Summary of Contents for Tektronix PRISM MPX2-25
- Page 1 PRISM MPX2-25 Media Analysis Platform Installation and Safety Instructions *P071368400* 071-3684-00...
- Page 3 PRISM MPX2-25 Media Analysis Platform Installation and Safety Instructions This document supports software version 2.0 and above. Register now! Click the following link to protect your product. ► www.tek.com/register www.tek.com 071-3684-00...
- Page 4 Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are protected by national copyright laws and international treaty provisions. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all previously published material.
- Page 5 Warranty Tektronix warrants that this product will be free from defects in materials and workmanship for a period of one (1) year from the date of shipment. If any such product proves defective during this warranty period, Tektronix, at its option, either will repair the defective product without charge for parts and labor, or will provide a replacement in exchange for the defective product.
- Page 6 2. Transfer the Program to any person or organization outside of Customer or the corporation of which Customer is a part without the prior written consent of Tektronix, except in connection with the transfer of the equipment within which the programs are encoded or incorporated;...
- Page 7 The license granted herein is effective upon acceptance by Customer, and shall remain in effect until terminated as provided herein. The license may be terminated by Customer at any time upon written notice to Tektronix. The license may be terminated by Tektronix or any third party from whom Tektronix may have obtained a respective licensing right if Customer fails to comply with any term or condition and such failure is not remedied within thirty (30) days after notice hereof from Tektronix or such third party.
- Page 9 Environmental considerations ....................PRISM MPX2-25 Installation and Safety Instructions...
- Page 10 Table of Contents PRISM MPX2-25 Installation and Safety Instructions...
- Page 11 Do not apply a potential to any terminal, including the common terminal, that exceeds the maximum rating of that terminal. Do not operate without covers. Do not operate this product with covers or panels removed, or with the case open. Hazardous voltage exposure is possible. PRISM MPX2-25 Installation and Safety Instructions...
- Page 12 Avoid improper or prolonged use of keyboards, pointers, and button pads. Improper or prolonged keyboard or pointer use may result in serious injury. Be sure your work area meets applicable ergonomic standards. Consult with an ergonomics professional to avoid stress injuries. Use only the Tektronix rackmount hardware specified for this product. PRISM MPX2-25 Installation and Safety Instructions...
- Page 13 (This symbol may also be used to refer the user to ratings in the manual.) The following symbol(s) may appear on the product: PRISM MPX2-25 Installation and Safety Instructions...
- Page 14 Video, Audio or Data Monitor PTP trend graphs to ensure proper IP system setup for robust sync system Tektronix patented Timing display showing the relative timing of the input signal and PTP reference that makes facility timing easy...
- Page 15 Download this manual link. See the image below for an example of the location. NOTE. The first seven numbers of the P/N are the Tektronix part number from the product documentation table. The last two numbers are the revision level number.
- Page 16 Figure ii: Location of the document part number and the date it was last updated. Conventions used in this manual The following icons may be used throughout this manual. Sequence Step Front panel Connect power Network SVGA power viii PRISM MPX2-25 Installation and Safety Instructions...
- Page 17 Touch or click the Utilities bar. c. Touch or click the Options bar. d. The display will list all installed product options (for example, MP2-IP-MEAS). The display will read “None” if no options are installed. PRISM MPX2-25 Installation and Safety Instructions...
- Page 18 For the rest of the instrument, use a 75% isopropyl alcohol solution as a cleaner and rinse with deionized water. Before using any other type of cleaner, consult your Tektronix Service Center or representative.
- Page 19 HD-BNC to BNC adapter cables (package of 3) MP-CBL Opt. √ HDBNC-BNC Cable kit for MPX2-DUALDSP dual external touch screen. MP-CBL Opt. DUALDSP √ The rackmount kit includes the Rackmount Slides and Rails Kit Instructions, Tektronix part number 071-2746-xx. PRISM MPX2-25 Installation and Safety Instructions...
- Page 20 When ordering the A99 option, it is the responsibility of the end user to ensure that a certified power cord, for the country or region it is installed, is used with this instrument. CAUTION. To reduce risk of fire and shock, use the certified power cord provided with the product. PRISM MPX2-25 Installation and Safety Instructions...
- Page 21 1/2 inch of clearance from the top of the instrument. Rackmount Use only the Tektronix Rackmount Slides and Rails Kit, MPX2-10 RACK, to install this instrument in an equipment rack. To ensure proper airflow when installing the instrument in a closed rack with solid walls, there must be at least 2 inches of clearance...
- Page 22 Equipment rack installation There is an optional Rackmount Slides and Rails Kit available for the PRISM MPX2-10 monitor (MPX2-10 RACK). The rackmount kit includes the Rackmount Slides and Rails Kit Installation Instructions document (Tektronix part number 071-2746-xx). PRISM MPX2-25 Installation and Safety Instructions...
- Page 23 12G-SDI eye pattern parameters (requires Options MP2-FMT-4K and PHY). PPS. The PPS connector outputs a 1 PPS (Pulse Per Second) signal when the instrument is locked to a PTP reference. PRISM MPX2-25 Installation and Safety Instructions...
- Page 24 firmware, or saving screen and stream captures. HDMI port. HDMI port output for an external monitor. The output video format is 1920×1080. When connecting to an external monitor, a monitor with a 1920×1080 capable display works best with the instrument. PRISM MPX2-25 Installation and Safety Instructions...
- Page 25 To prevent static damage to the SFP module, if you remove the SFP module from the instrument, always transport the SFP module in a anti-static bag or container. NOTE. QSFP modules are not yet supported. PRISM MPX2-25 Installation and Safety Instructions...
- Page 26 To minimize the risk of damage to the instrument, it is strongly recommended that the power cord be connected to the instrument before the power cord is connected to the AC power source. Figure 3: Connecting the power cord to the instrument PRISM MPX2-25 Installation and Safety Instructions...
- Page 27 2. To completely remove power from the instrument, disconnect the power cord from the instrument. The power cord has a locking mechanism to keep it attached to the instrument. Push the button on the cord housing to release the locking mechanism. PRISM MPX2-25 Installation and Safety Instructions...
- Page 28 When you use the PRESET and INPUT buttons, the associated menus appear on the display. The menus close after a short time-out period. Similarly, when you use the VOLUME or BALANCE control, the volume or balance slider and mute controls appear on the display and close after a short time-out period. PRISM MPX2-25 Installation and Safety Instructions...
- Page 29 Application tabs. Some applications have selectable tabs (highlighted readouts) you can use to display additional information. Application tile 4. Application tile 2. The application panels can be shown in four-tile mode or in full screen mode. PRISM MPX2-25 Installation and Safety Instructions...
- Page 30 Perform the following steps to recall instrument presets using the front panel: 1. Press the INPUT button to prepare the instrument for an input selection. 2. Press the SELECTIONS numbered button corresponding to the input you want to monitor. PRISM MPX2-25 Installation and Safety Instructions...
- Page 31 The terms "press and hold", “ tap”, “swipe”, and “pinch” apply to the touchscreen on the instrument. If you are using a mouse and keyboard you must “click and hold”, “click”, “scroll” and use the scroll wheel on the mouse. PRISM MPX2-25 Installation and Safety Instructions...
- Page 32 2. On your computer, enter the following in the URL box of your Web browser, where xxx.xxx.xxx.xxx is the IP address of the Control IP Port of the instrument. http://xxx.xxx.xxx.xxx:6080/vnc.html PRISM MPX2-25 Installation and Safety Instructions...
- Page 33 3. This opens a login Web page as shown below. 4. In the Control bar, click the Settings icon to open the Settings dialog. 5. In the Settings dialog, use the Scaling Mode drop-down list to select Local Scaling, and then click Apply. PRISM MPX2-25 Installation and Safety Instructions...
- Page 34 You can use the WEB REMOTE tab of the PRISM Settings > Network menu to change the default password for the NOTE. remote Web connection. 8. The Web browser connects to the instrument with the browser display appearing exactly like the display on the external monitor, but with a slower update rate. PRISM MPX2-25 Installation and Safety Instructions...
- Page 35 Australia / New Zealand EMC Complies with the EMC provision of the Radiocommunications Act per the following standard, in accordance with ACMA: PRISM MPX2-25 Installation and Safety Instructions...
- Page 36 Use – Part 1: General Requirements. Additional compliances IEC 61010-1. Safety Requirements for Electrical Equipment for Measurement, Control, and Laboratory Use – Part 1: General Requirements. Equipment type Test and measuring equipment. Safety class Class 1 – grounded product. PRISM MPX2-25 Installation and Safety Instructions...
- Page 37 Only mains power supply circuits have an overvoltage category rating. Only measurement circuits have a measurement category rating. Other circuits within the product do not have either rating. Mains overvoltage category rating Overvoltage category II (as defined in IEC 61010-1). PRISM MPX2-25 Installation and Safety Instructions...
- Page 38 This symbol indicates that this product complies with the applicable European Union requirements according to Directives 2012/19/EU and 2006/66/EC on waste electrical and electronic equipment (WEEE) and batteries. For information about recycling options, check the Tektronix Web site (www.tek.com/productrecycling). Battery recycling.
