- Page 1 PRISM MPI2-25 Media Analysis Platform Installation and Safety Instructions *P071365100* 071-3651-00...
- Page 3 PRISM MPI2-25 Media Analysis Platform Installation and Safety Instructions This document supports software version 2.0 and above. Register now! Click the following link to protect your product. ► www.tek.com/register www.tek.com 071-3651-00...
- Page 4 Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are protected by national copyright laws and international treaty provisions. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all previously published material.
- Page 5 Warranty Tektronix warrants that this product will be free from defects in materials and workmanship for a period of one (1) year from the date of shipment. If any such product proves defective during this warranty period, Tektronix, at its option, either will repair the defective product without charge for parts and labor, or will provide a replacement in exchange for the defective product.
- Page 6 2. Transfer the Program to any person or organization outside of Customer or the corporation of which Customer is a part without the prior written consent of Tektronix, except in connection with the transfer of the equipment within which the programs are encoded or incorporated;...
- Page 7 The license granted herein is effective upon acceptance by Customer, and shall remain in effect until terminated as provided herein. The license may be terminated by Customer at any time upon written notice to Tektronix. The license may be terminated by Tektronix or any third party from whom Tektronix may have obtained a respective licensing right if Customer fails to comply with any term or condition and such failure is not remedied within thirty (30) days after notice hereof from Tektronix or such third party.
- Page 9 Environmental considerations ....................PRISM MPI2-25 Installation and Safety Instructions...
- Page 10 Table of Contents PRISM MPI2-25 Installation and Safety Instructions...
- Page 11 Do not apply a potential to any terminal, including the common terminal, that exceeds the maximum rating of that terminal. Do not operate without covers. Do not operate this product with covers or panels removed, or with the case open. Hazardous voltage exposure is possible. PRISM MPI2-25 Installation and Safety Instructions...
- Page 12 Be sure your work area meets applicable ergonomic standards. Consult with an ergonomics professional to avoid stress injuries. Use only the Tektronix rackmount hardware specified for this product. Use care when lifting and carrying the product. This product is provided with a handle as optional carrying case for lifting and carrying.
- Page 13 (This symbol may also be used to refer the user to ratings in the manual.) The following symbol(s) may appear on the product: PRISM MPI2-25 Installation and Safety Instructions...
- Page 14 SDI/IP signal paths. PRISM is an ideal solution for monitoring SDI/IP hybrid environments including master control rooms, production studios, OB vans, and signal contribution/distribution centers. Figure i: PRISM Media Analysis Platform shown with the optional portable cabinet PRISM MPI2-25 Installation and Safety Instructions...
- Page 15 Video, Audio or Data Monitor PTP trend graphs to ensure proper IP system setup for robust sync system Tektronix patented Timing display showing the relative timing of the input signal and PTP reference that makes facility timing easy...
- Page 16 4. Sort by Date above the search bar. 5. The first manual in the list should be the latest PRISM User Manual. Click the link to the manual for additional information and to download. viii PRISM MPI2-25 Installation and Safety Instructions...
- Page 17 Download this manual link. See the image below for an example of the location. NOTE. The first seven numbers of the P/N are the Tektronix part number from the product documentation table. The last two numbers are the revision level number.
- Page 18 Preface PRISM MPI2-25 Installation and Safety Instructions...
- Page 19 The cloth can either be used dry or dampened with water or eyeglass cleaner. For the rest of the instrument, use a 75% isopropyl alcohol solution as a cleaner and rinse with deionized water. Before using any other type of cleaner, consult your Tektronix Service Center or representative. PRISM MPI2-25 Installation and Safety Instructions...
- Page 20 For one MPI2-25 unit or one MPI2-25 unit in a side-by-side installation MPI-RACK-MW √ with a WFM52x0, WFM7200, WFM8x00 instrument The dual rack cabinet kit includes the PRISM Dual Rack Cabinet Installation Instructions, Tektronix part number 071-3577-xx. PRISM MPI2-25 Installation and Safety Instructions...
- Page 21 When ordering the A99 option, it is the responsibility of the end user to ensure that a certified power cord, for the country or region it is installed, is used with this instrument. CAUTION. To reduce risk of fire and shock, use the certified power cord provided with the product. PRISM MPI2-25 Installation and Safety Instructions...
- Page 22 1/2 inch of clearance from the top of the instrument. sleeves) Portable Use only the Tektronix portable cabinet, MPI2-PTBL, to ensure proper airflow with this Cabinet instrument. When using the portable cabinet, the same minimum clearances as the Bare Instrument apply.
- Page 23 Dimensions Height 13.72 cm (5.4 in.) Width Chassis: 20.83 cm (8.2 in.) Bezel: 22.10 cm (8.7 in.) Depth 29.85 cm (11.75 in.) Weight Approximately 3.3 kg (7.3 lb.) Shipping Typically 10.64 kg (23.4 lb.) PRISM MPI2-25 Installation and Safety Instructions...
- Page 24 There are two optional dual rack cabinets (19”, 3RU) available for the PRISM monitor. Each of the cabinet kits include the PRISM MPI Dual Rack Cabinet and Extender Installation Instructions document (Tektronix part number 071-3577-xx). MPI-RACK-MM. Allows you to install one MPI2-25 unit or two MPI2-25 units side-by-side. The front of the cabinet has two USB ports and a headphone jack for each MPI2-25 unit.
- Page 25 1/10GE SFP+. Optional SFP+ output for 1/10GE signals . SDI SFP+ inputs 3 and 4 support HD/3G signals. 25/100GE SFP+ 1-2. Two optional SFP+ ports for 25/100GE Ethernet applications. Aux OUT. SDI output of the selected SDI or ST2022-6 IP input. PRISM MPI2-25 Installation and Safety Instructions...
- Page 26 Audio output. 3.5 mm line out port for using headphones to listen to the selected audio channel pair. Mic input. This connector is for future use. When connecting to an external monitor, a monitor with a 1920×1080 capable display works best with the instrument. PRISM MPI2-25 Installation and Safety Instructions...
- Page 27 An optical SFP module is shown above. Other types of SFP modules may have different latching mechanisms. SFP module transportation CAUTION. To prevent static damage to the SFP module, if you remove the SFP module from the instrument, always transport the SFP module in a anti-static bag or container. PRISM MPI2-25 Installation and Safety Instructions...
- Page 28 To minimize the risk of damage to the instrument, it is strongly recommended that the power cord be connected to the instrument before the power cord is connected to the AC power source. Figure 4: Connecting the power cord to the instrument PRISM MPI2-25 Installation and Safety Instructions...
- Page 29 2. To completely remove power from the instrument, disconnect the power cord from the instrument. The power cord has a locking mechanism to keep it attached to the instrument. Push the button on the cord housing to release the locking mechanism. PRISM MPI2-25 Installation and Safety Instructions...
- Page 30 Application tabs. Some applications have selectable tabs (highlighted readouts) you can use to display additional information. Application tile 4. Application tile 2. The application panels can be shown in four-tile mode, full screen mode, or in vertical extended tile mode. PRISM MPI2-25 Installation and Safety Instructions...
- Page 31 The terms "press and hold", “ tap”, “swipe”, and “pinch” apply to the touchscreen on the instrument. If you are using a mouse and keyboard you must “click and hold”, “click”, “scroll” and use the scroll wheel on the mouse. PRISM MPI2-25 Installation and Safety Instructions...
- Page 32 Connect the Display Port output from the PRISM monitor to the input on the external device. Connect the USB output of the external device to one of the USB ports on the PRISM monitor. NOTE. A monitor with a 1920×1080 capable display works best with the instrument. PRISM MPI2-25 Installation and Safety Instructions...
- Page 33 2. On your computer, enter the following in the URL box of your Web browser, where xxx.xxx.xxx.xxx is the IP address of the Control IP Port of the instrument. http://xxx.xxx.xxx.xxx:6080/vnc.html 3. This opens a login Web page as shown below. 4. In the Control bar, click the Settings icon to open the Settings dialog. PRISM MPI2-25 Installation and Safety Instructions...
- Page 34 7. In the Settings dialog, enter the default password PRISM, and then click Connect. NOTE. You can use the WEB REMOTE tab of the PRISM Settings > Network menu to change the default password for the remote Web connection. PRISM MPI2-25 Installation and Safety Instructions...
- Page 35 Operation 8. The Web browser connects to the instrument with the browser display appearing exactly like the instrument display, but with a slower update rate. PRISM MPI2-25 Installation and Safety Instructions...
- Page 36 Australia / New Zealand EMC Complies with the EMC provision of the Radiocommunications Act per the following standard, in accordance with ACMA: PRISM MPI2-25 Installation and Safety Instructions...
- Page 37 Use – Part 1: General Requirements. Additional compliances IEC 61010-1. Safety Requirements for Electrical Equipment for Measurement, Control, and Laboratory Use – Part 1: General Requirements. Equipment type Test and measuring equipment. Safety class Class 1 – grounded product. PRISM MPI2-25 Installation and Safety Instructions...
- Page 38 Only mains power supply circuits have an overvoltage category rating. Only measurement circuits have a measurement category rating. Other circuits within the product do not have either rating. Mains overvoltage category rating Overvoltage category II (as defined in IEC 61010-1). PRISM MPI2-25 Installation and Safety Instructions...
- Page 39 This symbol indicates that this product complies with the applicable European Union requirements according to Directives 2012/19/EU and 2006/66/EC on waste electrical and electronic equipment (WEEE) and batteries. For information about recycling options, check the Tektronix Web site (www.tek.com/productrecycling). Battery recycling.
