MODELS: COSMO32-IFT, COSMO42-IFT, COSMO32-IFT-B, COSMO36-IFT-B, COSMO42-IFT-B,
Leave this manual with party responsible for use
and operation.
WARNING! Choking Hazard! Keep stones out of reach
of children.
CAUTION! Risk of Cuts, Abrasions or Flying Debris.
Wear protective gloves and safety glasses during instal-
lation. Sheet metal edges are sharp.
Note: STONES-C32 and STONES-C3642 may not be used
with the media supplied with the COSMO32-IFT,
COSMO42-IFT, COSMO32-IFT-B, COSMO36-IFT-B,
COSMO42-IFT-B, SLR-X-AU, SLR -X-AU-L or B41L-
AU models.
NOTICE: THE SLR-X-AU-L appliance requires a
burner change to be able to be used with this kit. Burner
SRV2491-007 is available throught your dealer. Follow
the instructions included with the burner prior to installing
this kit.
NOTICE: When installing stones into B41L-AU, burner
must be replaced with part number 2617-007. Stones are
not approved for use with burner that is shipped with the
BL41-AU. See installation manual for burner replacement
instructions.
Heat & Glo • STONES-C32, STONES-C3642 Installation Instructions • 2491-949 Rev. E • 2/20
STONES-C32, STONES-C3642
SLR-X-AU, SLR-X-AU-L, B41L-AU
- Installation Instructions -
PREPARATION
CAUTION! Risk of Burns! The fireplace should be turned
off and cooled before stones are installed.
1. Remove decorative front and glass assembly. Refer
to appliance installation manual for glass removal and
replacement instructions.
WARNING
Delayed Ignition Risk
Risk of Asphyxiation or Fumes.
• Place stones according to instructions.
• Do NOT place stones on burner.
• Do NOT place stones in gap between pilot/pilot
shield and burner.
• Do NOT place stones in a position that they may lodge or
fall into the gap between pilot/pilot shield and burner.
• Do NOT place stones in area between glass and firebox.
• Do NOT place stones in a position that they may fall into
area between glass and firebox.
• Do NOT use any stones other than the Hearth & Home
Technologies-supplied options for this fireplace model.
Fireplace will not function properly.
Delayed ignition could occur.
STONES INSTALLATION
1. The maximum number of stones that may be installed
varies depending on the model size. See Table 1.
MODEL
COSMO32-IFT
COSMO32-IFT-B
COSMO36-IFT-B
B41L-AU
COSMO42-IFT
COSMO42IFT-B
SLR-X-AU
SLR-X-AU-L
Table 1.
MAX. STONE QUANTITY
45
45
63
63
63
63
63
63
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the STONES-C32 and is the answer not in the manual?

Questions and answers

Summary of Contents for Heat & Glo STONES-C32

  • Page 1 1. The maximum number of stones that may be installed varies depending on the model size. See Table 1. MODEL MAX. STONE QUANTITY COSMO32-IFT COSMO32-IFT-B COSMO36-IFT-B B41L-AU COSMO42-IFT COSMO42IFT-B SLR-X-AU SLR-X-AU-L Table 1. Heat & Glo • STONES-C32, STONES-C3642 Installation Instructions • 2491-949 Rev. E • 2/20...
