Winmate S101TG User Manual

10.1-inch rugged windows tablet
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
S101TG
10.1" Rugged Windows Tablet
Intel Core i3-1115G4 3.0 GHz (turbo boost up to 3.9 GHz)
Intel Core i5-1135G7 @ 2.4GHz (turbo boost up to 4.2GHz, optional)
User Guide
Version 1.0
Document Part No.
9152101K1018
https://dc.winmate.com

Advertisement

Table of Contents
loading

Related Manuals for Winmate S101TG

Summary of Contents for Winmate S101TG

  • Page 1 S101TG 10.1" Rugged Windows Tablet Intel Core i3-1115G4 3.0 GHz (turbo boost up to 3.9 GHz) Intel Core i5-1135G7 @ 2.4GHz (turbo boost up to 4.2GHz, optional) User Guide Version 1.0 https://dc.winmate.com Document Part No. 9152101K1018...

  • Page 2: Table Of Contents

    S101TG Rugged Tablet User Guide Contents Chapter 1: Read Me First .......................... 3 1.1 Advisory Conventions .......................... 3 1.2 Safety Information ..........................4 1.3 Handling and Maintenance ........................6 1.4 Declaration of Conformity (DoC) ......................7 1.5 Copyright Notice ..........................8 1.6 Trademark Acknowledgement ......................
  • Page 3 10.1" Rugged Windows Tablet S101TG User Guide 5.1.1 Changing Display Scaling (Recommended) ................37 5.1.2 Changing Screen Resolution ....................38 5.2 Replacing Battery ..........................40 5.3 Using Recovery Wizard to Restore Computer ................... 41 5.4 Docking Connector Pin Definition ...................... 43 5.5 COM Port Definition ..........................

  • Page 4: Chapter 1: Read Me First

    Chapter 1: Read Me First Chapter 1: Read Me First 1.1 Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings.

  • Page 5: Safety Information

    S101TG Rugged Tablet User Guide 1.2 Safety Information When the Battery Pack Has Deteriorated, Precaution on Battery Pack Replace It with a New Battery. Continued use Précaution avec le bloc-pile of a damaged battery pack may result in heat generation, ignition, or battery rupture.
  • Page 6 S101TG Rugged Tablet User Guide ▪ This product should not be used near water General Product Safety such as bathtubs, sinks, swimming pools, wet Sécurité générale des basement, etc. produits [FR] Ce produit ne dois pas être utilisé près de l'eau comme les baignoires, les éviers, les...

  • Page 7: Handling And Maintenance

    Chapter 1: Read Me First 1.3 Handling and Maintenance Gently wipe the display with a soft, lint-free cloth. Do not use alcohol or detergent on the product. General Guideline [FR] Essuyer délicatement l'écran avec un chiffon doux non pelucheux. Ne pas utiliser Guide Général d'alcool ou un détergent sur le produit.
  • Page 8 FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

  • Page 9: Declaration Of Conformity (Doc)

    The SAR limit of USA/Canada (FCC/IC) is 1.6 W/kg averaged over one gram of tissue. Device types: S101TG (FCC ID: PX9S101，IC: 9911A-S101) has also been tested against this SAR limit. The highest SAR value reported under this standard during product certification for use properly worn on the body is 0.311W/kg.

  • Page 10: Copyright Notice

    Brand and product names are trademarks or registered trademarks of their respective owners. 1.7 Disclaimer Winmate Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. We assume...

  • Page 11: Chapter 2: Getting Started

    2.1 Introduction Congratulations on purchasing Winmate® 10.1-inch Rugged Windows Tablet S101TG. S101TG is a rugged tablet with robust features designed to withstand industrial use while providing high- tech solutions that increase productivity, improve safety, and reduce operational costs. The processing power comes from the 11 generation Intel®...

  • Page 12: Description Of Parts

    Chapter 2: Getting Started 2.3 Description of Parts Dimensions: 268 x 187 x 22.2 mm Front: Left: Right: Item Description Item Description 10.1" Touch Display and act as one of Micro HDMI HDMI output Screen the inputs for the Tablet (Optional) external display Computer...

  • Page 13: Indicators

    S101TG Rugged Tablet User Guide Rear: Top: Bottom: Item Description Item Description Fn1 Button Programmable function Barcode Barcode Scanner key configured by Hottab Reader reading 1D/2D Utility (Optional) barcode. Fn2 Button Programmable function Docking Port to docking solutions key configured by Hottab...

  • Page 14: Hotkey For Specific Functions

    Chapter 2: Getting Started 2.5 Hotkey for Specific Functions Physical buttons with its dedicated functions can also be used to emulate commonly used keyboard keystrokes. Under a different scenario, a single physical button or a combination of physical buttons provide different keyboard keystrokes, which are specified below: In POST (before Windows boots up): In Windows:...

  • Page 15: Installing Sim Card (For 4G/Lte Equipped Devices)

    S101TG Rugged Tablet User Guide 2.6.2 Installing SIM card (For 4G/LTE Equipped Devices) The Tablet Computer supports 4G/LTE data connections and fits a Nano-SIM card. To install the SIM card: ❶ Remove the battery, as described in section 2.6.1 ❷ Open the SIM-card slot rubber protection cover.

  • Page 16: Installing A Microsd Card

    Chapter 2: Getting Started 2.6.3 Installing a MicroSD Card Your tablet supports up to 128GB additional storage with an optional microSD card slot. To install MicroSD Card: 1. Remove the battery, as described in section 2.6.1 Installing Battery. 2. Open microSD slot protective cover 3.

  • Page 17: Starting The Tablet

    S101TG Rugged Tablet User Guide 2.6.5 Starting the Tablet Important: When powering on the device for the first time, please make sure there's no interruption during the Windows setting up process, for example, accidentally powering off. If it happened, please access the recovery menu by pressing Fn1 button to initiate the recovery process.

  • Page 18: Chapter 3: Setting Up Windows For The First Time

    This chapter details how to setup the Windows that may be installed on the tablet for the first time. 3.1 Introduction The S101TG Tablet Computer operates on Windows 10 IoT Enterprise operating system. Caution Make sure the battery is full charged before starting the Tablet Computer for the first time with internal battery power.
  • Page 19 S101TG Rugged Tablet User Guide 3. On the Here's the legal stuff screen, read through the disclosures, then tap Accept. 4. Windows will then try to connect to a network. Tap Skip this step to continue without a wireless connection, as you can then set up the network later.
  • Page 20 Chapter 3: Setting Up Windows for the First Time 6. To create a local account, type your User name, password, and Password hint in the fields provided, then tap Next. 7. The initial setup screens are complete, and the desktop is displayed. 8.

  • Page 21: Chapter 4: Operating The Device

    WWAN, WLAN, GPS features. Note: Please download the SDK from Winmate Download Center (the QR code in the cover page) >> S101TG >> Development Kit. Please notice that the barcode reader is an optional module. Please make sure you have ordered the module before using the SDK.

  • Page 22: Shortcuts

    Chapter 4: Operating the Device Icon Description Allows users to configure short cut to access programs quickly with a few tabs. Shortcuts Allows users to take a picture or record a video. Users can also adjust the setting related to the camera in this menu option.

  • Page 23: Using Camera

    S101TG Rugged Tablet User Guide 4.3 Using Camera This Hottab menu option allows users to take a picture or record a video. Before use, make sure the camera is on under the Device ON/OFF menu with the following scenarios. To open camera interface: 1.

  • Page 24: Built-In Devices On/Off

    Chapter 4: Operating the Device 4.4 Built-in Devices On/Off This section describes how to get quick access to set up built-in devices, including turning on/off RF modules and setting up barcode reader. 4.4.1 Using the Wireless LAN (Wi-Fi) To use the wireless LAN (Wi-Fi) feature to connect to the network, perform the following procedure: 1.

  • Page 25: Using The Wireless Wan

    S101TG Rugged Tablet User Guide 4.4.2 Using the Wireless WAN The Tablet Computer supports data connection with 4G/LTE modules and fits a Nano SIM card. (Note: 4G/LTE feature is optional). 4.4.2.1 Installing a SIM card Caution Power off the tablet before installing the 4G/LTE module and Nano SIM card, or the tablet computer might be damaged by the incorrect installation behaviors.

  • Page 26: Using The Gps

    Chapter 4: Operating the Device 4.4.2.2 Using Wireless WAN Feature To connect to the network using wireless WAN: 1. Launch the Hottab Utility application. 2. Tap on the Device ON/OFF button. 3. Check the status color of the WWAN icon: Item Status Color Description...

  • Page 27: Turning On/Off Led Indicators

    4.4.6 Using the Barcode Reader The 2D/1D Barcode Reader is optional for S101TG Tablet PC and is not re-workable by the end-user. To use this feature, please make sure the tablet PC has a built-in barcode reader before use, or contact our sales contact window for more details.
  • Page 28 Chapter 4: Operating the Device 4.4.6.1 Device Configuring and Setting Click on Windows and search for EZConfig-Scanning from the Start menu. Click on EZConfig-Scanning v4_IE and allow the blocked content if the browser is blocking the content. Click on the Connected Device icon and wait for the system to discover the device (Honeywell N660X).
  • Page 29 S101TG Rugged Tablet User Guide Once Honeywell N660X is discovered please click the Configure Device button as shown.
  • Page 30 Chapter 4: Operating the Device 4.4.6.2 Scanning mode Settings 1. Click on Device Settings under the Input/Output Settings section. 2. Select the desire scanning mode from the drop-down menu shown below. 3. After selecting a desire scanning mode, click on the Save to Device on the sidebar.
  • Page 31 S101TG Rugged Tablet User Guide Scanning Description mode When in manual trigger mode, the scanner scans until a bar code is read or until the trigger is released. Two modes are available, Normal and Enhanced. Normal mode Manual offers good scan speed and the longest working ranges (depth of field). The...
  • Page 32 Chapter 4: Operating the Device 4.4.6.3 Setting the 1D/2D Barcode Scanner Symbologies The barcode scanner is shipped with the default settings shown below. If the default setting suits the usage requirement, setting symbologies is not necessary. Symbologies Default Settings: Symbologies Default UPC-A Enable...
  • Page 33 S101TG Rugged Tablet User Guide Method (2). Click on the Reset to Default button on the side as shown: ※Warning※ 1. The reset to default button will change all settings to default. 2. N660X could disconnect with the system after clicking the Reset to Default button.
  • Page 34 Chapter 4: Operating the Device 4.4.6.4 Adding a Prefix or Suffix To add a refix or suffix, please click on the Data Formatting icon. Click on the Editor button under the Prefix or Suffix section and create Prefix/Suffix value by typing in the block or select desire characters in the Control chars, Printable chars, and Extended ASCII.
  • Page 35 S101TG Rugged Tablet User Guide When you finish creating Prefix/Suffix, please click on Save to Device on the sidebar. To check the functionality of Prefix/Suffix, please click on the Scan Data Window icon on the top. Then scan a barcode to verify if the Prefix/Suffix appears correctly.

  • Page 36: Turn On/Off The Gps External Antenna

    4.4.7 Turn on/off the GPS External Antenna The vehicle dock of the S101TG Tablet PC supports an external GPS antenna through a standard SMA connector. To work with an external GPS antenna, please make sure the tablet PC is installed correctly to the vehicle dock and the vehicle dock has connected with an external GPS antenna.

  • Page 37: Changing Touchscreen Modes

    S101TG Rugged Tablet User Guide 4.4.9 Changing Touchscreen Modes The tablet computer supports three built-in operating modes for different usage scenarios: Mode Description In Hand/Rain mode, the touchscreen rejects false inputs from liquid drops. When the liquid is removed, the touchscreen accepts touch inputs from bare fingertips.
  • Page 38 4.4.9.2 Switch via Programmable Function Buttons: To switch between the different touchscreen modes via the programmable function buttons, ensure the touchscreen mode switching is set to the programmable function buttons first. Launch the Hottab Utility application. Tap on the Setting button. Tap on Fn1 icon.

  • Page 39: Chapter 5: Frequently Used Settings

    Chapter 5: Frequently Used Settings 5.1 Screen Resolution Scaling and Setting The S101TG's 1920 x 1200 high-resolution display is perfect for viewing images, videos, or other applications. However, the Windows user interface (icons, buttons, and other user interface elements) may be too small to read and operate at the default Windows settings. By changing the display scaling or the display resolution setting of the device, you can adjust the size of the text and other items on the desktop for optimal viewing.

  • Page 40: Changing Screen Resolution

    Chapter 5: Frequently Used Settings 2. A "Display" Window will show up. Click on the drop-down option under the "Scale and layout" section and change the scaling option to "150% (Recommended)" or any other desired display scaling. 5.1.2 Changing Screen Resolution Alternatively, instead of changing the display scaling setting, user may choose to change the overall resolution setting to make screen elements bigger.
  • Page 41 S101TG Rugged Tablet User Guide 2. Click on the drop-down option next to Resolution and select the desire resolution by tapping on the scale: 3. Hit Apply. A Display Settings prompt will show up to ask the user if the applied resolution is usable.

  • Page 42: Replacing Battery

    Chapter 5: Frequently Used Settings 5.2 Replacing Battery The S101TG Tablet supports an optional hot-swap battery design, meaning the tablet doesn't need to be powered off to replace the main battery. To support hot-swap, there is a backup battery inside the tablet that is charged together with the main battery.

  • Page 43: Using Recovery Wizard To Restore Computer

    5.3 Using Recovery Wizard to Restore Computer S101TG Tablet Computer has a dedicated recovery partition stored on the tablet's hard drive to enable a quick one-key recovery process. This partition occupies about 11GB of the storage space and comes built- in to each S101TG Tablet Computer.
  • Page 44 Chapter 5: Frequently Used Settings 5. Wait till the recovery process to complete. During the recovery process, a command prompt will show up to indicate the percent of the recovery process. 6. After the recovery is complete, please press any key to continue, and the tablet computer will shut down automatically.

  • Page 45: Docking Connector Pin Definition

    S101TG Rugged Tablet User Guide 5.4 Docking Connector Pin Definition S101TG tablet computer supports one 19-pin docking connector at the bottom side. The pin definition is listed in the following table. 19 Pin Docking Connector Pin No. Description Pin No.
  • Page 46 Chapter 5: Frequently Used Settings Tap on the Port Setting tab and click on Advanced button. Tap on the drop-down list, choose the correct COM Port Number (refer to the COM Port Definition Table), and click OK. Double-check Device Manager to make sure the COM Port number has been re-defined successfully, and then restart the system.

  • Page 47: Pairing With A Wireless Bluetooth Barcode Scanner

    S101TG Rugged Tablet User Guide 5.6 Pairing with a Wireless Bluetooth Barcode Scanner The computer is affixed with a Bluetooth MAC (Media Access Control) address barcode label that enables wireless Bluetooth Barcode Scanner to establish a Bluetooth connection quickly. It is encoded with leading characters to instruct the wireless Bluetooth barcode scanner to initial Bluetooth Serial Port Profile pairing request.
  • Page 48 Chapter 5: Frequently Used Settings 3. Once the Bluetooth & other devices Menu appears, click More Bluetooth options under Related settings section as shown below. 4. Go to Options tab, and make sure that in the Discovery section, the computer is set to Allow Bluetooth devices to find this computer as shown below: Click OK to continue.
  • Page 49 S101TG Rugged Tablet User Guide 5. In the Bluetooth Settings menu, go to COM Ports tab. COM port has to be setup for the wireless Bluetooth Barcode Scanner to communicate via the Bluetooth Serial Port Profile. Click on the Add… button.
  • Page 50 Chapter 5: Frequently Used Settings 7. The computer will automatically assign COM Port to the Bluetooth connection. In the screenshot below, COM4 is allocated. Click OK to continue. 8. Next, the user has to configure the application to accept the scanned data from the wireless Bluetooth Barcode Scanner.

  • Page 51: Set Up The Barcode Scanner For Bluetooth Pairing

    S101TG Rugged Tablet User Guide 5.6.2 Set up the Barcode Scanner for Bluetooth Pairing Important: The wireless Bluetooth Barcode Scanner has to be configured as a Bluetooth Serial Port Profile Master device to establish connection via Bluetooth MAC address barcode label.
  • Page 52 Chapter 5: Frequently Used Settings 5. In Add a Bluetooth Device window, click Next to connect the Barcode Scanner to the Computer. In order to ensure that Bluetooth Device is successfully paired to the computer, follow the steps below: 1. Locate the Bluetooth icon in the Notification Area. Select Show Bluetooth Devices. You can access this menu in the Control Panel: ➔Control Panel ➔...

  • Page 53: Chapter 6: Troubleshooting

    S101TG Rugged Tablet User Guide Chapter 6: Troubleshooting 6.1 Basic Troubleshooting Problem Solution • The removable battery is not charging. Make sure the AC adapter is properly connected and that the removable battery is properly inserted. • Nothing appears on the screen.
  • Page 54 Chapter 6: Troubleshooting Problem Solution • No sound is produced. Adjust the volume of the tablet computer by pressing on the volume rocker. • If using an external audio device, make sure that the cable is properly connected. • I cannot project the tablet computer Make sure the VGA driver is installed.

  • Page 55: Appendix

    S101TG Rugged Tablet User Guide Appendix Appendix A: Product Specifications S101TG Model Name Size 10.1 inches Resolution 1920x1200 Brightness 800 nits Contrast Ratio 800:1 (typ) Display Viewing Angle 85/85/85/85 Touch Projected Capacitive Multi-Touch Bonding Optical Bonding for Sunlight Viewability Viewability Anti-Glare touch treatment Intel Core i3-1115G4 3.0 GHz (turbo boost up to 3.9 GHz)
  • Page 56 Appendix Model Name S101TG Operating Humidity 10% to 90% RH, non-condensing Operating -20°C to 60°C (AC mode), -10°C to 50°C (Battery mode) Temperature Storage -30°C to 70°C (-22°F to 158°F) Temperature Environment Shock MIL-STD-810H Method 516.8 Procedure I Vibration MIL-STD-810H Method 514.8 Procedure I Drop MIL-STD-810H Method 516.8, 4 ft.
  • Page 57 Notes...
  • Page 58 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © 2021 Winmate Inc. All rights reserved.
