5-piece firepit conversation set

Advertisement

Quick Links

Item #1000-000-000
Model #FSS10036R-ST
USE AND CARE GUIDE
HOUSTON 5-PIECE FIREPIT CONVERSATION SET
Questions, problems, missing parts? Before returning to the store call
Hampton Bay Customer Service.
8 a.m. - 6 p.m., EST, Monday - Friday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this conversation set. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HOUSTON FSS10036R-ST and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for HAMPTON BAY HOUSTON FSS10036R-ST

  • Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this conversation set. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
  • Page 2: Table Of Contents

    Table of Contents Table of Contents ............2 Chair Assembly ............. 5 Warranty ................ 2 Table Assembly ............8 Care and Cleaning ............11 What is Covered ..............2 What is Not Covered ..............2 Pre-Assembly ..............2 Planning Assembly ..............2 Hardware Included ..............
  • Page 3: Chair Package Contents

    Pre-Assembly (continued) CHAIR PACKAGE CONTENTS Part Description Quantity Right arm Left arm Support tube Support bar Chair back Back cushion Seat cushion HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 4 Pre-Assembly (continued) TABLE PACKAGE CONTENTS Part Description Quantity Table rim Table leg Leg connector Tile Barbecue grate Poker Log grate Fire bowl Cover...
  • Page 5: Chair Assembly

    Chair Assembly Connecting the support tube and support bar to the chair arms Place the right arm (A) on a soft surface. Attach one end of the support tube (C) to the right arm (A) using M8x28 hex bolts (EE), M8 spring washers (CC), and M8 washers (DD).
  • Page 6 Chair Assembly (continued) Connecting the chair back to the support tube Attach the bottom of the chair back (E) to the support tube (C) by inserting M8x35 hex bolts (FF) through the metal sheets (GG), the chair back (E), the support tube (C), M8 washers (DD), M8 spring washers (CC), and into the M8 nuts (HH). NOTE : Loosely tighten all bolts using the wrench (JJ).
  • Page 7 Chair Assembly (continued) Tightening the bolts Once all the bolts are in place, fully tighten all bolts. Ensure that all connections are secure before use. Place the chair back (KK) and seat (LL) cushions to finish the assembly of the chairs. HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 8 Table Assembly Connecting the table legs Place the table rim (F) upside down on a soft surface. Attach the table legs (G) to the table rim (F) using M6x15 bolts (AA), and M6 washers (BB). NOTE: Loosely tighten the bolts using the hex wrench (II).
  • Page 9 Table Assembly (continued) Connecting the leg connector to the table legs Attach the leg connector (H) to the table legs (G) using M6x15 bolts (AA) and M6 washers (BB). NOTE: Loosely tighten all the bolts using the hex wrench (II). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 10 Table Assembly (continued) Tightening all the bolts and adding the tiles Once all bolts are in place, fully tighten all bolts. Turn the table right side up. Carefully place the tiles (I) on the table. ò...
  • Page 11: Care And Cleaning

    Table Assembly (continued) Adding the fire pits Carefully place the fire bowl (M) in the table rim (F). Then place the following in order, from bottom to top: the log grate (L), the barbecue grate (L) and the lid (N) or the cover (O). When not in use, store the poker (K) under the log grate (L).
  • Page 12 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 6 p.m., EST Monday - Friday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
