Item # 1001 000 000
Model # FSS60654A-ST-2
USE AND CARE GUIDE
KINGSBURY 7 PIECE DINING SET
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HOMEDEPOT.CA
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this set. We strive continually to create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HAMPTON BAY KINGSBURY FSS60654A-ST-2
Summary of Contents for HAMPTON BAY KINGSBURY FSS60654A-ST-2
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this set. We strive continually to create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents Table of Contents........2 Hardware Included . -
Page 3: Warranty
Warranty 3 YEARS FRAME AND FABRIC LIMITED WARRANTY WHAT IS COVERED We warrant the frame to be free of manufacturing defects to the original purchaser for three years, and the fabric to have three years limited warranty. WHAT IS NOT COVERED Its remains the customer’s responsibility for freight and packaging charges to and from our service center. -
Page 4: Hardware Included
Pre-assembly (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity M8X30 Combination Bolt 24+1 M6X45 Combination Bolt 24+1 M6X15 Combination Bolt 10+1 Hex Wrench CHAIR PACKAGE CONTENTS Part Description Quantity Chair Back Chair Seat Right Arm Left Arm Back Cushion Seat Cushion... - Page 5 Pre-assembly (continued) TABLE PACKAGE CONTENTS Part Description Quantity Table Top Table Leg Leg Connector HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance.
-
Page 6: Chair Assembly
Chair Assembly Connecting The Chair Seat To The Right Arm NOTE: Loosely tighten all bolts using the hex wrench (DD). Place the right arm (C) on a soft surface. Attach the chair seat (B) to the right arm (C) using M8x30 combination bolts (AA). Do not tighten all bolts at this step. - Page 7 Chair Assembly (continued) Connecting The Chair Back To The Arms NOTE: Pay attention to the side of chair back when NOTE: Loosely tighten all bolts using the hex wrench (DD). assembly the chair back to chair arms. Attach the chair back (A) to the arms (C&D ) using M6X45 Combination Bolts (BB).
- Page 8 Table Assembly Attaching The Table Legs To The Table Top NOTE: Loosely tighten all bolts using the hex wrench (DD). Place the table top (G) upside down on a soft surface. Attach the table legs (H) to the table top (G) using M6x15 combination bolts (CC). Do not tighten all bolts at this step.
-
Page 9: Tightening The Bolts
Table Assembly (continued) Tightening The Bolts Once all of the bolts are in place, fully tighten all the bolts using the hex wrench (DD). Turn the table right side up. Ensure all connections are secure before use. Care Care and Cleaning For best results, clean the frame and fabric with a damp cloth and dry thoroughly. - Page 10 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HOMEDEPOT.CA Retain this manual for future use. For certification use only...
