- Page 1 Stacked TV Stand FOLLOW US: CONTACT INFO: ITEM NO. 014-HG-41033 The instruction booklet contains IMPORTANT support@belleze.com @bellezefurniture safety information. Please read it in full and 1-800-682-6376 keep it for future reference. www.belleze.com...
- Page 2 Scan this QR Code to view our online tutorial Estimated time for assembly: 100 mins Weight limitations are as follows: Maximum Load 70 lb Maximum Load 25 lb...
- Page 3 Assemble the furniture on an empty carton, carpet, or rug to prevent scratches or damage. For safety, please keep pets and children away from the assembly area. Ensure the product is fully assembled before use. If you are missing any hardware or products, do not use it until you have restored the missing parts.
-
Page 4: Package Contents
PACKAGE CONTENTS... - Page 5 PACKAGE CONTENTS CODE DESCRIPTION Top Panel Bottom Panel Left Lateral Panel Right Lateral Panel Medial Panel Storage Shelf Panel Back Support Panel Back Panel Top Back Panel Left Cabinet Door Right Cabinet Door Long Base Strip Short Base Strip Top Divider Panel Center Panel Crossbar v.12272024...
- Page 6 PACKAGE CONTENTS 45x + 4x 37x + 3x 45x + 4x 42x + 4x 10x + 1x 48x + 4x 16x + 1x 16x + 1x Install all hardware perpendicular to the opening.
- Page 7 PACKAGE CONTENTS 8x + 1x v.12272024...
- Page 8 Required tools for assembly (Not included) Attach cam bolts to the lateral panels (3, 4) and center panel (15).
- Page 9 Insert wood dowels to the medial panel (5), top divider panel (14) and center panel (15). v.12272024...
- Page 10 Assemble the center panel (15) between the lateral panels (3, 4). Assemble the top divider panel (14) on top of the center panel (15).
- Page 11 Assemble the medial panel (5) to the bottom of the center panel (15). Insert wood dowels to the lateral panels (3, 4). v.12272024...
- Page 12 Insert wood dowels to the back support panels (7). Assemble the back support panels (7) to the center panel (15).
- Page 13 Slide in the back panels (8). Attach cam bolts to the bottom panel (2). v.12272024...
- Page 14 Assemble the bottom panel to the TV stand assembly.
- Page 15 Secure the back support panels (7) to the bottom panel (2). v.12272024...
- Page 16 Attach cam bolts to the bottom panel (2) and long base strips (12).
- Page 17 Insert wood dowels to all the base strips (12, 13). Assemble the short base strips (13) between the long base strips (12). v.12272024...
- Page 18 Assemble the base to the bottom panel.
- Page 19 Insert wood dowels to the top back panels (9). Attach cam bolts to the center panel (15). v.12272024...
- Page 20 Assemble top back panels (9) on top of the center panel (15). Note: Make sure to use the correct hardwares.
- Page 21 Attach crossbar (16) to the top panel (1). Attach cam bolts to the top panel (1). v.12272024...
- Page 22 Assemble the top panel(1) to the TV stand assembly.
- Page 23 Secure the top back panel to the top panel. Note: Make sure to use the correct hardwares. v.12272024...
- Page 24 Secure the back panels (8) in place. Insert shelf pegs into the TV stand and place storage shelf panels (6) on top of the pegs.
- Page 25 Attach door hinges to cabinet doors (10, 11). Attach door handles to all the cabinet doors. v.12272024...
- Page 26 Attach cabinet doors to the TV stand.
- Page 27 lf you still have trouble while adjusting the door, please contact us. Up and down Side to side In and out adjustment by adjustment using adjustment by loosening the screws the front adjustment loosening the screws on the mounting screw on the hinge. on the hinge arm.
- Page 28 Attach anti-tipping straps to the back of the TV stand.
- Page 29 device to prevent the furniture from tipping over. • Mark drill positions on the wall with a pencil. • Drill a small hole on the marked position. • Insert wall anchors into the drilled holes. • Zip tie the rack to the anti-tipping devices. YOU’RE FINISHED! v.12272024...
- Page 30 Warning Serious or fatal crushing injuries may occur if the furniture tip-over. xed to the wall with included anti-tipping device in order to prevent the furniture from tipping over. stability and load bearing capacity of the furniture. If you are uncertain about which type of device to use, please contact us or your local hardware store.
- Page 31 WARNING For use with televisions weighing 70lbs (31.75kg) or less. Use with heavier televisions may result in instability, causing tip over resulting in death or serious injury. Death or serious injury may occur when children climb on audio and/or video equipment furniture. A remote control or toys placed on the furnishing may encourage a child to climb on the furnishing and as a result the furnishing may tip over on to the child.
-
