Winmate S101MT User Manual

10.1" rugged windows tablet
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
S101MT
10.1" Rugged Windows Tablet
Intel® Core™ Ultra 5 Processor 125U @ 2.1GHz (Turbo Boost up to 4.3 GHz)
User Guide
Version 1.0
Document Part No. 9152101K102C
Please read the instructions carefully before using this product and save this manual for future use.
https://dc.winmate.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S101MT and is the answer not in the manual?

Questions and answers

Related Manuals for Winmate S101MT

Summary of Contents for Winmate S101MT

  • Page 1 S101MT 10.1" Rugged Windows Tablet Intel® Core™ Ultra 5 Processor 125U @ 2.1GHz (Turbo Boost up to 4.3 GHz) User Guide Version 1.0 Document Part No. 9152101K102C https://dc.winmate.com Please read the instructions carefully before using this product and save this manual for future use.

  • Page 2: Table Of Contents

    10.1” Rugged Windows Tablet S101MT User Guide Content Chapter 1: Read Me First .......................... 3 1.1 Advisory Conventions .......................... 3 1.2 Safety Information ..........................4 1.3 Handling and Maintenance ........................6 1.4 Declaration of Conformity (DoC) ......................7 1.5 Copyright Notice ..........................8 1.6 Trademark Acknowledgement ......................
  • Page 3 Content 4.5 Check for IMEI Number ........................42 4.6 Check for Update ..........................44 Chapter 5: Frequently Used Settings ..................... 45 5.1 Screen Resolution Setting ......................... 45 5.1.1 Changing Display Scaling (Recommended) ................45 5.1.2 Changing Screen Resolution ....................46 5.1.3 Advanced Display Setting ......................

  • Page 4: Chapter 1: Read Me First

    10.1” Rugged Windows Tablet S101MT User Guide Chapter 1: Read Me First 1.1 Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings.

  • Page 5: Safety Information

    Chapter 1: Read Me First 1.2 Safety Information Precaution on Battery Pack When the Battery Pack Has Deteriorated, Précaution avec le bloc-pile Replace It with a New Battery. Continued use of a damaged battery pack may result in heat generation, ignition, or battery rupture. [FR] Lorsque la pile est détériorée, la Do Not Disassemble, Modify, or Insert Sharp remplacer par une nouvelle pile.
  • Page 6 10.1” Rugged Windows Tablet S101MT User Guide General Product Safety ▪ This product should not be used near water Sécurité générale des such as bathtubs, sinks, swimming pools, wet basement, etc. produits [FR] Ce produit ne dois pas être utilisé près de l'eau comme les baignoires, les éviers, les...

  • Page 7: Handling And Maintenance

    Chapter 1: Read Me First 1.3 Handling and Maintenance Gently wipe the display with a soft, lint-free cloth. Do not use alcohol or detergent on the product. General Guideline [FR] Essuyer délicatement l'écran avec un Guide Général chiffon doux non pelucheux. Ne pas utiliser d'alcool ou un détergent sur le produit.

  • Page 8: Declaration Of Conformity (Doc)

    10.1” Rugged Windows Tablet S101MT User Guide 1.4 Declaration of Conformity (DoC) FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. ⚫ This device must accept any interference received, including interference that may ⚫...

  • Page 9: Copyright Notice

    Brand and product names are trademarks or registered trademarks of their respective owners. 1.7 Disclaimer Winmate Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. We assume...

  • Page 10: Chapter 2: Getting Started

    Generation Intel® Meteor Lake processor for high performance. The tablet features a brilliant, in-plane switching with anti-glare screen, projective capacitive touch screen, which is outdoor viewable and offers 1920 x 1200 pixel resolution, and weighing at just 1.1 kg, the S101MT delivers lightweight mobility in a rugged tablet.

  • Page 11: Description Of Parts

    Chapter 2: Getting Started 2.3 Description of Parts Dimensions: 272 x 192 x 25 mm Front: Left: Right: Item Description Item Description 10.1” Touch Micro HDMI HDMI output to the Display and act as one of Screen (Optional) external display the inputs for the Tablet Reset Button Hardware reset button...

  • Page 12: Indicators

    10.1" Rugged Windows Tablet S101MT User Guide Rear: Top: Bottom: Item Description Item Description Fn2 Button Programmable function Barcode Barcode Scanner for key configured by Hottab Reader reading of 1D/2D Utility (Optional) barcode. Fn1 Button Programmable function Docking Port to docking solutions...

  • Page 13: Hotkey For Specific Functions

    Chapter 2: Getting Started 2.5 Hotkey for Specific Functions Physical buttons with its dedicated functions can also be used to emulate commonly used keyboard keystrokes. Under a different scenario, a single physical button or a combination of physical buttons provide different keyboard keystrokes, which are specified below: In POST (before Windows boots up): In Windows:...

  • Page 14: Installing Sim Card (For 4G/Lte Equipped Devices)

    10.1" Rugged Windows Tablet S101MT User Guide 2.6.2 Installing SIM card (For 4G/LTE Equipped Devices) The Tablet Computer supports 4G/LTE data connections and fits a Nano-SIM card. To install the SIM card: ❶ Remove the battery, as described in the section ❷...

  • Page 15: Installing A Microsd Card

    Chapter 2: Getting Started 2.6.3 Installing a MicroSD Card Your tablet supports up to 128GB additional storage with an optional microSD card slot. To install MicroSD Card: 1. Remove the battery, as described in section 2.6.1 Installing Battery. 2. Open microSD slot protective cover 3.

  • Page 16: Starting The Tablet

    10.1" Rugged Windows Tablet S101MT User Guide 2.6.5 Starting the Tablet Important: When powering on the device for the first time, please make sure there's no interruption during the Windows setting up process, for example, accidentally powering off. If it happened, please access the recovery menu by pressing Fn1 button to initiate the recovery process.

  • Page 17: Chapter 3: Setting Up Windows For The First Time

    This chapter details how to setup the Windows that may be installed on the tablet for the first time. 3.1 Introduction The S101MT Tablet Computer operates on Windows 11 IoT Enterprise LTSC operating system. Caution Make sure the battery is full charged before starting the Tablet Computer for the first time with internal battery power.
  • Page 18 10.1" Rugged Windows Tablet S101MT User Guide 3. Select your preferred keyboard layout, then tap Yes.
  • Page 19 Chapter 3: Setting Up Windows for the First Time 4. Tap Add layout if you want to add a second keyboard layout, or tap Skip for the next step. 5. Windows will then try to connect you to a network. Select your network and press Next to continue, or tap I don't have internet to continue without a wireless connection, as you can set up the network later.
  • Page 20 10.1" Rugged Windows Tablet S101MT User Guide 6. Review the License Agreement, then select Accept to proceed with the setup. 7. Type your name, then tap Next.
  • Page 21 Chapter 3: Setting Up Windows for the First Time 8. Create your password, then tap Next. 9. Read each privacy settings and choose it, you can tap Learn more for more information, or tap Accept to save them. You can change these settings at any time.
  • Page 22 10.1" Rugged Windows Tablet S101MT User Guide 10. Read any introductory screens describing features of your computer, and tap Next upon completing each. You are now done with the initial setup process.

  • Page 23: Chapter 4: Operating The Device

    This chapter describes how to operate the S101MT Tablet Computer, including camera, Hottab, barcode, WWAN, WLAN, GPS features. Note: Please download the SDK from Winmate Download Center (the QR code in the cover page) >> S101MT >> Development Kit. Please notice that the barcode reader is an optional module.

  • Page 24: Shortcuts

    10.1" Rugged Windows Tablet S101MT User Guide Icon Description Allows users to configure short cut to access programs quickly with a few tabs. Shortcuts Allows users to take a picture or record a video. Users can also adjust the setting related to the camera in this menu option.

  • Page 25: Using The Camera

    Chapter 4: Operating the Device 4.3 Using the Camera CAUTION Possibly hazardous optical radiation emitted from this product. Do not stare at operating lamp. May be harmful to the eyes. This Hottab menu option allows users to take a picture or record a video. Before use, make sure the camera is on under the Device ON/OFF menu with the following scenarios.
  • Page 26 10.1" Rugged Windows Tablet S101MT User Guide 2. The default camera is the rear camera. To change into the front camera, click on the Switch Camera button. No Item Description Switch Camera Switch between front camera or rear camera. Settings Set picture quality.

  • Page 27: Built-In Devices On/Off

    Chapter 4: Operating the Device 4.4 Built-in Devices On/Off This section describes how to get quick access to set up built-in devices, including turning on/off RF modules and setting up barcode reader. 4.4.1 Using the Wireless LAN To use the wireless LAN (WLAN) feature to connect to the network, perform the following procedure: 1.

  • Page 28: Using The Wireless Wan

    10.1" Rugged Windows Tablet S101MT User Guide 4.4.2 Using the Wireless WAN The Tablet Computer supports data connection with 4G/LTE modules and fits a Nano SIM card. (Note: 4G/LTE feature is optional). 4.4.2.1 Installing a SIM card Caution Power off the tablet before installing the 4G/LTE module and Nano SIM card, or the tablet computer might be damaged by the incorrect installation behaviors.

  • Page 29: Using The Gps

    Chapter 4: Operating the Device 4.4.2.2 Using Wireless WAN Feature To connect to the network using wireless WAN: 1. Launch the Hottab Utility application. 2. Tap on the Device ON/OFF button. 3. Check the status color of the WWAN icon: Item Status Color Description...

  • Page 30: Turning On/Off Led Indicators

    4. If the indicator is disabled (white), tap on the Indicator icon to enable it (orange). 4.4.6 Replacing Battery The S101MT Tablet supports optional hot-swap, meaning the tablet doesn’t need to be powered off to replace the main battery. To support hot-swap, there is a built-in backup battery inside the tablet that is charged together with the main battery.
  • Page 31 Chapter 4: Operating the Device 5. If the indicator is disabled (white), tap on the Hot-Swap Bat icon to enable it (orange). 6. A Warning Message dialog box will pop out. Click Ready for hot swapping before replacing the battery. Important: 1.

  • Page 32: Using The Barcode Reader

    4.4.7 Using the Barcode Reader The 2D/1D Barcode Reader is optional for S101MT Tablet PC and is not re-workable by the end-user. To use this feature, please make sure the tablet PC has a built-in barcode reader before use, or contact our sales contact window for more details.
  • Page 33 Chapter 4: Operating the Device 4.4.7.1 Device Configuring and Setting Click on Windows and search for EZConfig-Scanning from the Start menu. Click on EZConfig-Scanning v4_IE and allow the blocked content if the browser is blocking the content. If you are connecting the device for the first time, as part of out of box experience, please ensure that REMIFC1! is enabled for a smooth connection with EZConfig application.
  • Page 34 10.1" Rugged Windows Tablet S101MT User Guide Once the device is discovered, please click the Configure Device button as shown. 4.4.7.2 Scanning mode Settings 1. Click on Device Settings under the Input/Output Settings section. 2. Select the desire scanning mode from the drop-down menu shown below.
  • Page 35 Chapter 4: Operating the Device 3. After selecting a desire scanning mode, click on the Save to Device on the sidebar. Scanning Description mode When in manual trigger mode, the scanner scans until a bar code is read or until the trigger is released.
  • Page 36 10.1" Rugged Windows Tablet S101MT User Guide 4.4.6.3 Setting the 1D/2D Barcode Scanner Symbologies The barcode scanner is shipped with the default settings shown below. If the default setting suits the usage requirement, setting symbologies is not necessary. Symbologies Default Settings:...
  • Page 37 Chapter 4: Operating the Device Method (2). Click on the Reset to Default button on the side as shown: ※Warning※ 1. The reset to default button will change all settings to default. 2. Honeywell barcode could disconnect with the system after clicking the Reset to Default button. If the Disconnection happened, please scan the barcodes below in the following steps.
  • Page 38 10.1" Rugged Windows Tablet S101MT User Guide 4.4.6.4 Adding a Prefix or Suffix To add a refix or suffix, please click on the Data Formatting icon. Click on the Editor button under the Prefix or Suffix section and create Prefix/Suffix value by typing in the block or select desire characters in the Control chars, Printable chars, and Extended ASCII.
  • Page 39 Chapter 4: Operating the Device When you finish creating Prefix/Suffix, please click on Save to Device on the sidebar. To check the functionality of Prefix/Suffix, please click on the Scan Data Window icon on the top. Then scan a barcode to verify if the Prefix/Suffix appears correctly.

  • Page 40: Turn On/Off The Gps External Antenna

    4.4.8 Turn on/off the GPS External Antenna The vehicle dock of the S101MT Tablet PC supports an external GPS antenna through a standard SMA connector. To work with an external GPS antenna, please make sure the tablet PC is installed correctly to the vehicle dock and the vehicle dock has connected with an external GPS antenna.

  • Page 41: Changing Touchscreen Modes

    Chapter 4: Operating the Device 4.4.10 Changing Touchscreen Modes The tablet computer supports three built-in operating modes for different usage scenarios: Mode Description In Hand/Rain mode, the touchscreen rejects false inputs from liquid drops. When the liquid is removed, the touchscreen accepts touch inputs from bare fingertips. Supports input by: ...
  • Page 42 10.1" Rugged Windows Tablet S101MT User Guide 4.4.10.2 Switch via Programmable Function Buttons: To switch between the different touchscreen modes via the programmable function buttons, ensure the touchscreen mode switching is set to the programmable function buttons first. Launch the Hottab Utility application.

  • Page 43: Check For Imei Number

    Chapter 4: Operating the Device 4.5 Check for IMEI Number The WWAN function is optional. To check how to read the IMEI number, follow the below steps: 1. Go to Windows Settings and click Network & Internet. 2. Select Cellular and click Advanced options.
  • Page 44 10.1" Rugged Windows Tablet S101MT User Guide 3. Then, you will be directed to the below screen, and the IMEI number will be shown.

  • Page 45: Check For Update

    Chapter 4: Operating the Device 4.6 Check for Update To check for software update, perform the following procedure: 1. Launch the Hottab Utility application. 2. Tap on the Setting button. 3. Check the Check for Update. 4. The available update will show up. Click Update to download and install it.

  • Page 46: Chapter 5: Frequently Used Settings

    Chapter 5: Frequently Used Settings 5.1 Screen Resolution Setting The S101MT's 1920 x 1200 high-resolution display is perfect for viewing images, videos, or other applications. However, when the device is used alone or connected to other device, the Windows user interface (icons, buttons, and other elements) may be too small to read and operate at the default Windows settings.

  • Page 47: Changing Screen Resolution

    Chapter 5: Frequently Used Settings 2. On Display Window, click on the drop-down option under the Scale and layout and change the scaling option to 150% (Recommended) or any other desired display scaling. 5.1.2 Changing Screen Resolution Alternatively, instead of changing the display scaling setting, user may choose to change the overall resolution setting to make screen elements bigger.

  • Page 48: Advanced Display Setting

    10.1" Rugged Windows Tablet S101MT User Guide 2. Click on the drop-down option next to Resolution and select the desire resolution by tapping on the scale. 3. Hit Apply. A Display Settings prompt will show up to ask the user if the applied resolution is usable.
  • Page 49 Chapter 5: Frequently Used Settings 2. When the S101MT is connected to external display, the Advanced display setting options is available. Click Advanced Display settings. 3. On the Choose display, change the display then change the refresh rate to 30.000 Hz.

  • Page 50: Using Recovery Wizard To Restore Computer

    5.2 Using Recovery Wizard to Restore Computer The S101MT Tablet Computer has a dedicated recovery partition stored on the tablet's hard drive to enable a quick one-key recovery process. This partition occupies about 11GB of the storage space and comes built-in to each S101MT Tablet Computer.
  • Page 51 Chapter 5: Frequently Used Settings 5. Wait till the recovery process to complete. During the recovery process, a command prompt will show up to indicate the percent of the recovery process. 6. After the recovery is complete, please press any key to continue, and the tablet computer will shut down automatically.

  • Page 52: Docking Connector Pin Definition

    1 x Giga LAN • 1x UART (TxRx) • 5V/1A out 5.5 Expansion Port Pin Definition The S101MT tablet computer includes a 40-pin expansion port connector located on the rear side. The pin definition is listed in the following table.
  • Page 53 Chapter 5: Frequently Used Settings 40-Pin Expansion Port Connector Type Pin No. Define (UART) Note UART MDI 0+ MDI 0- MDI 1+ Using the Giga LAN from the MDI 1- Giga LAN Expansion Port will automatically MDI 2+ disable the Tablet’s default LAN. MDI 2- MDI 3+ MDI 3-...

  • Page 54: Com Port Definition

    10.1" Rugged Windows Tablet S101MT User Guide 5.6 COM Port Definition The S101MT tablet computer uses Hottab utility for built-in peripherals control. All the COM port numbers have been defined in the OS image coming with the package. COM Port...
  • Page 55 Chapter 5: Frequently Used Settings Tap on the Port Setting tab and click on Advanced button. Tap on the drop-down list, choose the correct COM Port Number (refer to the COM Port Definition Table), and click OK. Double-check Device Manager to make sure the COM Port number has been re-defined successfully, and then restart the system.

  • Page 56: Pairing With A Wireless Bluetooth Barcode Scanner

    10.1" Rugged Windows Tablet S101MT User Guide 5.7 Pairing with a Wireless Bluetooth Barcode Scanner The computer is affixed with a Bluetooth MAC (Media Access Control) address barcode label that enables wireless Bluetooth Barcode Scanner to establish a Bluetooth connection quickly. It is encoded with leading characters to instruct the wireless Bluetooth barcode scanner to initial Bluetooth Serial Port Profile pairing request.
  • Page 57 Chapter 5: Frequently Used Settings 3. Once the Bluetooth & other devices Menu appears, click More Bluetooth options under Related settings section as shown below. 4. Go to Options tab, and make sure that in the Discovery section, the computer is set to Allow Bluetooth devices to find this computer as shown below: Click OK to continue.
  • Page 58 10.1" Rugged Windows Tablet S101MT User Guide 5. In the Bluetooth Settings menu, go to COM Ports tab. COM port has to be setup for the wireless Bluetooth Barcode Scanner to communicate via the Bluetooth Serial Port Profile. Click on the Add…...
  • Page 59 Chapter 5: Frequently Used Settings 7. The computer will automatically assign COM Port to the Bluetooth connection. In the screenshot below, COM4 is allocated. Click OK to continue. 8. Next, the user has to configure the application to accept the scanned data from the wireless Bluetooth Barcode Scanner.

  • Page 60: Set Up The Barcode Scanner For Bluetooth Pairing

    10.1" Rugged Windows Tablet S101MT User Guide 5.7.2 Set up the Barcode Scanner for Bluetooth Pairing Important: The wireless Bluetooth Barcode Scanner has to be configured as a Bluetooth Serial Port Profile Master device to establish connection via Bluetooth MAC address barcode label.
  • Page 61 Chapter 5: Frequently Used Settings 5. In Add a Bluetooth Device window, click Next to connect the Barcode Scanner to the Computer. In order to ensure that Bluetooth Device is successfully paired to the computer, follow the steps below: 1. Locate the Bluetooth icon in the Notification Area. Select Show Bluetooth Devices. You can access this menu in the Control Panel: ➔Control Panel ➔...

  • Page 62: Chapter 6: Troubleshooting

    10.1" Rugged Windows Tablet S101MT User Guide Chapter 6: Troubleshooting 6.1 Basic Troubleshooting Problem Solution • The removable battery is not charging. Make sure the AC adapter is properly connected and that the removable battery is properly inserted. • Nothing appears on the screen.
  • Page 63 Chapter 6: Troubleshooting Problem Solution • No sound is produced. Adjust the volume of the tablet computer by pressing on the volume rocker. • If using an external audio device, make sure that the cable is properly connected. • I cannot project the tablet computer Make sure the VGA driver is installed.

  • Page 64: Appendix

    Appendix Appendix Appendix A: Product Specifications S101MT Model Name Size 10.1 inches Resolution 1920x1200 Brightness 800 nits Contrast Ratio 800:1 (typ) Display Viewing Angle 85/85/85/85 Touch Projected Capacitive Multi-Touch Bonding Optical Bonding for Sunlight Viewability Viewability Anti-Glare touch treatment Intel Core Ultra 5 Processor 125U Meteor Lake @ 2.1GHz Processor (Turbo Boost up to 4.3 GHz)
  • Page 65 1. Accessories and Integrated Options may vary depending on your configuration. The product shown in this document is a standard model. For diagrams that contain customized or optional I/O, please contact the Winmate Sales Team for more information. 2. All specifications are subject to change without prior notice.
  • Page 66 NOTES...
  • Page 67 NOTES...
