- Page 1 VIWA S 90 VIWA S 100 VIWA S 115 VIWA S 125 VIWA S 150 WALL MOUNTED CONDENSING BOILER INSTALLATION & USER MANUAL...
-
Page 2: Table Of Contents
2.3.7. Ventilation...................9 3.2.1. On / Off / Summer and Winter Modes........31 2.3.8. Ventilation requirements for Viwa S 90 -150 boilers and cascade 3.2.2. Resetting the Boiler (Re-operate) .......... 33 systems....................9 3.2.3. Operating in Winter Mode ............33 2.4. -
Page 3: Dear Warmhaus Customer
WARMHAUS declares that Viwa S 90, Viwa S 100, and Viwa 125 boilers comply with the essential requirements of the following directives: - Gas Appliances Regulation (EU) 2016/426... -
Page 4: Boiler Gas Categories & Regions
Pulling and pushing the boiler may require the use of a stacker Gas categories for Warmhaus boilers are implemented on the CE certificate given below by SZU Test / BRNO;- appliance categories according to direct some residual water in the hydraulic circuit. -
Page 5: Sizes And Connections
• It is recommended to mount the boiler between 1.8 - 2.2 m length of hanger plate from the ground. “Viwa S 90 - 150” boilers an be installed in boiler rooms whose size and • In places where mounting area is limited, the boiler must be mounted requirements meet current regulations. -
Page 6: Natural Gas Connection
Figure 2.10 There is a Warmhaus logo in the flue elbow. • Sheaths should be used in the passages of the heating and hot water necessary filter systems (in order to ensure the purification of the fuel) in from the walls and they should be fixed with wall clamps as not to allow the gas supply line. - Page 7 Ø100/150 mm b) CO2 content in nominal operating conditions; 9.00% c) Flue characteristics to which the boiler can be Lmax= 18 m (Viwa S 90) • Concentric extension pipes and plug-in type (tolerance + 0.5% / -0.5%) connected depend on Figure 2.14.
-
Page 8: Connection Of ( 100/150 Mm) Horizontal Concentric Flue Sets And Mounting Horizontal Concentric Flue Set To The Boiler
Additional 90° Elbow d- Horizontal Flue Set Pipe Concentric (Optional) Flue Accessories ( 100/150 mm) for Viwa S 90, 100, 125 and 150 Wall Type Condensing Boilers Figure 2.24 III. Single 90° and two 45° angled sample flue installation Flue accessories can be mounted to each other by tight fit method and therefore no additional parts are required for connection. -
Page 9: Mounting To Partially Protected Outer Spaces 1
Pin No Pin Description Notes 128 x 99 x 36mm (compatible with box 503) 130g WARMHAUS A.Ş. shall not be held responsible for any damage or loss MAIN SUPPLY GROUND Z2 PUMP FREE CONTACT HIGH Power Supply: Bipolar and nonpolar cable... -
Page 10: Hydraulic Installation Mounting Rules
Do not forget that all these products must be used strictly in accordance Warmhaus recommends the use of these corrosion inhibitors in preventive Warmhaus recommends using a dirt separator, filter, etc. in order to prevent with the instructions of the water treatment manufacturers. -
Page 11: Installation
Min Ø 19 mm should be 3 m. Viwa S 100 YP HF 25/7 used for Viwa S 90, Viwa S 100, Viwa Internal Viwa S 125 Pump Set S 125, Viwa 90, Viwa 115, and Viwa 125... - Page 12 Viwa Boilers Optional Pump Sets Viwa S 90, Viwa S 100, Viwa 90 and Viwa S 125 and Viwa 125 Boiler Pump Set Viwa 115 Boiler Pump Set WH-125 UPMXL 25-125 Auto130 WH-90/115 UPML 25-105 Auto130 Boiler Pump Selection Table...
- Page 13 Pump Set that will be used as a Viwa 50, boiler pump in the return line for Viwa 65, the boiler models Viwa S 90, Viwa Viwa 90, 115 Viwa 50, Viwa 65, Viwa 90, Viwa 115 Viwa 115, and it is comprised of a modulating pump, 2 x unions, check valve, and gasket set.
- Page 15 WDHS-01-Exterior Sensor that allows the boiler to regulate Viwa 50-150 15311660600001 Temperature Sensor according to exterior temperature. Viwa S 90-150 Open Therm MASTER Boiler Connection The unit that can be used as a thermostat or RC 21.11-Room Viwa 50-150 15311660600045...
-
Page 16: Controls For The First Operation Of The Boiler
Warmhaus Authorized Service. • Leave the boiler in Stand-by (stated OFF on the display) and so its... -
Page 17: Resetting The Boiler (Re-Operate)
These features are the property of Warmhaus Isıtma ve Sogutma Sistemleri San. Tic. A.Ş. It must not be passed on to any person not authorized by Warmhaus Isıtma ve Sogutma Sistemleri San. Tic. A.Ş or be copied or otherwise utilized by anybody without expressed written permission. -
Page 18: Screen Symbols
Symbol lights up during parameter settings. These features are the property of Warmhaus Isıtma ve Sogutma Sistemleri San. Tic. A.Ş. It must not be passed on to any person not authorized by Warmhaus Isıtma ve Sogutma Sistemleri San. Tic. A.Ş or be copied or otherwise utilized by anybody without expressed written permission. - Page 19 INFO Menu Pos No Operation Description INFO 7: Display of heating flow ( CH ) SET temperature ZONE 2. Attention: This procedure must be applied by authorised persons and valid for only condensing boiler. INFO 8: Display of ionisation current ( μA). Push INFO button at ones.
-
Page 20: Use With Room Thermostat (Optional)
Authorized Service. These features are the property of Warmhaus Isıtma ve Sogutma Sistemleri San. Tic. A.Ş. It must not be passed on to any person not authorized by Warmhaus Isıtma ve Sogutma Sistemleri San. Tic. A.Ş or be copied or otherwise utilized by anybody without expressed written permission. -
Page 21: Solving Faults And Failures
3.3. SOLVING FAULTS AND FAILURES 3.3.1. Error Codes Table ALL 13 Exhaust temperature probe Boiler does not work, ALL > Over temperature flue 1-) Reset & Restart boiler over-temperature alarm 13 error code flashing on gas outlet value > P80 2-) Call for authorised service at first Fault Finding &... -
Page 22: Suggestions For Using Boiler Economically
217/12,2 134,21/9,9 256,0/91,1 48,4/12,6 85,6/53,2 217,0/10,6 258,6/114,6 265,0 /14,2 Customer Communication Centre. 11,51 4. Ask the person came for service for the Warmhaus identity card issued CO2 (Max. / Min.) (80/60 °C) 9,1/8,6 10,4/9,8 9,5/9,1 10,6/10,2 9,3/8,6 10,3/10,1 9,5/9,1 10,5/10,3... - Page 23 VIWA S 90 VIWA S 100 VIWA S 115 VIWA S 125 VIWA S 150...
