Technical information

The heat pump's factory settings

This table indicates the factory settings for all the settings likely to be
changed by the installer.
Menu Setting
1.1 Temp. incr. / decr.
1.2 Temp. Fine-tune
1.3 Heat curve adjust. (break)
1.4 Heat curve hysteresis
1.5 Mix. valve incr/decr
1.6 Mix. valve fi ne-tune
1.7 Adapting the mixing valve curve
1.8 Mixing valve curve neutral zone
1.9 Mixing valve curve max at GT4
1.10 Setting the room temperature
1.11 Setting the room sensor infl uence
1.12 Setting of holiday function
1.13 Remote control temperature
1.14 Setting of summer disconnection
2.1 Number of hours for extra hot water
2.2 Interval for hot water peak
2.3 Setting of hot water temperature
4.1 Clock setting HP accord. to clock
4.1.1 Setting level heat pump +/-
4.2 Clock setting additional heat according to clock
4.3 Clock setting hot water according to clock
5.2 Select connection capacity electric heater
5.4 Select function only additional heat
5.5 Select function additional heat
5.7 Select external controls
5.10 Select operation alt. P2
5.11 Select operation alt. P3
8.1 Setting additional heat timer
8.3.4 Ramp time open
8.3.5 Ramp time close
9.4 Min. temp pump inlet
9.5 Min. temp. pump outlet
Factor y setting
4
0º
n/a
5º
4
0º
0º
3º
60º
20º
5
0 day
Inactive
18º
0 hours
Inactive
52º
00:00 - 00:00 (inactive)
0º
00:00 - 00:00 (inactive)
00:00 - 00:00 (inactive)
2/3
Normal operation
yes
0
P2 running cont.
P3 with Compres.
120 minutes
20 min
3 min
-10º
-10º
41
Technical information

Sensor table

This table indicates the values of the sensor
resistors to different temperatures.
Temperature (
ºC)
-40 154.00
-35 111.700
-30 81.700
-25 60.400
-20 45.100
-15 33.950
-10 25.800
-5 19.770
0 15.280
5 11.900
10 9.330
15 7.370
20 5.870
25 4.700
30 3.790
35 3.070
40 2.510
45 2.055
50 1.696
55 1.405
60 1.170
65 0.980
70 0.824
75 0.696
80 0.590
85 0.503
90 0.430
kΩ
