This assembly manual contains important safety informa on. Please read and keep for future reference.
Useful Hints Before You Start
1. Read each step carefully before star
2. Before beginning assembly, iden fy, sort and count the parts before assembly.
3. Using the wrong screw will cause damage.
4. Using incompa
e hardware might cause damage to product.
5. It is important that each step is performed in correct order to avoid di
6. Assemble your furniture on packaging cardboard to prevent scratch or damage.
7. Do not ghten any screws or bolt un the unit is completely assembled.
8. Keep all hardware parts out of reach of children.
Necessary Tools
Phillips
Screwdriver
OR
g.
Flat Head
Screwdriver
Distributed exclusively by COE Distribu ng!
Tel: 800-388-8202 (Mon-Fri | 9am – 5pm EST.)
Model No.:
Description:
CAUTION – Risk of product damage!
Hammer
Power Drill can be used on lowest
torque se ng.
Customer Service
o cesourcefurniture.com
OSBTR30/OSBTR36/OSBTR48/
OSBTR60/OSBTR66/OSBTC30L/
OSBTC30R/OSBTC36L/
OSBTC36R/OSBTC66L/ OSBTC66R
Transac�on Top
es.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for OfficeSource OSBTR30
Summary of Contents for OfficeSource OSBTR30
- Page 1 Customer Service Tel: 800-388-8202 (Mon-Fri | 9am – 5pm EST.) o cesourcefurniture.com This assembly manual contains important safety informa on. Please read and keep for future reference. Model No.: OSBTR30/OSBTR36/OSBTR48/ OSBTR60/OSBTR66/OSBTC30L/ OSBTC30R/OSBTC36L/ OSBTC36R/OSBTC66L/ OSBTC66R Description: Transac�on Top Useful Hints Before You Start 1.
- Page 2 Locknut x 1 1” Screw x 4 Template x 1 PAN EL PARTS KIT TR AN SACTION TOP PARTS KIT (Not recommended for use on 24” posts) OSBTR30 OSBTR36 OSBTR48 OSBTC30L OSBTR60 OSBTC30R Regular Panel x 1 Filler Panel x 1...
- Page 3 STEP 1. ATTACH MOUNTING PLATE Fold sides of template downward and position template tight against work surface corner. Expose double sided tape and position mounting plate inside the template opening. Remove the template and install the short 1” screw into one of the inside holes.
- Page 4 STEP 2. MOUNT DIVIDER POST Place divider post over mounting plate. Screw threaded rod through divider post and into mounting plate. Place washer then nut on rod and finger tighten only. STEP 3. SLIDE PANELS INTO PLACE Insert a 3/4” screw into threaded hole in each corner of the panel.
- Page 5 STEP 5. STACKING ON PANELS Note: When using 2 stacked 12” panels, 24” high posts must be used. Attach first level of panels as described in Step 3. Insert 2nd level of panels between 24” high posts in same fashion. Tighten locking nut on the threaded rod and place caps on top of divider post.
