Single lever commercial style kitchen faucet

Advertisement

Nola Single Lever Commercial
TM
Style Kitchen Faucet
KPF-1650
www.kraususa.com
I
Toll Free: 1.800.775.0703
I
© 2018 Kraus USA Inc.
I
REV. December 6, 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Nola KPF-1650 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kraus Nola KPF-1650

  • Page 1 Nola Single Lever Commercial Style Kitchen Faucet KPF-1650 www.kraususa.com Toll Free: 1.800.775.0703 © 2018 Kraus USA Inc. REV. December 6, 2018...
  • Page 2 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance or have any problems with your product: Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com...
  • Page 3: Prior To Installation

    · Make sure you have all necessary parts by checking the diagram and parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775-0703 for a replacement. Turn off the hot and cold water supply at the angle stops and turn on ·...
  • Page 4 Diagram and Parts List A. Spray Head D. Metal Base Ring B. Faucet Body E. Hot & Cold Waterlines C. Mounting Hardware F. 2.5 mm Hex Wrench C1. Rubber & Metal Washer G. Deck Plate Assembly C2. Mounting Nut C3. Mounting Screw...
  • Page 5 Faucet Dimensions...
  • Page 6 Step 1. Remove mounting hardware Remove mounting hardware (C) from mounting pipe. Step 2. Install faucet and mounting hardware Insert faucet body (B) into hole in countertop or sink. Install mounting hardware (C) from underneath countertop. Note: Deck plate assembly (G) can be used to cover pre-existing holes.
  • Page 7 Step 3. Secure mounting hardware Adjust the direction of faucet body (B). Tighten mounting nut (C2) until snug. Tighten mounting screws (C3) to nut with a Phillips screwdriver until snug. Step 4. Connect waterlines Connect waterlines (E) to copper lines and angle stops.
  • Page 8 Step 5. Flush spray hose Remove spray head (A) from hose. Hold tip of hose. Turn faucet on for 60 seconds to flush any debris. Installer Tip: Please make sure washer is installed prior to attaching spray head to hose.
  • Page 9 Step 6. Check for leaks Check for leaks at the connections.
  • Page 10: Replacement Parts

    Replacement Parts Replacement Parts List Finish/Color Part # CH, SS KP06088 1. A. Spray Head B. Check Valve KP06106 Washer KP06113 Spray Hose & Spring CH, SS KP06114 Set Screw KP06054 Handle Button CH, SS KP06029 Set Screw KP06053 CH, SS Metal Handle KP06003 CH, SS...
  • Page 11: Troubleshooting

    Trouble-Shooting If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps: PROBLEM CAUSE ACTION Leakage under faucet handle Locking nut has come loose or Remove button located at top of handle. cartridge needs to be reseated.
  • Page 12 Maintenance - Cartridge Replacement Step 1: Remove button located at the top of the handle. Loosen the set screw with a hex wrench. Remove the handle and unscrew cartridge cover by hand. Step 2: Unscrew the locking nut with an adjustable wrench. Remove ceramic disc cartridge.
  • Page 13 Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and is not transferable to a subsequent owner.
  • Page 14 This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. KRAUS USA has the right to change, modify, and/or update the warranty policy at any time. For the latest, most up to date comprehensive warranty, go to www.kraususa.com/warranty...
  • Page 15 Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration...
