Summary of Contents for GAMEMAX Titan Silent II
- Page 2 Specification Color Black Case Size 512(L)x210(W)x527(H)mm Material Chassis 0.8mm SPCC M/B Support E-ATX / ATX / MicroATX PSU Support Bottom / ATX HDD Drive Bay 3.5"HDDx8, 2.5"SSDx2 FRONT BACK PCI Expansion Slots 8 slots, Support Max. 450mm VGA Card 165mm Max.CPU Cooler(Height) Water-Cooling System Front Fan: 120mm*2 (Included) Top Fan: 120mm*3 or 140mm*2 (Optional)
- Page 3 Chassis Exploded View Introduction Chassis Left side tempered glass panel Right side panel PSU Cover Front Dust Filter Bottom Dust Filter ６ Front: 2x120mm fans(included) Bottom: 1x120mm fan(optional) Rear: 1x120mm fan(included) Top: 3x120mm / 2x140mm fans(optional) HDD Bracket SSD Bracket - 02 -...
- Page 4 Accessory Name Figure Use For QT’y M/B Standoff M/B Tray CD-ROM Screw M/B, CD-ROM, 2.5” SSD Install PSU Screw Power Supply, PCI Slot Install 3.5” HDD Screw 3.5” HDD Install Stand-off Socket M/B Tray Cable Binder Cable Fix Cable Tie Cable Management Shockproof Pad HDD(installed on the M/B tray)
- Page 5 Top I/O Panel Power USB 2.0 HD Audio Reset Fan Controller(Low-Stop-High) USB 3.0 Power Light HDD Light - 04 -...
- Page 6 Installation Guide 1, Open the side panel Unscrew the side panel screws and open the side panels in the direction of the arrow - 05 -...
- Page 7 2, Install the power supply and the bottom fan Unscrew the power supply cover fixing Put in the power supply Locking screw fixing power supply screw, remove the power supply cover Place the fan in the position shown Locking screw fixing fan Cover the power supply cover and lock fixing screw - 06 -...
- Page 8 3, Installl Motherboard Stand-off socket As shown in the figure, install the motherboard, fix screws. (support E-ATX motherboard, limit size: 305*272mm) - 07 -...
- Page 9 4, Installl VGA Card Remove the PCI slot protection cover, install the VGA card Fix with screws 5, Installl VGA Card Holder 1, Adjusting length for position C, then fixing the Hand-Screw 2, Adjusting length for position D 3, Adjusting angle between position A and position C Remarks: (0, 45, 90, 135, 180degree).
- Page 10 6, Install ODD Move the bezel clips to the sides by hand and remove the bezel. Align the position to be loaded, load the optical drive, adjust to the appropriate position, lock the lock-free screw. - 09 -...
- Page 11 7, Install HDD and SSD Insert the HDD and the SSD into the hard disk mounting position. - 10 -...
- Page 12 8, Install SSD Install the SSD into the hard drive bracket and fix it with four screws. - 11 -...
- Page 13 9, Installl Cooling Fan 9, Installl Cooling Fan 9.1 Install front fans 9.1 Install front fans Remove the hard drive cage Remove the hard drive cage Put in the fan and lock the screws Put in the fan and lock the screws 9.2 Install top fans 9.2 Install top fans 9.3 Install rear fan...
- Page 14 10, Disassemble the Air Filter Remove the panel air filter Removing the floor air filter Open the four fixing buckles on both sides by hand and take Remove the floor air filter from the direction of the arrow out the front panel dustproof net in the direction of the arrow. - 13 -...
- Page 15 Remove the top dust filter Press the two corners of the air filter by hand, then release it, the air filter will automatically pop up and remove the air filter. - 14 -...
- Page 16 Power Up with Gamemax, Gaming to the Max! www.gamemaxpc.com...
