Fujitsu UTY-LNV Series Operation Manual

OPERATION
MANUAL
WIRELESS REMOTE CONTROLLER
(for VRF system)
UTY-LNV*
Before using this product, read these instruc-
tions thoroughly and keep this manual for future
reference.
Contents
1. SAFETY PRECAUTIONS ...............................................1
2. PREPARATION ...............................................................2
2.1. How to use the remote controller holder ................2
3. NAME OF PARTS ...........................................................2
3.1. Inserting batteries ...................................................3
3.2. Clock adjust ............................................................3
3.3. Time display (24h ↔ 12h) switching .......................3
4. BASIC OPERATIONS .....................................................4
5. AIRFLOW SETTINGS .....................................................4
5.1. Fan speed setting ...................................................4
5.2. Airflow direction setting ..........................................4
6. TIMER OPERATIONS .....................................................5
6.1. On timer or Off timer ...............................................5
6.2. Program timer .........................................................5
6.3. Sleep timer ..............................................................5
7. ENERGY SAVING OPERATIONS ..................................5
7.1. Economy operation .................................................5
8. OTHER OPERATIONS....................................................5
8.1. Filter reset ...............................................................5
9. SETTINGS ON INSTALLATION .....................................6
9.1. Temperature unit switching.....................................6
9.2. Remote controller custom code setting ..................6
10. TROUBLESHOOTING ....................................................6
10.1. Service check .........................................................6
11. OTHERS ..........................................................................7
11.1. Specifications .........................................................7
11.2. Information on Disposal of WEEE ..........................7
SIMPLIFIED EU/GB DECLARATION OF CONFORMITY
The simplifi ed EU/GB Declaration of conformity referred to
Article 10 (9) shall be provided as follows: Hereby, FUJIT-
SU GENERAL LIMITED declares the radio equipment type
UTY-LNVY/UTY-LNVG complies with Directive 2014/53/EU.
The following items are available from
our global site.
• Full text of the EU/GB Declaration of
conformity
• Operation manual
www.fujitsu-general.com/global/support/
PART No. 9379143110-01
[Original instructions]

1. SAFETY PRECAUTIONS

To prevent personal injury or property damage, read this
section carefully before you use this product, and be sure to
comply to the following safety precautions. Incorrect operation
due to failure to follow the instructions may cause harm or
damage, the seriousness of which is classified as follows:
WARNING
This mark warns of death or serious injury.
CAUTION
This mark warns of injury or damage to property.
This mark denotes an action that is
PROHIBITED.
This mark denotes an action that is
COMPULSORY.
WARNING
• This product contains no user-serviceable parts.
Always consult authorized service personnel for re-
pairing of this product. Improper handling will cause
electric shock or fire.
• In the event of a malfunction such as burning smell,
immediately stop operation of the air conditioner,
and disconnect all the power supply by turning off
the electrical breaker or disconnecting the power
plug. Then consult authorized service personnel.
• In the event of a thunder storm or any prior sign
of a lightning strike, turn off the air conditioner via
the remote controller, and refrain from touching the
air conditioner or the power source to prevent any
electrical hazards.
• This product is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervi-
sion or instruction concerning use of this product
by a person responsible for their safety. Children
should be supervised to ensure that they do not
play with this product.
• Dispose of the packing materials safely. Tear and
dispose of the plastic packing bags so that children
cannot play with them. There is the danger of suffo-
cation if children play with the original plastic bags.
• Do not use flammable gases near this product.
• Do not operate with wet hands.
CAUTION
• Ensure that any electronic equipment is at least 1 m
(40 in) away from this product.
• After a long period of use, ensure the mounting of
the remote controller holder is firmly to prevent this
product from falling down.
• Do not install the remote controller holder near a
fireplace or other heating apparatus.
• Do not expose this product directly to water.
• Do not touch the buttons with sharp objects.
En-1
