- Page 1 MFG.H605-TR...
-
Page 2: Specification
Specification Color Black Left side pannel Tempered Glass M/B Type MicroATX / ITX Tool-less kit 2 sets of tool-less kit HDD Drive Bay 3.5” HDD*2 / 2.5”SSD*2 Bottom Front Back Expansion Slots 4 Slots Support VGA card 330mm Height of CPU 155mm Cooling System Rear: 120mm*1(Included) - Page 3 Right side panel Chassis Front panel Tempered Glass panel Foot Bottom dust fillter HDD tray LOGO Nameplate Top fan place Top dust fillter Rear fan place PSU place M/B place I/O Panel...
- Page 4 Power Reset HD Audio USB 2.0 USB 3.0...
-
Page 5: How To Install Psu
How to install PSU How to install M/B Install PSU Fix with screws Install M/B How to install 2.5”SSD & 3.5” HDD Install HDD Install SSD Insert the SSD into place Tighten screws on the back Insert the HDD into place to complete the installation... - Page 6 How to install cooling system Installation for top fan Installation for rear fan Top: optional 2x fans Rear: 1x fan pre-installed Top panel support 2x120mm fan, Rear panel support 1x120mm or 1x80mm put the fan in the top panel then fan, put the fan in the rear panel then fix fix with screws.
- Page 7 How to install VGA card fix unit(Optional) Adjustment Introduce: 1, Loosen the screw , adjust fix units up and down. 2, Loosen the screw , adjust fix units around.
