - Page 9 If you have activated a memory batch, the statistics for this memory batch will be displayed in the area above the reading instead of the logo. Actions Overview of the action area in the measurement display. List-Magnetik GmbH EN MP-4000 2025-03.doc...
- Page 10 After resetting, the peak value is determined again in ascending order from 0. To activate a memory batch, switch to data log management with this icon "Folder". From the moment of activation, measurements can be stored List-Magnetik GmbH EN MP-4000 2025-03.doc...
- Page 11 Range 2 also above 3,000 A/cm). Special Function Scan Measurement SCAN See separate chapter " Special Measurement Methods ". The jump to the scan measurement is only possible if the peak value measurement / PEAK is switched off. List-Magnetik GmbH EN MP-4000 2025-03.doc...
-
Page 12: Memory Management
"M". A maximum of 10,000 measurements can be stored in the M memory batches. If you have not created or activated a memory batch, the floppy disk icon will not be visible during the measurement. List-Magnetik GmbH EN MP-4000 2025-03.doc... - Page 13 The additional text entered will be displayed. You can view the individual values by clicking on the navigation icon of the data log. Select a memory batch for immediate use Delete the currently displayed memory batch List-Magnetik GmbH EN MP-4000 2025-03.doc...
-
Page 14: Special Measurement Methods
The trigger measurement processes pulse field measurements at an enormous speed of less than 0.1 msec. The measured values generated in this way can be displayed in the MP-4000 as a graph and give an accurate picture of the pulse progression of a magnetic field. - Page 15 You can enter a short text that will be displayed later when scrolling below the statistics. You can create as many trigger batches as you like. The batches are given a unique free number and a prefixed "T". List-Magnetik GmbH EN MP-4000 2025-03.doc...
-
Page 16: Scan
During the scan measurement, the current measured value and the trigger value are also displayed. If you want to scan the curve of an AC field, switch the MP-4000 to DC measurement mode, not AC. With AC you will always get the RMS value. - Page 17 Browse through the saved scans. The statistics, short text, and graphical progress curve are displayed Delete the currently displayed scan For scan measurements of multipole rotors, we recommend the additionally available ROTOR-CHECK RC-300 measuring system. List-Magnetik GmbH EN MP-4000 2025-03.doc...
-
Page 18: Data Log
The trash can icon deletes the entire series of measurements. The memory batch remains active, however, so that further measurements will be written to this memory batch. If an individual reading is inactive, it can be permanently deleted by clicking the scissors icon. List-Magnetik GmbH EN MP-4000 2025-03.doc... -
Page 19: Setup
You can set the automatic shutdown time: 5 minutes, 10 minutes, 30 minutes or "never off" if you do not want the device to turn off automatically. The power save mode switches the brightness back to 10% after 1 minute. List-Magnetik GmbH EN MP-4000 2025-03.doc... -
Page 20: Probe Settings
As long as you are in peak or trigger measurement, selecting the range is not possible. Normally, MP-4000 works in auto-range mode, which automatically switches between the two measuring ranges 1 (below 3,000 A/cm) and 2 (above 3,000 A/cm). -
Page 21: Mode (Selection Dc-Ac)
(set as "Level" in the trigger area) is exceeded. The time selection (80 msec, 320 msec, 1.30 s) determines how long the trigger measurement measures the pulse. The longer you record the pulse, the longer it takes to prepare the waveform. List-Magnetik GmbH EN MP-4000 2025-03.doc... -
Page 22: Limits
Upper limit value exceeded: measured value red Falling below the lower limit: measured value blue The color change occurs both in the measurement display and in the data log. List-Magnetik GmbH EN MP-4000 2025-03.doc... -
Page 23: Info And System
TIME Date and time can be set manually or via the PC application Lima Connect. When setting manually, please note the notation xxxx-xx-xx (with hyphens) for the date and xx:xx:xx (with colons) for the time. List-Magnetik GmbH EN MP-4000 2025-03.doc... -
Page 24: Delete Memory
Battery voltage must be above 2.8V. Below 2.8V, the unit will automatically shut down. ROBE Probe and device are independently configured. The probe can be plugged into another MP-4000. The probe data includes the serial number and firmware version of the probe and the configuration. List-Magnetik GmbH EN MP-4000 2025-03.doc... -
Page 25: Technical Data
3x 1.5 V AA Mignon. External power supply can be connected via USB approx. 25 hours with battery, Operating time: unlimited with external power supply Dimensions: 150 x 85 x 35 mm Weight: 320 g with batteries List-Magnetik GmbH EN MP-4000 2025-03.doc... -
Page 26: Measuring Probes
Total length of the probe: 127 mm Length of the probe handle: 65 mm Length of the probe reed: 62 mm (in 90° direction when using the angle piece 56 mm) Width of the probe reed: 4.3 mm List-Magnetik GmbH EN MP-4000 2025-03.doc... -
Page 27: Applications For Windows, Android, Ios
Lima Connect for Android and iOS. Exclusively in these two mobile versions you can manage projects and assign the measuring points on a photo. The measurement results can be statistically evaluated and displayed graphically. The app for Android and iOS is also free. List-Magnetik GmbH EN MP-4000 2025-03.doc... - Page 28 Android List-Magnetik GmbH EN MP-4000 2025-03.doc...
-
Page 29: Scpi Communication Interface
The SCPI Demo installation package contains: a runtime environment for LabView, a sample application (EXE) for each of the three devices MP-4000, FerroPro compact and MEGA- CHECK DX as well as the sources (SRC) for these three applications. To be able to read and edit the sources, however, a license for LabView is required, which is not included. -
Page 30: Checking With Calibration Standard
If the value is within tolerance, the instrument and probe are working properly. If there is a discrepancy, the entire package of instrument, probe, and calibration standard should be returned to the manufacturer for inspection and recalibration. List-Magnetik GmbH EN MP-4000 2025-03.doc... -
Page 31: Important Instructions
HANGING THE PROBE To replace the measuring probe, switch off the device beforehand. Connect the desired measuring probe to the probe cable, then switch the device on again. List-Magnetik GmbH EN MP-4000 2025-03.doc... - Page 32 • Devices for Materials Testing (Permeability and Ferrite content) We provide expert advice and design metrology solutions tailored to your specific needs. Fast calibration and repair service NDT Supply.com, Inc. 7952 Nieman Road Lenexa, KS 66214-1560 USA Phone: (913)-685-0675 Email: sales@ndtsupply.com...
