10" water-cooled sharpening system
Hide thumbs
Table of Contents

Advertisement

Quick Links

For replacement parts visit
WENPRODUCTS.COM
Your new tool has been engineered and manufactured to WEN's highest standards for dependability, ease
of operation, and operator safety. When properly cared for, this product will supply you years of rugged,
trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If
you use your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.
NOTICE: Please refer to wenproducts.com for the most up-to-date instruction manual.
10" WATER-COOLED
SHARPENING SYSTEM
IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
techsupport@wenproducts.com
WENPRODUCTS.COM
MODEL BG9910
(M-F 8am-5pm CST)
S1E-JS-250
226766

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BG9910 and is the answer not in the manual?

Questions and answers

Related Manuals for Wen BG9910

Summary of Contents for Wen BG9910

  • Page 1 WENPRODUCTS.COM IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.

  • Page 2: Table Of Contents

    Leather Stropping Wheel Size 9 x 1-3/16 in. (230 x 30 mm) Arbor Diameter 12 mm Product Net Weight 31.2 lbs Assembled Dimensions 13-3/8 x 10-1/2 x 12-7/8 in. Compatible with the WEN 42704A 4-Piece Sharpening Accessory Kit, available at wenproducts.com...

  • Page 3: Introduction

    INTRODUCTION Thanks for purchasing the WEN Sharpener. We know you are excited to put your tool to work, but first, please take a moment to read through the manual. Safe operation of this tool requires that you read and understand this operator’s manual and all the labels affixed to the tool. This manual provides information regarding potential safety concerns, as well as helpful assembly and operating instructions for your tool.

  • Page 4: General Safety Rules

    GENERAL SAFETY RULES Safety is a combination of common sense, staying alert and knowing how your item works. SAVE THESE SAFETY INSTRUCTIONS. WARNING: Read and understand all warnings, cautions and operating instructions before using this tool. Failure to follow all instructions listed below may result in personal injury and tool damage. WORK AREA SAFETY 1.

  • Page 5: Specific Rules For Sharpeners

    GENERAL SAFETY RULES 4. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energizing power tools that have the switch on invites accidents. 5.
  • Page 6 SPECIFIC RULES FOR SHARPENERS WARNING: Do not let comfort or familiarity with the product replace strict adherence to product safety rules. Failure to follow the safety instructions may result in serious personal injury. 1. TOOL PURPOSE. This sharpener is designed for sharpening and honing cutting tools, using the appropri- ate accessories.
  • Page 7 SPECIFIC RULES FOR SHARPENERS 11. STARTING UP. Never start the machine with any load already applied to either grinding wheel. Stand to the side of the sharpener during start-up. Switch it ON and let the sharpener reach full speed for roughly one minute to warm up the wheel and to ensure proper operation.

  • Page 8: Electrical Information

    ELECTRICAL INFORMATION GROUNDING INSTRUCTIONS This tool is equipped with an electric cord that has an equipment grounding conductor and a grounding plug. In the event of a malfunction or breakdown, grounding provides the path of least resistance for an electric current and reduces the risk of electric shock.

  • Page 9: Know Your Sharpener

    KNOW YOUR SHARPENER UNPACKING Carefully remove the sharpener from the packaging. Make sure to take out all contents and accessories. Check your packing list against the diagram below. If any part is damaged or missing, please contact our customer service at (800) 232-1195, M-F 8-5 CST or email us at techsupport@wenproducts.com. Do not discard the packaging until the sharpener is completely assembled.

  • Page 10: Assembly & Adjustments

    ASSEMBLY & ADJUSTMENTS WARNING: To prevent accidental starting, make sure the machine is switched OFF and the power plug is disconnected before assembly, setting up or making adjustments. POSITIONING THE MACHINE Place the machine on a stable, flat work surface. The machine has four rubber feet pre-installed to increase stability and reduce vibration.
  • Page 11 ASSEMBLY & ADJUSTMENTS INSTALLING THE WORK SUPPORT The universal work support (Fig. 3 - 1) acts as both a work rest and as an attachment arm for various jigs. The work support can be installed either in the verti- cal (A) or horizontal (B) position. The diameter of the work support bar is 12 mm.
  • Page 12 This will help you balance the weight of the work- piece and keep it steady. WEN 42704A 4-Piece Sharpening Accessory Kit OTHER SHARPENING JIGS To sharpen knives, scissors and axes, you’ll need the WEN 42704A 4-Piece Sharpening Accessory Kit (Fig.
  • Page 13 ASSEMBLY & ADJUSTMENTS SETTING THE ANGLE USING THE ANGLE GUIDE Use the included angle guide (Fig. 7) to help set the correct angle for sharpening your tools. Blade Bevel Protractor Arrow (in.) Measuring Edge Pointer Protractor Arrow (mm) Protractor Locking Knob Curved Foot Flat Edge Fig.
  • Page 14 ASSEMBLY & ADJUSTMENTS WARNING: To prevent accidental starting, make sure the machine is switched OFF and the power plug is disconnected before assembly, setting up or making adjustments. FILLING THE WATER RESERVOIR WARNING: This sharpener’s grinding wheel is designed for wet grinding only. NEVER USE THE GRINDING WHEEL WITHOUT WATER.

  • Page 15: Operation

    OPERATION WARNING: Do not plug in or turn on the tool until it is fully assembled according on the instruc- tions. Failure to follow the safety instructions may result in serious personal injury. ADJUSTING THE DRIVE SYSTEM TORQUE 1. Before each operation, tighten the torque adjustment knob LOOSEN (Fig.
  • Page 16 OPERATION SHARPENING A BLADE 1. Stand to one side of the sharpener. Plug in and turn ON the machine. Let the grinding wheel run for about one minute to warm up, making sure it is rotating evenly. 2. Firmly grasp the tool to be sharpened with both hands. Make sure it is properly supported.

  • Page 17: Maintenance

    MAINTENANCE WARNING: To avoid accidents, turn OFF and unplug the tool from the electrical outlet before clean- ing, adjusting, or performing any maintenance or lubrication work. Servicing of the tool must be per- formed by a qualified technician. ROUTINE INSPECTION Before each use, inspect the general condition of the tool.
  • Page 18 Grinding wheels should be inspected for any damage or cracking before each use. Store the grinding wheels to prevent them from the potential hazards of moisture, containments and other damage. Replacement 10- inch grinding wheels (part no. BG9910-050) can be purchased from wenproducts.com. To replace a grinding wheel: 1.
  • Page 19 If the leather strop- ping wheel becomes damaged or worn, replace it as follows. Replacement 9-inch leather stropping wheels (part no. BG9910-034) can be purchased from wenproducts.com. 1. Unscrew the locking knob (Fig. 15 - 1).

  • Page 20: Exploded View & Parts List

    S1E-JS-250 爆炸 EXPLODED VIEW & PARTS LIST 48 51 77 7 7 NOTE: Replacement parts can be purchased from wenproducts.com, or by calling our customer service at (800) 232-1195, M-F 8-5 CST. Parts and accessories that wear down over the course of normal use (e.g. grinding wheels, water reservoir, carbon brushes, etc.) are not covered by the two-year warranty.
  • Page 21 BG9910-017 Rotating Direction Label BG9910-056 Screw M4x10 BG9910-018 Warning Label BG9910-057 Motor Mounting Stem Cap BG9910-019 Screw M6x16 BG9910-058 Motor Mounting Guide Plate BG9910-020 Screw M5x6 BG9910-059 Screw M4x55 Internal Tooth Lock Washer BG9910-060 Motor Mounting Stem BG9910-021 BG9910-062 Motor Tension Spring...

  • Page 22: Troubleshooting Guide

    TROUBLESHOOTING GUIDE WARNING: Stop using the tool immediately if any of the following problems occur. Repairs and replacements should only be performed by an authorized technician. For any questions, please contact our customer service at (800) 232-1195, M-F 8-5 CST or email us at techsupport@wenproducts.com. PROBLEM CAUSE SOLUTION...

  • Page 23: Warranty Statement

    WARRANTY STATEMENT WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN consumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase.
  • Page 24 THANKS FOR REMEMBERING...
