- Page 1 Brixston TV Stand FOLLOW US: CONTACT INFO: ITEM NO. 014-HG-41020 The instruction booklet contains IMPORTANT support@belleze.com @bellezefurniture safety information. Please read it in full and 1-800-682-6376 keep it for future reference. www.belleze.com...
- Page 2 Scan this QR Code to view our online tutorial Estimated time for assembly: 90 mins Weight limitations are as follows: Maximum Load 90 lb Maximum Load 20 lb...
- Page 3 Assemble the furniture on an empty carton, carpet, or rug to prevent scratches or damage. For safety, please keep pets and children away from the assembly area. Ensure the product is fully assembled before use. If you are missing any hardware or products, do not use it until you have restored the missing parts.
-
Page 4: Package Contents
PACKAGE CONTENTS... - Page 5 PACKAGE CONTENTS CODE DESCRIPTION Top Panel Left Side Panel Center Panel Right Side Panel Upper Crossbar Storage Shelf Panel Back Support Panel Back Panel Bottom Panel Lower Crossbar Front Leg Left Leg Center Support Leg Right Leg Back Leg Left Shelf Left Cabinet Door Left Shelf Right Cabinet Door Right Shelf Left Cabinet Door Right Shelf Right Cabinet Door...
- Page 6 PACKAGE CONTENTS 43x + 3x 43x + 3x 34x + 3x 48x + 3x 10x + 1x 16x + 1x 16x + 1x Install all hardware perpendicular to the opening.
- Page 7 PACKAGE CONTENTS Install all hardware perpendicular to the opening. v.07252022...
- Page 8 Required tools for assembly (Not included) Attach cam bolts underneath the top panel.
- Page 9 Attach cam bolts to the side panels. Insert wood dowels to the sidel panels. v.07252022...
- Page 10 Attach cam bolts to both sides of the center panel. Flip 180° Insert wood dowels to the center panel.
- Page 11 Insert wood dowels to the bottom panel. Attach cam bolts to both sides of the bottom panel. Flip 180° v.07252022...
- Page 12 Attach cam bolts to the lower crossbar. Attach cam bolts to the legs.
- Page 13 Insert wood dowels to the legs. v.07252022...
- Page 14 Insert wood dowels to the upper crossbars. Assemble upper crossbars between the side panels and the center panels.
- Page 15 Assemble lower crossbar to the bottom panel. Beware of the orientation of the lower crossbar. v.07252022...
- Page 16 Assemble the side panels and center panel to the bottom panel.
- Page 17 Attach the left, right and center support leg to the back leg. Attach the front leg to the leg assembly. v.07252022...
- Page 18 Assemble the leg assembly underneath the bottom panel. Assemble the back support panels on the bottom panel.
- Page 19 Slide in the back panels. Assemble the top panel on top of the TV stand assembly. v.07252022...
- Page 20 Secure the top panel to the upper crossbars. Secure the back support panels to the top panel.
- Page 21 Secure the back panels in place. Insert shelf pegs inside the TV stand and put on the storage shelf panels. v.07252022...
- Page 22 Attach door handles to the cabinet doors. Attach door hinges to the cabinet door. Use the correct door hinge type.
- Page 23 Attach door hinges to the cabinet doors. Attach the outer side of the cabinet doors to the TV stand. v.07252022...
- Page 24 Attach the rest of the cabinet doors to the TV stand...
- Page 25 Adjust the position of the cabinet doors. Up and down In and out adjustment Side to side adjustment adjustment by by loosening the screws using the front loosening the screws on the hinge arm. adjustment screw on on the mounting plate. the hinge.
- Page 26 Attach anti-tipping strap behind the TV stand.
- Page 27 Affix the TV stand to the wall. Furniture must permanently fixed to the wall stud with included anti-tipping device to prevent the furniture from tipping over. • Mark the drill position on the wall with a pencil. • Drill a small hole on the marked position. •...
- Page 28 Warning Only place items on top of the product if they meet the recommended size and weight limits. Climbing on, stepping on, or placing overweighted objects on the product may cause property damage and/or injuries. Items placed onto this product must be resting on a support surface without hanging over the edges.
- Page 29 ⚠ WARNING For use with televisions weighing 90lbs (40.8kg) or less. Use with heavier televisions may result in instability, causing tip over resulting in death or serious injury. Death or serious injury may occur when children climb on audio and/or video equipment furniture. A remote control or toys placed on the furnishing may encourage a child to climb on the furnishing and as a result the furnishing may tip over on to the child.
- Page 30 FURNITURE CARE AND MAINTENANCE Medium - Density Fiberboard Thank you for your purchase. We want your item to last as long as possible. To ensure the product gives you years of longevity, please follow the recommendations in this care and maintenance guide. MAINTENANCE •...
- Page 31 © All copyright of this document belongs to BELLEZE . This document may not be printed, translated, reproduced, or distributed in whole or in part without written permission from BELLEZE. v.07252022...
-
Page 32: Warranty
WARRANTY BELLEZE products come with a 1-year warranty from the date of delivery. Register your product on our website to enjoy our limited lifetime warranty! AFTER-SALE SERVICE Encounter any difficulties or missing parts? Contact us at 1-800-682-6376 or email us at support@belleze.com We will send you replacement.
