Summary of Contents for GAMEMAX Brufen COC
- Page 1 USER MANUAL CopyRight @ 2024.10...
- Page 2 SPECIFICATION Model No. Brufen COC Materials Chassis 0.5mm SPCC, tempered glass on left side panel Motherboard support E-ATX/ATX/M-ATX/ITX PSU type ATX PSU (Bottom located) TOP panel I/O ports USB3.0*2+Type-C*1, Combo Audio, LED SW Drive Bays 3.5'' HDD*2 + 2.5'' SSD*2 Expansion Slots 7 slots , Support up to 340mm (Max.) VGA card...
- Page 3 EXPLOSIVE VIEW Chassis Left tempered glass side panel Right side panel Front panel PSU cover 3*120mm fans on the front ６ 1*120mm fan on the rear HDD bracket V5.0 ARGB+PWM controller SSD bracket Magnetic dust filter on the top Dust filter on the bottom VGA card bracket COC Turbo Fan - 02 -...
- Page 4 I/O PORTS Power SW Light Mode SW Combo Audio Speaker Jack USB 3.0 x2 Type-C - 03 -...
- Page 5 SIDE PANEL INSTALLATION Drop-proof screws Loose the drop-proof screws A, pull out the right side Open left side panel and Remove the tempered panel toward to the arrowhead direction. glass side panel; Put hand into bottom of front panel , then you can pull up it .
- Page 6 POWER SUPPLY INSTALLATION Insert PSU from left side Secure with screws MOTHERBOARD INSTALLATION Pre-installed MB standoff screws Use the provided standoffs and screws to secure the motherboard - 05-...
- Page 7 VGA CARD INSTALLATION Remove the PCI slot protection cover. Install the graphics card and secure it with a screw. - 06 -...
- Page 8 VGA CARD HOLDER INSTALLATION A. VGA Card Holder B. Put the holder into the situable position on C. Fix the screws at the rear side of the the motherboard plate according to the VGA motherboard plate HDD AND SSD INSTALLATION HDD installation Loosen 2pcs screws for HDD bracket, pull out HDD bracket Secure with screws...
- Page 9 Put bracket on chassis after HDD installation, and secure Fix SSD on bracket up side and secure with screws with 2pcs screws first, then fix HDD SSD installation Take off SSD bracket, then fix SSD on bracket and lock bracket to previous place - 08 -...
- Page 10 COOLING FAN AND LIQUID COOLING SYSTEM INSTALLATION 2x120/140mm fans (optional) 120/140/240mm liquid cooling system (optional) Rear 120mm Fan x1 (included) 120mm Liquid cooling system (optional) 140mm COC Turbo Fan x1 (included) Front 120mm Fan x3 (included) 120/140/240/280mm liquid cooling system (optional) Bottom 120mm Fan x2 (optional) - 09 -...
- Page 11 V5.0 PWM ARGB HUB DEMO LINK GUIDE Please do not plug in the wrong power interface, Link LED SW or RESET Button, otherwise it will burn out Manual ARGB Control equipment! 5V 3pin AURA Cabel LED-KEY1 PC-IN1 ARGB 1026 V2.0 POWER PWM TEMP Cable SATA Power input...
- Page 12 REMOTE CONTROL BUTTON FUNCTION Automatic Mode Cycle ON/MB SYNC Power o Mode + Static Brightness + Fan Speed + Fan Speed - Static Brightness - Mode - Static Color Button Double click 10 times RGB sequence adjustment Press the red key until the red Press the greey key until the green Press OFF key to save Double click 10 times...
- Page 13 COC TURBO FAN CONNECTION INSTRUCTION Link to CHA_FAN/SYS_FAN on Motherboard - 12 -...
- Page 14 Power Up with Gamemax, Gaming to the Max! www.gamemaxpc.com...
