SHPE2250, SHPE2250RED,
SHPE2250YEL SaltDogg
Drive Poly Hopper Spreader
2.2 cubic yards
US PATENT 9,562,333
Table of Contents
General Information ................................................................... 1
Safety Precautions ..................................................................... 1
Installation Instructions ........................................................... 2-4
Spreader Operation ................................................................... 5
Spreader Maintenance ............................................................... 5
Repair Parts & Drawings .........................................................6-8
Warranty Information ................................................................. 8
General Information
Overall Length: 104.5 inches
Overall Width: 48 inches
Overall Height: 44 inches
Empty Weight: 707 lbs
Capacity Struck: 2.2 cu. yd.
Vehicle Requirements
Trucks with minimum GVWR 13,000 lbs.
150 AMP or higher alternator is recommended.
Average Material Weights
Materials to use
Fine Salt-Dry
Coarse Salt-Dry
Sand Coarse-Dry
Note: To calculate the total spreader weight (including ice
control material), add the empty spreader weight plus the ice
control material and spreader accessories.
Installation Instructions
Electric
®
Weight (pounds per cubic yard)
2,250
1,431
2,565
Phone (440) 974-8888 • Fax (800) 841-8003
Do not overload vehicle beyond the vehicle's GVWR or
GAWR. Check vehicle's load rating certification sticker
for maximum vehicle capacity.
Improper installation and operation could cause personal
injury, and/or property damage. Observe the following Safety
Precautions before, during and after operating this spreader.
By following these precautions and common sense, possible
injury to persons and potential damage to this machine may
be avoided.
Safety Precautions
1. Read the entire Installation Instructions before operating this
spreader.
2. Read all safety decals on the spreader before operating.
3. Check to make sure all safety guards are securely mounted
into place before operating this spreader.
4. Verify that all personnel are clear of the spreader spray area
before starting or operating this spreader.
5. Do not over-load your vehicle beyond payload limits. If there
are any questions, contact the vehicle manufacturer.
6. Do not adjust, clean, lubricate or unclog material jambs
without first turning off the spreader.
7. Do not climb on or in the spreader during operation. Do not
ride on the spreader while the vehicle is in motion.
8. Make sure the spreader is securely fastened to the vehicle in
accordance with this manual.
9. Do not operate a spreader that is in need of maintenance or
repairs.
10. Batteries normally produce explosive gases which can
cause personal injury. Always disconnect the battery before
removing or replacing electrical components.
11. Do not leave unused material in hopper. Material can
freeze or solidify, causing spreader to not work properly, and/or
damage the unit. Empty and clean after each use.
1
9049 Tyler Blvd. • Mentor, Ohio 44060
www.saltdogg.com
CAUTION
WARNING
-continued inside
Advertisement
Table of Contents
Related Manuals for Buyers SaltDogg SHPE2250
Summary of Contents for Buyers SaltDogg SHPE2250
-
Page 1: Table Of Contents
