Digitized Automation for a Changing World

AX-5 Series Module Manual

www.deltaww.com

Advertisement

Need help?

Need help?

Do you have a question about the AX-5 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Delta AX-5 Series

Page 1 Digitized Automation for a Changing World AX-5 Series Module Manual www.deltaww.com...
Page 2 AX-5 Series Module Manual Revision History Ve r s i o n R e v i s i o n D a t e T h e f i r s t v e r s i o n w a s p u b l i s h e d .
Page 3 AX-5 Series Module Manual Table of Contents Chapter 1 Product Introduction Overview ................... 1-2 1.1.1 Table of Models and Descriptions ............1-2 Technical Specifications ..............1-3 1.2.1 Certifications and Standards ............1-3 1.2.2 Electromagnetic Compatibility ............1-3 1.2.3 Transport and Storage ..............1-4 1.2.4...
Page 4 Chapter 3 Power Supply Modules and Connector Modules AX-502PS11-0A ................. 3-2 3.1.1 Specifications ................3-2 3.1.2 Dimensions and Parts ..............3-2 3.1.3 Arrangement of Terminals, LED Indicators and Wiring ..... 3-4 3.1.4 Settings in DIADesigner-AX ............3-7 3.1.5 Process Data ................3-11 3.1.6 Troubleshooting .................
Page 5 4.1.4 Settings in DIADesigner-AX............4-8 4.1.5 Parameter Descriptions ............. 4-16 4.1.6 EtherCAT Operation Modes ............4-20 4.1.7 Process Data ................4-21 4.1.8 Troubleshooting ................ 4-23 AX-516AM20-0A ................4-24 4.2.1 Specifications ................4-24 4.2.2 Dimensions and Parts ..............4-25 4.2.3 Arrangement of Terminals, LED Indicators and Wiring ....4-26 4.2.4 Settings in DIADesigner-AX............
Page 6 4.5.4 Settings in DIADesigner-AX ............4-88 4.5.5 Parameter Descriptions .............. 4-96 4.5.6 EtherCAT Operation Modes ............4-100 4.5.7 Process Data ................4-101 4.5.8 Troubleshooting ............... 4-102 AX-516AP22-0A ................4-103 4.6.1 Specifications ................4-103 4.6.2 Dimensions and Parts ............... 4-104 4.6.3 Arrangement of Terminals, LED Indicators and Wiring ....
Page 7 AX-508AD10-0A ................5-58 5.3.1 Specifications ................5-58 5.3.2 Dimensions and Parts ..............5-59 5.3.3 Arrangement of Terminals, LED Indicators and Wiring ....... 5-61 5.3.4 Settings in DIADesigner-AX ............5-64 5.3.5 Parameter Descriptions ..............5-73 5.3.6 EtherCAT Operation Modes ............5-84 5.3.7 Process Data ................
Page 8 AX-508DA01-0A ................5-168 5.7.1 Specifications ................5-168 5.7.2 Dimensions and Parts ..............5-169 5.7.3 Arrangement of Terminals, LED Indicators and Wiring...... 5-171 5.7.4 Settings in DIADesigner-AX ............5-174 5.7.5 Parameter Descriptions ..............5-183 5.7.6 EtherCAT Operation Modes ............5-193 5.7.7 Process Data ................5-194 5.7.8 Troubleshooting ................
Page 9 5.11 AX-504PT10-0B ................5-273 5.11.1 Specifications ................5-273 5.11.2 Dimensions and Parts ............... 5-274 5.11.3 Arrangement of Terminals, LED Indicators and Wiring ....5-276 5.11.4 Settings in DIADesigner-AX ............5-279 5.11.5 Parameter Descriptions ............. 5-288 5.11.6 EtherCAT Operation Modes ............5-296 5.11.7 Process Data ................
Page 10 Chapter 7 Load Cell Modules 7.1 AX-501LC10-0A ................. 7-3 7.1.1 Specifications ................7-3 7.1.2 Dimensions and Parts ..............7-4 7.1.3 Arrangement of Terminals, LED Indicators and Wiring ...... 7-5 7.1.4 Settings in DIADesigner-AX ............7-9 7.1.5 Parameter Descriptions ............... 7-17 7.1.6 Gross Weight, Net Weight and Tare Weight ........
Page 11 Caution This is an OPEN TYPE module and therefore should be installed in an enclosure free of airborne  dust, humidity, electric shock and vibration. The enclosure should prevent non-maintenance staff from operating the device (e.g. key or specific tools are required for operating the enclosure) in case danger and damage on the device may occur.
Page 12 Product Introduction Table of Contents Overview ....................1-2 Technical Specifications ................. 1-3 Hardware Installation ................1-6 Software Installation ................1-20 1 - 1...
Page 13 AX-5 Ser i es M od ul e M an ua l Overview This manual introduces the AX-5 series modules including their functions, electrical specifications, troubleshooting, as well as appearances, dimensions, and so forth. Table of Models and Descriptions Classification...
Page 14 Technical Specifications In this section, you can find applicable technical specifications, compliances, and certifications for AX-5 series products. Certifications and Standards AX-5 series products have obtained the following certificate of compliances and met the safety, health, environment, and other requirements. Certification...
Page 15 0.5 to 30 MHz: < 73 dB (μV) quasi-peak < 60 dB (μV) average Transport and Storage The original packaging of AX-5 series is in compliant with IEC (EN) 61131-2 standard, in terms of transport and storage. The conditions and specifications are listed in the table below. Condition...
Page 16 Ch ap te r 1 Prod uc ti on In tr od ucti on Protection Class The following table shows the information related to protection class for AX-5 series modules. Type Description Designed in accordance with IEC/EN 61131-2, IEC/EN 61010-1 and Insulation IEC/EN 61010-2-201.
Page 17 AX-5 Ser i es M od ul e M an ua l Hardware Installation Installing Modules Steps for installing modules are shown below: Push the two DIN rail clips on the top and bottom of the CPU or coupler towards the middle as shown by the arrows ...
Page 18 Ch ap te r 1 Prod uc ti on In tr od ucti on Please first align the upper and lower guides before pushing the module towards the rail when installing an I/O module. Install the protective cover at the end position, just like installing a module, by aligning the cover and then pushing it towards the rail.
Page 19 If there is a vibration source on the installation site, installing anti-vibration baffles on both the leftmost and rightmost sides of the AX-5 series modules is recommended to stabilize all modules. See the gray baffles on the two sides in the following figure.
Page 20 Ch ap te r 1 Prod uc ti on In tr od ucti on Install the baffles: Hook the baffle onto the DIN rail and press it down as the directional arrow shows below. 2. Use a screwdriver to tighten the screw of the baffle after the baffle is clipped up on the rail. 1 - 9...
Page 21 AX-5 Ser i es M od ul e M an ua l The completed baffle installation is as shown below. 1 - 1 0...
Page 22 Ch ap te r 1 Prod uc ti on In tr od ucti on Installing and Removing a Terminal Block Installation Hook the terminal block onto the guide at the bottom of the module, and press it up into the module. Removal Press down the clip at the top of the removable terminal block and move it outward.
Page 23 AX-5 Ser i es M od ul e M an ua l Keeping the cable secured into a terminal hole of the terminal block: Press down the part ① above a terminal hole with a screwdriver, and then insert a suitable cable into the hole ②...
Page 24 Ch ap te r 1 Prod uc ti on In tr od ucti on Note 2: Operation of screwdriver: Correct operation  Incorrect operation  1 - 1 3...
Page 25 AX-5 Ser i es M od ul e M an ua l After wiring terminal blocks is completed, you can organize the cables by fastening them with a plastic cable tie through the cable tie hole below each terminal block. Note: Specifications of cable tie 1 - 1 4...
Page 26 Ch ap te r 1 Prod uc ti on In tr od ucti on Replacing a Module Remove the terminal block from a module, and then pull out the upper and lower clips of the module as shown below. Remove the module. 1 - 1 5...
Page 27 AX-5 Ser i es M od ul e M an ua l Slide a new module in as shown below. Precautions 1.3.4.1 General Notes EN: System assemblers should take the responsibility for the system security of installed and assembled  equipment.
Page 28 Ch ap te r 1 Prod uc ti on In tr od ucti on EN: For the installation inside the control box, keep at least 10cm space around the product to ensure sufficient  air convection. Otherwise, it may cause the product overheating and failure. FR: Pour l’installation à...
Page 29 Connecting the power cable and the ground Connect the power cable for PLC system and the ground as described below. In AX-5 series modules, the coupler module (See Chapter 2 in this manual.) and some power modules (See  Chapter 3 in this manual.) are equipped with terminals for grounding.
Page 30 Ch ap te r 1 Prod uc ti on In tr od ucti on 1.3.4.3 Signal Cable, Communication Cable and Shielded Cable I/O signal cables for digital modules Supports a cable length of up to 100 m with the impedance less than 2 ohms. ...
Page 31 DIAStudio for DIAInstaller. To enter the download page of Delta official website, you need to sign in first. Please apply for a user account if you log in for the first time. After login, click DIAStudio download icon to download DIAStudio for installation as shown below.
Page 32 Ch ap te r 1 Prod uc ti on In tr od ucti on Follow the steps below to install DIADesigner-AX after the above installation is finished. Open DIAInstaller to see the latest version of DIADesigner-AX. Click Download to download the setup file of DIADesigner-AX. After DIADesigner-AX is downloaded, click Install to install the software.
Page 33 AX-5 Ser i es M od ul e M an ua l An InstallShied Wizard shows up and installing starts. Click Next. The window of License Agreement shows up. Select “I accept the terms in the license agreement” option and then click Next.
Page 34 Ch ap te r 1 Prod uc ti on In tr od ucti on After that, the Very important information page comes up. Select “I have read the information” option and then click Next. Next comes the Destination Folder page. If you leave the default path unchanged, click Next. 1 - 2 3...
Page 35 AX-5 Ser i es M od ul e M an ua l Or click Change… to change the path to destination folder. The window of Setup Type shows up as shown below. Select a setup type you need and then click Next. 1 - 2 4...
Page 36 Ch ap te r 1 Prod uc ti on In tr od ucti on The window of Ready to Install the Program appears as below and then click Install. It may take some time to have the installation done. 1 - 2 5...
Page 37 AX-5 Ser i es M od ul e M an ua l After installation, the window of InstallShield Wizard Completed appears. Click Finish to complete the installation. 1.4.1.2 Uninstalling DIADesigner-AX Follow the steps below to uninstall DIADesigner-AX. Open DIAInstaller, and then click Uninstall icon of DIADesigner-AX to remove the software. The system executes the removal of DIADesigner-AX from your computer in the background.
Page 38 Ch ap te r 1 Prod uc ti on In tr od ucti on MEMO 1 - 2 7...
Page 39 Chapter 2 Coupler Table of Contents AX-500CEC00-0A ................... 2-2 AX-500CPN00-0A ................. 2-12 2 - 1...
Page 40 AX-5 Ser i es M od ul e M an ua l 2.1 AX-500CEC00-0A AX500CEC00-0A is an EtherCAT coupler. This section introduces its specifications, operations, and wirings. 2.1.1 Specification Item Specification One spring-clamp terminal block (16 terminals) External connectors Two RJ45 IN: EtherCAT input port;...
Page 41 Ch ap te r 2 Cou pl er 2.1.2 Dimensions and Parts Dimensions  50.5 Unit：mm Parts  Name DIN rail clip Model number and model description Wiring EtherCAT communication port System status indicator Spring to hold the connection Spring-clamp terminal block Model code AX connector (R) Label (manufacturer information, service information, safety, serial number, firmware/hardware...
Page 42 AX-5 Ser i es M od ul e M an ua l 2.1.3 Arrangement of Terminals, LED Indicators and Wiring 2.1.3.1 Arrangement of Terminals System LED Power LED LV LED DC24V DC24V Pin No. Symbol Description Pin No. Symbol Description Module unit power input: DC 24 V Module unit power input: DC 0 V Module unit power input: DC 24 V...
Page 43 Ch ap te r 2 Cou pl er 2.1.3.2 LED Indicators Name Color Status Description ECAT INIT Blinking (0.2s) ECAT Pre OP System Blue Blinking(1s) ECAT Safe OP Normal (OP) No under-voltage warning Under-voltage warning Not supplied with power Power Blue Power on 2.1.3.3 Wiring and Loop Configuration...
Page 44 AX-5 Ser i es M od ul e M an ua l DC/DC 24 VDC 24 VDC Unit Power AX Connector Power This product shall be powered by a certified SELV/PELV power supply unit with operating temperature  of minimum 60 °C, which meets the requirements of IEC 61010-1:2010 or latest edition. With the SELV/PELV power supply connected to 24V/0V terminals of the removable terminal block, the ...
Page 45 Ch ap te r 2 Cou pl er 2.1.4 Settings in DIADesigner-AX This section introduces some basic operations and settings in the DIADesigner-AX software. 2.1.4.1 Basic Operation Double-click the DIADesigner-AX icon to open the software and create a new project. Add Modules in Method 1: Add the modules in manually.
Page 46 AX-5 Ser i es M od ul e M an ua l Right-click System Coupler you added, and then click Add Device… again to select and add modules in. 2 - 8...
Page 47 Ch ap te r 2 Cou pl er Method 2: Scan to add the modules in.  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Scan for Devices…. After the auto-scan is over, the actually connected devices will appear. Click Copy All Devices to Project button to add them to the list under EtherCAT Master SoftMotion.
Page 48 AX-5 Ser i es M od ul e M an ua l 2.1.4.2 Process Data In the Process Data tab, select the desired outputs and inputs. Click on the toolbar to go into online mode. In the EtherCAT I/O Mapping tab, you can find the variables, status, and error codes for each channel.
Page 49 Ch ap te r 2 Cou pl er 2.1.4.4 Information In the Information tab, you can find the module information, including Name, Vendor, Categories, Type, ID, Version, Order Number and Description for the coupler. 2.1.5 EtherCAT Operation Modes There are two modes for EtherCAT modules to run during operation, FreeRun mode (non-synchronization mode) and DC mode (synchronization mode).
Page 50 AX-5 Ser i es M od ul e M an ua l 2.2 AX-500CPN00-0A AX500CEC00-0A is a PROFINET coupler. This section introduces its specifications, operations, and wirings. 2.2.1 Specification Specification Item One spring-clamp terminal block (16 terminals) External connectors RJ45 x 2 IN: PROFINET input port / OUT: PROFINET output port Dimension(mm) 61 (W) ×...
Page 51 Ch ap te r 2 Cou pl er 2.2.2 Dimensions and Parts Dimensions  Unit: mm Parts  ⑤ ② ⑥ ⑨ ① ③ ⑩ ⑦ ④ ⑧ ⑪ Name DIN rail clip Model number and model description Wiring PROFINET communication port System status indicator Spring to hold the connection Spring-clamp terminal block...
Page 52 AX-5 Ser i es M od ul e M an ua l 2.2.3 Arrangement of Terminals, LED Indicators and Wiring 2.2.3.1 Arrangement of Terminals Power LED RUN LED LV LED DC24V DC24V Pin No. Symbol Description Pin No. Symbol Description Module unit power input: 24 VDC Module unit power input: 0 VDC Module unit power input: 24 VDC...
Page 53 Ch ap te r 2 Cou pl er 2.2.3.2 LED Indicators Color Status Description Name PLC CPU STOP Green Blinking (0.5s) During the boot-up process PLC CPU RUN I/O module communication is working normally Error codes occurred in I/O modules BUS FAULT No response from I/O module Blinking (0.5s)
Page 54 AX-5 Ser i es M od ul e M an ua l 2.2.3.3 Wiring and Loop Configuration Wiring  AX-500CPN00-0A 24 VDC 24 VDC 2 - 1 6...
Page 55 Ch ap te r 2 Cou pl er DC/DC 24 VDC 24 VDC Unit Power Connector(R) Power This product shall be powered by a certified SELV/PELV power supply unit with operating temperature  of minimum 60 °C, which meets the requirements of IEC 61010-1:2010 or latest edition. With the SELV/PELV power supply connected to 24V/0V terminals of the removable terminal block, the ...
Page 56 AX-5 Ser i es M od ul e M an ua l 2.2.4 Settings in DIADesigner-AX This section introduces some basic operations and settings in the DIADesigner-AX software. 2.2.4.1 DIADesigner-AX 2.2.4.1.1 Scan for Devices Double-click the DIADesigner-AX icon to open the software and create a new project. Scan to add the modules in.
Page 57 Ch ap te r 2 Cou pl er Once the scanning is complete, the actual system design will be generated as depicted in the figure below. Simply click the Copy to project button to add the device under PN Controller. The system design is as below: On the right-side of AX-500CPN00-0A, the following modules are connected, AX-516AP22-0A (Input Data: 2 bytes;...
Page 58 AX-5 Ser i es M od ul e M an ua l Configure the values under General Tab for AX-508AD10-0A and AX-508DA01-0A. The following example uses 0 V to +10 V. After settings are complete, click on the toolbar to enter the online mode. You can find the values for each channel under the tab of PNIO Module I/O Mapping.
Page 59 Ch ap te r 2 Cou pl er 2.2.4.1.2 Add Modules in Manually Double-click the DIADesigner-AX icon to open the software and create a new project. Right-click Ethernet in the Devices tree, and then click Add Device… -> Profinet IO -> Profinet IO Master to add PN Coupler.
Page 60 AX-5 Ser i es M od ul e M an ua l Find PN Controller in the Devices tree. Right-click it and select Add Device… to add Profinet Coupler (AX- 500CPN). 2 - 2 2...
Page 61 Ch ap te r 2 Cou pl er (4) Right-click the added Profinet Coupler (AX-500CPN) and click Add Device…. 2 - 2 3...
Page 62 AX-5 Ser i es M od ul e M an ua l Before adding the devices in manually, make sure that the domain of the IP address in the IP Parameter (under the  General tab of Profinet Coupler) and the domain of the network interface are the same. Settings for Profinet Controller: ...
Page 63 Ch ap te r 2 Cou pl er (1) The system design is as below: On the right-side of AX-500CPN00-0A, the following modules are connected, AX-516AP22-0A (Input Data: 2 bytes; Output Data: 1 byte), AX-508AD10-0A (Input Data: 34 bytes) and AX-508DA01-0A (Input Data: 1 byte; Output Data: 32 bytes);...
Page 64 AX-5 Ser i es M od ul e M an ua l 2.2.4.1.3 PNIO I/O Mapping This part provides an explanation of the settings under PNIO I/O Mapping tab. This model reserves 10 bytes of space for Input Data to store the error codes of the coupler and the status of its connected IO modules.
Page 65 Ch ap te r 2 Cou pl er 2.2.4.1.4 Port Setting This part provides an explanation of the settings under Port data tab. ① Peer station/port: Select its corresponding PN main station and port.  Before selecting the Peer station/port, you need to go to the Topology tab of this PN Controller and select the device and port that correspond to its main station.
Page 66 AX-5 Ser i es M od ul e M an ua l 2.2.4.1.5 Status Click on the toolbar to enter the online mode. You can check the current status and any error messages of the Status tab. modules in the 2.2.4.1.6 Information You can see information related to the module in the Information Tab.
Page 67 Ch ap te r 2 Cou pl er 2.2.4.1.7 Install a GSD File DIADesigner-AX comes with a Profinet Coupler (AX-500CPN) by default, eliminating the need for any manual installation. However, if you prefer to perform a manual update, you can do so using the following method. Click Tools ->...
Page 68 AX-5 Ser i es M od ul e M an ua l After installation, you can see the manually added AX-500CPN00-0A as the image shown below. 2 - 3 0...
Page 69 Ch ap te r 2 Cou pl er 2.2.4.2 TIA Portal 2.2.4.2.1 Steps to Install GSD Files Import GSDML files of AX-500CPN00-0A into TIA portal. 1. Open TIA Portal and then go to Options in the toolbar. 2. Go to Manage general station description files (GSD) and select the GSD file. 3.
Page 70 Open TIA Portal and create a new project. Click Other field devices under Hardware catalog. Go to PROFINET IO -> I/O > Delta Electronics, Inc. -> RTU – Remote Terminal Unit -> Head module Select AX-500CPN00-0A. After the device is added, you can find it on the topology view page.
Page 71 Ch ap te r 2 Cou pl er 2.2.5 Troubleshooting There are two categories of error codes: IO Error and Diagnosis Error. If an error occurs, the register RTU Error Code will store the latest error code. And the Log page will record all the error messages that have occurred.
Page 72 AX-5 Ser i es M od ul e M an ua l MEMO 2 - 3 4...
Page 73 Chapter 3 Power Supply Modules and Connector Modules Table of Contents AX-502PS11-0A..................3-2 3.1.1 Specifications ..................3-2 3.1.2 Dimensions and Parts ................3-2 3.1.3 Arrangement of Terminals, LED Indicators and Wiring ......... 3-4 3.1.4 Settings in DIADesigner-AX ..............3-7 3.1.5 Process Data ..................
Page 74 AX-5 Ser i es M od ul e M an ua l AX-502PS11-0A AX-502PS11-0A is a unit power supply module. This section introduces its specifications, operations and wirings. 3.1.1 Specifications Item Specification External connector Spring-clamp terminal block (16 terminals) Dimension (mm) 12 (W) ×...
Page 75 Ch ap te r 3 Pow er Supp ly Mod ul es a nd Co nnec tor M odul es Parts  ⑪ ⑤ ④ ⑫ ⑥ ① ⑦ ② ⑧ ③ ⑨ ⑩ Name AX connector (L) Label (manufacturer information, service information, safety, serial number, firmware/hardware version) DIN rail clip System status indicator...
Page 76 AX-5 Ser i es M od ul e M an ua l 3.1.3 Arrangement of Terminals, LED Indicators and Wiring 3.1.3.1 Arrangement of Terminals 02PS System LED LV LED Power LED DC24V Pin No. Symbol Description Pin No. Symbol Description Module unit power input: 24 VDC Module unit power input: 0 VDC Module unit power input: 24 VDC...
Page 77 Ch ap te r 3 Pow er Supp ly Mod ul es a nd Co nnec tor M odul es 3.1.3.2 LED Indicators Name Color Status Description ECAT INIT Blinking (0.2s) ECAT Pre OP System Blue Blinking(1s) ECAT Safe OP Normal (OP) No under-voltage warning Under-voltage warning...
Page 78 AX-5 Ser i es M od ul e M an ua l Loop Configuration  DC/DC 24 VDC Unit Unit Power Power Connector (L) Connector (R) Power Power This product shall be powered by a certified SELV/PELV power supply unit with operating temperature ...
Page 79 Ch ap te r 3 Pow er Supp ly Mod ul es a nd Co nnec tor M odul es 3.1.4 Settings in DIADesigner-AX This section introduces some basic operations and settings in the DIADesigner-AX software. 3.1.4.1 Basic Operation Double-click the DIADesigner-AX icon to open the software and create a new project. 3 - 7...
Page 80 AX-5 Ser i es M od ul e M an ua l Add Modules in Method 1: Add the modules in manually.  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Add Device… to select and add System Coupler.
Page 81 Ch ap te r 3 Pow er Supp ly Mod ul es a nd Co nnec tor M odul es Method 2: Scan to add the modules in.  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Scan for Devices…. After the auto-scan is over, the actually connected devices will appear.
Page 82 AX-5 Ser i es M od ul e M an ua l 3.1.4.2 Process Data In the Process Data tab, select the desired outputs and inputs. Click on the toolbar to go into online mode. In the I/O Mapping tab, you can find the variables, current value, status and error codes for each channel.
Page 83 Ch ap te r 3 Pow er Supp ly Mod ul es a nd Co nnec tor M odul es 3.1.4.4 Information In the Information tab, you can find the module information, including Name, Vendor, Categories, Type, ID, Version, Order Number and Description for the power supply module. 3.1.5 Process Data This section introduces the settings and monitoring of PDO data exchange.
Page 84 AX-5 Ser i es M od ul e M an ua l AX-510PS12-0A AX-510PS12-0A is an I/O power supply module. This section introduces its specifications, operations and wirings. 3.2.1 Specifications Item Specification External connector Spring-clamp terminal block (16 terminals) Dimension (mm) 12 (W) ×...
Page 85 Ch ap te r 3 Pow er Supp ly Mod ul es a nd Co nnec tor M odul es ⑪ ⑤ ④ ⑫ ⑥ ① ⑦ ② ⑧ ③ ⑨ ⑩ Name AX connector (L) Label (manufacturer information, service information, safety, serial number, firmware/hardware version) DIN rail clip System status indicator...
Page 86 AX-5 Ser i es M od ul e M an ua l 3.2.3 Arrangement of Terminals, LED Indicators and Wiring 3.2.3.1 Arrangement of Terminals 10PS DC24V Pin No. Symbol Description Pin No. Symbol Description I/O power output: 24 VDC I/O power output: 0 VDC I/O power output: 24 VDC I/O power output: 0 VDC I/O power output: 24 VDC...
Page 87 Ch ap te r 3 Pow er Supp ly Mod ul es a nd Co nnec tor M odul es 3.2.3.2 LED Indicators Name Color Status Description Not supplied with power Power Green Power on 3.2.3.3 Wiring and Loop Configuration Wiring ...
Page 88 AX-5 Ser i es M od ul e M an ua l Loop Configuration  24 VDC Unit Unit Power Power Connector Connector Power Power This product shall be powered by a certified SELV/PELV power supply unit with operating temperature ...
Page 89 Ch ap te r 3 Pow er Supp ly Mod ul es a nd Co nnec tor M odul es AX-516PC10-0A AX-516PC10-0A is an I/O power connector module. This section introduces its specifications, operations and wirings. 3.3.1 Specifications Item Specification External connector Spring-clamp terminal block (16 terminals) Dimension (mm)
Page 90 AX-5 Ser i es M od ul e M an ua l Parts  ⑪ ⑤ ④ ⑫ ⑥ ① ⑦ ② ⑧ ③ ⑨ ⑩ Name AX connector (L) Label (manufacturer information, service information, safety, serial number, firmware/hardware version) DIN rail clip System status indicator Model code...
Page 91 Ch ap te r 3 Pow er Supp ly Mod ul es a nd Co nnec tor M odul es 3.3.3 Arrangement of Terminals, LED Indicators and Wiring 3.3.3.1 Arrangement of Terminals Pin No. Symbol Description Pin No. Symbol Description I/O power output: 24 VDC I/O power output: DC 24 V I/O power output: 24 VDC...
Page 92 AX-5 Ser i es M od ul e M an ua l 3.3.3.3 Wiring and Loop Configuration Wiring  AX-516PC10-0A Loop Configuration  Unit Unit Power Power Connector Connector Power Power 3 - 2 0...
Page 93 Ch ap te r 3 Pow er Supp ly Mod ul es a nd Co nnec tor M odul es AX-516PC20-0A AX-516PC20-0A is an I/O power connector module. This section introduces its specifications, operations and wirings. 3.4.1 Specifications Item Specification External connector Spring-clamp terminal block (16 terminals) Dimension (mm)
Page 94 AX-5 Ser i es M od ul e M an ua l Parts  ⑪ ⑤ ④ ⑫ ⑥ ① ⑦ ② ⑧ ③ ⑨ ⑩ Name AX connector (L) Label (manufacturer information, service information, safety, serial number, firmware/hardware version) DIN rail clip System status indicator Model code...
Page 95 Ch ap te r 3 Pow er Supp ly Mod ul es a nd Co nnec tor M odul es 3.4.3 Arrangement of Terminals, LED Indicators and Wiring 3.4.3.1 Arrangement of Terminals Pin No. Symbol Description Pin No. Symbol Description I/O power output: 0 VDC I/O power output: 0 VDC I/O power output: 0 VDC...
Page 96 AX-5 Ser i es M od ul e M an ua l 3.4.3.3 Wiring and Loop Configuration Wiring  AX-516PC20-0A Loop Configuration  Unit Unit Power Power Connector Connector Power Power 3 - 2 4...
Page 97 Ch ap te r 3 Pow er Supp ly Mod ul es a nd Co nnec tor M odul es AX-516PC30-0A AX-516PC30-0A is an I/O power connector module. This section introduces its specifications, operations and wirings. 3.5.1 Specifications Item Specification External connector Spring-clamp terminal block (16 terminals) Dimension (mm)
Page 98 AX-5 Ser i es M od ul e M an ua l Parts  ⑪ ⑤ ④ ⑫ ⑥ ① ⑦ ② ⑧ ③ ⑨ ⑩ Name AX connector (L) Label (manufacturer information, service information, safety, serial number, firmware/hardware version) DIN rail clip System status indicator Model code...
Page 99 Ch ap te r 3 Pow er Supp ly Mod ul es a nd Co nnec tor M odul es 3.5.3 Arrangement of Terminals, LED Indicators and Wiring 3.5.3.1 Arrangement of Terminals Pin No. Symbol Description Pin No. Symbol Description I/O power output: 24 VDC I/O power output: 0 VDC I/O power output: 24 VDC...
Page 100 AX-5 Ser i es M od ul e M an ua l 3.5.3.3 Wiring and Loop Configuration Wiring  AX-516PC30-0A Loop Configuration  Unit Unit Power Power Connector Connector Power Power 3 - 2 8...
Page 101 Ch ap te r 3 Pow er Supp ly Mod ul es a nd Co nnec tor M odul es AX-514PC40-0A AX-514PC40-0A is an I/O power connector module. This section introduces its specifications, operations and wirings. 3.6.1 Specifications Item Specification External connector Spring-clamp terminal block (16 terminals) Dimension (mm)
Page 102 AX-5 Ser i es M od ul e M an ua l Parts  ⑪ ⑤ ④ ⑫ ⑥ ① ⑦ ⑧ ② ③ ⑨ ⑩ Name AX connector (L) Label (manufacturer information, service information, safety, serial number, firmware/hardware version) DIN rail clip System status indicator Model code...
Page 103 Ch ap te r 3 Pow er Supp ly Mod ul es a nd Co nnec tor M odul es 3.6.3 Arrangement of Terminals, LED Indicators and Wiring 3.6.3.1 Arrangement of Terminals Pin No. Symbol Description Pin No. Symbol Description For shielding For shielding For shielding...
Page 104 AX-5 Ser i es M od ul e M an ua l 3.6.3.3 Wiring and Loop Configuration Wiring  AX-514PC40-0A Loop Configuration  Unit Unit Power Power Connector Connector Power Power 3 - 3 2...
Page 105 Chapter 4 Digital Input / Output Modules Table of Contents AX-516AM10-0A ..................4-3 4.1.1 Specifications ..................4-3 4.1.2 Dimensions and Parts ................4-4 4.1.3 Arrangement of Terminals, LED Indicators and Wiring ......... 4-5 4.1.4 Settings in DIADesigner-AX ..............4-8 4.1.5 Parameter Descriptions .................
Page 106 4.5.2 Dimensions and Parts ................4-84 4.5.3 Arrangement of Terminals, LED Indicators and Wiring ....... 4-85 4.5.4 Settings in DIADesigner-AX ..............4-88 4.5.5 Parameter Descriptions ................ 4-96 4.5.6 EtherCAT Operation Modes ..............4-100 4.5.7 Process Data ..................4-101 4.5.8 Troubleshooting ................4-102 AX-516AP22-0A ..................
Page 107 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es AX-516AM10-0A AX-516AM10-0A, a digital input module, receives external 16-point digital signals (NPN). This section introduces its specifications, operations, and wirings. Specifications Item Specification...
Page 108 AX-5 Ser i es M od ul e M an ua l Dimensions and Parts Dimensions  Unit：mm ⑪ Parts  ⑤ ④ ⑫ ⑥ ① ⑦ ② ⑧ ③ ⑨ ⑩ Name AX connector (L) Label (manufacturer information, service information, safety, serial number, firmware/hardware version) DIN rail clip System status indicator...
Page 109 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Arrangement of Terminals, LED Indicators and Wiring 4.1.3.1 Arrangement of Terminals *1. The marked black areas are terminals with LED indicators. Refer to the table below to see the terminals and corresponding symbols and channels.
Page 110 AX-5 Ser i es M od ul e M an ua l 4.1.3.2 LED Indicators Name Color Status Description ECAT INIT Blinking (0.2s) ECAT Pre OP System Blue Blinking(1s) ECAT Safe OP Normal (OP) Module is functioning correctly. Error A severe error occurs on the module. The channel is OFF.
Page 111 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Loop Configuration  AX-516AM10-0A I0 to I15 Unit Unit Power Power Connector Connector Power Power 4 - 7...
Page 112 AX-5 Ser i es M od ul e M an ua l Settings in DIADesigner-AX This section introduces some basic operations and settings in the DIADesigner-AX software. 4.1.4.1 Basic Operation Double-click the DIADesigner-AX icon to open the software and create a new project. 4 - 8...
Page 113 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Add Modules in Method 1: Add the modules in manually  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Add Device… to select and add System Coupler.
Page 114 AX-5 Ser i es M od ul e M an ua l Method 2: Scan to add the modules in.  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Scan for Devices…. After the auto-scan is over, the actually connected devices will appear. Click Copy All Devices to Project button to add them to the list under EtherCAT Master SoftMotion.
Page 115 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es 4.1.4.2 Parameter Settings In the CoE Parameters tab, you can do the following settings of parameters. Favorites You can add the desired parameters to the Favorites list. Click on the toolbar to go into online mode, and ...
Page 116 AX-5 Ser i es M od ul e M an ua l Startup Parameters Once the module is started up, the setting values of parameters in the Startup Parameters list are written to the  module. For editing, you have to set up these parameters in offline mode. Icon Function Description...
Page 117 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Icon Function Description Compare Compare Upload the selected parameters from the module Upload Selection from Device to DIADesigner-AX. Upload all the parameters from the module to Upload All from Device DIADesigner-AX.
Page 118 AX-5 Ser i es M od ul e M an ua l 4.1.4.3 Process Data In the Process Data tab, select the desired outputs and inputs. Click on the toolbar to go into online mode. In the EtherCAT I/O Mapping tab, you can find the variables, current value, status and error codes for each channel.
Page 119 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es 4.1.4.4 Diagnosis History Click on the toolbar to go into online mode. The Diagnosis History tab records all error information that occurred on the module.
Page 120 AX-5 Ser i es M od ul e M an ua l 4.1.4.6 Information In the Information tab, you can find the module information, including Name, Vendor, Categories, Type, ID, Version, Order Number and Description for the module. Click on the toolbar to go into online mode. Go to the All Parameters page in the CoE Parameters tab, and then you can find the hardware version and software version of the module.
Page 121 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es 4.1.5.1 Module Status Index Subindex Name Description Data Type Attr. Default 16#5000 16#01 Module Status Status of the module UINT Parameter explanation ...
Page 122 AX-5 Ser i es M od ul e M an ua l 4.1.5.3 Input Filter Time Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Input Filter Time USINT 16#02 CH1 Input Filter Time USINT 16#03 CH2 Input Filter Time USINT 16#04 CH3 Input Filter Time...
Page 123 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es 4.1.5.4 Input Filter Threshold Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Input Filter Threshold USINT 16#02 CH1 Input Filter Threshold USINT 16#03 CH2 Input Filter Threshold...
Page 124 AX-5 Ser i es M od ul e M an ua l EtherCAT Operation Modes There are two modes for EtherCAT modules to run during operation, FreeRun mode (non-synchronization mode) and DC mode (synchronization mode). Different synchronization modes can be applied to different modules in the same system. 4.1.6.1 FreeRun Mode The I/O values of each module are refreshed based on its own cycle.
Page 125 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Process Data This section introduces the settings and monitoring of PDO data exchange. Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Digital Input Status...
Page 126 AX-5 Ser i es M od ul e M an ua l 4.1.7.1 Process Data Go to the Process Data tab and select the data that you’d like to monitor. Digital Input Value: You can monitor the selected channels and deselect the unused channels to save the cycle ...
Page 127 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es 4.1.7.3 Always Update Variables This field is for global setting to define whether or not the I/O variables in the bus cycle task are updated. Option Description DIADesigner-AX updates the I/O variables according to the...
Page 128 AX-5 Ser i es M od ul e M an ua l AX-516AM20-0A AX-516AM20-0A, a digital input module, receives external 16-point digital signals (PNP). This section introduces its specifications, operations and wirings. Specifications Item Specification Input points External connector type Spring-clamp terminal block (16 terminals) 1.
Page 129 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Dimensions and Parts Dimensions  Unit：mm ⑪ Parts  ⑤ ④ ⑫ ⑥ ① ⑦ ② ⑧ ③ ⑨ ⑩ Name AX connector (L) Label (manufacturer information, service information, safety, serial number, firmware/hardware...
Page 130 AX-5 Ser i es M od ul e M an ua l Arrangement of Terminals, LED Indicators and Wiring 4.2.3.1 Arrangement of Terminals System LED ERROR LED Channel LED *1. The marked black areas are terminals with LED indicators. Refer to the table below to see their corresponding channels.
Page 131 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es 4.2.3.2 LED Indicators Name Color Status Description ECAT INIT Blinking (0.2s) ECAT Pre OP System Blue Blinking(1s) ECAT Safe OP Normal (OP) Module is functioning correctly.
Page 132 AX-5 Ser i es M od ul e M an ua l Loop Configuration  AX-516AM20-0A I0 to I15 Unit Unit Power Power Connector Connector Power Power 4 - 2 8...
Page 133 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Settings in DIADesigner-AX This section introduces some basic operations and settings in the DIADesigner-AX software. 4.2.4.1 Basic Operation Double-click the DIADesigner-AX icon to open the software and create a new project. 4 - 2 9...
Page 134 AX-5 Ser i es M od ul e M an ua l Add Modules in Method 1: Add the modules in manually  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Add Device… to select and add System Coupler.
Page 135 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Method 2: Scan to add the modules in.  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Scan for Devices…. After the auto-scan is over, the actually connected devices will appear.
Page 136 AX-5 Ser i es M od ul e M an ua l 4.2.4.2 Parameter Settings In the CoE Parameters tab, you can do the following settings of parameters. Favorites You can add the selected parameter to Favorites according to your preference. Click on the toolbar to go ...
Page 137 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Startup Parameters Once the module is started up, the setting values of parameters in the Startup Parameters list are written to the ...
Page 138 AX-5 Ser i es M od ul e M an ua l All Parameters You can find all the CoE parameters here. Click on the toolbar to go into online mode, and then you can  start to upload and download the parameters. After clicking the upload button, you can see the current values of parameters in Current Value column.
Page 139 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es  You can select and right-click the parameter to add the selected parameter to Favorites. Function Description Add to Favorites Add the selected to Favorites Add to Startup Parameters Add the selected to Startup Parameters...
Page 140 AX-5 Ser i es M od ul e M an ua l Click on the toolbar to go into online mode. In the EtherCAT I/O Mapping tab, you can find the variables, current value, status and error codes for each channel. 4.2.4.4 Diagnosis History Click...
Page 141 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es 4.2.4.5 Status Click on the toolbar to go into online mode. In the Status tab, you can monitor the current status and latest diagnostic messages of the module.
Page 142 AX-5 Ser i es M od ul e M an ua l Parameter Descriptions You can use DIADesigner-AX to set up the module. For software operation, refer to section 4.2.4 for more information. The function blocks in the software are available for you to set relevant parameters. Please refer to the function block manual for the usage of function blocks.
Page 143 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es 4.2.5.3 Input Filter Time Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Input Filter Time USINT 16#02 CH1 Input Filter Time USINT 16#03 CH2 Input Filter Time...
Page 144 AX-5 Ser i es M od ul e M an ua l Index Subindex Name Description Data Type Attr. Default 16#0E CH13 Input Filter Threshold USINT 16#0F CH14 Input Filter Threshold USINT 16#10 CH15 Input Filter Threshold USINT Parameter explanation ...
Page 145 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es EtherCAT Operation Modes There are two modes for EtherCAT modules to run during operation, FreeRun mode (non-synchronization mode) and DC mode (synchronization mode).
Page 146 AX-5 Ser i es M od ul e M an ua l Process Data This section introduces the settings and monitoring of PDO data exchange. Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Digital Input Status BOOL 16#02 CH1 Digital Input Status BOOL 16#03...
Page 147 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es 4.2.7.2 EtherCAT I/O Mapping The corresponding data from the Process Data will be shown in the tab of EtherCAT I/O Mapping. 4.2.7.3 Always Update Variables This field is for global setting to define whether or not the I/O variables in the bus cycle task are updated.
Page 148 AX-5 Ser i es M od ul e M an ua l AX-516AN01-0A AX-516AN01-0A, a digital output module, outputs 16-point digital signals (NPN). This section introduces its specifications, operations and wirings. Specifications Item Specification Output points External connector type Spring-clamp terminal block (16 terminals) 1.
Page 149 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Dimensions and Parts Dimensions  Unit：mm ⑪ Parts  ⑤ ④ ⑫ ⑥ ① ⑦ ② ⑧ ③ ⑨ ⑩ Name AX connector (L) Label (manufacturer information, service information, safety, serial number, firmware/hardware...
Page 150 AX-5 Ser i es M od ul e M an ua l Arrangement of Terminals, LED Indicators and Wiring 4.3.3.1 Arrangement of Terminals System LED ERROR LED Channel LED *1. The marked black areas are terminals with LED indicators. Refer to the table below to see their corresponding channels.
Page 151 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es 4.3.3.2 LED Indicators Name Color Status Description ECAT INIT Blinking (0.2s) ECAT Pre OP System Blue Blinking(1s) ECAT Safe OP Normal (OP) Module is functioning correctly.
Page 152 AX-5 Ser i es M od ul e M an ua l Loop Configuration  Q0 to Q15 Unit Unit Power Power Connector Connector Power Power The output circuit and internal circuit of this product are separated only by functional ...
Page 153 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Settings in DIADesigner-AX This section introduces some basic operations and settings in the DIADesigner-AX software. 4.3.4.1 Basic Operation Double-click the DIADesigner-AX icon to open the software and create a new project. 4 - 4 9...
Page 154 AX-5 Ser i es M od ul e M an ua l Add Modules in Method 1: Add the modules in manually  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Add Device… to select and add System Coupler.
Page 155 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Method 2: Scan to add the modules in.  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Scan for Devices…. After the auto-scan is over, the actually connected devices will appear.
Page 156 AX-5 Ser i es M od ul e M an ua l 4.3.4.2 Parameter Settings In the CoE Parameters tab, you can do the following settings of parameters. Favorites You can add the selected parameter to Favorites according to your preference. Click on the toolbar to go ...
Page 157 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Startup Parameters Once the module is started up, the setting values of parameters in the Startup Parameters list are written to the ...
Page 158 AX-5 Ser i es M od ul e M an ua l All Parameters You can find all the CoE parameters here. Click on the toolbar to go into online mode, and then you can  start to upload and download the parameters. After clicking the upload button, you can see the current values of parameters in Current Value column.
Page 159 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es  You can select and right-click the parameter to add the selected parameter to Favorites. Function Description Add to Favorites Add the selected to Favorites Add to Startup Parameters Add the selected to Startup Parameters...
Page 160 AX-5 Ser i es M od ul e M an ua l Click on the toolbar to go into online mode. In the EtherCAT I/O Mapping tab, you can find the variables, current value, status and error codes for each channel. 4.3.4.4 Diagnosis History Click...
Page 161 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es 4.3.4.5 Status Click on the toolbar to go into online mode. In the Status tab, you can monitor the current status and latest diagnostic messages of the module.
Page 162 AX-5 Ser i es M od ul e M an ua l Index Function Description Output Settings when EtherCAT The setting for the output when the EtherCAT connection is 16#8000 Connection Lost lost. Output Settings when Module in The setting for the output when the module is in the stopped 16#8001 Stopped State state.
Page 163 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es 4.3.5.3 Output Settings when EtherCAT Connection Lost Index Subindex Name Description Data Type Attr. Default USINT 16#01 CH0 Output Settings when EtherCAT Connection Lost 16#02 CH1 Output Settings when EtherCAT Connection Lost USINT...
Page 164 AX-5 Ser i es M od ul e M an ua l 4.3.5.4 Output Settings when Module in Stopped State Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Output Settings when Module in Stopped State USINT 16#02 CH1 Output Settings when Module in Stopped State USINT 16#03 CH2 Output Settings when Module in Stopped State...
Page 165 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es EtherCAT Operation Modes There are two modes for EtherCAT modules to run during operation, FreeRun mode (non-synchronization mode) and DC mode (synchronization mode).
Page 166 AX-5 Ser i es M od ul e M an ua l Process Data This section introduces the settings and monitoring of PDO data exchange. Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Digital Output Status BOOL 16#02 CH1 Digital Output Status BOOL 16#03...
Page 167 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es 4.3.7.2 EtherCAT I/O Mapping The corresponding data from the Process Data will be shown in the tab of EtherCAT I/O Mapping. 4.3.7.3 Always Update Variables This field is for global setting to define whether or not the I/O variables in the bus cycle task are updated.
Page 168 AX-5 Ser i es M od ul e M an ua l AX-516AN02-0A AX-516AN02-0A, a digital output module, outputs 16-point digital signals (PNP). This section introduces its specifications, operations and wirings. Specifications Item Specification Output points External connector type Spring-clamp terminal block (16 terminals) 1.
Page 169 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Dimensions and Parts Dimensions  Unit：mm Parts  ⑪ ⑤ ④ ⑫ ⑥ ① ⑦ ② ⑧ ③ ⑨ ⑩ Name AX connector (L) Label (manufacturer information, service information, safety, serial number, firmware/hardware...
Page 170 AX-5 Ser i es M od ul e M an ua l Arrangement of Terminals, LED Indicators and Wiring 4.4.3.1 Arrangement of Terminals System LED ERROR LED Channel LED *1. The marked black areas are terminals with LED indicators. Refer to the table below to see their corresponding channels.
Page 171 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es 4.4.3.2 LED Indicators Name Color Status Description ECAT INIT Blinking (0.2s) ECAT Pre OP System Blue Blinking(1s) ECAT Safe OP Normal (OP) Module is functioning correctly.
Page 172 AX-5 Ser i es M od ul e M an ua l Loop Configuration  Q0 to Q15 Unit Unit Power Power Connector Connector Power Power The output circuit and internal circuit of this product are separated only by functional ...
Page 173 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Settings in DIADesigner-AX This section introduces some basic operations and settings in the DIADesigner-AX software. 4.4.4.1 Basic Operation Double-click the DIADesigner-AX icon to open the software and create a new project. 4 - 6 9...
Page 174 AX-5 Ser i es M od ul e M an ua l Add Modules in Method 1: Add the modules in manually  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Add Device… to select and add System Coupler.
Page 175 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Method 2: Scan to add the modules in.  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Scan for Devices…. After the auto-scan is over, the actually connected devices will appear.
Page 176 AX-5 Ser i es M od ul e M an ua l 4.4.4.2 Parameter Settings In the CoE Parameters tab, you can do the following settings of parameters. Favorites You can add the selected parameter to Favorites according to your preference. Click on the toolbar to go ...
Page 177 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Startup Parameters Once the module is started up, the setting values of parameters in the Startup Parameters list are written to the ...
Page 178 AX-5 Ser i es M od ul e M an ua l Icon Function Description Compare Compare Upload the selected parameters from the module Upload Selection from Device to DIADesigner-AX. Upload all the parameters from the module to Upload All from Device DIADesigner-AX.
Page 179 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es 4.4.4.3 Process Data In the Process Data tab, select the desired outputs and inputs. Click on the toolbar to go into online mode. In the EtherCAT I/O Mapping tab, you can find the variables, current value, status and error codes for each channel.
Page 180 AX-5 Ser i es M od ul e M an ua l 4.4.4.4 Diagnosis History Click on the toolbar to go into online mode. The Diagnosis History tab records all error information that occurred on the module. Message column shows the TEXT ID plus error description. Please refer to the troubleshooting section for details on errors.
Page 181 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es 4.4.4.6 Information In the Information tab, you can find the module information, including Name, Vendor, Categories, Type, ID, Version, Order Number and Description for the module. Click on the toolbar to go into online mode.
Page 182 AX-5 Ser i es M od ul e M an ua l Value Status Description The module is controlled by the controller and the status of the Controlled by Controller (Stop) controller is Stop. 4.4.5.2 User Command Users write the commands into the module and the module will execute accordingly. After execution, the module will respond with a corresponding value to show if the execution is success or not.
Page 183 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Parameter explanation  The parameter set is for setting the output behavior of output points when the EtherCAT connection is lost. Output behavior settings ...
Page 184 AX-5 Ser i es M od ul e M an ua l EtherCAT Operation Modes There are two modes for EtherCAT modules to run during operation, FreeRun mode (non-synchronization mode) and DC mode (synchronization mode). Different synchronization modes can be applied to different modules in the same system. 4.4.6.1 FreeRun Mode The I/O values of each module are refreshed based on its own cycle.
Page 185 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Process Data This section introduces the settings and monitoring of PDO data exchange. Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Digital Output Status...
Page 186 AX-5 Ser i es M od ul e M an ua l 4.4.7.2 EtherCAT I/O Mapping The corresponding data from the Process Data will be shown in the tab of EtherCAT I/O Mapping. 4.4.7.3 Always Update Variables This field is for global setting to define whether or not the I/O variables in the bus cycle task are updated. Option Description DIADesigner-AX updates the I/O variables according to the...
Page 187 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es AX-516AP11-0A AX-516AP11-0A, a digital input / output module, inputs 8-point digital signals and outputs 8-point digital signals (NPN). This section introduces its specifications, operations and wirings. Specifications Item Specification...
Page 188 AX-5 Ser i es M od ul e M an ua l Dimensions and Parts Dimensions  Unit：mm ⑪ Parts  ⑤ ④ ⑫ ⑥ ① ⑦ ② ⑧ ③ ⑨ ⑩ Name AX connector (L) Label (manufacturer information, service information, safety, serial number, firmware/hardware version) DIN rail clip System status indicator...
Page 189 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Arrangement of Terminals, LED Indicators and Wiring 4.5.3.1 Arrangement of Terminals System LED ERROR LED Channel LED *1. The marked black areas are terminals with LED indicators. Refer to the table below to see their corresponding channels.
Page 190 AX-5 Ser i es M od ul e M an ua l 4.5.3.3 Wiring and Loop Configuration Wiring  AX-510PS12-0A AX-516PC30-0A AX-516AP11-0A 2-wire AX-510PS12-0A AX-516PC30-0A AX-516AP11-0A 3-wire 4 - 8 6...
Page 191 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Loop Configuration  I0 to I7 Q0 to Q7 Unit Unit Power Power Connector Connector Power Power The output circuit and internal circuit of this product are separated only by functional ...
Page 192 AX-5 Ser i es M od ul e M an ua l Settings in DIADesigner-AX This section introduces some basic operations and settings in the DIADesigner-AX software. 4.5.4.1 Basic Operation Double-click the DIADesigner-AX icon to open the software and create a new project. 4 - 8 8...
Page 193 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Add Modules in Method 1: Add the modules in manually  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Add Device… to select and add System Coupler.
Page 194 AX-5 Ser i es M od ul e M an ua l Method 2: Scan to add the modules in.  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Scan for Devices…. After the auto-scan is over, the actually connected devices will appear. Click Copy All Devices to Project button to add them to the list under EtherCAT Master SoftMotion.
Page 195 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es 4.5.4.2 Parameter Settings In the CoE Parameters tab, you can do the following settings of parameters. Favorites You can add the selected parameter to Favorites according to your preference. Click on the toolbar to go ...
Page 196 AX-5 Ser i es M od ul e M an ua l Startup Parameters Once the module is started up, the setting values of parameters in the Startup Parameters list are written to the  module. For editing, you have to set up these parameters in offline mode. Icon Function Description...
Page 197 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Icon Function Description Compare Compare Upload the selected parameters from the module Upload Selection from Device to DIADesigner-AX. Upload all the parameters from the module to Upload All from Device DIADesigner-AX.
Page 198 AX-5 Ser i es M od ul e M an ua l 4.5.4.3 Process Data In the Process Data tab, select the desired outputs and inputs. Click on the toolbar to go into online mode. In the EtherCAT I/O Mapping tab, you can find the variables, current value, status and error codes for each channel.
Page 199 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es 4.5.4.4 Diagnosis History Click on the toolbar to go into online mode. The Diagnosis History tab records all error information that occurred on the module.
Page 200 AX-5 Ser i es M od ul e M an ua l 4.5.4.6 Information In the Information tab, you can find the module information, including Name, Vendor, Categories, Type, ID, Version, Order Number and Description for the module. Click on the toolbar to go into online mode. Go to the All Parameters page in the CoE Parameters tab, and then you can find the hardware version and software version of the module.
Page 201 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Parameter explanation  This parameter displays the current control status of the module. Status of the module  Value Status Description Controlled by EtherCAT State Machine The module is controlled by EtherCAT State Machine...
Page 202 AX-5 Ser i es M od ul e M an ua l Parameter explanation  The parameter set is to set the filtering time for the inputs of the module. If the duration time for received signals is shorter than the set filtering time, the signals received will be seen as noises and will be filtered out. The default filtering value is 3 ms.
Page 203 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es 4.5.5.5 Output Settings when EtherCAT Connection Lost Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Output Settings when EtherCAT Connection Lost USINT 16#02 CH1 Output Settings when EtherCAT Connection Lost...
Page 204 AX-5 Ser i es M od ul e M an ua l EtherCAT Operation Modes There are two modes for EtherCAT modules to run during operation, FreeRun mode (non-synchronization mode) and DC mode (synchronization mode). Different synchronization modes can be applied to different modules in the same system. 4.5.6.1 FreeRun Mode The I/O values of each module are refreshed based on its own cycle.
Page 205 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Process Data This section introduces the settings and monitoring of PDO data exchange. Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Digital Input Status...
Page 206 AX-5 Ser i es M od ul e M an ua l 4.5.7.2 EtherCAT I/O Mapping The corresponding data from the Process Data will be shown in the tab of EtherCAT I/O Mapping. 4.5.7.3 Always Update Variables This field is for global setting to define whether or not the I/O variables in the bus cycle task are updated. Option Description DIADesigner-AX updates the I/O variables according to the...
Page 207 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es AX-516AP22-0A AX-516AP22-0A, a digital input/ output module, inputs 8-point digital signals and outputs 8-point digital signals (PNP). This section introduces its specifications, operations and wirings. Specifications Item Specification...
Page 208 AX-5 Ser i es M od ul e M an ua l Dimensions and Parts Dimensions  Unit：mm ⑪ Parts  ⑤ ④ ⑫ ⑥ ① ⑦ ② ⑧ ③ ⑨ ⑩ Name AX connector (L) Label (manufacturer information, service information, safety, serial number, firmware/hardware version) DIN rail clip System status indicator...
Page 209 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Arrangement of Terminals, LED Indicators and Wiring 4.6.3.1 Arrangement of Terminals System LED ERROR LED Channel LED *1. The marked black areas are terminals with LED indicators. Refer to the table below to see their corresponding channels.
Page 210 AX-5 Ser i es M od ul e M an ua l 4.6.3.3 Wiring and Loop Configuration Wiring  AX-510PS12-0A AX-516PC30-0A AX-516AP22-0A 2-wire AX-510PS12-0A AX-516PC30-0A AX-516AP22-0A 3-wire 4 - 1 0 6...
Page 211 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Loop Configuration  I0 to I7 Q0 to Q7 Unit Unit Power Power Connector Connector Power Power The output circuit and internal circuit of this product are separated only by functional ...
Page 212 AX-5 Ser i es M od ul e M an ua l Settings in DIADesigner-AX This section introduces some basic operation and settings in the DIADesigner-AX software. 4.6.4.1 Basic Operation Double-click the DIADesigner-AX icon to open the software and create a new project. 4 - 1 0 8...
Page 213 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Add Modules in Method 1: Add the modules in manually  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Add Device… to select and add System Coupler.
Page 214 AX-5 Ser i es M od ul e M an ua l Method 2: Scan to add the modules in.  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Scan for Devices…. After the auto-scan is over, the actually connected devices will appear. Click Copy All Devices to Project button to add them to the list under EtherCAT Master SoftMotion.
Page 215 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es 4.6.4.2 Parameter Settings In the CoE Parameters tab, you can do the following settings of parameters. Favorites You can add the selected parameter to Favorites according to your preference. Click on the toolbar to go ...
Page 216 AX-5 Ser i es M od ul e M an ua l Startup Parameters Once the module is started up, the setting values of parameters in the Startup Parameters list are written to the  module. For editing, you have to set up these parameters in offline mode. Icon Function Description...
Page 217 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Icon Function Description Compare Compare Upload the selected parameters from the module Upload Selection from Device to DIADesigner-AX. Upload all the parameters from the module to Upload All from Device DIADesigner-AX.
Page 218 AX-5 Ser i es M od ul e M an ua l 4.6.4.3 Process Data In the Process Data tab, select the desired outputs and inputs. Click on the toolbar to go into online mode. In the EtherCAT I/O Mapping tab, you can find the variables, current value, status and error codes for each channel.
Page 219 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es 4.6.4.4 Diagnosis History Click on the toolbar to go into online mode. The Diagnosis History tab records all error information that occurred on the module.
Page 220 AX-5 Ser i es M od ul e M an ua l 4.6.4.6 Information In the Information tab, you can find the module information, including Name, Vendor, Categories, Type, ID, Version, Order Number and Description for the module. Click on the toolbar to go into online mode. Go to the All Parameters page in the CoE Parameters tab, and then you can find the hardware version and software version of the module.
Page 221 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es 4.6.5.1 Module Status Index Subindex Name Description Data Type Attr. Default 16#5000 16#01 Module Status Status of the module UINT Parameter explanation ...
Page 222 AX-5 Ser i es M od ul e M an ua l Parameter explanation  The parameter set is to set the filtering time for the inputs of the module. If the duration time for received signals is shorter than the set filtering time, the signals received will be seen as noises and will be filtered out. The default filtering value is 3 ms.
Page 223 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es 4.6.5.5 Output Settings when EtherCAT Connection Lost Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Output Settings when EtherCAT Connection Lost USINT 16#02 CH1 Output Settings when EtherCAT Connection Lost...
Page 224 AX-5 Ser i es M od ul e M an ua l EtherCAT Operation Modes There are two modes for EtherCAT modules to run during operation, FreeRun mode (non-synchronization mode) and DC mode (synchronization mode). Different synchronization modes can be applied to different modules in the same system. 4.6.6.1 FreeRun Mode The I/O values of each module are refreshed based on its own cycle.
Page 225 Ch ap te r 4 Di gi tal Inp u t / O u tpu t M od ul es Process Data This section introduces the settings and monitoring of PDO data exchange. Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Digital Input Status...
Page 226 AX-5 Ser i es M od ul e M an ua l 4.6.7.2 EtherCAT I/O Mapping The corresponding data from the Process Data will be shown in the tab of EtherCAT I/O Mapping. 4.6.7.3 Always Update Variables This field is for global setting to define whether or not the I/O variables in the bus cycle task are updated. Option Description DIADesigner-AX updates the I/O variables according to the...
Page 227 Chapter 5 Analog Input / Output Modules Table of Contents AX-504AD10-0A ................... 5-4 5.1.1 Specifications ................... 5-4 5.1.2 Dimensions and Parts ................5-5 5.1.3 Arrangement of Terminals, LED Indicators and Wiring ........5-7 5.1.4 Settings in DIADesigner-AX ..............5-10 5.1.5 Parameter Descriptions ................
Page 228 AX-5 Ser i es M od ul e M an ua l 5.5.3 Arrangement of Terminals, LED Indicators and Wiring ........ 5-121 5.5.4 Settings in DIADesigner-AX ..............5-124 5.5.5 Parameter Descriptions ................5-133 5.5.6 EtherCAT Operation Modes ..............5-140 5.5.7 Process Data ..................
Page 229 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.10.8 Troubleshooting ................. 5-272 5.11 AX-504PT10-0B ..................5-273 5.11.1 Specifications ..................5-273 5.11.2 Dimensions and Parts ................. 5-274 5.11.3 Arrangement of Terminals, LED Indicators and Wiring ......5-276 5.11.4 Settings in DIADesigner-AX ..............
Page 230 AX-5 Ser i es M od ul e M an ua l AX-504AD10-0A AX-504AD10-0A, an analog input module, receives analog voltage signals through 4 input points and converts the received signals to 16-bit digital signals. This section introduces its specifications, wirings and operations. 5.1.1 Specifications Item...
Page 231 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.1.2 Dimensions and Parts Dimensions  Unit: mm 5 - 5...
Page 232 AX-5 Ser i es M od ul e M an ua l ⑪ Parts  ⑤ ④ ⑫ ⑥ ① ⑦ ② ⑧ ③ ⑨ ⑩ Name AX connector (L) Label (manufacturer information, service information, safety, serial number, firmware/hardware version) DIN rail clip System status indicator Model code...
Page 233 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.1.3 Arrangement of Terminals, LED Indicators and Wiring 5.1.3.1 Arrangement of Terminals System LED ERROR LED Channel RUN LED *1. The marked black areas are terminals with LED indicators. Refer to the table below to see their corresponding channels.
Page 234 AX-5 Ser i es M od ul e M an ua l 5.1.3.2 LED Indicators Name Color Status Description No power supplied or ECAT INIT Blinking (0.2 s) ECAT Pre OP System Blue Blinking (1 s) ECAT Safe OP Normal OP No power supplied or the module is functioning correctly.
Page 235 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Loop Configuration  Input voltage -10 to +10 V 1 mΩ V0+ to V3+ CH0 to 3 1 mΩ V0- to V3- Shielded cable *1 Power isolation Unit Unit...
Page 236 AX-5 Ser i es M od ul e M an ua l 5.1.4 Settings in DIADesigner-AX The software DIADesigner-AX is the programming tool for the AX Series PLCs. This section introduces some basic operations and settings. 5.1.4.1 Basic Operation Double-click the DIADesigner-AX icon to open the software and create a new project. 5 - 1 0...
Page 237 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Add Modules in Method 1: Add the modules in manually  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Add Device… to select and add System Coupler.
Page 238 AX-5 Ser i es M od ul e M an ua l Method 2: Scan to add the modules in.  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Scan for Devices…. After the auto-scan is over, the actually connected devices will appear. Click Copy All Devices to Project button to add them to the list under EtherCAT Master SoftMotion.
Page 239 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.1.4.2 Parameter Settings In the CoE Parameters tab, you can do the following settings of parameters. Favorites You can select and right-click the parameter to add the selected parameter to the Favorites. Click on the ...
Page 240 AX-5 Ser i es M od ul e M an ua l Startup Parameters Once the module is started up, the setting values of parameters in the Startup Parameters list are written to the  module. For editing, you have to set up these parameters in offline mode. Icon Function Description...
Page 241 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les All Parameters You can find all the CoE parameters here. Click on the toolbar to go into online mode first, and then you can ...
Page 242 AX-5 Ser i es M od ul e M an ua l  You can select and right-click the parameter to add the selected parameter to the Favorites. Function Description Add to Favorites Add the selected to Favorites Add to Startup Parameters Add the selected to Startup Parameters Import…...
Page 243 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Click on the toolbar to go into online mode. In the EtherCAT I/O Mapping tab, you can find the variables, current value, status and error codes for each channel. 5.1.4.4 Diagnosis History Click on the toolbar to go into online mode.
Page 244 AX-5 Ser i es M od ul e M an ua l 5.1.4.5 Status Click on the toolbar to go into online mode. In the Status tab, you can monitor the current status and latest diagnostic messages of the module. 5.1.4.6 Information In the Information tab, you can find the module information, including Name, Vendor, Categories, Type, ID, Version, Order Number and Description for the module.
Page 245 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.1.5 Parameter Descriptions You can use DIADesigner-AX to set up the functions for the module by directly selecting the setting mode and parameters. For software operation, refer to section 5.1.4 for more information. The function blocks in the software are available for you to set relevant parameters.
Page 246 AX-5 Ser i es M od ul e M an ua l 5.1.5.1 Module Status Index Subindex Name Description Data Type Attr. Default 16#5000 16#01 Module Status Status of the module UINT Explanation  When AX5 series PLC CPU is used, the module status is synchronized with the status of AX5 series PLC CPU, and it will be either 1 (Run) or 2 (Stop).
Page 247 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Supported modes:  Mode Mode range DINT range Disable -10 to 10 V ±30000 0 to 10 V 0 to 30000 -5 to 5 V ±30000 0 to 5 V 0 to 30000...
Page 248 AX-5 Ser i es M od ul e M an ua l Explanation  The parameters here are for setting digital filter function. The module provides 3 types of filters, Moving Average Filter, Infinite Impulse Response (IIR) Filter and Finite Impulse Response (FIR) Filter for users to choose from. The filters can work only when the EtherCAT operation mode is the Free Run mode.
Page 249 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les FIR (Finite impulse response) Filter A finite impulse response filter attenuates unwanted frequency from the input signals. In terms of attenuating noises, a FIR filter works more effectively than a moving average filter does.
Page 250 AX-5 Ser i es M od ul e M an ua l 5.1.5.6 User Limit Alarm Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Enable User Limit Alarm DINT USINT Enable/disable the alarm of exceeding the user-defined 16#02 CH1 Enable User Limit Alarm DINT USINT limit (DINT)
Page 251 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Hardware Range User Upper Limit Input Signal User Lower Limit Hardware Range Over Hardware Range Under Hardware Range Upper Limit Alarm Lower Limit Alarm 5.1.5.7 Exceed Hardware Limit Index Subindex...
Page 252 AX-5 Ser i es M od ul e M an ua l 5.1.5.8 Format Index Subindex Name Description Data Type Attr. Default 0: DINT Format 16#01 Format USINT 1: REAL Format 16#8010 16#02 Decimal Places Setting value: 0 to 5 USINT Explanation ...
Page 253 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.1.5.10 ADC Raw Data Index Subindex Name Description Data Type Attr. Default 16#01 CH0 ADC Raw data DINT 16#02 CH1 ADC Raw data DINT 16#8100 Raw data 16#03...
Page 254 AX-5 Ser i es M od ul e M an ua l 5.1.6 EtherCAT Operation Modes There are two modes for EtherCAT modules to run during operation, FreeRun mode (non-synchronization mode) and DC mode (synchronization mode). Different synchronization modes can be applied to different modules in the same system. 5.1.6.1 FreeRun Mode The I/O values of each module are refreshed based on its own cycle.
Page 255 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.1.7 Process Data This section introduces the settings and monitoring of PDO data exchange. Index Subindex Name Description Data Type Attr. Default 16#6000 16#01 CH0 Analog Input Value DINT 16#6001...
Page 256 AX-5 Ser i es M od ul e M an ua l 5.1.7.2 EtherCAT I/O Mapping The corresponding data from the Process Data will be shown in the tab of EtherCAT I/O Mapping. 5.1.7.3 Always Update Variables This field is for global setting to define whether or not the I/O variables in the bus cycle task are updated. Option Description DIADesigner-AX updates the I/O variables according to the...
Page 257 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.1.8 Troubleshooting In the Diagnosis History tab, the error information that has occurred on the module is recorded. In the Status tab, the current information of system error (16#A000) is displayed. In the CoE Parameters tab, you can view the error status through Index/SubIndex of the All Parameter list.
Page 258 AX-5 Ser i es M od ul e M an ua l AX-504AD20-0A AX-504AD20-0A, an analog input module, receives analog current signals through 4 input points and converts the received signals to 16-bit digital signals. This section introduces its specifications, wirings and operations. 5.2.1 Specifications Item...
Page 259 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.2.2 Dimensions and Parts Dimensions  Unit: mm ⑪ Parts  ⑤ ④ ⑫ ⑥ ① ⑦ ② ⑧ ③ ⑨ ⑩ Name AX connector (L) Label (manufacturer information, service information, safety, serial number, firmware/hardware version) DIN rail clip...
Page 260 AX-5 Ser i es M od ul e M an ua l 5.2.3 Arrangement of Terminals, LED Indicators and Wiring 5.2.3.1 Arrangement of Terminals System LED ERROR LED Channel RUN LED *1. The marked black areas are terminals with LED indicators. Refer to the table below to see their corresponding channels.
Page 261 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.2.3.2 LED Indicators Name Color Status Description No power supplied or ECAT INIT Blinking (0.2 s) ECAT Pre OP System Blue Blinking (1 s) ECAT Safe OP Normal OP No power supplied or the module is...
Page 262 AX-5 Ser i es M od ul e M an ua l  Loop Configuration Input current -20 to +20mA 1 mΩ I0+ to I3+ CH0 to CH3 250 Ω I0- to I3- 1 mΩ Shielded cable *1 Power isolation Unit Unit Power...
Page 263 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.2.4 Settings in DIADesigner-AX The software DIADesigner-AX is the programming tool for the AX Series PLCs. This section introduces some basic operations and settings. 5.2.4.1 Basic Operation Double-click the DIADesigner-AX icon to open the software and create a new project.
Page 264 AX-5 Ser i es M od ul e M an ua l Add Modules in Method 1: Add the modules in manually  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Add Device… to select and add System Coupler.
Page 265 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Method 2: Scan to add the modules in.  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Scan for Devices…. After the auto-scan is over, the actually connected devices will appear. Click Copy All Devices to Project button to add them to the list under EtherCAT Master SoftMotion.
Page 266 AX-5 Ser i es M od ul e M an ua l 5.2.4.2 Parameter Settings In the CoE Parameters tab, you can do the following settings of parameters. Favorites You can select and right-click the parameter to add the selected parameter to the Favorites. Click on the ...
Page 267 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Startup Parameters Once the module is started up, the setting values of parameters in the Startup Parameters list are written to the  module. For editing, you have to set up these parameters in offline mode. Icon Function Description...
Page 268 AX-5 Ser i es M od ul e M an ua l All Parameters You can find all the CoE parameters here. Click on the toolbar to go into online mode first, and then you can  start to upload and download the parameters. After clicking the upload button, you can see the current values in Current Value column.
Page 269 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les You can select and right-click the parameter to add the selected parameter to the Favorites.  Function Description Add to Favorites Add the selected to Favorites Add to Startup Parameters Add the selected to Startup Parameters Import…...
Page 270 AX-5 Ser i es M od ul e M an ua l 5.2.4.4 Diagnosis History Click on the toolbar to go into online mode. The Diagnosis History tab records all error information that occurred on the module. Message column shows the TEXT ID plus error description. Please refer to the troubleshooting section for details on errors.
Page 271 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.2.4.5 Status Click on the toolbar to go into online mode. In the Status tab, you can monitor the current status and latest diagnostic messages of the module.
Page 272 AX-5 Ser i es M od ul e M an ua l 5.2.5 Parameter Descriptions You can use DIADesigner-AX to set up the functions for the module by directly selecting the setting mode and parameters. For software operation, refer to section 5.2.4 for more information. The function blocks in the software are available for you to set relevant parameters.
Page 273 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Status of the module  Value Status Description Controlled by EtherCAT State Machine The module is controlled by EtherCAT State Machine The module is controlled by the controller and the status of the Controlled by Controller (Run) controller is Run.
Page 274 AX-5 Ser i es M od ul e M an ua l 5.2.5.4 Calibration Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Calibration Offset REAL 16#02 CH1 Calibration Offset REAL Offset 16#8001 Setting range: no limit 16#03 CH2 Calibration Offset REAL 16#04 CH3 Calibration Offset...
Page 275 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les IIR (Infinite Impulse Response) Filter An infinite impulse response filter attenuates unwanted frequency from the input signals. In terms of attenuating noises, an IIR filter works more efficiently than a moving average filter does. This IIR filter is a low-pass filter. The advantage of an IIR filter is that within the same length of operation time, the filtering result of an IIR filter is better than what a FIR filter can offer.
Page 276 AX-5 Ser i es M od ul e M an ua l 50 Hz low-pass FIR filter 60 Hz low-pass FIR filter Digital filter modes  Mode Name of digital filter Cut-off frequency (-3 dB) Inactive Moving Average Works with Moving Average Time IIR1 1000 Hz IIR2...
Page 277 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Index Subindex Name Description Data Type Attr. Default point); 16#03 CH2 Enable User Limit Alarm REAL USINT 0: Disable(default) 16#04 CH3 Enable User Limit Alarm REAL USINT 1: Enable 16#01...
Page 278 AX-5 Ser i es M od ul e M an ua l 5.2.5.7 Exceed Hardware Limit Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Exceed Hardware Limit Setting USINT Hardware limit setting; 16#02 CH1 Exceed Hardware Limit Setting USINT 16#8008 Setting range:...
Page 279 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.2.5.9 Scale Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Scale Upper Limit REAL REAL 20.0 16#02 CH1 Scale Upper Limit REAL REAL 20.0 Scale upper limit setting;...
Page 280 AX-5 Ser i es M od ul e M an ua l 5.2.6 EtherCAT Operation Modes There are two modes for EtherCAT modules to run during operation, FreeRun mode (non-synchronization mode) and DC mode (synchronization mode). Different synchronization modes can be applied to different modules in the same system. 5.2.6.1 FreeRun Mode The I/O values of each module are refreshed based on its own cycle.
Page 281 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.2.7 Process Data This section introduces the settings and monitoring of PDO data exchange. Index Subindex Name Description Data Type Attr. Default 16#6000 16#01 CH0 Analog Input Value DINT 16#6001...
Page 282 AX-5 Ser i es M od ul e M an ua l 5.2.7.2 EtherCAT I/O Mapping The corresponding data from the Process Data will be shown in the tab of EtherCAT I/O Mapping. 5.2.7.3 Always Update Variables This field is for global setting to define whether or not the I/O variables in the bus cycle task are updated. Option Description DIADesigner-AX updates the I/O variables according to the...
Page 283 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.2.8 Troubleshooting In the Diagnosis History tab, the error information that has occurred on the module is recorded. In the Status tab, the current information of system error (16#A000) is displayed. In the CoE Parameters tab, you can view the error status through Index/SubIndex of the All Parameter list.
Page 284 AX-5 Ser i es M od ul e M an ua l AX-508AD10-0A AX-508AD10-0A, an analog input module, receives analog voltage signals through 8 input points and converts the received signals to 16-bit digital signals. This section introduces its specifications, wirings and operations. 5.3.1 Specifications Item...
Page 285 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.3.2 Dimensions and Parts Dimensions  Unit: mm 5 - 5 9...
Page 286 AX-5 Ser i es M od ul e M an ua l Parts  ⑪ ⑤ ④ ⑫ ⑥ ① ⑦ ② ⑧ ③ ⑨ ⑩ Name AX connector (L) Label (manufacturer information, service information, safety, serial number, firmware/hardware version) DIN rail clip System status indicator Model code...
Page 287 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.3.3 Arrangement of Terminals, LED Indicators and Wiring 5.3.3.1 Arrangement of Terminals System LED ERROR LED Channel RUN LED *1. The marked black areas are terminals with LED indicators. Refer to the table below to see their corresponding channels.
Page 288 AX-5 Ser i es M od ul e M an ua l 5.3.3.2 LED Indicators Name Color Status Description No power supplied or ECAT INIT Blinking (0.2 s) ECAT Pre OP System Blue Blinking (1 s) ECAT Safe OP Normal OP No power supplied or the module is functioning correctly.
Page 289 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Loop Configuration  Input voltage -10 to +10 V 1 mΩ V0+ to V7+ CH0 to CH7 1 mΩ V0- to V7- Shielded cable *1 Power isolation Unit Unit...
Page 290 AX-5 Ser i es M od ul e M an ua l 5.3.4 Settings in DIADesigner-AX The software DIADesigner-AX is the programming tool for the AX Series PLCs. This section introduces some basic operations and settings. 5.3.4.1 Basic Operation Double-click the DIADesigner-AX icon to open the software and create a new project. 5 - 6 4...
Page 291 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Add Modules in Method 1: Add the modules in manually  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Add Device… to select and add System Coupler.
Page 292 AX-5 Ser i es M od ul e M an ua l Method 2: Scan to add the modules in  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Scan for Devices…. After the auto-scan is over, the actually connected devices will appear. Click Copy All Devices to Project button to add them to the list under EtherCAT Master SoftMotion.
Page 293 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.3.4.2 Parameter Settings In the CoE Parameters tab, you can do the following settings of parameters. Favorites You can select and right-click the parameter to add the selected parameter to the Favorites. Click on the ...
Page 294 AX-5 Ser i es M od ul e M an ua l Icon Function Description Delete Delete Move up Move up Move down Move down All Parameters You can find all the CoE parameters here. Click on the toolbar to go into online mode first, and then you can ...
Page 295 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Icon Function Description Compare Compare Upload the selected parameters from the Upload Selection from Device module to DIADesigner-AX. Upload all the parameters from the module to Upload All from Device DIADesigner-AX.
Page 296 AX-5 Ser i es M od ul e M an ua l  You can select and right-click the parameter to add the selected parameter to the Favorites. Function Description Add to Favorites Add the selected to Favorites Add to Startup Parameters Add the selected to Startup Parameters Import…...
Page 297 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Click on the toolbar to go into online mode. In the EtherCAT I/O Mapping tab, you can find the variables, current value, status and error codes for each channel. 5.3.4.4 Diagnosis History Click on the toolbar to go into online mode.
Page 298 AX-5 Ser i es M od ul e M an ua l 5.3.4.5 Status Click on the toolbar to go into online mode. In the Status tab, you can monitor the current status and latest diagnostic messages of the module. 5.3.4.6 Information In the Information tab, you can find the module information, including Name, Vendor, Categories, Type, ID, Version, Order Number and Description for the module.
Page 299 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.3.5 Parameter Descriptions You can use DIADesigner-AX to set up the functions for the module by directly selecting the setting mode and parameters. For software operation, refer to section 5.3.4 for more information. The function blocks in the software are available for you to set relevant parameters.
Page 300 AX-5 Ser i es M od ul e M an ua l 5.3.5.1 Module Status Index Subindex Name Description Data Type Attr. Default 16#5000 16#01 Module Status Status of the module UINT Explanation  When the AX5 series PLC is used as the controller, the module status is synchronized with the status of AX5 series PLC CPU, and it will be either 1 (Run) or 2 (Stop).
Page 301 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.3.5.3 Mode Setting Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Mode Setting USINT 16#02 CH1 Mode Setting USINT 16#03 CH2 Mode Setting USINT 16#04 CH3 Mode Setting...
Page 302 AX-5 Ser i es M od ul e M an ua l Explanation  When there is an obvious difference between input values and actual values, you can change Offset and Gain to correct the input curve. The formula is Example The mode of channels is -10.0 to +10.0 V.
Page 303 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les such as oscilloscope waveform and electrocardiography that require demanding waveforms. Frequency response of IIR filter Frequency response of IIR filter (enlarged figure) FIR (Finite impulse response) Filter A finite impulse response filter attenuates unwanted frequency from the input signals.
Page 304 AX-5 Ser i es M od ul e M an ua l 50 Hz low-pass FIR filter 60 Hz low-pass FIR filter Digital filter modes  Mode Name of digital filter Cut-off frequency (-3 dB) Inactive Moving Average Works with Moving Average Time IIR1 1000 Hz IIR2...
Page 305 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.3.5.6 User Limit Alarm Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Enable User Limit Alarm DINT USINT 16#02 CH1 Enable User Limit Alarm DINT USINT 16#03 CH2 Enable User Limit Alarm DINT...
Page 306 AX-5 Ser i es M od ul e M an ua l Index Subindex Name Description Data Type Attr. Default 16#04 CH3 User Upper Limit REAL REAL 10.0 16#05 CH0 User Upper Limit REAL REAL 10.0 16#06 CH1 User Upper Limit REAL REAL 10.0 16#07...
Page 307 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.3.5.7 Exceed Hardware Limit Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Exceed Hardware Limit Setting USINT 16#02 CH1 Exceed Hardware Limit Setting USINT 16#03 CH2 Exceed Hardware Limit Setting...
Page 308 AX-5 Ser i es M od ul e M an ua l 5.3.5.9 Scale Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Scale Upper Limit REAL REAL 10.0 16#02 CH1 Scale Upper Limit REAL REAL 10.0 16#03 CH2 Scale Upper Limit REAL REAL 10.0 16#04...
Page 309 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.3.5.10 ADC Raw Data Index Subindex Name Description Data Type Attr. Default 16#01 CH0 ADC Raw data DINT 16#02 CH1 ADC Raw data DINT 16#03 CH2 ADC Raw data DINT...
Page 310 AX-5 Ser i es M od ul e M an ua l 5.3.6 EtherCAT Operation Modes There are two modes for EtherCAT modules to run during operation, FreeRun mode (non-synchronization mode) and DC mode (synchronization mode). Different synchronization modes can be applied to different modules in the same system. 5.3.6.1 FreeRun Mode The I/O values of each module are refreshed based on its own cycle.
Page 311 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.3.7 Process Data This section introduces the settings and monitoring of PDO data exchange. Index Subindex Name Description Data Type Attr. Default 16#6000 16#01 CH0 Analog Input Value DINT 16#6001...
Page 312 AX-5 Ser i es M od ul e M an ua l 5.3.7.2 EtherCAT I/O Mapping The corresponding data from the Process Data will be shown in the tab of EtherCAT I/O Mapping. 5.3.7.3 Always Update Variables This field is for global setting to define whether or not the I/O variables in the bus cycle task are updated. Option Description DIADesigner-AX updates the I/O variables according to the...
Page 313 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.3.8 Troubleshooting In the Diagnosis History tab, the error information that has occurred on the module is recorded. In the Status tab, the current information of system error (16#A000) is displayed. In the CoE Parameters tab, you can view the error status through Index/SubIndex of the All Parameter list.
Page 314 AX-5 Ser i es M od ul e M an ua l AX-508AD20-0A AX-508AD20-0A, an analog input module, receives analog current signals through 8 input points and converts the received signals to 16-bit digital signals. This section introduces its specifications, wirings and operations. 5.4.1 Specifications Item...
Page 315 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.4.2 Dimensions and Parts Dimensions  Unit: mm 5 - 8 9...
Page 316 AX-5 Ser i es M od ul e M an ua l ⑪ ⑤ ④ ⑫ ⑥ ① ⑦ ② ⑧ ③ ⑨ ⑩ Parts  Name AX connector (L) Label (manufacturer information, service information, safety, serial number, firmware/hardware version) DIN rail clip System status indicator Model code...
Page 317 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.4.3 Arrangement of Terminals, LED Indicators and Wiring 5.4.3.1 Arrangement of Terminals System LED ERROR LED Channel RUN LED *1. The marked black areas are terminals with LED indicators. Refer to the table below to see their corresponding channels.
Page 318 AX-5 Ser i es M od ul e M an ua l 5.4.3.2 LED Indicators Name Color Status Description No power supplied or ECAT INIT Blinking (0.2 s) ECAT Pre OP System Blue Blinking (1 s) ECAT Safe OP Normal OP No power supplied or the module is functioning correctly.
Page 319 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Loop Configuration  Input current -20 to +20 mA 1 mΩ I0+ to I7+ CH0 to CH7 250 Ω I0- to I7- 1 mΩ Shielded cable *1 Power isolation Unit...
Page 320 AX-5 Ser i es M od ul e M an ua l 5.4.4 Settings in DIADesigner-AX The software DIADesigner-AX is the programming tool for the AX Series PLCs. This section introduces some basic operations and settings. 5.4.4.1 Basic Operation Double-click the DIADesigner-AX icon to open the software and create a new project. 5 - 9 4...
Page 321 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Add Modules in Method 1: Add the modules in manually  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Add Device… to select and add System Coupler.
Page 322 AX-5 Ser i es M od ul e M an ua l Method 2: Scan to add the modules in.  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Scan for Devices…. After the auto-scan is over, the actually connected devices will appear. Click Copy All Devices to Project button to add them to the list under EtherCAT Master SoftMotion.
Page 323 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.4.4.2 Parameter Settings In the CoE Parameters tab, you can do the following settings of parameters. Favorites You can select and right-click the parameter to add the selected parameter to the Favorites. Click on the ...
Page 324 AX-5 Ser i es M od ul e M an ua l Startup Parameters Once the module is started up, the setting values of parameters in the Startup Parameters list are written to the  module. For editing, you have to set up these parameters in offline mode. Icon Function Description...
Page 325 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Icon Function Description Compare Compare Upload the selected parameters from the Upload Selection from Device module to DIADesigner-AX. Upload all the parameters from the module to Upload All from Device DIADesigner-AX.
Page 326 AX-5 Ser i es M od ul e M an ua l  You can select and right-click the parameter to add the selected parameter to the Favorites. Function Description Add to Favorites Add the selected to Favorites Add to Startup Parameters Add the selected to Startup Parameters Import…...
Page 327 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Click on the toolbar to go into online mode. In the EtherCAT I/O Mapping tab, you can find the variables, current value, status and error codes for each channel. 5.4.4.4 Diagnosis History Click on the toolbar to go into online mode.
Page 328 AX-5 Ser i es M od ul e M an ua l 5.4.4.5 Status Click on the toolbar to go into online mode. In the Status tab, you can monitor the current status and latest diagnostic messages of the module. 5.4.4.6 Information In the Information tab, you can find the module information, including Name, Vendor, Categories, Type, ID, Version, Order Number and Description for the module.
Page 329 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.4.5 Parameter Descriptions You can use DIADesigner-AX to set up the functions for the module by directly selecting the setting mode and parameters. For software operation, refer to section 5.4.4 for more information. The function blocks in the software are available for you to set relevant parameters.
Page 330 AX-5 Ser i es M od ul e M an ua l 5.4.5.1 Module Status Index Subindex Name Description Data Type Attr. Default 16#5000 16#01 Module Status Status of the module UINT Explanation  When the AX5 series PLC is used as the controller, the module status is synchronized with the status of AX5 series PLC CPU, and it will be either 1 (Run) or 2 (Stop).
Page 331 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.4.5.3 Mode Setting Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Mode Setting USINT 16#02 CH1 Mode Setting USINT 16#03 CH2 Mode Setting USINT 16#04 CH3 Mode Setting...
Page 332 AX-5 Ser i es M od ul e M an ua l Explanation  When there is an obvious difference between input values and actual values, you can change Offset and Gain to correct the input curve. The formula is Example The mode of channels is -20.0 to +20.0 mA.
Page 333 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les an IIR filter works more efficiently than a moving average filter does. This IIR filter is a low-pass filter. The advantage of an IIR filter is that within the same length of operation time, the filtering result of an IIR filter is better than what a FIR filter can offer.
Page 334 AX-5 Ser i es M od ul e M an ua l 50 Hz low-pass FIR filter 60 Hz low-pass FIR filter Digital filter modes  Mode Name of digital filter Cut-off frequency (-3 dB) Inactive Moving Average Works with Moving Average Time IIR1 1000 Hz IIR2...
Page 335 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.4.5.6 User Limit Alarm Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Enable User Limit Alarm DINT USINT 16#02 CH1 Enable User Limit Alarm DINT USINT 16#03 CH2 Enable User Limit Alarm DINT...
Page 336 AX-5 Ser i es M od ul e M an ua l Index Subindex Name Description Data Type Attr. Default 16#04 CH3 User Upper Limit REAL REAL 10.0 16#05 CH0 User Upper Limit REAL REAL 10.0 16#06 CH1 User Upper Limit REAL REAL 10.0 16#07...
Page 337 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.4.5.7 Exceed Hardware Limit Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Exceed Hardware Limit Setting USINT 16#02 CH1 Exceed Hardware Limit Setting USINT 16#03 CH2 Exceed Hardware Limit Setting...
Page 338 AX-5 Ser i es M od ul e M an ua l 5.4.5.9 Scale Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Scale Upper Limit REAL REAL 20.0 16#02 CH1 Scale Upper Limit REAL REAL 20.0 16#03 CH2 Scale Upper Limit REAL REAL 20.0 16#04...
Page 339 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.4.5.10 ADC Raw Data Index Subindex Name Description Data Type Attr. Default 16#01 CH0 ADC Raw data DINT 16#02 CH1 ADC Raw data DINT 16#03 CH2 ADC Raw data DINT...
Page 340 AX-5 Ser i es M od ul e M an ua l 5.4.6 EtherCAT Operation Modes There are two modes for EtherCAT modules to run during operation, FreeRun mode (non-synchronization mode) and DC mode (synchronization mode). Different synchronization modes can be applied to different modules in the same system. 5.4.6.1 FreeRun Mode The I/O values of each module are refreshed based on its own cycle.
Page 341 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.4.7 Process Data This section introduces the settings and monitoring of PDO data exchange. Index Subindex Name Description Data Type Attr. Default 16#6000 16#01 CH0 Analog Input Value DINT 16#6001...
Page 342 AX-5 Ser i es M od ul e M an ua l 5.4.7.1 Process Data Go to the Process Data tab and select the data that you’d like to monitor. Analog Input Value: You can monitor the selected channels and deselect the unused channels to save cycle time. ...
Page 343 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.4.7.3 Always Update Variables This field is for global setting to define whether or not the I/O variables in the bus cycle task are updated. Option Description DIADesigner-AX updates the I/O variables according to the...
Page 344 AX-5 Ser i es M od ul e M an ua l AX-504DA01-0A AX-504DA01-0A, an analog output module, receives 4 sets of 16-bit digital data from the PLC and converts the received digital signals into analog voltage signals which are output through 4 output points. This section introduces its specifications, wirings and operations.
Page 345 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.5.2 Dimensions and Parts Dimensions  Unit: mm 5 - 11 9...
Page 346 AX-5 Ser i es M od ul e M an ua l Parts  ⑪ ⑤ ④ ⑫ ⑥ ① ⑦ ② ⑧ ③ ⑨ ⑩ Name AX connector (L) Label (manufacturer information, service information, safety, serial number, firmware/hardware version) DIN rail clip System status indicator Model code...
Page 347 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.5.3 Arrangement of Terminals, LED Indicators and Wiring 5.5.3.1 Arrangement of Terminals System LED ERROR LED Channel RUN LED *1. The marked black areas are terminals with LED indicators. Refer to the table below to see their corresponding channels.
Page 348 AX-5 Ser i es M od ul e M an ua l 5.5.3.2 LED Indicators Name Color Status Description No power supplied or ECAT INIT Blinking (0.2 s) ECAT Pre OP System Blue Blinking (1 s) ECAT Safe OP Normal OP No power supplied or the module is functioning correctly.
Page 349 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Loop Configuration  Output voltage -10 to +10V Shielded cable *1 CH0 to CH3 V0+ to V3+ AC motor drive, recorder, proportioning valve Power isolation Unit Unit Power...
Page 350 AX-5 Ser i es M od ul e M an ua l 5.5.4 Settings in DIADesigner-AX The software DIADesigner-AX is the programming tool for the AX Series PLCs. This section introduces some basic operations and settings. 5.5.4.1 Basic Operation Double-click the DIADesigner-AX icon to open the software and create a new project. 5 - 1 2 4...
Page 351 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Add Modules in Method 1: Add the modules in manually  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Add Device… to select and add System Coupler.
Page 352 AX-5 Ser i es M od ul e M an ua l Method 2: Scan to add the modules in.  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Scan for Devices…. After the auto-scan is over, the actually connected devices will appear. Click Copy All Devices to Project button to add them to the list under EtherCAT Master SoftMotion.
Page 353 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.5.4.2 Parameter Settings In the CoE Parameters tab, you can do the following settings of parameters. Favorites You can select and right-click the parameter to add the selected parameter to the Favorites. Click on the ...
Page 354 AX-5 Ser i es M od ul e M an ua l Startup Parameters Once the module is started up, the setting values of parameters in the Startup Parameters list are written to the  module. For editing, you have to set up these parameters in offline mode. Icon Function Description...
Page 355 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les All Parameters You can find all the CoE parameters here. Click on the toolbar to go into online mode first, and then you can ...
Page 356 AX-5 Ser i es M od ul e M an ua l  You can select and right-click the parameter to add the selected parameter to the Favorites. Function Description Add to Favorites Add the selected to Favorites Add to Startup Parameters Add the selected to Startup Parameters Import…...
Page 357 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.5.4.4 Diagnosis History Click on the toolbar to go into online mode. The Diagnosis History tab records all error information that occurred on the module. Message column shows the TEXT ID plus error description. Please refer to the troubleshooting section for details on errors 5.5.4.5 Status Click...
Page 358 AX-5 Ser i es M od ul e M an ua l 5.5.4.6 Information In the Information tab, you can find the module information, including Name, Vendor, Categories, Type, ID, Version, Order Number and Description for the module. Click on the toolbar to go into online mode. Go to the All Parameters page in the CoE Parameters tab, and then you can find the hardware version and software version.
Page 359 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.5.5 Parameter Descriptions You can use DIADesigner-AX to set up the functions for the module by directly selecting the setting mode and parameters. For software operation, refer to section 5.5.4 for more information. The function blocks in the software are available for you to set relevant parameters.
Page 360 AX-5 Ser i es M od ul e M an ua l 5.5.5.1 Module Status Index Subindex Name Description Data Type Attr. Default 16#5000 16#01 Module Status Status of the module UINT Explanation  When the AX5 series PLC is used as the controller, the module status is synchronized with the status of AX5 series PLC CPU, and it will be either 1 (Run) or 2 (Stop).
Page 361 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Supported modes  Mode Mode range DINT range Disable -10 to 10 V ±30000 0 to 10 V 0 to 30000 -5 to 5 V ±30000 0 to 5 V 0 to 30000...
Page 362 AX-5 Ser i es M od ul e M an ua l 5.5.5.5 Output Setting and Value Setting when EtherCAT Connection Lost Data Index Subindex Name Description Attr. Default Type CH0 Output Setting when EtherCAT Connection 16#01 USINT Lost DINT CH1 Output Setting when EtherCAT Connection 16#02 USINT...
Page 363 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.5.5.6 Output Setting and Value Setting when Module in Stopped State Data Index Subindex Name Description Attr. Default Type CH0 Output Setting when Module in Stopped 16#01 USINT State DINT...
Page 364 AX-5 Ser i es M od ul e M an ua l 5.5.5.7 Format Index Subindex Name Description Data Type Attr. Default 0: DINT Format 16#8010 16#01 Format USINT 1: REAL Format Explanation  You can set the format and the decimal places according to your demand. When the data format is set to DINT Format, set up the DINT parameters which are with “DINT”...
Page 365 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.5.5.9 DAC Raw Data Index Subindex Name Description Data Type Attr. Default 16#01 CH0 DAC Raw data DINT 16#02 CH1 DAC Raw data DINT 16#8100 Raw data 16#03...
Page 366 AX-5 Ser i es M od ul e M an ua l 5.5.6 EtherCAT Operation Modes There are two modes for EtherCAT modules to run during operation, FreeRun mode (non-synchronization mode) and DC mode (synchronization mode). Different synchronization modes can be applied to different modules in the same system. 5.5.6.1 FreeRun Mode The I/O values of each module are refreshed based on its own cycle.
Page 367 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.5.7 Process Data This section introduces the settings and monitoring of PDO data exchange. Index Subindex Name Description Data Type Attr. Default 16#7000 16#01 CH0 Analog Output Value DINT 16#7001...
Page 368 AX-5 Ser i es M od ul e M an ua l 5.5.7.3 Always Update Variables This field is for global setting to define whether or not the I/O variables in the bus cycle task are updated. Option Description DIADesigner-AX updates the I/O variables according to the Use parent device setting Always update variables in the CPU setting for the...
Page 369 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les AX-504DA02-0A AX-504DA02-0A, an analog output module, receives 4 sets of 16-bit digital data from the PLC and converts the received digital signals to analog current signals, which are output through 4 output points. This section introduces its specifications, wirings and operations.
Page 370 AX-5 Ser i es M od ul e M an ua l 5.6.2 Dimensions and Parts Dimensions  Unit: mm 5 - 1 4 4...
Page 371 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Parts  ⑪ ⑤ ④ ⑫ ⑥ ① ⑦ ② ⑧ ③ ⑨ ⑩ Name AX connector (L) Label (manufacturer information, service information, safety, serial number, firmware/hardware version) DIN rail clip System status indicator...
Page 372 AX-5 Ser i es M od ul e M an ua l 5.6.3 Arrangement of Terminals, LED Indicators and Wiring 5.6.3.1 Arrangement of Terminals System LED ERROR LED Channel RUN LED *1. The marked black areas are terminals with LED indicators. Refer to the table below to see their corresponding channels.
Page 373 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.6.3.2 LED Indicators Name Color Status Description No power supplied or ECAT INIT Blinking (0.2 s) ECAT Pre OP System Blue Blinking (1 s) ECAT Safe OP Normal OP No power supplied or the module is...
Page 374 AX-5 Ser i es M od ul e M an ua l Loop Configuration  CH0 to CH3 Output current 0 to +20 mA Shield cable*1 I0+ to I3+ AC motor drive, recorder, proportioning valve Power isolation Unit Unit Power Power AX Connector AX Connector...
Page 375 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.6.4 Settings in DIADesigner-AX The software DIADesigner-AX is the programming tool for the AX Series PLCs. This section introduces some basic operations and settings. 5.6.4.1 Basic Operation Double-click the DIADesigner-AX icon to open the software and create a new project.
Page 376 AX-5 Ser i es M od ul e M an ua l Add Modules in Method 1: Add the modules in manually  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Add Device… to select and add System Coupler.
Page 377 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Method 2: Scan to add the modules in.  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Scan for Devices…. After the auto-scan is over, the actually connected devices will appear. Click Copy All Devices to Project button to add them to the list under EtherCAT Master SoftMotion.
Page 378 AX-5 Ser i es M od ul e M an ua l 5.6.4.2 Parameter Settings In the CoE Parameters tab, you can do the following settings of parameters. Favorites You can select and right-click the parameter to add the selected parameter to the Favorites. Click on the ...
Page 379 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Startup Parameters Once the module is started up, the setting values of parameters in the Startup Parameters list are written to the  module. For editing, you have to set up these parameters in offline mode. Icon Function Description...
Page 380 AX-5 Ser i es M od ul e M an ua l All Parameters You can find all the CoE parameters here. Click on the toolbar to go into online mode first, and then you can  start to upload and download the parameters. After clicking the upload button, you can see the current values in Current Value column.
Page 381 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les  You can select and right-click the parameter to add the selected parameter to the Favorites. Function Description Add to Favorites Add the selected to Favorites Add to Startup Parameters Add the selected to Startup Parameters Import…...
Page 382 AX-5 Ser i es M od ul e M an ua l 5.6.4.4 Diagnosis History Click on the toolbar to go into online mode. The Diagnosis History tab records all error information that occurred on the module. Message column shows the TEXT ID plus error description. Please refer to the troubleshooting section for details on errors 5.6.4.5 Status Click...
Page 383 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.6.4.6 Information In the Information tab, you can find the module information, including Name, Vendor, Categories, Type, ID, Version, Order Number and Description for the module. Click on the toolbar to go into online mode.
Page 384 AX-5 Ser i es M od ul e M an ua l 5.6.5 Parameter Descriptions You can use DIADesigner-AX to set up the functions for the module by directly selecting the setting mode and parameters. For software operation, refer to section 5.6.4 for more information. The function blocks in the software are available for you to set relevant parameters.
Page 385 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.6.5.1 Module Status Index Subindex Name Description Data Type Attr. Default 16#5000 16#01 Module Status Status of the module UINT Explanation  When the AX5 series PLC is used as the controller, the module status is synchronized with the status of AX5 series PLC CPU, and it will be either 1 (Run) or 2 (Stop).
Page 386 AX-5 Ser i es M od ul e M an ua l 5.6.5.3 Mode Setting Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Mode Setting USINT 16#02 CH1 Mode Setting USINT 16#8000 Current mode setting 16#03 CH2 Mode Setting USINT 16#04 CH3 Mode Setting...
Page 387 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.6.5.5 Output Setting and Value Setting when EtherCAT Connection Lost Data Index Subindex Name Description Attr. Default Type CH0 Output Setting when EtherCAT Connection 16#01 USINT Lost DINT...
Page 388 AX-5 Ser i es M od ul e M an ua l 5.6.5.6 Output Setting and Value Setting when Module in Stopped State Data Index Subindex Name Description Attr. Default Type CH0 Output Setting when Module in Stopped 16#01 USINT State DINT CH1 Output Setting when Module in Stopped 16#02...
Page 389 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.6.5.7 Format Index Subindex Name Description Data Type Attr. Default 0: DINT Format 16#8010 16#01 Format USINT 1: REAL Format Explanation  You can set the format and the decimal places according to your demand. When the data format is set to DINT Format, set up the DINT parameters which are with “DINT”...
Page 390 AX-5 Ser i es M od ul e M an ua l 5.6.5.9 DAC Raw Data Index Subindex Name Description Data Type Attr. Default 16#01 CH0 DAC Raw data DINT 16#02 CH1 DAC Raw data DINT 16#8100 Raw data 16#03 CH2 DAC Raw data DINT 16#04...
Page 391 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.6.6 EtherCAT Operation Modes There are two modes for EtherCAT modules to run during operation, FreeRun mode (non-synchronization mode) and DC mode (synchronization mode). Different synchronization modes can be applied to different modules in the same system. 5.6.6.1 FreeRun Mode The I/O values of each module are refreshed based on its own cycle.
Page 392 AX-5 Ser i es M od ul e M an ua l 5.6.7 Process Data This section introduces the settings and monitoring of PDO data exchange. Index Subindex Name Description Data Type Attr. Default 16#7000 16#01 CH0 Analog Output Value DINT 16#7001 16#01...
Page 393 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.6.7.3 Always Update Variables This field is for global setting to define whether or not the I/O variables in the bus cycle task are updated. Option Description DIADesigner-AX updates the I/O variables according to the...
Page 394 AX-5 Ser i es M od ul e M an ua l AX-508DA01-0A AX-508DA01-0A, an analog output module, receives 8 sets of 16-bit digital data from the PLC and converts the received digital signals into analog voltage signals, which are output through 8 output points. This section introduces its specifications, wirings and operations.
Page 395 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.7.2 Dimensions and Parts Dimensions  Unit: mm 5 - 1 6 9...
Page 396 AX-5 Ser i es M od ul e M an ua l Parts  ⑪ ⑤ ④ ⑫ ⑥ ① ⑦ ② ⑧ ③ ⑨ ⑩ Name AX connector (L) Label (manufacturer information, service information, safety, serial number, firmware/hardware version) DIN rail clip System status indicator Model code...
Page 397 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.7.3 Arrangement of Terminals, LED Indicators and Wiring 5.7.3.1 Arrangement of Terminals System LED ERROR LED Channel RUN LED *1. The marked black areas are terminals with LED indicators. Refer to the table below to see their corresponding channels.
Page 398 AX-5 Ser i es M od ul e M an ua l 5.7.3.2 LED Indicators Name Color Status Description No power supplied or ECAT INIT Blinking (0.2 s) ECAT Pre OP System Blue Blinking (1 s) ECAT Safe OP Normal OP No power supplied or the module is functioning correctly.
Page 399 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Loop Configuration  Output voltage Shielded cable *1 -10 to +10V CH0 to CH7 V0+ to V7+ AC motor drive, recorder, proportioning valve Power isolation Unit Unit Power...
Page 400 AX-5 Ser i es M od ul e M an ua l 5.7.4 Settings in DIADesigner-AX The software DIADesigner-AX is the programming tool for the AX Series PLCs. This section introduces some basic operations and settings. 5.7.4.1 Basic Operation Double-click the DIADesigner-AX icon to open the software and create a new project. 5 - 1 7 4...
Page 401 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Add Modules in Method 1: Add the modules in manually  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Add Device… to select and add System Coupler.
Page 402 AX-5 Ser i es M od ul e M an ua l Method 2: Scan to add the modules in.  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Scan for Devices…. After the auto-scan is over, the actually connected devices will appear. Click Copy All Devices to Project button to add them to the list under EtherCAT Master SoftMotion.
Page 403 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.7.4.2 Parameter Settings In the CoE Parameters tab, you can do the following settings of parameters. Favorites You can select and right-click the parameter to add the selected parameter to the Favorites. Click on the ...
Page 404 AX-5 Ser i es M od ul e M an ua l Startup Parameters Once the module is started up, the setting values of parameters in the Startup Parameters list are written to the  module. For editing, you have to set up these parameters in offline mode. Icon Function Description...
Page 405 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les All Parameters You can find all the CoE parameters here. Click on the toolbar to go into online mode first, and then you can ...
Page 406 AX-5 Ser i es M od ul e M an ua l  You can select and right-click the parameter to add the selected parameter to the Favorites. Function Description Add to Favorites Add the selected to Favorites Add to Startup Parameters Add the selected to Startup Parameters Import…...
Page 407 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.7.4.4 Diagnosis History Click on the toolbar to go into online mode. The Diagnosis History tab records all error information that occurred on the module. Message column shows the TEXT ID plus error description. Please refer to the troubleshooting section for details on errors 5.7.4.5 Status Click...
Page 408 AX-5 Ser i es M od ul e M an ua l 5.7.4.6 Information In the Information tab, you can find the module information, including Name, Vendor, Categories, Type, ID, Version, Order Number and Description for the module. Click on the toolbar to go into online mode. Go to the All Parameters page in the CoE Parameters tab, and then you can find the hardware version and software version.
Page 409 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.7.5 Parameter Descriptions You can use DIADesigner-AX to set up the functions for the module by directly selecting the setting mode and parameters. For software operation, refer to section 5.7.4 for more information. The function blocks in the software are available for you to set relevant parameters.
Page 410 AX-5 Ser i es M od ul e M an ua l 5.7.5.1 Module Status Index Subindex Name Description Data Type Attr. Default 16#5000 16#01 Module Status Status of the module UINT Explanation  When the AX5 series PLC is used as the controller, the module status is synchronized with the status of AX5 series PLC CPU, and it will be either 1 (Run) or 2 (Stop).
Page 411 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.7.5.3 Mode Setting Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Mode Setting USINT 16#02 CH1 Mode Setting USINT 16#03 CH2 Mode Setting USINT 16#04 CH3 Mode Setting...
Page 412 AX-5 Ser i es M od ul e M an ua l 5.7.5.4 Calibration Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Calibration Offset REAL 16#02 CH1 Calibration Offset REAL 16#03 CH2 Calibration Offset REAL 16#04 CH3 Calibration Offset REAL Offset 16#8001...
Page 413 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.7.5.5 Output Setting and Value Setting when EtherCAT Connection Lost Data Index Subindex Name Description Attr. Default Type CH0 Output Setting when EtherCAT Connection 16#01 USINT Lost DINT...
Page 414 AX-5 Ser i es M od ul e M an ua l Data Index Subindex Name Description Attr. Default Type CH4 Output Value Settings when EtherCAT 16#05 REAL Connection Lost REAL CH5 Output Value Settings when EtherCAT 16#06 REAL Connection Lost REAL CH6 Output Value Settings when EtherCAT 16#07 REAL...
Page 415 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.7.5.6 Output Setting and Value Setting when Module in Stopped State Data Index Subindex Name Description Attr. Default Type CH0 Output Setting when Module in Stopped 16#01 USINT State DINT...
Page 416 AX-5 Ser i es M od ul e M an ua l Data Index Subindex Name Description Attr. Default Type CH0 Output Value Settings when Module in 16#05 REAL Stopped State REAL CH1 Output Value Settings when Module in 16#06 REAL Stopped State REAL CH2 Output Value Settings when Module in...
Page 417 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.7.5.8 Scale Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Scale Upper Limit REAL REAL 10.0 16#02 CH1 Scale Upper Limit REAL REAL 10.0 16#03...
Page 418 AX-5 Ser i es M od ul e M an ua l 5.7.5.9 DAC Raw Data Index Subindex Name Description Data Type Attr. Default 16#01 CH0 DAC Raw data DINT 16#02 CH1 DAC Raw data DINT 16#03 CH2 DAC Raw data DINT 16#04 CH3 DAC Raw data...
Page 419 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.7.6 EtherCAT Operation Modes There are two modes for EtherCAT modules to run during operation, FreeRun mode (non-synchronization mode) and DC mode (synchronization mode). Different synchronization modes can be applied to different modules in the same system. 5.7.6.1 FreeRun Mode The I/O values of each module are refreshed based on its own cycle.
Page 420 AX-5 Ser i es M od ul e M an ua l 5.7.7 Process Data This section introduces the settings and monitoring of PDO data exchange. Index Subindex Name Description Data Type Attr. Default 16#7000 16#01 CH0 Analog Output Value DINT 16#7001 16#01...
Page 421 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.7.7.2 EtherCAT I/O Mapping The corresponding data from the Process Data will be shown in the tab of EtherCAT I/O Mapping. 5.7.7.3 Always Update Variables This field is for global setting to define whether or not the I/O variables in the bus cycle task are updated.
Page 422 AX-5 Ser i es M od ul e M an ua l AX-502TC10-0B AX-502TC10-0B, a temperature measurement module, converts the values received from the external thermocouple sensors into digital signals. You can select either Celsius or Fahrenheit as the unit of measurement. This section describes its specifications, wirings and operations.
Page 423 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.8.2 Dimensions and Parts Dimensions  Unit: mm Parts  ⑪ ⑤ ④ ⑫ ⑥ ① ⑦ ② ⑧ ③ ⑨ ⑩ Name AX connector (L) Label (manufacturer information, service information, safety, serial number, firmware/hardware version) DIN rail clip...
Page 424 AX-5 Ser i es M od ul e M an ua l 5.8.3 Arrangement of Terminals, LED Indicators and Wiring 5.8.3.1 Arrangement of Terminals System LED ERROR LED Channel RUN LED *1. The marked black areas are terminals with LED indicators. Refer to the table below to see their corresponding channels.
Page 425 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.8.3.2 LED Indicators Name Color Status Description No power supplied or ECAT INIT Blinking (0.2 s) ECAT Pre OP System Blue Blinking (1 s) ECAT Safe OP Normal OP No power supplied or the module is...
Page 426 AX-5 Ser i es M od ul e M an ua l Loop Configuration  Shielded cable *1 J, K, R, S, T, E, N, B, L, U, C, PLⅡ Input voltage Shielded cable *1 -130 to 130mV Power isolation Unit Unit Power...
Page 427 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.8.4 Settings in DIADesigner-AX The software DIADesigner-AX is the programming tool for the AX Series PLCs. This section introduces some basic operations and settings. 5.8.4.1 Basic Operation Double-click the DIADesigner-AX icon to open the software and create a new project.
Page 428 AX-5 Ser i es M od ul e M an ua l Add Modules in Method 1: Add the modules in manually  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Add Device… to select and add System Coupler.
Page 429 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Method 2: Scan to add the modules in.  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Scan for Devices…. After the auto-scan is over, the actually connected devices will appear. Click Copy All Devices to Project button to add them to the list under EtherCAT Master SoftMotion.
Page 430 AX-5 Ser i es M od ul e M an ua l 5.8.4.2 Parameter Settings In the CoE Parameters tab, you can do the following settings of parameters. Favorites You can select and right-click the parameter to add the selected parameter to the Favorites. Click on the ...
Page 431 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Startup Parameters Once the module is started up, the setting values of parameters in the Startup Parameters list are written to the  module. For editing, you have to set up these parameters in offline mode. Icon Function Description...
Page 432 AX-5 Ser i es M od ul e M an ua l All Parameters You can find all the CoE parameters here. Click on the toolbar to go into online mode first, and then you can  start to upload and download the parameters. After clicking the upload button, you can see the current values in Current Value column.
Page 433 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les  You can select and right-click the parameter to add the selected parameter to the Favorites. Function Description Add to Favorites Add the selected to Favorites Add to Startup Parameters Add the selected to Startup Parameters Import…...
Page 434 AX-5 Ser i es M od ul e M an ua l 5.8.4.4 Diagnosis History Click on the toolbar to go into online mode. The Diagnosis History tab records all error information that occurred on the module. Message column shows the TEXT ID plus error description. Please refer to the troubleshooting section for details on errors 5.8.4.5 Status Click...
Page 435 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.8.4.6 Information In the Information tab, you can find the module information, including Name, Vendor, Categories, Type, ID, Version, Order Number and Description for the module. Click on the toolbar to go into online mode.
Page 436 AX-5 Ser i es M od ul e M an ua l 5.8.5 Parameter Descriptions You can use DIADesigner-AX to set up the functions for the module by directly selecting the setting mode and parameters. For software operation, refer to section 5.8.4 for more information. The function blocks in the software are available for you to set relevant parameters.
Page 437 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.8.5.1 Module Status Index Subindex Name Description Data Type Attr. Default 16#5000 16#01 Module Status Status of the module UINT Explanation  When the AX5 series PLC is used as the controller, the module status is synchronized with the status of AX5 series PLC CPU, and it will be either 1 (Run) or 2 (Stop).
Page 438 AX-5 Ser i es M od ul e M an ua l Supported modes  Setting value Mode Setting range (°C) Setting range (°F) Disable -200 to 1200°C -328 to 2192°F -200 to 1360°C -328 to 2480°F -200 to 400°C -328 to 752°F -200 to 1000°C -328 to 1832°F...
Page 439 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.8.5.5 Digital Filter Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Digital Filter Setting USINT 16#8003 Digital filter setting 16#02 CH1 Digital Filter Setting USINT Moving average times 16#01...
Page 440 AX-5 Ser i es M od ul e M an ua l FIR (Finite impulse response) Filter A finite impulse response filter attenuates unwanted frequency from the input signals. In terms of attenuating noises, a FIR filter works more efficiently than a moving average filter does. This FIR filter is a low-pass filter. The advantage of a FIR filter is that it has a linear phase response which means a FIR filter has a consistent output delay at all frequencies while an IIR filter has an unequal delay at different frequencies.
Page 441 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.8.5.6 User Limit Alarm Index Subindex Name Description Data Type Attr. Default Enable/disable the alarm 16#01 CH0 Enable User Limit Alarm of exceeding the user- defined limit 16#8003 USINT...
Page 442 AX-5 Ser i es M od ul e M an ua l 5.8.5.7 Decimal Places Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Decimal Places USINT Decimal places; 16#8010 Setting value: 0 to 1 16#02 CH1 Decimal Places USINT Explanation ...
Page 443 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.8.5.11 CJ Temperature Index Subindex Name Description Data Type Attr. Default 16#01 CH0 CJ Temperature DINT Temperature of the internal 16#8101 cold junction (CJ) 16#02 CH1 CJ Temperature DINT...
Page 444 AX-5 Ser i es M od ul e M an ua l 5.8.7.1 Process Data Go to the Process Data tab and select the data that you’d like to monitor. Analog Input Value: You can monitor the selected channels and deselect the unused channels to save cycle time. ...
Page 445 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.8.7.3 EtherCAT I/O Mapping The corresponding data from the Process Data will be shown in the tab of EtherCAT I/O Mapping. 5.8.7.4 Always Update Variables This field is for global setting to define whether or not the I/O variables in the bus cycle task are updated.
Page 446 AX-5 Ser i es M od ul e M an ua l 5.8.8 Troubleshooting In the Diagnosis History tab, the error information that has occurred on the module is recorded. In the Status tab, the current error information is displayed. In the CoE Parameters tab, you can view the error status through Index/SubIndex of the All Parameter list.
Page 447 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les AX-504TC10-0B AX-504TC10-0B, a temperature measurement module, converts the values received from the external thermocouple sensors into digital signals. You can select either Celsius or Fahrenheit as the unit of measurement. This section describes its specifications, wirings and operations.
Page 448 AX-5 Ser i es M od ul e M an ua l 5.9.2 Dimensions and Parts Dimensions  Unit: mm 5 - 2 2 2...
Page 449 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Parts  ⑪ ⑤ ④ ⑫ ⑥ ① ⑦ ② ⑧ ③ ⑨ ⑩ Name AX connector (L) Label (manufacturer information, service information, safety, serial number, firmware/hardware version) DIN rail clip System status indicator...
Page 450 AX-5 Ser i es M od ul e M an ua l 5.9.3 Arrangement of Terminals, LED Indicators and Wiring 5.9.3.1 Arrangement of Terminals System LED ERROR LED Channel RUN LED *1. The marked black areas are terminals with LED indicators. Refer to the table below to see their corresponding channels.
Page 451 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.9.3.2 LED Indicators Name Color Status Description No power supplied or ECAT INIT Blinking (0.2 s) ECAT Pre OP System Blue Blinking (1 s) ECAT Safe OP Normal OP No power supplied or the module is...
Page 452 AX-5 Ser i es M od ul e M an ua l Loop Configuration  Shielded cable *1 J, K, R, S, T, E, N, B, L, U, C, PLⅡ Input voltage Shielded cable *1 -130 to 130 mV Power isolation Unit Unit Power...
Page 453 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.9.4 Settings in DIADesigner-AX The software DIADesigner-AX is the programming tool for the AX Series PLCs. This section introduces some basic operations and settings. 5.9.4.1 Basic Operation Double-click the DIADesigner-AX icon to open the software and create a new project.
Page 454 AX-5 Ser i es M od ul e M an ua l Add Modules in Method 1: Add the modules in manually  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Add Device… to select and add System Coupler.
Page 455 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Method 2: Scan to add the modules in.  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Scan for Devices…. After the auto-scan is over, the actually connected devices will appear. Click Copy All Devices to Project button to add them to the list under EtherCAT Master SoftMotion.
Page 456 AX-5 Ser i es M od ul e M an ua l 5.9.4.2 Parameter Settings In the CoE Parameters tab, you can do the following settings of parameters. Favorites You can select and right-click the parameter to add the selected parameter to the Favorites. Click on the ...
Page 457 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Startup Parameters Once the module is started up, the setting values of parameters in the Startup Parameters list are written to the  module. For editing, you have to set up these parameters in offline mode. Icon Function Description...
Page 458 AX-5 Ser i es M od ul e M an ua l All Parameters You can find all the CoE parameters here. Click on the toolbar to go into online mode first, and then you can  start to upload and download the parameters. After clicking the upload button, you can see the current values in Current Value column.
Page 459 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les  You can select and right-click the parameter to add the selected parameter to the Favorites. Function Description Add to Favorites Add the selected to Favorites Add to Startup Parameters Add the selected to Startup Parameters Import…...
Page 460 AX-5 Ser i es M od ul e M an ua l 5.9.4.4 Diagnosis History Click on the toolbar to go into online mode. The Diagnosis History tab records all error information that occurred on the module. Message column shows the TEXT ID plus error description. Please refer to the troubleshooting section for details on errors 5.9.4.5 Status Click...
Page 461 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.9.4.6 Information In the Information tab, you can find the module information, including Name, Vendor, Categories, Type, ID, Version, Order Number and Description for the module. Click on the toolbar to go into online mode.
Page 462 AX-5 Ser i es M od ul e M an ua l 5.9.5 Parameter Descriptions You can use DIADesigner-AX to set up the functions for the module by directly selecting the setting mode and parameters. For software operation, refer to section 5.9.4 for more information. The function blocks in the software are available for you to set relevant parameters.
Page 463 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Status of the module  Value Status Description Controlled by EtherCAT State Machine The module is controlled by EtherCAT State Machine The module is controlled by the controller and the status of the Controlled by Controller (Run) controller is Run.
Page 464 AX-5 Ser i es M od ul e M an ua l Setting value Mode Setting range (°C) Setting range (°F) 200 – 1800 °C 392 – 3272 °F C (WRe5-26) 20 – 2300 °C 68 – 4172 °F PLII 0 –...
Page 465 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Explanation  The parameters here are for setting digital filter function. The module provides 3 types of filters, Moving Average Filter, Infinite Impulse Response (IIR) Filter and Finite Impulse Response (FIR) Filter for users to choose from. The conversion time will not be affected when the digital filter is enabled.
Page 466 AX-5 Ser i es M od ul e M an ua l FIR (Finite impulse response) Filter A finite impulse response filter attenuates unwanted frequency from the input signals. In terms of attenuating noises, a FIR filter works more efficiently than a moving average filter does. This FIR filter is a low-pass filter. The advantage of a FIR filter is that it has a linear phase response which means a FIR filter has a consistent output delay at all frequencies while an IIR filter has an unequal delay at different frequencies.
Page 467 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.9.5.6 User Limit Alarm Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Enable User Limit Alarm Enable/disable the alarm 16#02 CH1 Enable User Limit Alarm of exceeding the user- defined limit 16#8003...
Page 468 AX-5 Ser i es M od ul e M an ua l Hardware Range User Upper Limit Input Signal User Lower Limit Hardware Range Over Hardware Range Under Hardware Range Upper Limit Alarm Lower Limit Alarm 5.9.5.7 Decimal Places Index Subindex Name Description...
Page 469 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.9.5.9 CJC Function Index Subindex Name Description Data Type Attr. Default 16#01 CH0 CJC Function 16#02 CH1 CJC Function 0: Disable 16#8012 USINT 1: Enable 16#03 CH2 CJC Function 16#04...
Page 470 AX-5 Ser i es M od ul e M an ua l 5.9.6 EtherCAT Operation Modes There are two modes for EtherCAT modules to run during operation, FreeRun mode (non-synchronization mode) and DC mode (synchronization mode). Different synchronization modes can be applied to different modules in the same system. For temperature measurement modules, only FreeRun mode is supported.
Page 471 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.9.7 Process Data This section introduces the settings and monitoring of PDO data exchange. Index Subindex Name Description Data Type Attr. Default 16#6000 CH0 Analog Input Value 16#6001 CH1 Analog Input Value 16#01...
Page 472 AX-5 Ser i es M od ul e M an ua l 5.9.7.1 Process Data Go to the Process Data tab and select the data that you’d like to monitor. Analog Input Value: You can monitor the selected channels and deselect the unused channels to save cycle time. ...
Page 473 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.9.7.3 EtherCAT I/O Mapping The corresponding data from the Process Data will be shown in the tab of EtherCAT I/O Mapping. 5.9.7.4 Always Update Variables This field is for global setting to define whether or not the I/O variables in the bus cycle task are updated.
Page 474 AX-5 Ser i es M od ul e M an ua l 5.9.8 Troubleshooting In the Diagnosis History tab, the error information that has occurred on the module is recorded. In the Status tab, the current error information is displayed. In the CoE Parameters tab, you can view the error status through Index/SubIndex of the All Parameter list.
Page 475 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.10 AX-502PT10-0B AX-502PT10-0B, a temperature measurement module, converts the values received from the RTD sensors into digital signals. You can select either Celsius or Fahrenheit as the unit of measurement. This section describes its specifications, wirings and operations.
Page 476 AX-5 Ser i es M od ul e M an ua l 5.10.2 Dimensions and Parts Dimensions  Unit: mm 5 - 2 5 0...
Page 477 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Parts  ⑪ ⑤ ④ ⑫ ⑥ ① ⑦ ② ⑧ ③ ⑨ ⑩ Name AX connector (L) Label (manufacturer information, service information, safety, serial number, firmware/hardware version) DIN rail clip System status indicator...
Page 478 AX-5 Ser i es M od ul e M an ua l 5.10.3 Arrangement of Terminals, LED Indicators and Wiring 5.10.3.1 Arrangement of Terminals System LED ERROR LED Channel RUN LED RTD0 RTD1 *1. The marked black areas are terminals with LED indicators. Refer to the table below to see their corresponding channels.
Page 479 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.10.3.2 LED Indicators Name Color Status Description No power supplied or ECAT INIT Blinking (0.2 s) ECAT Pre OP System Blue Blinking (1 s) ECAT Safe OP Normal OP No power supplied or the module is...
Page 480 AX-5 Ser i es M od ul e M an ua l Loop Configuration  IDAC1 Pt100, Ni100, Pt1000, Ni1000, 0 to 300 Ω Shielded cable *1 IDAC2 2-Wire Pt100, Ni100, Pt1000, Ni1000, 0 to 300 Ω Shielded cable *1 3-Wire Shielded cable *1 Pt100, Ni100, Pt1000, Ni1000, 0 to 300 Ω...
Page 481 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.10.4 Settings in DIADesigner-AX The software DIADesigner-AX is the programming tool for the AX Series PLCs. This section introduces some basic operations and settings. 5.10.4.1 Basic Operation Double-click the DIADesigner-AX icon to open the software and create a new project.
Page 482 AX-5 Ser i es M od ul e M an ua l Add Modules in Method 1: Add the modules in manually  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Add Device… to select and add System Coupler.
Page 483 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Method 2: Scan to add the modules in.  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Scan for Devices…. After the auto-scan is over, the actually connected devices will appear. Click Copy All Devices to Project button to add them to the list under EtherCAT Master SoftMotion.
Page 484 AX-5 Ser i es M od ul e M an ua l 5.10.4.2 Parameter Settings In the CoE Parameters tab, you can do the following settings of parameters. Favorites You can select and right-click the parameter to add the selected parameter to the Favorites. Click on the ...
Page 485 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Startup Parameters Once the module is started up, the setting values of parameters in the Startup Parameters list are written to the  module. For editing, you have to set up these parameters in offline mode. Icon Function Description...
Page 486 AX-5 Ser i es M od ul e M an ua l All Parameters You can find all the CoE parameters here. Click on the toolbar to go into online mode first, and then you can  start to upload and download the parameters. After clicking the upload button, you can see the current values in Current Value column.
Page 487 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les  You can select and right-click the parameter to add the selected parameter to the Favorites. Function Description Add to Favorites Add the selected to Favorites Add to Startup Parameters Add the selected to Startup Parameters Import…...
Page 488 AX-5 Ser i es M od ul e M an ua l 5.10.4.4 Diagnosis History Click on the toolbar to go into online mode. The Diagnosis History tab records all error information that occurred on the module. Message column shows the TEXT ID plus error description. Please refer to the troubleshooting section for details on errors 5.10.4.5 Status Click...
Page 489 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.10.4.6 Information In the Information tab, you can find the module information, including Name, Vendor, Categories, Type, ID, Version, Order Number and Description for the module. Click on the toolbar to go into online mode.
Page 490 AX-5 Ser i es M od ul e M an ua l 5.10.5 Parameter Descriptions You can use DIADesigner-AX to set up the functions for the module by directly selecting the setting mode and parameters. For software operation, refer to section 5.10.4 for more information. The function blocks in the software are available for you to set relevant parameters.
Page 491 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Status of the module  Value Status Description Controlled by EtherCAT State Machine The module is controlled by EtherCAT State Machine The module is controlled by the controller and the status of the Controlled by Controller (Run) controller is Run.
Page 492 AX-5 Ser i es M od ul e M an ua l Setting value Mode Setting range (°C) Setting range (°F) Ni100 (2 Wire) -100℃–260℃ -148℉–500℉ Ni100 (2 Wire) -100℃–260℃ -148℉–500℉ Ni100 (2 Wire) -100℃–260℃ -148℉–500℉ Ni1000 (2 Wire) -100℃–260℃ -148℉–500℉...
Page 493 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les IIR (Infinite Impulse Response) Filter An infinite impulse response filter attenuates unwanted frequency from the input signals. In terms of attenuating noises, an IIR filter works more efficiently than a moving average filter does. This IIR filter is a low-pass filter. The advantage of an IIR filter is that within the same length of operation time, the filtering result of an IIR filter is better than what a FIR filter can offer.
Page 494 AX-5 Ser i es M od ul e M an ua l Digital filter modes  Mode Name of digital filter Inactive Moving Average IIR1 IIR2 IIR3 IIR4 FIR4 FIR8 FIR16 FIR32 Conversion time for enabled channels and corresponding cut-off frequency of filters ...
Page 495 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Example  Set the parameters as follows: 16#8003 Enable User Limit Alarm: Enable 16#8004 User Upper Limit: 850 16#8005 User Lower Limit: -200 When the input signal exceeds the user-defined upper or lower limit, an error occurs. Hardware Range User Upper Limit Input Signal...
Page 496 AX-5 Ser i es M od ul e M an ua l 5.10.5.9 Compensation in two-wire mode Index Subindex Name Description Data Type Attr. Default Compensation in two-wire 16#01 REAL CH0 Compensation in two-wire mode ０ mode 16#8012 16#02 REAL CH1 Compensation in two-wire mode ０...
Page 497 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.10.7.1 Process Data Go to the Process Data tab and select the data that you’d like to monitor. Analog Input Value: You can monitor the selected channels and deselect the unused channels to save cycle time. ...
Page 498 AX-5 Ser i es M od ul e M an ua l 5.10.8 Troubleshooting In the Diagnosis History tab, the error information that has occurred on the module is recorded. In the Status tab, the current error information is displayed. In the CoE Parameters tab, you can view the error status through Index/SubIndex of the All Parameter list.
Page 499 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.11 AX-504PT10-0B The AX-504PT10-0B, a temperature measurement module, converts the values received from the RTD sensors into digital signals. You can select either Celsius or Fahrenheit as the unit of measurement. This section describes its specifications, wirings and operations.
Page 500 AX-5 Ser i es M od ul e M an ua l 5.11.2 Dimensions and Parts Dimensions  Unit: mm 5 - 2 7 4...
Page 501 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Parts  ⑪ ⑤ ④ ⑫ ⑥ ① ⑦ ② ⑧ ③ ⑨ ⑩ Name AX connector (L) Label (manufacturer information, service information, safety, serial number, firmware/hardware version) DIN rail clip System status indicator...
Page 502 AX-5 Ser i es M od ul e M an ua l 5.11.3 Arrangement of Terminals, LED Indicators and Wiring 5.11.3.1 Arrangement of Terminals System LED ERROR LED Channel RUN LED RTD0 RTD1 RTD2 RTD3 *1. The marked black areas are terminals with LED indicators. Refer to the table below to see their corresponding channels.
Page 503 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.11.3.2 LED Indicators Name Color Status Description No power supplied or ECAT INIT Blinking (0.2 s) ECAT Pre OP System Blue Blinking (1 s) ECAT Safe OP Normal OP No power supplied or the module is...
Page 504 AX-5 Ser i es M od ul e M an ua l Loop Configuration  IDAC1 Pt100, Ni100, Pt1000, Ni1000, 0 to 300 Ω Shielded cable *1 IDAC2 2-Wire Pt100, Ni100, Pt1000, Ni1000, 0 to 300 Ω Shielded cable *1 3-Wire Pt100, Ni100, Pt1000, Ni1000, 0 to 300 Ω...
Page 505 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.11.4 Settings in DIADesigner-AX The software DIADesigner-AX is the programming tool for the AX Series PLCs. This section introduces some basic operations and settings. 5.11.4.1 Basic Operation Double-click the DIADesigner-AX icon to open the software and create a new project.
Page 506 AX-5 Ser i es M od ul e M an ua l Add Modules in Method 1: Add the modules in manually.  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Add Device… to select and add System Coupler.
Page 507 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Method 2: Scan to add the modules in.  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Scan for Devices…. After the auto-scan is over, the actually connected devices will appear. Click Copy All Devices to Project button to add them to the list under EtherCAT Master SoftMotion.
Page 508 AX-5 Ser i es M od ul e M an ua l 5.11.4.2 Parameter Settings In the CoE Parameters tab, you can do the following settings of parameters. Favorites You can select and right-click the parameter to add the selected parameter to the Favorites. Click on the ...
Page 509 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les Startup Parameters Once the module is started up, the setting values of parameters in the Startup Parameters list are written to the  module. For editing, you have to set up these parameters in offline mode. Icon Function Description...
Page 510 AX-5 Ser i es M od ul e M an ua l All Parameters You can find all the CoE parameters here. Click on the toolbar to go into online mode first, and then you can  start to upload and download the parameters. After clicking the upload button, you can see the current values in Current Value column.
Page 511 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les  You can select and right-click the parameter to add the selected parameter to the Favorites. Function Description Add to Favorites Add the selected to Favorites Add to Startup Parameters Add the selected to Startup Parameters Import…...
Page 512 AX-5 Ser i es M od ul e M an ua l Click on the toolbar to go into online mode. In the EtherCAT I/O Mapping tab, you can find the variables, current value, status and error codes for each channel. 5.11.4.4 Diagnosis History Click on the toolbar to go into online mode.
Page 513 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.11.4.5 Status Click on the toolbar to go into online mode. In the Status tab, you can monitor the current status and latest diagnostic messages of the module.
Page 514 AX-5 Ser i es M od ul e M an ua l 5.11.5 Parameter Descriptions You can use DIADesigner-AX to set up the functions for the module by directly selecting the setting mode and parameters. For software operation, refer to section 5.9.4 for more information. The function blocks in the software are available for you to set relevant parameters.
Page 515 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.11.5.2 User Command Index Subindex Name Description Data Type Attr. Default 16#5001 16#01 User Command Commands for users to use UINT Explanation  Users write a command value into the module and the module will execute the command accordingly. After execution, the module will respond with a corresponding value to show if the execution is success or not.
Page 516 AX-5 Ser i es M od ul e M an ua l Supported modes  Setting value Mode Setting range (°C) Setting range (°F) Disable Pt100 (2 Wire) -200 – 850 -328 –1562 Pt100 (3 Wire) -200 – 850 -328 –1562 Pt100 (4 Wire) -200 –...
Page 517 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.11.5.5 Digital Filter Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Digital Filter Setting USINT 16#02 CH1 Digital Filter Setting USINT 16#8003 Digital filter setting 16#03 CH2 Digital Filter Setting...
Page 518 AX-5 Ser i es M od ul e M an ua l FIR (Finite impulse response) Finite impulse response filter attenuates unwanted frequency from the input signals. In terms of attenuating noises, a FIR filter works more efficiently than a moving average filter does. This FIR filter is a low-pass filter; it works tremendously well.
Page 519 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.11.5.6 User Limit Alarm Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Enable User Limit Alarm Enable/disable the alarm of 16#02 CH1 Enable User Limit Alarm exceeding the user-defined limit 16#8003 USINT...
Page 520 AX-5 Ser i es M od ul e M an ua l Hardware Range User Upper Limit Input Signal User Lower Limit Hardware Range Over Hardware Range Under Hardware Range Upper Limit Alarm Lower Limit Alarm 5.11.5.7 Decimal Places Index Subindex Name Description...
Page 521 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.11.5.9 Compensation in two-wire mode Index Subindex Name Description Data Type Attr. Default 16#01 CH0 Compensation in two-wire mode REAL Compensation in two-wire 16#02 REAL CH1 Compensation in two-wire mode mode...
Page 522 AX-5 Ser i es M od ul e M an ua l 5.11.6 EtherCAT Operation Modes There are two modes for EtherCAT modules to run during operation, FreeRun mode (non-synchronization mode) and DC mode (synchronization mode). Different synchronization modes can be applied to different modules in the same system. For temperature measurement modules, only FreeRun mode is supported.
Page 523 Ch ap te r 5 Ana lo g In pu t/O u tput Mo du les 5.11.7.1 Process Data Go to the Process Data tab and select the data that you’d like to monitor. Analog Input Value: You can monitor the selected channels and deselect the unused channels to save cycle time. ...
Page 524 AX-5 Ser i es M od ul e M an ua l 5.11.7.3 Always Update Variables This field is for global setting to define whether or not the I/O variables in the bus cycle task are updated. Option Description DIADesigner-AX updates the I/O variables according to the Use parent device setting Always update variables in the CPU setting for the...
Page 525 Chapter 6 Positioning Modules Table of Contents AX-502PU01-0A ................... 6-2 6.1.1 Specifications ................... 6-2 6.1.2 Dimensions and Parts ................6-3 6.1.3 Arrangement of Terminals, LED Indicators and Wiring ........6-5 6.1.4 Settings in DIADesigner-AX ................ 6-8 6.1.5 CiA402 Drive Profile ................6-17 6.1.6 Functions and Descriptions of Objects ............
Page 526 AX-5 Ser i es M od ul e M an ua l AX-502PU01-0A AX-502PU01-0A, a pulse output module, sends 2-axis pulse signals, driving corresponding pulse-type servos. This section introduces its specifications, wirings and operations. 6.1.1 Specifications Item Specification Number of Axes External connector type Spring-clamp terminal block (16 terminals) Free Run mode...
Page 527 Ch ap te r 6 Pos i ti on ing Mod ul es Item Specification Connection Lost Protection Short Circuit Protection (SCP) Digital output Over Voltage Protection (OVP) / Over Current Protection (OCP) 6.1.2 Dimensions and Parts Dimensions  Unit: mm 6 - 3...
Page 528 AX-5 Ser i es M od ul e M an ua l Parts  ⑪ ⑤ ④ ⑫ ⑥ ① ⑦ ② ⑧ ③ ⑨ ⑩ Name AX connector (L) Label (manufacturer information, service information, safety, serial number, firmware/hardware version) DIN rail clip System status indicator Model code...
Page 529 Ch ap te r 6 Pos i ti on ing Mod ul es 6.1.3 Arrangement of Terminals, LED Indicators and Wiring Arrangement of Terminals System LED ERROR LED Channel RUN LED AX-502PU01-0A *1. The marked black areas are terminals with LED indicators. Pin No.
Page 530 AX-5 Ser i es M od ul e M an ua l LED Indicators Name Color Status Description No power supplied or INIT Blinking (0.2s) EtherCAT Pre OP System Blue Blinking (1s) EtherCAT Safe OP Normal (OP) No power supplied or the module is functioning correctly.
Page 531 Ch ap te r 6 Pos i ti on ing Mod ul es Loop Configuration  AX-502PU01-0A ASDA-A3-L I0-I9 PULL HI_P PULSE- 3W/470Ω PULL HI_S SIGN- 3W/470Ω COM+ CCLR System System Power Power AX Connector AX Connector Power Power *1 When ASDA-A3-L is in the open-collector NPN form, use the external power supply, and the power supply for COM+, PULL HI-P, and PULL HI-S is from IOV.
Page 532 AX-5 Ser i es M od ul e M an ua l 6.1.4 Settings in DIADesigner-AX The software DIADesigner-AX is the programming tool for the AX Series PLCs. This section introduces some basic operations and settings. Basic Operation Double-click the DIADesigner-AX icon to open the software and create a new project. 6 - 8...
Page 533 Ch ap te r 6 Pos i ti on ing Mod ul es Add modules in Method 1: Add the modules in manually  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Add Device… to select and add System Coupler.
Page 534 AX-5 Ser i es M od ul e M an ua l Method 2: Scan to add the modules in.  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Scan for Devices…. After the auto-scan, the actually-connected devices will appear. Click Copy All Devices to Project button to add them to the list under EtherCAT Master SoftMotion.
Page 535 Ch ap te r 6 Pos i ti on ing Mod ul es Parameter Settings In the CoE Parameters tab, you can do the following settings of parameters. (1) Favorites You can select and right-click the parameter to add the selected parameter to the Favorites. Click on the ...
Page 536 AX-5 Ser i es M od ul e M an ua l Icon Function Description Delete Delete Move up Move up Move down Move down (3) All Parameters You can find all the CoE parameters here. Click on the toolbar to go into the online mode first, and then you ...
Page 537 Ch ap te r 6 Pos i ti on ing Mod ul es Icon Function Description Upload all the parameters from the module to Upload All from Device DIADesigner-AX. Download the selected parameters from Download Selection to Device DIADesigner-AX to the module. Download all the parameters from Download All to Device DIADesigner-AX to the module.
Page 538 AX-5 Ser i es M od ul e M an ua l Process Data In the Process Data tab, select the desired outputs and inputs. (2) Click on the toolbar to go into the online mode. In the EtherCAT I/O Mapping tab, you can find the variables, current value, status and error codes for each channel.
Page 539 Ch ap te r 6 Pos i ti on ing Mod ul es Diagnosis History Click on the toolbar to go into the online mode. In the Diagnosis History tab, all error information that occurred on the module is recorded. Message column shows the TEXT ID plus error description. Please refer to the troubleshooting section for details on errors.
Page 540 AX-5 Ser i es M od ul e M an ua l Information In the Information tab, you can find the module information including Name, Vendor, Categories, Type, ID, Version, Order Number and Description for the module. on the toolbar to go into the online mode. Go to the All Parameters page in the CoE Parameters tab, Click and then you can find the hardware version and software version.
Page 541 Ch ap te r 6 Pos i ti on ing Mod ul es 6.1.5 CiA402 Drive Profile This section is an introduction to various standardized modes of operation for AX-502PU01 in EtherCAT mode following the CiA 402 protocol, including basic operation settings and description of objects when. Axis0 is taken as an example for explanation here.
Page 542 AX-5 Ser i es M od ul e M an ua l Index Subindex Name Attr. Unit Data type mapping 16#6083 16#00 Axis0 Profile Acceleration Pulse/s UDINT 16#6084 16#00 Axis0 Profile Deceleration Pulse/s UDINT 16#6085 16#00 Axis0 Quick Stop Deceleration Pulse/s UDINT 16#6086...
Page 543 Ch ap te r 6 Pos i ti on ing Mod ul es Profile Velocity Mode In this mode, the target velocity, max. profile velocity and acceleration/deceleration are specified in the upper device, and then the motion command generator of AX-502PU01 plans the motion trajectory based on given conditions. The architecture for Profile Velocity mode: Target Velocity Max Profile Velocity...
Page 544 AX-5 Ser i es M od ul e M an ua l Homing Mode In this mode, the speed, acceleration and homing mode are specified through input and output objects. The architecture for Homing Mode: Control Word Status Word Homing Method Position Motion Homing Speeds...
Page 545 Ch ap te r 6 Pos i ti on ing Mod ul es List of related objects: Index Subindex Name Attr. Unit Data type mapping 16#605A 16#00 Axis0 Quick Stop Option Code 16#6064 16#00 Axis0 Position Actual Value Pulse/s DINT 16#606C 16#00 Axis0 Velocity Actual Value...
Page 546 AX-5 Ser i es M od ul e M an ua l 6.1.6 Functions and Descriptions of Objects In this section, Axis0 is taken as an example for explanation of objects. To set up for Axis1, please give the index of each object for Axis0 an offset of 16#800 and then set them.
Page 547 Ch ap te r 6 Pos i ti on ing Mod ul es Index Function Description 16#6040 Axis0 ControlWord Control word of Axis 0 16#6041 Axis0 StatusWord Status word of Axis 0 16#605A Axis0 Quick Stop Option Code Behavior option of Axis 0 for a quick stop 16#605B Axis0 Shutdown Option Code Behavior option of Axis 0 for a shutdown...
Page 548 AX-5 Ser i es M od ul e M an ua l Index Function Description 16#A002 Errors Error flag set of the module 16#A003 Warnings Warning flag set of the module Objects: 16#F000 – 16#FFFF  Index Function Description 16#F000 Factory Action Factory mode Manufacturer Specific Objects...
Page 549 Ch ap te r 6 Pos i ti on ing Mod ul es Axis0 DIQ Function DI6 and Axis1 DIQ Function DI7  Mode Name Description General digital input Encoder Z pulse for homing Axis0 DIQ Function DI8 and Axis1 DIQ Function DI9 ...
Page 550 AX-5 Ser i es M od ul e M an ua l Index Subindex Name Description Data type Attr. Default 16#05 Axis0 DIQ Negative Logic DI8 USINT 16#06 Axis0 DIQ Negative Logic DQAB USINT 16#07 Axis0 DIQ Negative Logic DQ0 USINT 16#01 Axis1 DIQ Negative Logic DI1...
Page 551 Ch ap te r 6 Pos i ti on ing Mod ul es Axis0/Axis1 DIQ Function Attribute LSN Option Code  Mode Name Description When LSN is triggered, the CiA402 state of the axis enters LSN_OP_QuickStopActive QuickStopActive. When LSN is triggered, the CiA402 state of the axis enters LSN_OP_Fault Fault.
Page 552 AX-5 Ser i es M od ul e M an ua l Axis1 DIQ Value DIn  Name Description Bit 0 Status of module’s local input pin DI1 for Axis 1 Bit 1 Status of module’s local input pin DI3 for Axis 1 Bit 2 Status of module’s local input pin DI5 for Axis 1 Bit 3...
Page 553 The function decides whether to enable EtherCAT module’s other DI as the judgment condition for Servo Ready. The default is DISABLE. If the function is enabled, all motion functions cannot be executed until the signal of the DI is ON. Take Delta AX series PLC as a master in the following figure: 6 - 2 9...
Page 554 The function decides whether to enable EtherCAT module’s other DI as the judgment condition for Alarm. If the signal of the DI is ON after the function is enabled, the state machine of the axis enters Fault. Take Delta AX series PLC as a master in the following figure: Axis0/Axis1 External DIQ Function DQ SON ...
Page 555 16#2006:02 goes by, which works with 16#2007:02: Bit1. The modes above sets whether to enable the Alarm Clear function using EtherCAT module’s other DO so as to clear servo errors. Take Delta AX series PLC as a master in the following figure. 6 - 3 1...
Page 556 This function sets the judgement time for Servo ON using EtherCAT module’s other DI. If the Servo ON is done within the set time length, the Servo ON process is completed. Take Delta AX series PLC as a master in the following figure: 6 - 3 2...
Page 557 The length of time that the output logic 1 from ALMCLR Bit lasts, which works with 16# 2007:02: Bit1 0 to 16#FFFF (unit: ms) Take Delta AX series PLC as a master in the following figure: Axis External DIQ Value (16#2007 and 16#2807) Index Subindex...
Page 558 AX-5 Ser i es M od ul e M an ua l Axis0/Axis1 External DIQ Value DQn  Name Description Send the request signal of Servo On to the Bit 0 DI SON servo. Send the request signal of Alarm Reset to the Bit 1 DI ALMCLR servo.
Page 559  When the Delta AX-5 PLC is used as the controller, the module status will be synchronized with the current status of the PLC, 1 (Run) or 2 (Stop). When the PLC is switched to Stop, the output module will behave differently according to the parameter settings for the module, but the input module will not be affected.
Page 560 AX-5 Ser i es M od ul e M an ua l Status of the module  Value Status Description When the module is controlled by the Controlled by EtherCAT State Machine EtherCAT state machine When the module is controlled by the PLC and Controlled by Controller (Run) the PLC is in Run state.
Page 561 Ch ap te r 6 Pos i ti on ing Mod ul es Warnings (16#A003) Index Subindex Name Description Data type Attr. Default 16#01 System Warning System warning flag BOOL 16#A003 16#02 Axis0 Warning Axis0 warning flag BOOL 16#03 Axis1 Warring Axis1 warning flag BOOL Explanation...
Page 562 AX-5 Ser i es M od ul e M an ua l Index Subindex Name Description Data type Attr. Default 16#26 Reserved Reserved UINT 16#27 Reserved Reserved UINT 16#28 Reserved Reserved UINT 16#29 Reserved Reserved UINT 16#30 Reserved Reserved UINT 16#31 Reserved Reserved...
Page 563 Ch ap te r 6 Pos i ti on ing Mod ul es Explanation of Bits 0-3 and Bit 7  Bits 0-3 and Bit 7: control commands for module states Bits of Control Word Command Bit 7 Bit 3 Bit 2 Bit 1 Bit 0...
Page 564 AX-5 Ser i es M od ul e M an ua l The Finite State Machine shown below defines how a drive behaves. Each state represents an internal or external behavior of the drive. For example, the point-to-point position movement can be allowed to perform only in the Operation enabled state.
Page 565 Ch ap te r 6 Pos i ti on ing Mod ul es Axis0 StatusWord (16#6041) Index Subindex Name Description Data type Attr. Default 16#6041 16#00 Axis0 StatusWord Status word of Axis0 UINT Explanation  Explanation of the status word: Function Description Bit 0...
Page 566 AX-5 Ser i es M od ul e M an ua l Explanation of Bits 10-13  Bits 10 and 12: Profile Position Mode Halt Name Value Description (ControlWord.bit 8) Target position is not reached. Axis decelerates. Target reached Target position is reached The velocity of the axis is 0 Previous set-point already processed, waiting for the new set-point.
Page 567 Ch ap te r 6 Pos i ti on ing Mod ul es Setting Description value With the Axis0 Quick Stop Deceleration in 16#6085 as the deceleration, the axis status in 16#6041 switches to “Switch on disabled” when the axis stops. With the Axis0 Profile Deceleration in 16#6084 as the deceleration, the axis status in 16#6041 remains “Quick stop active”...
Page 568 AX-5 Ser i es M od ul e M an ua l Axis0 Fault Reaction Option Code (16#605E) Index Subindex Name Description Data type Attr. Default Axis 0 behavior selection for 16#605E 16#00 Axis0 Fault Reaction Option Code the reaction to a fault Explanation ...
Page 569 Ch ap te r 6 Pos i ti on ing Mod ul es Axis0 End Velocity (16#6082) Index Subindex Name Description Data type Attr. Default 16#6082 16#00 Axis0 End Velocity End profile velocity of Axis0 UDINT Explanation  The parameter sets the end profile velocity of axis 0 when the position is reached during movement (unit: pulse/sec). Axis0 Profile Jerk Use (16#60A3) Index Subindex...
Page 570 AX-5 Ser i es M od ul e M an ua l Explanation  The motion modes that Axis 0 supports are shown in the table below: Description Bit 0 Profile Position Mode Bit 1 Bit 2 Profile Velocity Mode Bit 3 Bit 4 Bit 5...
Page 571 Ch ap te r 6 Pos i ti on ing Mod ul es Axis0 Max Profile Velocity (16#607F) Index Subindex Name Description Data type Attr. Default Maximum profile velocity of 16#607F 16#00 Axis0 Max Profile Velocity UDINT 500000 Axis 0 Explanation ...
Page 572 AX-5 Ser i es M od ul e M an ua l Explanation  Motion profile types: Setting value Description JerkFreeVelocityGuarantee (Jerk free curve with the velocity meeting the guarantee) JerkFreeAccelerationGuarantee (Jerk free curve with the acceleration meeting the guarantee) LinearRampTrapezoidalVelocityGuarantee (Trapezoidal curve with the velocity meeting the guarantee) LinearRampTrapezoidalAccelerationGuarantee...
Page 573 Ch ap te r 6 Pos i ti on ing Mod ul es Axis0 Homing Method (16#6098) Index Subindex Name Description Data type Attr. Default 16#6098 16#00 Axis0 Homing Method Homing mode of Axis 0 SINT Explanation  There are a total of 35 modes for users to set up for axis 0 to perform homing. In modes 1-16, the axis needs to look for the Z pulse after homing is performed;...
Page 574 AX-5 Ser i es M od ul e M an ua l • Mode 2: Depending on the positive limit switch and Z pulse Case 1: The homing instruction is executed when the positive limit switch is OFF and the axis moves in the positive direction at the first-phase speed (homing speed during the search for a switch).
Page 575 Ch ap te r 6 Pos i ti on ing Mod ul es • Mode 4: Depending on the home switch and Z pulse Case 1: When the home switch is OFF, the homing instruction is executed and the axis moves in the positive direction at the first-phase speed (homing speed during the search for a switch).
Page 576 AX-5 Ser i es M od ul e M an ua l • Mode 6: Depending on the home switch and Z pulse Case 1: When the home switch is ON, the homing instruction is executed and the axis moves in the positive direction at the second-phase speed (homing speed during the search for Z pulse).
Page 577 Ch ap te r 6 Pos i ti on ing Mod ul es • Mode 7: Depending on the home switch, positive limit switch and Z pulse Case 1: When the home switch is OFF, the homing instruction is executed and the axis moves in the positive direction at the first-phase speed (homing speed during the search for a switch).
Page 578 AX-5 Ser i es M od ul e M an ua l • Mode 8: Depending on the home switch, positive limit switch and Z pulse Case 1: When the home switch is OFF, the homing instruction is executed and the axis moves in the positive direction at the first-phase speed (homing speed during the search for a switch).
Page 579 Ch ap te r 6 Pos i ti on ing Mod ul es • Mode 9: Depending on the home switch, positive limit switch and Z pulse Case 1: When the home switch is OFF, the homing instruction is executed and the axis moves in the positive direction at the first-phase speed (homing speed during the search for a switch).
Page 580 AX-5 Ser i es M od ul e M an ua l • Mode 10: Depending on the home switch, positive limit switch and Z pulse Case 1: When the home switch is OFF, the homing instruction is executed and the axis moves in the positive direction at the first-phase speed (homing speed during the search for a switch).
Page 581 Ch ap te r 6 Pos i ti on ing Mod ul es Mode 11 to mode 14: Depending on the home switch, negative limit switch and Z pulse • Mode 11: Depending on the home switch, negative limit switch and Z pulse Case 1: When the home switch is OFF, the homing instruction is executed and the axis moves in the negative direction at the first-phase speed (homing speed during the search for a switch).
Page 582 AX-5 Ser i es M od ul e M an ua l • Mode 12: Depending on the home switch, negative limit switch and Z pulse Case 1: When the home switch is OFF, the homing instruction is executed and the axis moves in the negative direction at the first-phase speed (homing speed during the search for a switch).
Page 583 Ch ap te r 6 Pos i ti on ing Mod ul es • Mode 13: Depending on the home switch, negative limit switch and Z pulse Case 1: When the home switch is OFF, the homing instruction is executed and the axis moves in the negative direction at the first-phase speed (homing speed during the search for a switch).
Page 584 AX-5 Ser i es M od ul e M an ua l • Mode 14: Depending on the home switch, negative limit switch and Z pulse Case 1: While the home switch is OFF, the homing instruction is executed and the axis moves in the negative direction at the first-phase speed (homing speed during the search for a switch).
Page 585 Ch ap te r 6 Pos i ti on ing Mod ul es Mode 15 and mode 16: Reserved Modes 15-16 are reserved for future development. Mode 17 to mode 30: No Z pulse is required. In modes 17-30 which are similar to modes 1-14, the home positioning is achieved simply based on the state of a home switch or/and a limit switch (positive or negative), with no Z pulse required.
Page 586 AX-5 Ser i es M od ul e M an ua l • Mode 19: Similar to mode 3, it depends on the home switch only, not considering the Z pulse. Case 1: While the home switch is OFF, the homing instruction is executed and the axis moves in the positive direction at the first-phase speed (homing speed during the search for a switch).
Page 587 Ch ap te r 6 Pos i ti on ing Mod ul es • Mode 21: Similar to mode 5, it depends on the home switch only, not considering the Z pulse. Case 1: While the home switch is ON, the homing instruction is executed and the axis moves in the positive direction at the second-phase speed (homing speed during the search for Z pulse).
Page 588 AX-5 Ser i es M od ul e M an ua l • Mode 23: Similar to mode 7, it depends on the home switch and the positive limit switch, not considering the Z pulse. Case 1: The homing instruction is executed while the home switch is OFF and the axis moves in the positive direction at the first-phase speed (homing speed during the search for a switch).
Page 589 Ch ap te r 6 Pos i ti on ing Mod ul es • Mode 24: Similar to mode 8, it depends on the home switch and the positive limit switch, but not considering the Z pulse. Case 1: The homing instruction is executed while the home switch is OFF and the axis starts to move in the positive direction at the first-phase speed (homing speed during the search for a switch).
Page 590 AX-5 Ser i es M od ul e M an ua l • Mode 25: Similar to mode 9, it depends on the home switch and the positive limit switch, not considering the Z pulse. Case 1: The homing instruction is executed while the home switch is OFF and the axis starts to move in the positive direction at the first-phase speed (homing speed during the search for a switch).
Page 591 Ch ap te r 6 Pos i ti on ing Mod ul es • Mode 26: Similar to mode 10, it depends on the home switch and the positive limit switch, not considering the Z pulse. Case 1: The homing instruction is executed while the home switch is OFF and the axis starts to move in the positive direction at the first-phase speed (homing speed during the search for a switch).
Page 592 AX-5 Ser i es M od ul e M an ua l • Mode 27: Similar to mode 11, it depends on the home switch and the negative limit switch, not considering the Z pulse. Case 1: The homing instruction is executed while the home switch is OFF and the axis starts to move in the negative direction at the first-phase speed (homing speed during the search for a switch).
Page 593 Ch ap te r 6 Pos i ti on ing Mod ul es • Mode 28: Similar to mode 12, it depends on the home switch and the negative limit switch, not considering the Z pulse. Case 1: The homing instruction is executed while the home switch is OFF and the axis starts to move in the negative direction at the first-phase speed (homing speed during the search for a switch).
Page 594 AX-5 Ser i es M od ul e M an ua l • Mode 29: Similar to mode 13, it depends on the home switch and the negative limit switch, not considering the Z pulse. Case 1: The homing instruction is executed while the home switch is OFF and the axis starts to move in the negative direction at the first-phase speed (homing speed during the search for a switch).
Page 595 Ch ap te r 6 Pos i ti on ing Mod ul es • Mode 30: Similar to mode 14, it depends on the home switch and the negative limit switch, not considering the Z pulse Case 1: The homing instruction is executed while the home switch is OFF and the axis starts to move in the negative direction at the first-phase speed (homing speed during the search for a switch).
Page 596 AX-5 Ser i es M od ul e M an ua l Mode 33 and mode 34: Only the Z pulse is required. • Mode 33: Depending on the Z pulse, in the negative direction In mode 33, the homing instruction is executed and then the axis moves in the negative direction at the second-phase speed (homing speed during the search for Z pulse).
Page 597 Ch ap te r 6 Pos i ti on ing Mod ul es Axis0 Homing Speeds (16#6099) Index Subindex Name Description Data type Attr. Default Axis0 Speed During Search For Homing speed of Axis 0 16#01 UDINT Switch during the search for Switch 16#6099 Axis0 Speed During Search For Homing speed of Axis 0...
Page 598 AX-5 Ser i es M od ul e M an ua l Digital Inputs/Outputs Axis0 Digital Inputs (16#60FD) Index Subindex Name Description Data type Attr. Default 16#60FD 16#00 Axis0 Digital Inputs Digital inputs of Axis 0 UDINT Explanation  Bits for digital inputs of Axis 0: Description Bit 0 Negative limit signal...
Page 599 Ch ap te r 6 Pos i ti on ing Mod ul es 6.1.7 EtherCAT Operation Modes There are two modes for EtherCAT modules to run during operation, FreeRun mode (non-synchronization mode) and DC mode (synchronization mode). Different synchronization modes can be applied to different modules in the same system. FreeRun Mode The I/O values of each module are refreshed based on its own cycle.
Page 600 AX-5 Ser i es M od ul e M an ua l 6.1.8 Process Data Under CSP or PP mode, the following objects are included in the RxPDO. Index Subindex Name Description Data type Attr. Default 16#6040 16#00 Axis0 ControlWord Control word of Axis0 UINT 16#607A...
Page 601 Ch ap te r 6 Pos i ti on ing Mod ul es Process Data Go to the Process Data tab and select the data that you’d like to monitor. You can monitor the data for the selected PDOs, and deselect the unused PDOs to save cycle time. ...
Page 602 AX-5 Ser i es M od ul e M an ua l 6.1.9 Example of Hardware Configuration and Software Operation In this section, the AX-502PU module combined with the AX-5 coupler is controlled by AX-3 series PLC. System Hardware Configuration The AX-308E PLC makes a connection with AX-500CEC plus AX-502PU through the EtherCAT port, controlling the pulse servo via AX-502PU.
Page 603 Ch ap te r 6 Pos i ti on ing Mod ul es CN1 pin signals:  Signal Pin No. Function PULSE+ Position pulses can be input by Line Driver (maximum single-phase pulse PULSE- Position frequency of 4 MHz), or the open-collector input (maximum single-phase pulse frequency of 200 kHz.
Page 604 The wiring diagram for AX-308E, AX-502PU and ASDA-B3-L  ASDA-B3-L ASDA-B3-L AX-502PU Home Switch Home Switch IMSTOP IMSTOP AX-308E Note: For more information on ASDA-B3-L’s DI/DO signal configuration, refer to Delta ASDA-B3 Series Servo Drive User Manual. 6 - 8 0...
Page 605 Ch ap te r 6 Pos i ti on ing Mod ul es Project Creation and Programming Start the DIADesigner-AX software. Open a new project for AX-308E. Right-click EtherCAT_Master_SoftMotion in the Devices tree, and then click Scan for Devices…. from the context menu.
Page 606 AX-5 Ser i es M od ul e M an ua l After entering the Scan Devices window, click Auto Merge and then OK in the following figures. After adding devices is completed, the AX-502PU module will be added to the device tree. 6 - 8 2...
Page 607 Ch ap te r 6 Pos i ti on ing Mod ul es In the device tree, double-click AX_502PU01_0A_SM, and then in its Hardware IO Configuration tab, click set up the hardware configurations you need. After setting up the hardware configurations is done, double-click on SM3_Drive_ETC_Delta_AX_502PU01_0A. 6 - 8 3...
Page 608 AX-5 Ser i es M od ul e M an ua l Set up the output mode of the pulse-type axis. In this example, A/B phase mode is used. Note: For more about pulse outputs, refer to section 6.1.6.1.1 Axis DIQ Function (16#2000 and 16#2800). After setting the required parameters for both axes is done, double-click Motion-PRG.
Page 609 Ch ap te r 6 Pos i ti on ing Mod ul es Note: The outputs to be used must be set up in the DIO page for AX-3. 11. After the axes are enabled, MC_Home is used to make them go back to home positions. Once the homing is done, axis motions can be performed.
Page 610 AX-5 Ser i es M od ul e M an ua l 6.1.10 Troubleshooting In the Diagnosis History tab, the system errors (16#A000) and axis errors (16#603F+16#800*n ) that occurred in the module are recorded. In the Status tab, only the current error information of System Error (16#A000) is recorded. From the All Parameters list in the CoE Parameters tab, find 16#A000 for system errors or 16#603F+16#800*n for axis errors to view their error codes.
Page 611 Ch ap te r 6 Pos i ti on ing Mod ul es Index SubIndex ErrorCode Name Description Emergency 16#6320 PARAMETER_ERROR Input parameter error 16#7120 MOTOR_ERROR Error in the motor drive While the CiA 402 state machine of the slave is in 16#7500 COMMUNICATION Operation enabled state, the...
Page 612 AX-5 Ser i es M od ul e M an ua l Error message  Index SubIndex ErrorCode Description Error Indicator Solution Check if the input parameters PARAMETER_ERR Blinking 16#6320 required for the axis are every 0.2 seconds correct. Check if the motor drive of the Blinking axis is abnormal (ALM bit is 16#7120...
Page 613 Ch ap te r 6 Pos i ti on ing Mod ul es AX-502HC10-0A AX-502HC10-0A, a high-speed counter module, receives pulse signals for counting with two built-in channels. This section introduces its specifications, wirings and operations. 6.2.1 Specifications Item Specification Number of channels External connector type Spring-clamp terminal block (16 terminals)
Page 614 AX-5 Ser i es M od ul e M an ua l Item Specification Filtering function Digital filter Connection Lost Protection Short Circuit Protection (SCP) Digital output Over Voltage Protection (OVP) / Over Current Protection (OCP) 6.2.2 Dimensions and Parts Dimensions ...
Page 615 Ch ap te r 6 Pos i ti on ing Mod ul es Parts  ⑪ ⑤ ④ ⑫ ⑥ ① ⑦ ② ⑧ ③ ⑨ ⑩ Name AX connector (L) Label (manufacturer information, service information, safety, serial number, firmware/hardware version) DIN rail clip System status indicator...
Page 616 AX-5 Ser i es M od ul e M an ua l 6.2.3 Arrangement of Terminals, LED Indicators and Wiring Arrangement of Terminals System LED ERROR LED Channel RUN *1. The marked black areas are terminals with LED indicators. Refer to the table below to see their corresponding channels.
Page 617 Ch ap te r 6 Pos i ti on ing Mod ul es LED Indicators Name Color Status Description No power supplied or INIT Blinking (0.2s) EtherCAT Pre OP System Blue Blinking (1s) EtherCAT Safe OP Normal (OP) No power supplied or the module is functioning correctly.
Page 618 AX-5 Ser i es M od ul e M an ua l Wiring and Loop Configuration Wiring  Incremental encoder AX-510PS12-0A AX-516PC30-0A AX-502HC10-0A 3W/470Ω 2-wire 2-wire *1. An external pull-up resistor of 3W/470 Ω is required for each of IA and IB input points. *2.
Page 619 Ch ap te r 6 Pos i ti on ing Mod ul es Loop Configuration  AX-502HC10-0A Incremental encoder Phase A 3W/470Ω Phase B 3W/470Ω Phase Z I0-I3 Q0-Q5 IOV *2 System System Power Power AX connector AX connector Power Power *1 Connect the encoder’s 0V to IOG of AX-516PC30-0A, AX-516PS20-0A, etc.
Page 620 AX-5 Ser i es M od ul e M an ua l 6.2.4 Settings in DIADesigner-AX The software DIADesigner-AX is the programming tool for the AX Series PLCs. This section introduces some basic operations and settings. Basic Operation Double-click the DIADesigner-AX icon to open the software and create a new project. 6 - 9 6...
Page 621 Ch ap te r 6 Pos i ti on ing Mod ul es Add modules in Method 1: Add the modules in manually  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Add Device… to select and add System Coupler.
Page 622 AX-5 Ser i es M od ul e M an ua l Method 2: Scan to add the modules in.  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Scan for Devices…. After the auto-scan, the actually-connected devices will appear. Click Copy All Devices to Project button to add them to the list under EtherCAT Master SoftMotion.
Page 623 Ch ap te r 6 Pos i ti on ing Mod ul es Parameter Settings In the CoE Parameters tab, you can do the following settings of parameters. Favorites You can select and right-click the parameter to add the selected parameter to the Favorites. Click on the ...
Page 624 AX-5 Ser i es M od ul e M an ua l Icon Function Description Delete Delete Move up Move up Move down Move down All Parameters You can find all the CoE parameters here. Click on the toolbar to go into the online mode first, and then you ...
Page 625 Ch ap te r 6 Pos i ti on ing Mod ul es Icon Function Description Compare Compare Upload the selected parameters from the module to Upload Selection from Device DIADesigner-AX. Upload all the parameters from the module to Upload All from Device DIADesigner-AX.
Page 626 AX-5 Ser i es M od ul e M an ua l Process Data In the Process Data tab, select the desired outputs and inputs. Click on the toolbar to go into the online mode. In the EtherCAT I/O Mapping tab, you can find the variables, current value, status and error codes for each channel.
Page 627 Ch ap te r 6 Pos i ti on ing Mod ul es Diagnosis History Click on the toolbar to go into the online mode. In the Diagnosis History tab, all error information that occurred on the module is recorded. The TEXT ID plus error description is displayed in the Message column. Please refer to the troubleshooting section for details on errors.
Page 628 In this section, the contents include basic operation settings and object descriptions of AX-502HC10 in EtherCAT mode, which is Delta user-defined mode. CH0 is taken as an example for explanation here. To set up for CH1, please make an offset of 16#10 for the index of each object and then set them.
Page 629 Ch ap te r 6 Pos i ti on ing Mod ul es List of related objects: Index Subindex Name Attr. Unit Data type mapping 16#7000 16#00 CH0 Counter Operation Control UINT 16#7001 16#00 CH0 Preset Command Value DINT 16#6000 16#00 CH0 Counter Status UINT...
Page 630 AX-5 Ser i es M od ul e M an ua l Pulse Rate Measurement Status Pulse Rate Pulse Rate Measurement Control Measurement Pulse Rate Measurement Value Function List of related objects: Index Subindex Name Attr. Unit Data type mapping 16#7003 16#00 CH0 Pulse Rate Measurement Control...
Page 631 Ch ap te r 6 Pos i ti on ing Mod ul es Index Function Description 16#2016 CH1 Counter Count Direction CH1 counter count direction selection 16#2017 CH1 Filter Depth Config CH1 filter configuration setting 16#2018 CH1 Pulse Rate Measurement Window CH1 pulse rate measurement window 16#2019 CH1 Pulse Rate Measurement Average Denominator...
Page 632 AX-5 Ser i es M od ul e M an ua l Index Name Description CH1 Pulse Rate Measurement Control Pulse rate measurement control of CH1 16#7013 CH1 Digital Outputs Digital outputs of CH1 16#7014 Objects: 16#A000–16#AFFF  Index Function Description 16#A000 System Error Codes...
Page 633 Ch ap te r 6 Pos i ti on ing Mod ul es Note: *1. If DI Function is set to DI and CLR, corresponding logic polarity and filter settings will not take effect until the Counter is enabled next time. *2.
Page 634 AX-5 Ser i es M od ul e M an ua l Digital output bits Voltage Polarity DQ LED between Connector Qn and IOG (16#7004 and 16#7014) TRUE 0: Normal FALSE 24 V TRUE 24 V 1: Inverse FALSE Note: *1.
Page 635 Ch ap te r 6 Pos i ti on ing Mod ul es Index Subindex Name Description Data type Attr. Default 16#2015 16#00 CH1 Pulse Input Method USINT Explanation  The value of Pulse Input Method is fixed at 0 (Phase Differential Pulse x4), and the object, a Read-Only object, cannot be modified.
Page 636 AX-5 Ser i es M od ul e M an ua l Explanation  The setting value of Pulse Rate Measurement Window ranges from 1 to 65535. If the HC module works in DC mode, the unit is a multiple of the EtherCAT cycle; if the slave works in FreeRun mode, the unit is a multiple of 0.5 ms. Example: 1.
Page 637  When the Delta AX-5 PLC is used as the controller, the module status will be synchronized with the current status of the PLC, 1 (Run) or 2 (Stop). When the PLC is switched to Stop, the output module will behave differently according to the parameter settings for the module, but the input module will not be affected.
Page 638 AX-5 Ser i es M od ul e M an ua l System Error (16#A000) Index Subindex Name Description Data type Attr. Default 16#A000 16#00 System Error System error UINT Explanation  A system error message. Refer to section 6.2.10.1 for details. Warning Codes (16#A001) Index Subindex...
Page 639 Ch ap te r 6 Pos i ti on ing Mod ul es Index Subindex Name Description Data type Attr. Default Reserved 16#08 Reserved STRING (12) Reserved 16#09 Reserved STRING (12) Reserved 16#10 Reserved STRING (12) Reserved 16#11 Reserved STRING (12) 16#12 Reserved Reserved...
Page 640 AX-5 Ser i es M od ul e M an ua l Applications Applications can be used in Process Data, with the following five categories: Counter Function Latch Function Pulse Rate Measurement Function Digital Inputs/Outputs Error Reset/Error Counter Function (16#7000, 16#7001, 16#6000 and 16#6001) This section describes counter-related settings and status.
Page 641 Ch ap te r 6 Pos i ti on ing Mod ul es Parameter Function If the value of the bit changes from 0 to 1, Bit4 of Counter Status: Bit5: External Reset Completed Flag Clear External Reset Completed Flag is reset to 0. If the value of the bit changes from 0 to 1, Bit5 of Counter Status: Bit6: Phase Z Reset Completed Flag Clear Phase Z Reset Completed Flag is reset to 0.
Page 642 AX-5 Ser i es M od ul e M an ua l Function Parameter Once Bit3 of Counter Operation Control: External Reset Enable is enabled, Bit4 of Counter Status: External Reset Enabled will immediately change from 0 to 1 and then the system will wait for the CLR signal trigger to reset the value of Counter Present Position to 0.
Page 643 Ch ap te r 6 Pos i ti on ing Mod ul es Latch Function (16#7002, 16#7012, 16#6002 and 16#6012) This section describes latch-related settings and status. Below is an introdution to Output (RxPDO) of Latch Function. Latch Control: Index Subindex Name Description...
Page 644 AX-5 Ser i es M od ul e M an ua l Each bit of Latch1 Input Control has a different function. Taking CH0 as an example, the functions of its bits are described as follows: Function Parameter Before using the Latch1 function, please first set Latch1 for the desired channel in Startup Parameters.
Page 645 Ch ap te r 6 Pos i ti on ing Mod ul es Below is an introdution to Input (TxPDO) of Latch Function. Latch Status and Input Value: Index Subindex Name Description Data type Attr. Default 16#01 CH0 Latch0 Input Status Latch0 input status of CH0 UINT 16#02...
Page 646 AX-5 Ser i es M od ul e M an ua l Function Parameter When Bit0 of Latch0 Input Status: Latch0 Input Enabled is 1, the Latch0 hardware function is triggered and the value of Counter Present Position is copied to Latch0 Input Value, and then Bit1: Latch0 Input Completed Flag changes from 0 to 1, indicating that the capture is a success.
Page 647 Ch ap te r 6 Pos i ti on ing Mod ul es Parameter Function When Bit0 of Internal Latch Control: Internal Latch Enable changes from 0 to 1, the Internal Latch function is enabled, the value of Counter Present Position is copied to Internal Latch Value, and both Bit0: Internal Latch Bit0: Internal Latch Enabled Enabled and Bit1: Internal Latch Completed Flag of Internal Latch Status...
Page 648 AX-5 Ser i es M od ul e M an ua l Parameter Function If Bit1: Pulse Rate Measurement Value Clear changes from 0 to 1, then Pulse Rate Measurement Value will be cleared to 0 and Bit1 of Pulse Bit1: Pulse Rate Measurement Value Clear Rate Measurement Status: Pulse Rate Measurement Value Clear Completed changes from 0 to 1 indicating that clearing the...
Page 649 Ch ap te r 6 Pos i ti on ing Mod ul es Example When AX-502HC10-0A receives 200,000 pulses which are output at a constant velocity, you want to use the  high-speed counter modules Pulse Rate Measurement function . Set Channel- Pulse Rate Measurement Window to 2.
Page 650 AX-5 Ser i es M od ul e M an ua l Parameter Function 0: Pin DQ1 OFF Bit0: Pin DQ1 setting 1: Pin DQ1 ON 0: Pin DQ3 OFF Bit1: Pin DQ3 setting 1: Pin DQ3 ON 0: Pin DQ5 OFF Bit2: Pin DQ5 setting 1: Pin DQ5 ON Bit3-Bit15: Reserved...
Page 651 Ch ap te r 6 Pos i ti on ing Mod ul es Error Reset/Error (16#200B, 16#201B and 16#A001) This section describes the error reset setting in Error Reset and error code in Error Code. Below is an introdution to Output (RxPDO) of Error Reset. Error Reset: Index Subindex...
Page 652 AX-5 Ser i es M od ul e M an ua l 6.2.7 EtherCAT Synchronization Modes There are two modes for EtherCAT modules to run during operation, FreeRun mode (non-synchronization mode) and DC mode (synchronization mode). Different synchronization modes can be applied to different modules in the same system. FreeRun Mode The I/O values of each module are refreshed based on its own cycle.
Page 653 Ch ap te r 6 Pos i ti on ing Mod ul es 6.2.8 Process Data This section introduces the PDOs for normal data exchanges, and the setting and monitoring of them. Outputs (RxPDO): Index Subindex Name Description Data type Attr. Default CH0 Counter Operation Control Counter operation control of CH0 16#7000 16#00...
Page 654 AX-5 Ser i es M od ul e M an ua l Inputs (TxPDO): Index Subindex Name Description Data type Attr. Default 16#6000 16#00 CH0 Counter Status Counter status of CH0 UINT 16#6001 16#00 CH0 Counter Present Position Present counter value of CH0 DINT Latch0 input status of CH0 16#01...
Page 655 Ch ap te r 6 Pos i ti on ing Mod ul es Process Data Go to the Process Data tab and select the data that you’d like to monitor. You can set the desired PDOs for CH0/CH1 in Outputs and Inputs, and deselect the unused PDOs to save the ...
Page 656 AX-5 Ser i es M od ul e M an ua l EtherCAT I/O Mapping The selected items in the Process Data tab are all shown in the tab of EtherCAT I/O Mapping. Always Update Variables This field is for global setting to define whether or not the I/O variables in the bus cycle task are updated. Option Description DIADesigner-AX updates the I/O variables according to the...
Page 657 Ch ap te r 6 Pos i ti on ing Mod ul es 6.2.9 Example of Hardware Configuration and Software Operation In this section, the AX-502HC module combined with the AX-5 coupler is controlled by AX-3 series PLC. System Hardware Configuration The AX-308E PLC makes a connection with AX-500 plus AX-502HC through the EtherCAT port, reading the encoder via AX-502HC.
Page 658 AX-5 Ser i es M od ul e M an ua l The wiring diagram for AX-502HC and ES3-02CN6941  ES3-02CN6941 AX-502HC 6 - 1 3 4...
Page 659 Ch ap te r 6 Pos i ti on ing Mod ul es Creat a Project and Write a Programm Start the DIADesigner-AX software. Open a new project for AX-308E. Right-click EtherCAT_Master_SoftMotion in the Devices tree, and then click Scan for Devices…. from the context menu.
Page 660 AX-5 Ser i es M od ul e M an ua l After entering the Scan Devices window, click Auto Merge and then OK in the following figures. After adding devices is completed, the AX-502HC module will be added to the device tree. 6 - 1 3 6...
Page 661 Ch ap te r 6 Pos i ti on ing Mod ul es In the device tree, double-click AX_502HC10_0A and then in its Hardware IO Configuration tab, click to set up the configurations you need. After setting up the hardware configurations is done, click the EtherCAT I/O Mapping tab to declare the variables to be used.
Page 662 AX-5 Ser i es M od ul e M an ua l Double-click on Motion_PRG after the declaration of variables for parameters. Enter the Motion-PRG page, where you can start programming with the initial counter value set to 1000 and execute the program.
Page 663 Ch ap te r 6 Pos i ti on ing Mod ul es 6.2.10 Troubleshooting In the Diagnosis History tab, the warnings and errors that occurred in the module are recorded. In the Status tab, only the current error information of System Error (16#A000), CH0 Error (16#200A) and CH1 Error (16#201A) is recorded.
Page 664 AX-5 Ser i es M od ul e M an ua l Index SubIndex ErrorCode Name Description Emergency CLR0 or CLR1 of CH1 DI CH1 DI Function is not Function has not been 16#FF23 set to CLR selected before ExternalReset is triggered. Latch0 of CH1 DI Function CH1 DI Function is not 16#FF21...
Page 665 Ch ap te r 6 Pos i ti on ing Mod ul es Error message  Index SubIndex ErrorCode Description Error LED Solution 1. Make sure that CH0 Counter function has been enabled before the counter- related functions are used. Blinking CH0 Counter is 2.
Page 666 AX-5 Ser i es M od ul e M an ua l Index SubIndex ErrorCode Description Error LED Solution Make sure that CH1 DI Function DI1 has been set to CLR0 or CH1 DI Function DI3 has been set to CLR1 before CH1 CounterExternalReset Blinking function is used.
Page 667 Chapter 7 Load Cell Module Table of Contents 7.1 AX-501LC10-0A ....................7-2 7.1.1 Specifications..................7-2 7.1.2 Dimensions and Parts ................. 7-3 7.1.3 Arrangement of Terminals, LED Indicators and Wiring ......7-4 7.1.4 Settings in DIADesigner-AX ..............7-8 7.1.5 Parameter Descriptions ..............7-16 7.1.6 Gross Weight, Net Weight and Tare Weight ...........
Page 668 AX-5 Ser i es M od ul e M an ua l AX-501LC10-0A AX-501LC10-0A, an analog input module, receives analog signals through 1 input points and converts the received signals to 24-bit digital signals. This section introduces its specifications, wirings and operations. 7.1.1 Specifications Item...
Page 669 Ch ap te r 7 Lo ad Ce ll Mo du le 7.1.2 Dimensions and Parts Dimensions  Unit: mm Parts  7 - 3...
Page 670 AX-5 Ser i es M od ul e M an ua l Name Name AX connector (L) Spring to hold the connection Label (manufacturer information, service information, Spring-clamp terminal block safety, serial number, firmware/hardware version) DIN rail clip Wiring System status indicator Wire fastener Model code Model number and model description...
Page 671 Ch ap te r 7 Lo ad Ce ll Mo du le Pin No. Symbol Description Pin No. Symbol Description SIG+ Sensor positive input SIG- Sensor negative input SEN+ Sensor positive voltage input SEN- Sensor negative voltage input EXC+ Positive excitation voltage output EXC- Negative excitation voltage output EXC+...
Page 672 AX-5 Ser i es M od ul e M an ua l 7.1.3.3 Wiring and Loop Configuration Wiring  6-wire sensor  AX-501LC10-0A SIG+ SIG- SEN+ SEN- EXC+ EXC- EXC+ EXC- 4-wire sensor  AX-501LC10-0A SIG+ SIG- SEN+ SEN- EXC+ EXC- EXC+ EXC-...
Page 673 Ch ap te r 7 Lo ad Ce ll Mo du le  Loop Configuration SIG+ SIG- SEN+ SEN- EXC+ EXC- Shielded cable*1 SIG+ SIG- SEN+ SEN- EXC+ EXC- EXC+ EXC- Power isolation Shielded cable*1 Unit Unit Power Power Connector Connector Power Power...
Page 674 AX-5 Ser i es M od ul e M an ua l 7.1.4 Settings in DIADesigner-AX This section introduces some basic operations and settings in the DIADesigner-AX software. 7.1.4.1 Basic Operation Double-click the DIADesigner-AX icon to open the software and create a new project. Add Modules in Method 1: Add the modules in manually ...
Page 675 Ch ap te r 7 Lo ad Ce ll Mo du le Right-click System Coupler you added, and then click Add Device… again to select and add modules in. 7 - 9...
Page 676 AX-5 Ser i es M od ul e M an ua l Method 2: Scan to add the modules in  Right-click EtherCAT Master SoftMotion in the Devices tree, and then click Scan for Devices…. After the auto-scan is over, the connected devices will appear. Click Copy All Devices to Project button to add them to the list under EtherCAT Master SoftMotion.
Page 677 Ch ap te r 7 Lo ad Ce ll Mo du le 7.1.4.2 Parameter Settings In the CoE Parameters tab, you can do the following settings of parameters. Favorites You can select and right-click the parameter to add the selected parameter to the Favorites. Click on the toolbar ...
Page 678 AX-5 Ser i es M od ul e M an ua l Startup Parameters Once the module is started up, the setting values of parameters in the Startup Parameters list are written to the  module. For editing, you have to set up these parameters in offline mode. Icon Function Description...
Page 679 Ch ap te r 7 Lo ad Ce ll Mo du le Icon Function Description Compare Compare Upload the selected parameters from the module to Upload Selection from Device DIADesigner-AX. Upload all the parameters from the module to Upload All from Device DIADesigner-AX.
Page 680 AX-5 Ser i es M od ul e M an ua l 7.1.4.3 Process Data (1) In the Process Data tab, select the desired outputs and inputs. Click on the toolbar to go into online mode. In the EtherCAT I/O Mapping tab, you can find the variables, current value, status and error codes for each channel.
Page 681 Ch ap te r 7 Lo ad Ce ll Mo du le 7.1.4.4 Diagnosis History Click on the toolbar to go into online mode. The Diagnosis History tab records all error information that occurred on the module. Message column shows the TEXT ID plus error description. Please refer to the troubleshooting section for details on errors.
Page 682 AX-5 Ser i es M od ul e M an ua l 7.1.4.6 Information In the Information tab, you can find the module information, including Name, Vendor, Categories, Type, ID, Version, Order Number and Description for the module. Click on the toolbar to go into online mode. Go to the All Parameters page in the CoE Parameters tab, and then you can find the hardware version and software version.
Page 683 Ch ap te r 7 Lo ad Ce ll Mo du le Index Function Description Function block DFB_LC_Zero DFB_LC_Tare 16#8010 LC Command Load cell application command DFB_LC_ClearTare DFB_LC_ResetExtremum DFB_LC_RD_TareWeight 16#8100 Tare Weight Tare Weight DFB_LC_WR_TareWeight 16#8101 ADC Raw Data ADC Raw Data 7.1.5.1 Module Status Index Subindex...
Page 684 AX-5 Ser i es M od ul e M an ua l 7.1.5.3 Characteristic Value Index Subindex Name Description Data type Attr. Default 16#8000 16#01 Characteristic Value Input characteristic value setting USINT Explanation  Based on the specification of used sensor, select a characteristic value setting that exceeds the specifications. For example, if the characteristic value specification of used sensor is 1.5 mV/V, please select the 2 mV/V mode.
Page 685 Ch ap te r 7 Lo ad Ce ll Mo du le Weight Illustration ± Stable Range △T = Stable Time △T The duration of the measured value within the stable range △T = Stable Time △T < Stable Time Time Stable Status 7.1.5.5 Empty Detection...
Page 686 AX-5 Ser i es M od ul e M an ua l 7.1.5.6 Zero Tracking Data Index Subindex Name Description Attr. Default type Zero Tracking Time, 16#01 Zero Tracking Time setting range: 0 to 600, (unit: 0.1 s) UINT 0 indicates that the function is disabled. 16#8003 Zero Tracking Range, setting range: ≧0,...
Page 687 Ch ap te r 7 Lo ad Ce ll Mo du le 7.1.5.7 Weight Limit Index Subindex Name Description Data type Attr. Default 16#8004 16#01 Weight Limit Upper weight limit REAL 10000.0 Explanation  When the input value exceeds the upper weight limit, the Weight Limit Exceeded value in the PDO data exchange will be 1, and Error LED will start blinking.
Page 688 AX-5 Ser i es M od ul e M an ua l Filter Delay Time explanation  After passing through the filter, the input signal will experience a time delay before stabilizing. Image below uses step response to explain the corresponding delay times for various setting. Actual input value Input value displayed by module...
Page 689 Ch ap te r 7 Lo ad Ce ll Mo du le 7.1.5.9 Decimal Places Index Subindex Name Description Data type Attr. Default Decimal Places setting 16#8006 16#01 Decimal Places USINT Setting range: 0 to 3 Explanation  Choose the number of decimal places based on your needs. 7.1.5.10 Extremum Index...
Page 690 AX-5 Ser i es M od ul e M an ua l 7.1.5.12 LC Command Index Subindex Name Description Data type Attr. Default 16#01 Zero Zeroing BOOL 16#02 Tare Tare BOOL 16#8010 16#03 Clear Tare Clear tare BOOL 16#04 Reset Extremum Value Reset extremum value BOOL Explanation...
Page 691 Ch ap te r 7 Lo ad Ce ll Mo du le 7.1.6 Gross Weight, Net Weight and Tare Weight The meaning of gross weight, net weight, and tare weight is to identify the total weight, the package weight, and the content weight, the definitions are as follows: Tare Weight: A tare is the weight of a package.
Page 692 AX-5 Ser i es M od ul e M an ua l 7.1.7 Calibration The module receives the signal from the load cell sensor as a voltage signal. However, the module does not know how much weight corresponds to the voltage signal. Therefore, the module needs to match the actual weight with the input value displayed by the module, calibrating the current input value to the corresponding weight.
Page 693 Ch ap te r 7 Lo ad Ce ll Mo du le Calibration methods  The following are three calibration methods, it is suggested to maximize the filter’s strength during the calibration and to perform the process in FreeRun Mode. The tare weight will automatically reset to zero after starting the calibration. DIADesigner-AX UI Calibration Configure the module.
Page 694 AX-5 Ser i es M od ul e M an ua l Set the points to be calibrated and their corresponding value. In this example, the total calibration points are 2 points, the first one is zero, and the second point is 100 g corresponding to value 100, as the setting below. After completing the settings, click “Start.”...
Page 695 Ch ap te r 7 Lo ad Ce ll Mo du le (9) Place the actual weight corresponding to the second point on the load cell sensor. In this example, put a weight of 100 g, then click “Calibrate”. Repeat this step if it is a multi-point calibration. (10) Click “Stop”...
Page 696 AX-5 Ser i es M od ul e M an ua l Example This example uses FB command (DFB_LC_Calibration) to perform two-point calibration on the first module to the right side of the EtherCAT Coupler 1. Set lc_enable to TRUE. 2.
Page 697 Ch ap te r 7 Lo ad Ce ll Mo du le Steps: 1. Set the calibration point number. 2. Set the calibration point weight corresponding to the numbers. 3. The sensor remains unloaded. 4. Write value 1 into the calibration command SDO to perform the first point calibration. 5.
Page 698 AX-5 Ser i es M od ul e M an ua l SYNC0  Using the SYNC signal SYNC0 to refresh the values of output channels among modules at the same time. SYNC0 SYNC0 IO Data IO Data AX EtherCAT Bus Refreshing Refreshing Output Module...
Page 699 Ch ap te r 7 Lo ad Ce ll Mo du le FALSE: input value is unstable 16#06 Stable Status BOOL TRUE: input value is stable FALSE: non-empty status 16#07 Empty Status BOOL TRUE: empty status FALSE: the input value is gross weight 16#08 Net Status BOOL...
Page 700 AX-5 Ser i es M od ul e M an ua l 7.1.9.3 Always Update Variables Global setting, define whether to update the I/O variables of bus cycle task. Option Description Use parent device setting Always update variables setting based on CPU. Enabled1 If not used in any other tasks, it will be updated in bus cycle task.
