Axis Q6215-LE User Manual

Hide thumbs Also See for Q6215-LE:

Advertisement

Quick Links

Download this manual
AXISQ6215-LEPTZNetwork
Camera
AXIS Q6215-LE PTZ Network Camera
User manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the Q6215-LE and is the answer not in the manual?

Questions and answers

Related Manuals for Axis Q6215-LE

Summary of Contents for Axis Q6215-LE

  • Page 1 AXISQ6215-LEPTZNetwork Camera AXIS Q6215-LE PTZ Network Camera User manual...
  • Page 2 AXIS Q6215-LE PTZ Network Camera Table of Contents Installation ..............................4 Preview mode ............................4 Get started..............................5 Find the device on the network.........................5 Browser support ..........................5 Open the device's web interface........................5 Create an administrator account.......................5 Secure passwords ............................5 Verify that no one has tampered with the device software................6 Web interface overview ...........................6...
  • Page 3 Control button ..........................68 Connectors ............................68 Network connector .........................68 Troubleshooting............................70 Reset to factory default settings ......................70 AXIS OS options ............................70 Check the current AXIS OS version ......................70 Upgrade AXIS OS...........................71 Technical issues, clues, and solutions.......................71 Performance considerations ........................73 Contact support ............................74...
  • Page 4 AXIS Q6215-LE PTZ Network Camera Installation Preview mode Preview mode is ideal for installers when fine tuning the camera view during the installation. No login is required to access the camera view in preview mode. It is available only in factory defaulted state for a limited time from powering up the device.
  • Page 5 Open the device's web interface Open a browser and type the IP address or host name of the Axis device. If you do not know the IP address, use AXIS IP Utility or AXIS Device Manager to find the device on the network.
  • Page 6 Verify that no one has tampered with the device software To make sure that the device has its original AXIS OS, or to take full control of the device after a security attack: Reset to factory default settings. See .
  • Page 7 Go to Video > Image > Wide dynamic range. If you still have problems, go to Exposure and adjust the Exposure zone to cover the area of interest. Find out more about WDR and how to use it at axis.com/web-articles/wdr.
  • Page 8 AXIS Q6215-LE PTZ Network Camera Remove water from the front glass with the wiper The wiper is controlled manually. Click on the Wiper button in the Live view control bar. Hide parts of the image with privacy masks You can create one or several privacy masks to hide parts of the image.
  • Page 9 AXIS Q6215-LE PTZ Network Camera Go to PTZ > Limits. Set the limits as needed. Create a guard tour with preset positions A guard tour displays the video stream from different preset positions either in a predetermined or random order, and for configurable periods of time.
  • Page 10 AXIS Q6215-LE PTZ Network Camera Click Add network storage under Network storage. Type the IP address of the host server. Type the name of the shared location on the host server under Network share. Type the username and password. Select the SMB version or leave it on Auto.
  • Page 11 AXIS Q6215-LE PTZ Network Camera Start the application if it is not already running. Make sure you have set up the application according to your needs. Create a rule: Go to System > Events and add a rule. Type a name for the rule.
  • Page 12 To add audio capability to your Axis network video device, connect the portcast compatible Axis audio device and I/O Interface between your device and the PoE switch which provides power.
  • Page 13 2 Axis portcast device 3 Switch Once the devices are connected, an audio tab becomes visible in the settings for your Axis network video device. Go to the audio tab and turn on Allow audio. See your Axis portcast device’s user manual for more information.
  • Page 14 Status Device info Shows the device information, including AXIS OS version and serial number. Upgrade AXIS OS: Upgrade the software on your device. Takes you to the Maintenance page where you can do the upgrade. Time sync status Shows NTP synchronization information, including if the device is in sync with an NTP server and the time remaining until the next sync.
  • Page 15 Shows what kind of access to the device that is active, what encryption protocols are in use, and if unsigned apps are allowed. Recommendations to the settings are based on the AXIS OS Hardening Guide. Hardening guide: Link to AXIS OS Hardening guide where you can learn more about cybersecurity on Axis devices and best practices.
  • Page 16 AXIS Q6215-LE PTZ Network Camera Click to play the live video stream. Click to freeze the live video stream. Click to take a snapshot of the live video stream. The file is saved in the ‘Downloads’ folder on your computer. The image file name is [snapshot_YYYY_MM_DD_HH_MM_SS.jpg]. The size of the snapshot depends on the compression that the specific web-browser engine where the snapshot is received applies, therefore, the snapshot size may vary from the actual compression setting that is configured in the device.
  • Page 17 AXIS Q6215-LE PTZ Network Camera • Autoplay: Turn on to autoplay a muted video stream whenever you open the device in a new session. • Client stream information: Turn on to show dynamic information about the video stream used by the browser that shows the live video stream.
  • Page 18 AXIS Q6215-LE PTZ Network Camera Important We recommend you not to use multiple image correction features at the same time, since it can lead to performance issues. Barrel distortion correction (BDC) : Turn on to get a straighter image if it suffers from barrel distortion.
  • Page 19 AXIS Q6215-LE PTZ Network Camera Image Appearance Scene profile : Select a scene profile that suits your surveillance scenario. A scene profile optimizes image settings, including color level, brightness, sharpness, contrast, and local contrast, for a specific environment or purpose.
  • Page 20 AXIS Q6215-LE PTZ Network Camera : Turn on to make both bright and dark areas of the image visible. Local contrast : Use the slider to adjust the contrast of the image. A higher value makes the contrast higher between dark and light areas.
  • Page 21 AXIS Q6215-LE PTZ Network Camera Light environment: • Automatic: Automatic identification and compensation for the light source color. This is the recommended setting which can be used in most situations. • Automatic – outdoors : Automatic identification and compensation for the light source color.
  • Page 22 AXIS Q6215-LE PTZ Network Camera IR-cut filter: • Auto: Select to automatically turn on and off the IR-cut filter. When the camera is in day mode, the IR-cut filter is turned on and blocks incoming infrared light, and when in night mode, the IR-cut filter is turned off and the camera’s light sensitivity increases.
  • Page 23 AXIS Q6215-LE PTZ Network Camera Exposure mode: • Automatic: The camera adjusts the aperture, gain, and shutter automatically. • Automatic aperture : The camera adjusts the aperture and gain automatically. The shutter is fixed. • Automatic shutter : The camera adjusts the shutter and gain automatically. The aperture is fixed.
  • Page 24 AXIS Q6215-LE PTZ Network Camera • Right : Uses an area with a fixed size and position in the right part of the image to calculate the exposure. • Spot: Uses an area with a fixed size and position in the live view to calculate the exposure.
  • Page 25 Zipstream is a bitrate reduction technology, optimized for video surveillance, that reduces the average bitrate in an H.264 or H.265 stream in real time. Axis Zipstream applies a high bitrate in scenes where there are multiple regions of interest, for example, in scenes with moving objects. When the scene is more static, Zipstream applies a lower bitrate, and thereby reduces the required storage.
  • Page 26 AXIS Q6215-LE PTZ Network Camera • Average: Select to automatically adjust the bitrate over a longer time period and provide the best possible image quality based on the available storage. – Click to calculate the target bitrate based on available storage, retention time, and bitrate limit.
  • Page 27 AXIS Q6215-LE PTZ Network Camera Overlays : Click to add an overlay. Select the type of overlay from the dropdown list: • Text: Select to show a text that is integrated in the live view image and visible in all views, recordings and snapshots.
  • Page 28 Label: Enter the text label for the x axis. – Time window: Enter how long time the data is visualized. – Time unit: Enter a time unit for the x axis. – Y axis – Label: Enter the text label for the y axis.
  • Page 29 AXIS Q6215-LE PTZ Network Camera – Min alarm threshold and Max alarm threshold: These values will add horizontal reference lines to the bar chart, making it easier to see when the data value becomes too high or too low. Privacy masks : Click to create a new privacy mask.
  • Page 30 AXIS Q6215-LE PTZ Network Camera Preset position A guard tour with preset positions continuously streams footage from a selection of preset positions in a random or fixed sequence. You can choose how long the camera should stay at each preset position before moving on to the next.
  • Page 31 AXIS Q6215-LE PTZ Network Camera Limits To narrow down the area under surveillance, you can limit the PTZ movements. Save as Pan 0 : Click to set the current position as zero-point for pan coordinates. Pan-tilt limits: The camera uses the coordinates of the center of the image when you set pan-tilt limits.
  • Page 32 AXIS Q6215-LE PTZ Network Camera Motion Proportional speed : Turn on to set the maximum proportional speed. • Max proportional speed : Set a value between 1 and 1000 to limit the pan and tilt speed. Max proportional speed is defined as a percentage, where the value 1000 equals 1000%.
  • Page 33 • PTZ control queue: Turn on to place PTZ control requests in a queue. This displays the users status and position in the queue. To use the PTZ controls in AXIS Camera Station, turn off this setting. – Enter queue: Click to add your request for PTZ control to the queue.
  • Page 34 AXIS Q6215-LE PTZ Network Camera Recordings Ongoing recordings: Show all ongoing recordings on the device. Start a recording on the device. Choose which storage device to save to. Stop a recording on the device. Triggered recordings will end when manually stopped or when the device is shut down.
  • Page 35 AXIS Q6215-LE PTZ Network Camera Apps Add app: Install a new app. Find more apps: Find more apps to install. You will be taken to an overview page of Axis apps. Allow unsigned apps : Turn on to allow installation of unsigned apps.
  • Page 36 AXIS Q6215-LE PTZ Network Camera Synchronization: Select an option for the device’s date and time synchronization. • Automatic date and time (manual NTS KE servers): Synchronize with the secure NTP key establishment servers connected to the DHCP server. – Manual NTS KE servers: Enter the IP address of one or two NTP servers. When you use two NTP servers, the device synchronizes and adapts its time based on input from both.
  • Page 37 AXIS Q6215-LE PTZ Network Camera Assign IPv4 automatically: Select to let the network router assign an IP address to the device automatically. We recommend automatic IP (DHCP) for most networks. IP address: Enter a unique IP address for the device. Static IP addresses can be assigned at random within isolated networks, provided that each address is unique.
  • Page 38 AXIS Q6215-LE PTZ Network Camera Allow access through: Select if a user is allowed to connect to the device through the HTTP, HTTPS, or both HTTP and HTTPS protocols. Note If you view encrypted web pages through HTTPS, you might experience a drop in performance, especially when you request a page for the first time.
  • Page 39 AXIS Q6215-LE PTZ Network Camera One-click cloud connection (O3C) together with an O3C service provides easy and secure internet access to live and recorded video from any location. For more information, see axis.com/end-to-end-solutions/hosted-services. Allow O3C: • One-click: This is the default setting. Press and hold the control button on the device to connect to an O3C service over the internet.
  • Page 40 – Authentication failed: Sends a trap message when an authentication attempt fails. Note All Axis Video MIB traps are enabled when you turn on SNMP v1 and v2c traps. For more information, see AXIS OS Portal > SNMP. • v3: SNMP v3 is a more secure version, which provides encryption and secure passwords. To use SNMP v3, we recommend you to activate HTTPS, as the password is then sent through HTTPS.
  • Page 41 : Show more fields to fill in or select. • Secure keystore: Select to use Secure element or Trusted Platform Module 2.0 to securely store the private key. For more information on which secure keystore to select, go to help.axis.com/en-us/axis- os#cryptographic-support. •...
  • Page 42 When configured without a CA certificate, server certificate validation is disabled and the device tries to authenticate itself regardless of what network it is connected to. When using a certificate, in Axis' implementation, the device and the authentication server authenticate themselves with digital certificates using EAP-TLS (Extensible Authentication Protocol - Transport Layer Security).
  • Page 43 AXIS Q6215-LE PTZ Network Camera Blocking: Turn on to block brute-force attacks. A brute-force attack uses trial-and-error to guess login info or encryption keys. Blocking period: Enter the number of seconds to block a brute-force attack. Blocking conditions: Enter the number of authentication failures allowed per second before the block starts.
  • Page 44 AXIS Q6215-LE PTZ Network Camera To install test software or other custom software from Axis on the device, you need a custom signed AXIS OS certificate. The certificate verifies that the software is approved by both the device owner and Axis. The software can only run on a specific device which is identified by its unique serial number and chip ID.
  • Page 45 AXIS Q6215-LE PTZ Network Camera Add SSH account: Click to add a new SSH account. • Restrict root access: Turn on to restrict functionality that requires root access. • Enable SSH: Turn on to use SSH service. Account: Enter a unique account name.
  • Page 46 AXIS Q6215-LE PTZ Network Camera Client ID: Enter the OpenID username. Outgoing Proxy: Enter the proxy address for the OpenID connection to use a proxy server. Admin claim: Enter a value for the admin role. Provider URL: Enter the web link for the API endpoint authentication. Format should be https://[insert URL]/.
  • Page 47 AXIS Q6215-LE PTZ Network Camera Recipients You can set up your device to notify recipients about events or send files. Note If you set up your device to use FTP or SFTP, don’t change or remove the unique sequence number that’s added to the file names.
  • Page 48 AXIS Q6215-LE PTZ Network Camera Add a recipient: Click to add a recipient. Name: Enter a name for the recipient. Type: Select from the list: • – Host: Enter the server's IP address or hostname. If you enter a hostname, make sure that a DNS server is specified under System >...
  • Page 49 ECDSA, ED25519, and DSA. Make sure to enter the right MD5 host key that is used by your SFTP server. While the Axis device supports both MD5 and SHA-256 hash keys, we recommend using SHA-256 due to stronger security over MD5. For more information on how to configure an SFTP server with an Axis device, go to the AXIS OS Portal.
  • Page 50 (IoT). It was designed for simplified IoT integration and is used in a wide variety of industries to connect remote devices with a small code footprint and minimal network bandwidth. The MQTT client in Axis device software can simplify integration of data and events produced in the device to systems which are not video management software (VMS).
  • Page 51 AXIS Q6215-LE PTZ Network Camera MQTT client...
  • Page 52 AXIS Q6215-LE PTZ Network Camera Connect: Turn on or off the MQTT client. Status: Shows the current status of the MQTT client. Broker Host: Enter the hostname or IP address of the MQTT server. Protocol: Select which protocol to use.
  • Page 53 AXIS Q6215-LE PTZ Network Camera can let the broker deliver a message to other clients. This LWT message has the same form as an ordinary message and gets routed via the same mechanics. Send message: Turn on to send messages.
  • Page 54 AXIS Q6215-LE PTZ Network Camera Note Connect to an MQTT broker before you add MQTT overlay modifiers. Add overlay modifier: Click to add a new overlay modifier. Topic filter: Add the MQTT topic that contains the data you want to show in the overlay.
  • Page 55 IP address can change) or that you use DNS. Windows SMB/CIFS names are not supported. • Network share: Enter the name of the shared location on the host server. Several Axis devices can use the same network share since each device gets its own folder.
  • Page 56 AXIS Q6215-LE PTZ Network Camera Important Risk of data loss and corrupted recordings. Do not remove the SD card while the device is running. Unmount the SD card before you remove it. Unmount: Click to safely remove the SD card.
  • Page 57 ONVIF enables interoperability between different vendor products, increased flexibility, reduced cost and future-proof systems. When you create an ONVIF account, you automatically enable ONVIF communication. Use the account name and password for all ONVIF communication with the device. For more information see the Axis Developer Community at axis.com.
  • Page 58 AXIS Q6215-LE PTZ Network Camera Add accounts: Click to add a new ONVIF account. Account: Enter a unique account name. New password: Enter a password for the account. Passwords must be 1 to 64 characters long. Only ASCII printable characters (code 32 to 126) are allowed in the password, for example, letters, numbers, punctuation, and some symbols.
  • Page 59 AXIS Q6215-LE PTZ Network Camera Add media profile: Click to add a new ONVIF media profile. Profile name: Add a name for the media profile. Video source: Select the video source for your configuration. • Select configuration: Select a user-defined configuration from the list. The configurations in the drop-down list correspond to the device's video channels, including multiviews, view areas and virtual channels.
  • Page 60 AXIS Q6215-LE PTZ Network Camera Analytics metadata Metadata producers Lists the apps that stream metadata and the channels they use. Producer: The app that produces the metadata. Below the app is a list of the types of metadata the app streams from the device.
  • Page 61 AXIS Q6215-LE PTZ Network Camera Reports • View the device server report: View information about the product status in a pop-up window. The Access Log is automatically included in the Server Report. • Download the device server report: It creates a .zip file that contains a complete server report text file in UTF–8 format, as well as a snapshot of the current live view image.
  • Page 62 Note All Axis device software is digitally signed to ensure that you only install verified software on your device. This further increases the overall minimum cybersecurity level of Axis devices. For more information, see the white paper “Axis Edge Vault” at axis.com.
  • Page 63 The image shows how the field of view and aspect ratio can change between two different capture modes. What capture mode to choose depends on the requirements for the frame rate and resolution of the specific surveillance setup. For specifications about available capture modes, see the product’s datasheet at axis.com. Privacy masks A privacy mask is a user-defined area that prevents users from viewing a part of the monitored area.
  • Page 64 The available options are: H.264 or MPEG-4 Part 10/AVC Note H.264 is a licensed technology. The Axis product includes one H.264 viewing client license. To install additional unlicensed copies of the client is prohibited. To purchase additional licenses, contact your Axis reseller.
  • Page 65 AXIS Q6215-LE PTZ Network Camera Maximum bitrate (MBR) Maximum bitrate lets you set a target bitrate to handle bitrate limitations in your system. You might see a decline in image quality or frame rate as the instantaneous bitrate is kept below the specified target bitrate. You can choose to prioritize either image quality or frame rate.
  • Page 66 2 Actual average bitrate Applications With applications, you can get more out of your Axis device. AXIS Camera Application Platform (ACAP) is an open platform that makes it possible for third parties to develop analytics and other applications for Axis devices.
  • Page 67 For in-depth information about cybersecurity in AXIS OS, read the AXIS OS Hardening guide. Signed OS Signed OS is implemented by the software vendor signing the AXIS OS image with a private key. When the signature is attached to the operating system, the device will validate the software before installing it. If the device detects that the integrity of the software is compromised, the AXIS OS upgrade will be rejected.
  • Page 68 AXIS Q6215-LE PTZ Network Camera Specifications Product overview 1 SD card slot 2 Control button 3 Ground screw 4 Part number (P/N) & Serial number (S/N) 5 Network connector (High PoE) 6 Impact protection bracket 7 Status LED 8 Wiper...
  • Page 69 To comply with the IP66-rated design of the camera and maintain the IP66 protection, the supplied RJ45 Push-pull Connector (IP66) shall be used. Alternatively, use the RJ45 IP66-rated cable with premounted connector which is available from your Axis reseller. Don’t remove the plastic network connector shield from the camera.
  • Page 70 LTS tracks provide a fixed platform with periodic releases focused mainly on bug fixes and security updates. Using AXIS OS from the active track is recommended if you want to access the newest features, or if you use Axis end-to-end system offerings. The LTS tracks are recommended if you use third-party integrations, which are not continuously validated against the latest active track.
  • Page 71 Make sure the device remains connected to the power source throughout the upgrade process. Note When you upgrade the device with the latest AXIS OS version in the active track, the product receives the latest functionality available. Always read the upgrade instructions and release notes available with each new release before you upgrade.
  • Page 72 AXIS Camera Station Edge: free of charge, ideal for small systems with basic surveillance needs. • AXIS Camera Station 5: 30-day trial version free of charge, ideal for small to mid-size systems. • AXIS Camera Station Pro: 90-day trial version free of charge, ideal for small to mid-size systems.
  • Page 73 AXIS Q6215-LE PTZ Network Camera Color saturation is Modify the settings for your graphics adapter. Go to the adapter’s documentation different in H.264 and for more information. Motion JPEG Lower frame rate than • See . expected • Reduce the number of applications running on the client computer.
  • Page 74 AXIS Q6215-LE PTZ Network Camera • Running multiple AXIS Camera Application Platform (ACAP) applications simultaneously may affect the frame rate and the general performance. Contact support If you need more help, go to axis.com/support.
  • Page 76 T10116228 2024-11 (M11.2) © 2018 – 2023 Axis Communications AB...
