Wen 456BV Instruction Manual

EXPLODED VIEW & PARTS LIST
2
6
No. Part No.
1 456BV-001
2 456BV-002
3 456BV-003
4 455BV-004
5 456BV-005
6 456BV-006
7 456BV-007
8 456BV-008
9 455BV-009
10 456BV-010
11 456BV-011
12 456BV-012
13 456BV-013
14 456BV-014
5 4
3
9
14
11 10
Description
Base
Movable Jaw
Body
Locking Nut
Jaw Plate
Leadscrew With Handle
Nut
Square Head Bolt, M10x40
Set Screw, M6x12
Split Pin, Ø3x30
Locking Washer, M20
Split Washer, M12
Hex Bolt, M12x30
Spring
INSTRUCTION MANUAL
KNOW YOUR BENCH VISE
13
12
7
1
Anvil
8
Locking Nut
Base
Qty.
1
1
1
2
SPECIFICATIONS
2
1
1
2
4
1
2
1
1
1
BENCH VISE
Jaw
Mounting Hole
Jaw Width 6 in.
Jaw Capacity 6-5/8 in.
Anvil Dimensions 109 x 91 mm
Mounting Hole Diameter 12.7 mm
Mounting Hole Spacing 137.7 mm
3709 lbf (16.5 kN)
Clamping Force
Pivoting Angle Range 125.0°
Dimensions 15-11/16 in. x 6-5/8 in. x 7-5/8 in.
35.7 lb
Weight
MODEL 456BV
6-INCH
ÉTAU DE BANC
Leadscrew
with Handle
