USE AND CARE GUIDE
ASHVILLE BENCH
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this bench. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HAMPTON BAY ASHVILLE FSS60711AL
Summary of Contents for HAMPTON BAY ASHVILLE FSS60711AL
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this bench. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Important Safety Instructions
Table of Contents Table of Contents........2 Pre-Assembly. -
Page 3: Warranty
Warranty 3 YEAR FRAME AND 3 YEAR FABRIC LIMITED WARRANTY WHAT IS COVERED We warrant the frame to be free of manufacturing defects to the original purchaser for three years, and a three year limited warranty for the fabric. WHAT IS NOT COVERED It remains the customer’s responsibility for freight and packaging charges to and from our service center. -
Page 4: Hardware Included
Pre-Assembly (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity M6x15 Combination Bolt 10+1 M6x30 Combination Bolt Hex Wrench PACKAGE CONTENTS Part Description Quantity Back Top Bar Back Seat Connector Bar Right Arm Left Arm Seat Cushion... - Page 5 Assembly Attaching the Seat to the Right Arm Place the right arm (E) on a soft surface. Attach the seat (C) to the right arm (E) using M6x30 combination bolts (BB). Do not tighten the bolts at this step. Attaching the Left Arm to the Seat Attach the left arm (F) to the seat (C) using M6x30 combination bolts (BB).
- Page 6 Assembly (continued) Connecting the Connector Bar to the Right Arm and Left Arm Connect the connector bar (D) to the right arm (E) and left arm (F) using M6x15 combination bolts (AA). Do not tighten the bolts at this step. Connecting the Back to the Seat Turn the bench right side up.
- Page 7 Assembly (continued) Connecting the Back Top Bar to the Back, Left Arm and Right Arm Connect the back top bar (A) to the back (B), right arm (E) and left arm (F) using M6X15 combination bolts (AA), as shown below. Once all of bolts are in place, fully tighten all the bolts using the hex wrench (CC).
-
Page 8: Care And Cleaning
Care and Cleaning For best results, clean the frame and fabric with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate. Do not clean with abrasive materials, bleach, or solvents. Store the bench in a dry sheltered place when not in use. Keep the bench away from re, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind. - Page 9 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use. For certification use only...
