- Page 1 Solid wood sauna LINDEA VIEW LARGE 221 x 223,5 x 212,5 cm INSTRUCTIONS FOR INSTALLATION English LINDEA-V-L-T-L / 1-051-757 Thermo/Linde LINDEA-V-L-T-T / 1-052-489 Thermo/Thermo Version 10/24 Ident. no. LINDEA-V-L...
-
Page 2: Table Of Contents
Table of Contents Preparing for installation 1.1. Tools required 1.2. Maintenance and cleaning 1.3. Disposal 1.4. Parts list 2. Floor plan 2.1. Floor plan for left-hand assembly 2.2. Floor plan for right-hand assembly 2.3. Changes for right-hand assembly installation 3. Assembling the cabin 3.1. -
Page 3: Preparing For Installation
Installation instructions, only for experts p. 3/32 1. Preparing for installation Read these assembly instructions carefully and keep them within reach when using the sauna so that you can look up product information at any time. These assembly instructions can also be found in the downloads section of our website: www.mediabank.harvia.com. -
Page 4: Tools Required
Installation instructions, only for experts p. 4/32 1.1. Tools required ● Hammer with a wooden head or a mallet ● Cordless screwdriver with bits for cross-head screws and Torx ● Roller tape measure ● Drill bits with a diameter of 3 mm, 10 mm, 20 - 30 mm (for sauna heater power cable) ●... -
Page 5: Maintenance And Cleaning
Installation instructions, only for experts p. 5/32 1.2. Maintenance and cleaning ● The sauna should be cleaned with a damp cloth. Only use warm water – no cleaning products. ● We recommend heating the cabin once a month if the sauna is not used for a long time. -
Page 6: Parts List
Installation instructions, only for experts p. 6/32 1.4. Parts list Name Dimensions in mm of items Base frame 1 Black base frame with ventilation aperture 2100x80x40 1 Black floor frame 2045x80x40 1 Black floor frame 1382x80x40 Wall elements 5 Black wall element 1995x663x70 2 Black electronic elements 1995x663x70... - Page 7 Installation instructions, only for experts p. 7/32 Name Dimensions in mm of items Roof elements 2 Black roof element 2100x630x70 1 Black roof element 2100x840x70 1 Cover strip for roof element 2020x110x15 1 Cover strip for roof element 688x110x15 Lindea interior decor 4 Lindea decor element 2020x656x40 3 Lindea decor element...
- Page 8 Installation instructions, only for experts p. 8/32 Name Dimensions in mm of items Accessories 1 Aluminium U strip 670x12x10 1 Aluminium U strip 1x 45° - left 680x12x10 1 Aluminium U strip 1x 45° - left 672x12x10 1 Aluminium U strip 1x 45° - right 680x12x10 1 Aluminium U strip 1x 45°...
-
Page 9: Floor Plan
Installation instructions, only for experts p. 9/32 2. Floor plan 2.1. Floor plan for left-hand assembly... -
Page 10: Floor Plan For Right-Hand Assembly
Installation instructions, only for experts p. 10/32 2.2. Floor plan for right-hand assembly... -
Page 11: Changes For Right-Hand Assembly Installation
Installation instructions, only for experts p. 11/32 2.3. Changes for right-hand assembly installation Remove the external tongue element from the W1 wall element and insert it in wall element W8. -
Page 12: Assembling The Cabin
Installation instructions, only for experts p. 12/32 Assembling the cabin ATTENTION! The cabin is designed for both “right-hand” and “left-hand” assembly. Please observe the floor plans on pages 9 and 10 in this regard. Observe the figures starting on Page 15. The installation subsequently described is for the left floor plan. -
Page 13: Fitting The Interior Lindea Decor
Installation instructions, only for experts p. 13/32 3.5. Fitting the interior Lindea decor Mount the interior decor elements with 8 screws each, starting at the side walls W1 and W8. Take account of the position of the ventilation slot. When mounting the Lindea decor elements on the rear wall, make sure the distances to the sides are correct.
